ASU-CRU0600Consumer Electronics

IMPORTANT PRODUCT INFORMATION 1 CONTENTS Important Safety Information 1 Federal Communication Commission Interference Statement 3 Industry Canada Statement 5 New Product Limited Warranty 8 Savant Return Authorization Policy and Procedure 12 Customer Support Back Page Warning – Risk of Electric Shock. Install in accordance with all regional, national, and local electrical codes. – Risk of Serious Injury, Death, or Property Damage or Loss. Install and use properly—as described in this and other products documents – to avoid danger of injury, death, or property damage or loss. – Risk of Serious Injury, Death, or Property Damage or Loss. If you are unsure about any part of these instructions, consult Customer Service or a qualified dealer. – Risk of Overheating. To reduce the risk of overheating and possible damage to other equipment, install and use properly as described in this and other product documents. – For the Savant Lamp Control: Prior to changing a light bulb or performing any other maintenance to the light fixture, turn off the lamp controller via the Savant App or unplug the lamp itself from the Savant Lamp Control. Caution – This product generates heat during normal operation – Charging your device: Please use only the Savant power adapter and USB charging cable packed with and intended for use with your Savant product. Other power adapters and accessories may damage your device. Do not use a power adapter and cable intended for other models of Savant products. Do not use a power adapter or cable that has frayed or otherwise been damaged. IMPORTANT SAFETY INFORMATION ! ! 32 Your Savant product is an electronic/electrical device. Follow the same basic safety procedures and cautions you would follow with any electrical device. – Your Savant device, USB cables, and adapters are not waterproof. To avoid risk of electric shock, overheating, melting, burns or other injury or damage, keep the device and all accessories away from water and other liquids. Do not use the cable if either end of the cable gets wet or is exposed to liquid spray or excessive moisture. Do not expose your Savant device, cables, and power adapter to food or any liquids, or to wet or damp conditions. – Use or modification of this product in a manner not expressly approved by Savant voids your warranty. Further. Savant is not liable for any damage incurred with the misuse of this product. See “Limited Warranty” Cleaning – To clean the outside of your Savant product, please use a dry, soft, lint-free or micro-fiber cloth to wipe any dust off from the surface of your device. Do not use any spray or liquid cleaners, or any aerosol sprays, solvents, or abrasives, which may damage the device. – For the Savant Remote only: To clean the touchscreen of your Savant Remote, first power off the remote and then use a dry, soft, lint-free or micro- fiber cloth to wipe clean the display. Avoid using any spray or liquid cleaners on the screen. ! This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. IMPORTANT SAFETY INFORMATION Continued FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT 54 FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. - This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: - this device may not cause interference, and - this device must accept any interference, including interference that may cause undesired operation of the device. - Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: - l’appareil ne doit pas produire de brouillage, et - l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. - This Class B digital apparatus complies with Canadian ICES-003. - Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. - This device complies with RSS-310 of Industry Canada. Operation is subject to the condition that this device does not cause harmful interference. - Cet appareil est conforme à la norme RSS-310 d’Industrie Canada. L’opération est soumise à la condition que cet apparei…

Text truncated - open the document above for the full version.

Savant Systems LLC 75 Perseverance Way Hyannis Massachusetts 02635 United States Date: July 20, 2015 Declaration To whom it may concern, SAV-CRU-0600, SAV-CRU-0601 is a WLAN/Bluetooth combination antenna with FCC ID: ASU-CRU0600. This WLAN/Bluetooth co-existence mechanism is to ensure that the WLAN and Bluetooth transmitters would not simultaneously operate. Therefore, WLAN and Bluetooth antenna in FCC ID: ASU-CRU0600 should not be considered to be able to transmit simultaneously. Though the users can use WLAN and Bluetooth simultaneously, but the real situation is that WLAN and Bluetooth are used by time sharing and no overlap transmission. Should you have any question, please have my best attention. Sincerely yours, Tel: 508-683-2438 Fax: 508-683-2738 E-mail: [email protected]

Savant Systems LLC 75 Perseverance Way Hyannis Massachusetts 02635 United States Date: July 15, 2015 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 Subject: Request for Confidentiality FCC ID: ASU-CRU0600 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely.
Schematic Diagram
Block Diagram
Parts List
Operational Description
Software Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations.  External Photos  Internal Photos  Test Setup Photos  Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Tel: 508-683-2438 Fax: 508-683-2738 E-mail: [email protected]

