Logitech ® Cordless Headset for PC & Mobile Phones User Manual  • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not push objects into apparatus vents or slots because fire or electric shock hazards could result. • Ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table clothes, curtains, etc. • No naked (open) flame sources, such as lighted candles, should be placed on or near the apparatus. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Unplug this apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. • The apparatus shall be disconnected from the mains by unplugging the power cord of the apparatus from the AC mains receptacle. • The socket-outlet shall be installed near the equipment and shall be easily accessible. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. Important Safety InStr UC tIon S CaUtIon eLeCtr IC SHoCK H aZar D Table of Contents Safety Table of Contents English pages 1 - 16  Charge Headset Battery The Logitech® Cordless Headset comes with a lithium-ion rechargeable, non-replaceable battery that must be fully charged before you use the headset for the first time. 1. Connect the power adapter to the headset. Plug the AC adapter into the electrical outlet. 2. The LED will be red when charging. If the LED is not red, check the connection. 3. During charging, the red LED will be lit. When the Logitech® Cordless Headset is fully charged, the red LED turns off. Charging can take up to 4 hours. 4. Remove the AC adapter from the headset. 5. Your headset is now ready for set-up with your PC or mobile phone. See the Quick Start Guide for details on pairing. Comfort and Fit 1. Rotate the rubber earpiece around the headset for use on either ear. 2a. Place the earpiece behind your ear and rotate the product to your comfort. OR 2b. With one hand, hold earpiece out from the headset and slide product over your ear. 3. Rotate microphone boom so it is pointing toward the corner of your mouth. Introduction Wearing and Using Your Headset Headset Overview A. WindStop ™ microphone B. LED indicator C. Volume down: lowers volume D. Volume up: raises volume E. Adjustable/reversible ear piece F. Multi-Function Button: Power on/off, answer/end calls USB Receiver Overview G. Receiver LED H. Connect Button Extender Stand I. Extender stand J. USB port for USB Receiver EF A B C D I H G J  Connecting Your Headset to the USB Receiver (PC) 1. With the USB receiver now plugged into the extender stand (preferred) or an available USB port and the headset in close proximity to the USB receiver, press the Multi-Function Button on the headset for 2 seconds and release to turn on the headset. There is no need to press the button on the USB receiver. Connection should take place automatically. Wait approximately 20 seconds, the USB receiver and headset should automatically connect. When connected you will see 2 blue flashes at regular intervals on the receiver. If your headset is still not connected, unplug the USB receiver and plug it back in while the headset is on and wait another 20 seconds for conversion to take place. . Shutting down your computer and headset. You do not need to unplug your USB receiver when you shut down. However we recommend turning off your headset to prevent power drain. Answering a call on the PC. Your PC must be on with your headset connected and the PC calling application running. When you hear a ring, simply press the Multi-Function Button a single time to answer the call. When you wish to hang up, simply press the same Multi-Function Button again. . Rebooting your PC. If you have not removed the USB receiver from your computer (or unplugged it from the receiver stand) simply turn on your headset. After your PC has completely rebooted and is running, simply wait 20 seconds for the headset to reconnect. . Disconnecting the headset from the receiver (in order to pair it with your mobile phone). In the CallCentral™ software, select “Disconnect” or press and release the button on the USB receiver once. This will disconnect the USB receiver. To learn how to connect your headset to your phone, see the next section (page 8), “Using Your Cordless Headset with Your Mobile Phone.” Open the CallCentral ™ software. Click on the disconnect button (note: disconnect can also be accomplished by pressing the button on the USB receiver once). The LED on the USB receiver will emit a single blue flash. . Reconnecting your headset to the USB receiver. Turn on your headset. Plug in the USB receiver if it is not already plugged in. Connection will automatically be initiated (wait 20 seconds for it to complete). If receiver is already plugged in, choose connect in the software or press and release the button on the USB receiver. Both actions will initiate connection. Wait approximately 20 seconds for connection to complete. Installing the Software Connecting Your Headset Using the Cordless Headset with Your PC Note: The headset can be used with only one device at a time, either the PC or a mobile ph…

Text truncated - open the document above for the full version.

