CBF-800RWireless Door Opening System, Receiver

Page 1 of 1 Elliott TCB 41039 Boyce Road Fremont, CA 94538 To whom it may concern: The enclosed documents constitute a formal submittal and application for Equipment Authorization for a low power 926.5 MHz transceiver pursuant to the following rules: Subpart C of Part 15.249 of FCC Rules (CFR 47) RSS-Gen Issue 3, December 2010, “General Requirements and Information for the Certification of Radiocommunication Equipment” RSS-210, Issue 8, December 2010, “Low-power Licence-exempt Radiocommunication Devices (All Frequency Bands): Category I Equipment” Elliott Laboratories, as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is included with the application. If there are any questions or if further information is needed, please contact Elliott Laboratories for assistance. Sincerely, David W. Bare Chief Engineer

Class Product/Project Sesam 800 Subject Document Id. Revision Label for 941241-000, S800RXD FCC 942046-000 A0 Approved by Category Date Page Björn Quickers 2011-07-06 1 (2) ÅKERSTRÖMS BJÖRBO AB, SE-780 45 BJÖRBO, Sweden Phone +46 241 25 000, Fax +46 241 232 90 Vat No SE556153982501 Registrated office BJÖRBO www.akerstroms.se Specification of label: Durability according to SS-EN 60950. The label shall remain clear and easy-to-read during normal operation and usage. The label shall withstand normal cleaning with specified cleaning agent It shall be impossible to remove the label from the unit without permanently damaging the label. The adhesive on the label shall not affect plastic materials in a negative way. The label shall be white. The text on the label shall be black. Content: Company logotype: Black: 100% black Grey scale: 30% black Text: Fonts: Arial Narrow Textsize: 2.00 mm: Power supply: 115V AC 30 mA 60 Hz Freq 926,5 MHz Åkerströms art.no: Art No: 941241-000 Manufactured year week: 1127 1 Serial number XXXXXXXX 2 IP-class IP65 FCC ID FCC ID: CBF-800R IC IC: 1339A-800R Textsize 1.0mm Origin MADE IN CHINA Web address www.akerstroms.se Warnings: See installation instruction before connecting to the supply Symbols: Min. height 5mm 1 This is a variable. The value shall be the value of the year and week that the unit was produced. 2 This is a variable. The value shall be the same as the serial- number of the unit being produced. Class Product/Project Sesam 800 Subject Document Id. Revision Label for 941241-000, S800RXD FCC 942046-000 A0 Approved by Category Date Page Björn Quickers 2011-07-06 2 (2) ÅKERSTRÖMS BJÖRBO AB, SE-780 45 BJÖRBO, Sweden Phone +46 241 25 000, Fax +46 241 232 90 Vat No SE556153982501 Registrated office BJÖRBO www.akerstroms.se Example Size: Height: 20mm + 0-0,1mm Width: 40mm + 0-0,1mm Example in scale 1:1 (approx) Art.no 941241-000 Power Supply: 115V AC Serial nr: XXXXXXXX Mdl: Sesam 800 RXD 30mA 60Hz Mfd 1127 Freq: 926,5MHz FCC ID: CBF-800R IC: 1339A-800R See installation instruction before connecting to the supply www.akerstroms.se Made in China

File: R85768 Page 1 EMC Test Report Application for Grant of Equipment Authorization Industry Canada RSS-Gen Issue 3 / RSS 210 Issue 8 FCC Part 15 Subpart C Model: Sesam 800 RXD IC CERTIFICATION #: 1339A-800R FCC ID: CBF-800R APPLICANT: Control Chief Corporation 200 Williams Street, P.O. Box 141 Bradford, PA 16701 TEST SITE(S): Elliott Laboratories 41039 Boyce Road. Fremont, CA. 94538-2435 IC SITE REGISTRATION #: 2845B-3, 2845B-5, 2845B-7 REPORT DATE: January 5, 2012 FINAL TEST DATES: November 18, 21 and December 7, 2011 TOTAL NUMBER OF PAGES: 30 PROGRAM MGR / QUALITY ASSURANCE DELEGATE / TECHNICAL REVIEWER: FINAL REPORT PREPARER: ______________________________ ______________________________ David W. Bare David Guidotti Chief Engineer Senior Technical Writer Elliott Laboratories is accredited by the A2LA, certificate number 0214.26, to perform the test(s) listed in this report, except where noted otherwise. This report and the information contained herein represent the results of testing test articles identified and selected by the client performed to specifications and/or procedures selected by the client. National Technical Systems (NTS) makes no representations, expressed or implied, that such testing is adequate (or inadequate) to demonstrate efficiency, performance, reliability, or any other characteristic of the articles being tested, or similar products. This report should not be relied upon as an endorsement or certification by NTS of the equipment tested, nor does it represent any statement whatsoever as to its merchantability or fitness of the test article, or similar products, for a particular purpose. This report shall not be reproduced except in full Elliott Laboratories -- EMC Department Test Report Report Date: January 5, 2012 File: R85768 Page 2 REVISION HISTORY Rev# Date Comments Modified By - 1-5-2012 First release Elliott Laboratories -- EMC Department Test Report Report Date: January 5, 2012 File: R85768 Page 3 TABLE OF CONTENTS REVISION HISTORY ................................................................................................................................................2 TABLE OF CONTENTS ............................................................................................................................................3 SCOPE..........................................................................................................................................................................4 OBJECTIVE ................................................................................................................................................................5 STATEMENT OF COMPLIANCE...........................................................................................................................5 DEVIATIONS FROM THE STANDARDS ..............................................................................................................5 TEST RESULTS SUMMARY- SESAM 800 RXD...................................................................................................6 DEVICES OPERATING IN THE 902 – 928 / 2400 – 2483.5 / 5725 – 5850 MHZ BANDS ...................................6 GENERAL REQUIREMENTS APPLICABLE TO ALL BANDS..........................................................................6 MEASUREMENT UNCERTAINTIES....................................................................................................................6 EQUIPMENT UNDER TEST (EUT) DETAILS ......................................................................................................7 GENERAL................................................................................................................................................................7 ANTENNA SYSTEM ..............................................................................................................................................7 ENCLOSURE...........................................................................................................................................................7 MODIFICATIONS...................................................................................................................................................7 SUPPORT EQUIPMENT.........................................................................................................................................7 EUT INTERFACE PORTS ......................................................................................................................................7 EUT OPERATION ...................................................................................................................................................7 TEST SITE...................................................................................................................................................................8 GENERAL INFORMATION ...................................................................................................................................8 CONDUCTED EMISSIONS CONSIDERATIONS ................................................................................................8 RADIATED EMISSIONS CONSIDERATIONS ....................................................................................................8 MEASUREMENT INSTRUMENTATION ..............................................................................................................9 RECEIVER SYSTEM ..............................................................................................................................................9 INSTRUMENT CONTROL COMPUTER ..............................................................................................................9 LINE IMPEDANCE STABILIZATION NETWORK (LISN).................................................................................9 FILTERS/ATTENUATORS ............................................................................................…
