DT9T-98002.4 GHz Wireless A/V Sender with Infrared Extender

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5 Page 6 Page 7 Page 8

FCC ID: DT9R-9800 ADT No.901224R01B Operational Description The EUT (433MHz Wireless A/V Sender with infrared extender) include 433MHz Transmitter part and 2.4GHz receiver part. 433MHz transmitter part was used for non-periodic control code transmission and can not be used transmit data/video/audio signals. The main function of 433MHz transmitter is transforming IR signal into 433.92MHz RF signal, the interior circuit of 433 MHz transmitter part will be triggered to cause oscillation when IR sensor receives the signal then transmit RF signal. This 433 MHz transmitter device is operated by manual, and activate time is less than 5 second after being released. 2.4 GHz receiver part was used for the receiver part of video/audio sender. The EUT is powered by AC power adapter. The transmitter uses detachable antenna. There are 4 channels in this product and channel selection is controlled by switch in 2.4GHz receiver.

FCC ID: DT9T-9800 Report No.: RF901224R01 28 Issued: Nov. 18, 2002 5. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: DT9T-9800 Report No.: RF901224R01 29 Issued: Nov. 18, 2002 RADIATED EMISSION TEST

FCC ID: DT9T-9800 Report No.: RF901224R011Issued: Nov. 18, 2002 FCC TEST REPORT REPORT NO.: RF901224R01 MODEL NO.: T-9800 RECEIVED: Aug. 16, 2002 TESTED: Aug. 20 ~ 21, 2002 APPLICANT:JEBSEE ELECTRONICS CO., LTD. ADDRESS: 24-3, Sin-Lo Road, P.O. Box 57, Tainan Taiwan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 30 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 ILAC MRA FCC ID: DT9T-9800 Report No.: RF901224R012Issued: Nov. 18, 2002 Table of Contents 1.CERTIFICATION ......................................................................................................... 3 2.SUMMARY OF TEST RESULTS ................................................................................ 4 3.GENERAL INFORMATION........................................................................................ 5 3.1GENERAL DESCRIPTION OF EUT .......................................................................... 5 3.2DESCRIPTION OF TEST MODES ............................................................................. 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ......................................... 6 3.4DESCRIPTION OF SUPPORT UNITS........................................................................ 6 4.TEST PROCEDURE AND RESULT ........................................................................... 7 4.1CONDUCTED EMISSION MEASUREMENT........................................................... 7 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 7 4.1.2TEST INSTRUMENTS ................................................................................................ 7 4.1.3TEST PROCEDURES .................................................................................................. 8 4.1.4DEVIATION FROM TEST STANDARD .................................................................... 8 4.1.5TEST SETUP ................................................................................................................9 4.1.6EUT OPERATING CONDITIONS .............................................................................. 9 4.1.7TEST RESULTS ......................................................................................................... 10 4.2RADIATED EMISSION MEASUREMENT ............................................................. 16 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................... 16 4.2.2TEST INSTRUMENT ................................................................................................ 17 4.2.3TEST PROCEDURE .................................................................................................. 18 4.2.4DEVIATION FROM TEST STANDARD .................................................................. 18 4.2.5TEST SETUP .............................................................................................................. 19 4.2.6EUT OPERATING CONDITION............................................................................... 19 4.2.7TEST RESULT ........................................................................................................... 20 4.3BAND EDGES MEASUREMENT ............................................................................ 24 4.3.1LIMITS OF BAND EDGES MEASUREMENT........................................................ 24 4.3.2TEST INSTRUMENTS .............................................................................................. 24 4.3.3TEST PROCEDURE .................................................................................................. 24 4.3.4EUT OPERATING CONDITION............................................................................... 25 4.3.5TEST RESULTS ......................................................................................................... 25 5.PHOTOGRAPHS OF THE TEST CONFIGURATION ............................................. 28 6.INFORMATION ON THE TESTING LABORATORIES ......................................... 30 FCC ID: DT9T-9800 Report No.: RF901224R013Issued: Nov. 18, 2002 1. CERTIFICATION PRODUCT : 2.4GHz Wireless A/V Sender with infrared extender BRAND NAME : JEBSEE MODEL NO : T-9800 APPLICANT : JEBSEE ELECTRONICS CO., LTD. STANDARDS :47 CFR Part 15, Subpart C (Section 15.249), ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility from Aug. 20, 2002 to Aug. 21,2002. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: DT9T-9800 Report No.: RF901224R014Issued: Nov. 18, 2002 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestPASS Minimum passing margin is –15.92dBuV at 0.502MHz 15.209 15.249 Radiated Emission TestPASS Minimum passing margin is –3.0dBuV at 840.00MHz 15.249 Band Edge Measurement Limit: 20 dB less than the peak value of fundamental frequency PASS Meet the requirement of limit NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: DT9T-9800 Report No.: RF901224R015Issued: Nov. 18, 2002 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT2.4GHz Wireless A/V Sender with infrared extender MODEL NO. T-9800 POWER …

Text truncated - open the document above for the full version.

FCC ID: DT9T-9800 Report No.: RF901224R01 28 Issued: Nov. 18, 2002 5. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: DT9T-9800 Report No.: RF901224R01 29 Issued: Nov. 18, 2002 RADIATED EMISSION TEST