August 30, 2005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern, We, the undersigned, hereby authorize Northwest EMC, Inc., to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Northwest EMC, Inc. within the scope of this authorization shall have the same affect as our own. This authorization shall expire 12 months from original date. Sincerely, Mitchell Phillipi Sr. Compliance Engineer

Northwest EMC TCB Compliance Opinion Rev. 9/15/03 LABT0203 Information about the Applicant Company Name Logitech, Inc. Grantee Mitchell Phillipi Address 1499 SE Tech Center Place Suite 350 City, State, Zip Vancouver, WA 98683 Job Number LABT0203 Model F-0550A FCC ID DZL-F-0550A Agent Northwest EMC, Inc. Approval Type Original Equipment Class DTS Digital Transmission System Rule Part 15C Industry Canada Information Model F-0550A Industry Canada ID 1807D-F-0550A Rule Part RSS 210 Overview Unlicensed Bluetooth Dongle low power transceiver designed to be connected to a USB port of a pc and enable a cordless two-way transmission with the supplied Logitech cordless Bluetooth headset. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature 8/9/2006 Dave Tolman, TCB Committee

July 26, 2006 FCC Authorization and Evaluation Division 7434 Oakland Mills Road Columbia, MD 21046 Subject: Cover Letter To Whom It May Concern: Logitech is requesting an original certification for our unlicensed Bluetooth Dongle (MN: F-0550A). The Logitech Bluetooth Dongle will operate under FCC Part 15.247 and consists of a Bluetooth USB Dongle. The Bluetooth dongle transceiver is a low power, transceiver which is designed to be connected to a USB port of a pc and enable a cordless two-way transmission with the supplied Logitech cordless Bluetooth headset. Logitech’s Bluetooth dongle will be utilizing the frequency range of 2402MHz – 2480MHz and employing a GFSK/FHSS modulation scheme. The FCC ID number is DZL-F-0550A. If further clarification of Logitech’s Bluetooth dongle is needed, please feel free to contact me at (360) 944-3708, via e-mail at [email protected] , or fax (360) 896-2020. Sincerely, Mitchell A. Phillipi Sr. Compliance Engineer Logitech, Inc.

July 31, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern, We hereby respectfully request that under the provision of 47 CFR 0.459, the documents listed below and attached with this application for certification be provided with confidential status. • Schematics • Theory of Operation • Frequency Block Diagrams Any exhibit / information for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents listed above contain trade secrets that are treated as confidential by us. Substantial competitive harm to us could result should they be made available to the public. Sincerely, Mitchell Phillipi Sr. Compliance Engineer

FCC ID: DZL-F-0550AIC ID: 1807D-F-0550AMN: F-0550A 865387-4000 N231

Per 15.203, the antenna is internal and permanently attached. It is not intended to be serviced by the customer and is, therefore only serviceable by Logitech, Inc. authorized personnel. The antenna is a chip antenna, Johanson part# 190482-0000 with 2.99dBi max peak gain.

Antenna Type Antenna Part No. Transmit Frequency Max Peak Conducted Output Power Antenna Gain Minimum Antenna Cable Loss Power Density @ 20 cm General Population Exposure Limit from 1.1310 (MHz)(mW)(dBi)(dB) (mW/cm 2 )(mW/cm 2 ) Chip Johanson part # 190482-0000 24002.892.9900.0011 FCC ID: DZL-F-0550A Compliance with 47 CFR 15.247(i) “Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter.” The EUT is a Bluetooth USB Dongle that operates in the 2400-2483.5MHz band. The F-0550A can be plugged into the USB port of a notebook or desktop pc or into the USB extension docking station provided with the unit. The F-0550A will typically be used with a separation distance of 20 centimeters or greater between the antenna and the body of the user or nearby persons and can therefore be considered a mobile transmitter per 47 CFR 2.1091(b). The F-0550A has a single internal antenna with a maximum peak gain of 2.99dBi. The maximum peak conducted output power of the device is 2.89mW. The maximum peak power is 5.75 mW (EIRP). In cases where the USB dongle is closer than 20 centimeters to the torso (e.g. laptop use of a notebook computer), both the peak conducted and effective radiated powers are below the low power threshold of 25 mW. Therefore the EUT does not require SAR evaluation per 2.1093. The EUT is not subject to routine environmental evaluation per 47 CFR 2.1091. Per 47 CFR 1.1310, the EUT must meet the General Population/Uncontrolled exposure limits listed in Table 1. The MPE estimates are as follows: Table 1 in 47 CFR 1.1310 defines the maximum permissible exposure (MPE) for the general population as (f MHz /1500) mW/cm 2 . The exposure level at a 20 cm distance from the EUT’s transmitting antenna is calculated using the general equation: S = (PG)/4πR 2 Where: S = power density (mW/cm 2 ) P = power input to the antenna (mW) G = numeric power gain relative to an isotropic radiator R = distance to the center of the radiation of the antenna (20 cm = limit for MPE estimates) PG = EIRP Solving for S, the maximum power density 20 cm from the transmitting antenna is summarized in the following table: The power density does not exceed 1.0 mW/cm 2 at 20 cm; therefore, the exposure condition is compliant with FCC rules. The applicant’s radio, FCC ID: DZL-F-0550A, is compliant with the requirements of 15.247.

