B8Q315390R1GARAGE DOOR REMOTE CONTROL RECEIVER

1 For Help, call 1-800-35-GENIE or visit www.geniecompany.com 3559535770 For 7' 6" Doors. Extension Kit is available for 8' Doors Included Wall Control MUST be installed prior to Operation of this Garage Door Operator. Safe-T-Beam ® Safety Reverse System Must be Installed and the Force Controls MUST be Properly Set to close door. This Equipment meets or exceeds all Federal, State and UL 325 Safet y Requirement s. SAVE THIS MANUAL FOR FUTURE REFERENCE COMPLETE WITHINTELLICODE® REMOTECONTROL ANDSERIES II ELECTRONICS Having Difficulty? Need Help? Please call us: 1-800-35-GENIE (354-3643) www.geniecompany.com Please have Model information ready when calling. Warranty Information . . . . . . . . . . . . . . . . . . . 2 Your Documentation Package . . . . . . . . . . 3 Safety Information . . . . . . . . . . . . . . . . . . . . . 4 Safety Features . . . . . . . . . . . . . . . . . . . . . . . . . 4 Important Installation Instuctions . . . . . . . 4 Pre-Installation Checklist . . . . . . . . . . . . . . 5-8 Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . 9-10 Programming the Remote Control . . . . . 11 Installing lightbulb and lens. . . . . . . . . . . . 12 Scheduled Maintenance . . . . . . . . . . . . . . . 13 Troubleshooting Guide . . . . . . . . . . . . . 15-16 Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . 17 Parts Lists and Exploded Views . . . . . . 18-19 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 TABLE OFCONTENTS CHAIN DRIVEN OPENER 2020 OPERATION ANDMAINTENANCEMANUAL 2 For Help, call 1-800-35-GENIE or visit www.geniecompany.com THEGENIECOMPANYLIMITEDWARRANTY What is covered? Any defect in material and product workmanship from personal, normal household use in accordance with the Owner’s Manual. For how long? MODEL 2020L . . . 10 years on motor, 2 years all other parts. MODEL 2020C . . . 10 years on motor, 2 years all other parts. Who gets the warranty? This warranty is limited to the consumer who originally purchased the product. Geographic scope: This warranty applies only to units installed and operated within the country where they were purchased. Limitations: IMPLIE D WARRANTIES, INCLUDING THOSE OF FITNESS FOR A PARTI CULAR PURPOSE AND MERCHANTABILITY (AN UNWRITTEN WARRANTY THAT THE PRODUCT IS FI T FOR ORDINARY USE), ARE LIMITED TO ONE YEAR FROM THE DATE OF PURCHASE. GENIE WILL NOT PAY FOR: LOSS OF TIME; INCONVENIENCE; LOSS OF USE OF YOUR GENIE PRODUCT OR PROPERTY DAMAGE CAUSED BY YOUR GENIE PRODUCT OR ITS FAILURE TO WORK; ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES; OR ANY DAMAGES RESULTING FROM MISUSE OR MODIFICATION OF YOUR GENIE PRODUCT. Some states and provinces do not allow limitations on how long an implied warranty lasts or the exclusion of incidental or consequential damages, so th e above limitations or exclusions may not apply to you. This warranty is the only one we will give on your Genie product, and it sets forth all our responsibilities regarding your Genie product. There ar e no other express warranties. State and province rights: This warranty gives you specific legal rights, an d you may also have other rights which vary from state to state and province to province. How to get warranty service: To obtain warranty service for your Genie product, you must provide proof of th e date and place of purchase of the product. 1.Do-It-Yourself-Service. Call the Genie Consumer Connection toll free at 1.800.354.3643 to speak in person to a trained Genie representative for assistance in diagnosing the problem and arranging to supply you with the required parts for do-it-yourself repairs. Trained service representatives are available Monday-Friday, 8:00 a.m. - 11:00 p.m., Eastern Time, and on Saturday, 10:00 a.m. to 7:00 p.m., Eastern Time (subject to holidays) You may also get the information you need at www.geniecompany.com. SAVE THESE INSTRUCTIONS Visit Our Website at: www.geniecompany.com Please note the following information,so it is available if you need to call us. Date Purchased __________/_________/__________ Serial Number ______________________________ Operator Model ______________________________ Remote Control Model______________________________ Dealer Name ______________________________ Dealer Address ______________________________ City ______________________________ State ______________________________ ______________________________ piZ 2.Service From Authorized Dealers. You also may obtain warranty service from Genie authorized dealers by calling the Genie Consumer Connection at 1.800.654.3643 or by visiting www.geniecompany.combefore scheduling warranty service. If warranty service is provided by an authorized dealer, Genie will provide all required parts under warranty at no charge to you, but the dealers are independent business people and may render a bench or service call charge for their services. Genie will no t rei mburse you or otherwise be responsible for those charges. We suggest that you retain your original packing material in the event we choose to repair or replaqce your Genie Product and request that you ship it to us. Be sure to include your name, address, telephone number, proof of date and place of purchase and a description of the operating problem. After repairing or replacing, your Genie product, we will ship it to your home at no cost to you fo r parts and labor, but you will have to pay a minimum of $8.00 for shipping an d handling charges. Your choice of either one of the above-described service options is your exclusive remedy under this warranty. What this warranty does not cover: This warranty does not cover batteries (which are considered replaceable parts), installation, commercial use, defects resulting from accidents, damage while in transit to our service location or damage resulting from alterations, misuse or abuse, lack of proper maintenance, unauthorized repair or modification of the product, affixing of any attachment not provided with the product, programming of th…