Report No.: 150518C08 1 of 7 CONSTRUCTION PHOTOS OF EUT Report No.: 150518C08 2 of 7 Report No.: 150518C08 3 of 7

Columbus Host Designed by Savant, USA Assembled in China FCC ID: ASU-CRU0600 IC: 10052A-CRU0600 M/N: SAV-CRU-0600 Input 5V 2A I.T.E. ACCESSORY E464369 S/N: 5150~5250 MHZ is for indoor use only

Columbus Host Designed by Savant, USA Assembled in China FCC ID: ASU-CRU0600 IC: 10052A-CRU0600 M/N: SAV-CRU-0601 Input 5V 2A I.T.E. ACCESSORY E464369 S/N: 5150~5250 MHZ is for indoor use only

Report No.: 150518C08 4 of 7 Report No.: 150518C08 5 of 7 Report No.: 150518C08 6 of 7 Report No.: 150518C08 7 of 7

FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 1 of 7 Report No. : SA150518C08 Issued Date : Jun. 18, 2015 FCC MPE Evaluation Report Report No. : SA150518C08 Applicant : Savant Systems LLC Address : 75 Perseverance Way Hyannis, MA 02635 USA Product : Consumer Electornics FCC ID : ASU-CRU0600 Brand : Simple Host Controller Model No. : SAV-CRU-0600,SAV-CRU-0601 Standards : FCC Part 2 (Section 2.1091) KDB 447498 D01 Sample Received Date : May 18, 2015 Date of Evaluation : Jun. 12, 2015 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Gina Liu / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 2 of 7 Report No. : SA150518C08 Issued Date : Jun. 18, 2015 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Description of Equipment Under Test ................................................................................................................................. 4 2. MPE (Maximum Permissible Exposure) Assessment ......................................................................................................... 5 2.1 Introduction .................................................................................................................................................................. 5 2.2 RF Radiation Exposure Limits ...................................................................................................................................... 5 2.3 MPE Assessment Method ............................................................................................................................................ 6 2.4 MPE Calculation for Standalone Operations ................................................................................................................ 6 3. Information on the Testing Laboratories ............................................................................................................................. 7 FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 3 of 7 Report No. : SA150518C08 Issued Date : Jun. 18, 2015 Release Control Record Report No. Reason for Change Date Issued SA150518C08 Initial release Jun. 18, 2015 FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 4 of 7 Report No. : SA150518C08 Issued Date : Jun. 18, 2015 1. Description of Equipment Under Test EUT Type Consumer Electornics FCC ID ASU-CRU0600 Brand Name Simple Host Controller Model Name SAV-CRU-0600,SAV-CRU-0601 Tx Frequency Bands (Unit: MHz) WLAN : 2412 ~ 2462, 5180 ~ 5240, 5745 ~ 5825 Bluetooth : 2402 ~ 2480 Uplink Modulations 802.11b : DSSS 802.11a/g/n : OFDM Bluetooth : GFSK Antenna Type PIFA Antenna EUT Stage Identical Prototype Note: 1. All models are listed as below. Brand Model Difference Simple Host Controller SAV-CRU-0600 All models are electrically identical, different model names are for marketing purpose. SAV-CRU-0601 2. The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. List of Accessory: AC Adapter 1 Brand Name SIAN POWER DEVICES INC. Model Name WB-10E05FU Power Rating I/P:100-240Vac, 50-60Hz, 0.4A; O/P: 5.0Vdc, 2A AC Adapter 2 Brand Name CUI INC. Model Name SWI10-5-N-I38-C1 Power Rating I/P:90-264Vac, 50-60Hz, 0.3A; O/P: 5.0Vdc, 2A WLAN Chip Brand Name Qualcomm Atheros Model Name QCA6234X FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 5 of 7 Report No. : SA150518C08 Issued Date : Jun. 18, 2015 2. MPE (Maximum Permissible Exposure) Assessment 2.1 Introduction According to 47 CFR §2.1091, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 cm is normally maintained between the transmitting antenna and the body of the user or nearby persons. In this context, the term “fixed lo…