Logitech, Inc. MN: F-0550A August 02, 2006 Report No. LABT0203.1 Report Prepared By www.nwemc.com 1-888-EMI-CERT © 2006 Northwest EMC, Inc 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Test Issue Date: August 02, 2006 Logitech, Inc. Model: MN: F-0550A Emissions Test Description Specification Test Method Pass Fail AC Powerline Conducted Emissions FCC 15.207 ANSI C63.4:2003 Occupied Bandwidth FCC 15.247:2006 ANSI C63.4:2003 Output Power FCC 15.247:2006 ANSI C63.4:2003 Power Spectral Density FCC 15.247:2006 ANSI C63.4:2003 Spurious Conducted Emissions FCC 15.247:2006 ANSI C63.4:2003 Spurious Radiated Emissions FCC 15.247:2006ANSI C63.4:2003 Band Edge Compliance FCC 15.247:2006 ANSI C63.4:2003 Modifications made to the product See the Modifications section of this report Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 22975 NW Evergreen Parkway, Suite 400; Hillsboro, OR 97124 Phone: (503) 844-4066 Fax: 844-3826 This site has been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada. Approved By: Greg Kiemel, Director of Engineering This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested, the specific description is noted in each of the individual sections of the test report supporting this certificate of test. Northwest EMC Revision History Revision 05/05/03 Revision Number Description Date Page Number 00 None Northwest EMC Accreditations and Authorizations Revision 03/18/05 FCC: Accredited by NVLAP for performance of FCC radio, digital, and ISM device testing. Our Open Area Test Sites, certification chambers, and conducted measurement facilities have been fully described in reports filed with the FCC and accepted by the FCC in letters maintained in our files. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by the FCC as a Telecommunications Certification Body (TCB). This allows Northwest EMC to certify transmitters to FCC specifications in accordance with 47 CFR 2.960 and 2.962. NVLAP: Northwest EMC, Inc. is accredited under the United States Department of Commerce, National Institute of Standards and Technology, and National Voluntary Laboratory Accreditation Program for satisfactory compliance with the requirements of ISO/IEC 17025 for Testing Laboratories. The NVLAP accreditation encompasses Electromagnetic Compatibility Testing in accordance with the European Union EMC Directive 89/336/EEC, ANSI C63.4, MIL- STD 461E, DO-160D and SAE J1113. Additionally, Northwest EMC is accredited by NVLAP to perform radio testing in accordance with the European Union R&TTE Directive 1999/5/EEC, the requirements of FCC, and the RSS radio standards for Industry Canada. NVLAP LAB CODE 200629-0 NVLAP LAB CODE 200630-0 NVLAP LAB CODE 200676-0 Industry Canada: Accredited by NVLAP for performance of Industry Canada RSS and ICES testing. Our Open Area Test Sites and certification chambers comply with RSS 212, Issue 1 (Provisional) and have been filed with Industry Canada and accepted. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by NIST and recognized by Industry Canada as a Certification Body (CB) per the APEC Mutual Recognition Arrangement (MRA). This allows Northwest EMC to certify transmitters to Industry Canada technical requirements. CAB: Designated by NIST and validated by the European Commission as a Conformity Assessment Body (CAB) to conduct tests and approve products to the EMC directive and transmitters to the R&TTE directive, as described in the U.S. - EU Mutual Recognition Agreement. TÜV Product Service: Included in TUV Product Service Group's Listing of Recognized Laboratories. It qualifies in connection with the TUV Certification after Recognition of Agent's Testing Program for the product categories and/or standards shown in TUV's current Listing of CARAT Laboratories, available from TUV. A certificate was issued to represent that this laboratory continues to meet TUV's CARAT Program requirements. Certificate No. USA0401C. TÜV Rheinland: Authorized to carryout EMC tests by order and under supervision of TÜV Rheinland. This authorization is based on "Conditions for EMC-Subcontractors" of November 1992. Northwest EMC Accreditations and Authorizations Revision 03/18/05 NEMKO: Assessed and accredited by NEMKO (Norwegian testing and certification body) for European emissions and immunity testing. As a result of NEMKO's laboratory assessment, they will accept test results from Northwest EMC, Inc. for product certification (Authorization No. ELA 119). Australia/New Zealand: The National Association of Testing Authorities (NATA), Australia has been appointed by the ACA as an accreditation body to accredit test laboratories and competent bodies for EMC standards. Accredited test reports or assessments by competent bodies must carry the NATA logo. Test reports made by an overseas laboratory that has been accredited for the relevant standards by an overseas accreditation body that has a Mutual Recognition Agreement (MRA) with NATA are also accepted as technical grounds for product conformity. The report should be endorsed with the respective logo of the accreditation body (NVLAP). VCCI: Accepted as an Associate Member to the VCCI, Acceptance No. 564. Conducted and radiated measurement facilities have been registered in accordance with Regulations for Voluntary Control Measures, Article 8. (Registration Numbers. - Hillsbo…
