DZLS00114Wireless module

1 BC05 Flash BT Module PRODUCT SPECIFICATION PROJECT Bluetooth Module CUSTOMER Logitech REVISION V1.0 DATE Jul 12, 2011 2 TABLE OF CONTENTS LIST OF TABLES..........................................................................................................................3 LIST OF FIGURES........................................................................................................................3 1. Revision History ....................................................................................................................3 2. Product Description and Specification.......................................................................................4 2.1 Product Description........... ....................................................................................................4 2.2 References.........................................................................................................................4 3. Hardware Description.............................................................................................................................5 3.1 BC05 Block Diagram........... .................................................................................................5 3.2 BT PIN Configuration and Mechanical Dimension .....................................................................6 3.3 BT PIN Description .............. ................................................................................................7 3.4 BT Module Schematics......................................................................................................8-9 3.5 Example Application Block Diagram........................................................................................9 3.6 BT Module Bill of Materials..................................................................................................10 4. FCC STATEMENT..................................................................................................................11 5. IC STATEMENT......................................................................................................................12 3 LIST OF TABLES Table 1: Revision History .......................................................................................................3 Table 2: General Specification .................................................................................................4 Table 3: BT Pin Description ....................................................................................................7 LIST OF FIGURES Figure 1: BC05 Block Diagram.................................................................................................5 Figure 2: Bluetooth Module Block Diagram ...............................................................................5 Figure 3: BT Pin Configuration and Mechanical Dimension ..........................................................6 Figure 4: BT Module Schematics.............................................................................................8 Figure 5: Example Application Block Diagram ...........................................................................9 Figure 6: BT Module Bill of Materials.......................................................................................10 1. Reversion History REVISION PREPARED BY DATE DESCRIPTION Rev 1.0 ZG Lou 12-Jul-2011 First Release Table 1: Revision History 4 2. Product description and specification This product is a Cost-effective single-chip stereo solution. Module used CSR BlueTunes Flash BGA BC57H687C chipset. 2.1 References BlueCore5-Multimedia External CS-121064-DSP2 General Features
Fully Qualified Bluetooth v2.1 + EDR Specification System
Best-in-class Bluetooth Radio with 8dBm Transmit Power and -90dBm Receive Sensitivity
64MIPS Kalimba DSP Co-processor
16-bit Internal Stereo CODEC 95dB SNR for DAC
Low-power 1.5V Operation, 1.8V to 3.6V I/O
Integrated 1.5V and 1.8V Linear Regulators
Integrated Switched-mode Regulator
Integrated Battery Charger
USB, I 2 C and UART with Dual Port Bypass Mode to 4Mbits/s
Supports up to 32Mbit of External Flash Memory (8Mbit Typical Requirement)
Multi-Configurable I2S, PCM or SPDIF Interface
Enhanced Audibility and Noise Cancellation
8 x8 x 1.2mm, 0.5mm Pitch 169-ball LFBGA
Support for IEEE 802.11 Co-existence
Green (RoHS Compliant and no Antimony or Halogenated Flame Retardants) 2.2 Specifications Table 2: BT Specifications Operating Frequency Band 2.4GHZ-2.48GHZ unlicensed ISM band Bluetooth Specification V2.1+EDR Output Power Class Class 2 RF Output Power ≦3.5dBm Dimension 46mm(L) X 35.23mm(W) X1.0mm(H) 5 3. Hardware Description 3.1 BC05 Block Diagram Figure 1: BC05 Block Diagram Figure 2: BT Module Block Diagram 6 3.2 BT Pin Configuration and Mechanical Dimension # Pin Pin label # Pin Function 1 VDD 2 ENC0 3 GND 4 ENC1 5 PCM_IN 6 SCL 7 PCM_OUT 8 SDA 9 PCM_SYNC 10 INPUT_CTRL 11 PCM_CLK 12 LD00 13 OTP_GDN 14 LD01 15 UART_RX 16 PWR_DET 17 UART_TX 18 AUDIO_DET 19 UART_CTS 20 SPKR_R_P 21 UART_RTS 22 SPKR_R_N 23 AIO0 24 SPKR_L_P 25 AIO1 26 SPKR_L_N Figure 3: BT Pin Configuration and Mechanical Dimension 7 3.3 BT Pin Description Pin No. Name Type Function Remark 1 VDD POWER 3.3V 2 ENC0 Output Power amplifier standby 3 GND Ground Cround connections 4 ENC1 OUTPUT NC 5 PCM_IN CMOS input, with weak internal pull-down. I2S 6 SCL OUTPUT CHARGE MODE CONTROL 7 PCM_OUT CMOS output, tri-state, with weak internal pull-down I2S 8 SDA OUTPUT CHARGE MODE CONTROL 9 PCM_SYNC Bi-directional with weak internal pull-down. I2S 10 INPUT_CTRL OUTPUT CHARGE MODE CONTROL 11 PCM_CLK Bi-directional with weak internal pull-down. I2S 12 LD00 OUTPUT NC 13 OPT_GND INPUT REST 14 LD01 OUTPUT NC 15 UART_RX Bidirectional with weak UART data input ,active high 16 PWR_DET INPUT NC 17 UART_TX Output tri-state with weak UART data output,active high 18 AUDIO_DET Input Audio detect pin 19 UART_CTS COMS input with weak UART clear to send act…

Text truncated - open the document above for the full version.

Cover Letter-Modular Approval FCC ID: DZLS00114 Data: July 18, 2011 To Whom It May Concern: Logitech is requesting an original certification for our unlicensed RF module transceiver product, Model # S-00114, FCC ID: DZLS00114. The Logitech RF module transceiver product will operate under FCC rules 47 CFR 15.247 as a FHSS transmitter. The product uses the Bluetooth protocol according to IEEE 802.15.1. The RF module transceiver device will be utilizing the frequency range of 2402MHz – 2480MHz and employing a GFSK @ 1Mbit/sec, π/4 DQPSK @ 2Mbit/sec, and 8DPSK @ 3Mbit/sec modulation with 1MHz channel spacing. Logitech is submitting the RF module transceiver device to have your authorization as a modular approval. It meets special requirements for full modular approval on FCC Public Notice DA 00-1407 Released: June 26, 2000 by cross-reference list below. Requirement of Public Notice DA001407‐ ‐‐ ‐ / part 15.212 Reference to S-00114 1. The modular transmitter must have its own RF shielding. The module has its own RF shielding. Please see external photo.pdf 2. The modular transmitter must have buffered modulation/data inputs. The modular has buffered data inputs, it is integrated in chip BC05. Please see sheet 3 of schematic.pdf 3. The modular transmitter must have its own power supply regulation. All power lines derived from the host device are regulated within the BC05 before energizing other circuits internal to the S-00114. Please see sheet 2 of schematic.pdf 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The S-00114 meets the FCC antenna requirements. It has a unique connector. Please see external photo.pdf 5. The modular transmitter must be tested in a stand alone ‐ configuration, i.e., the module must not be inside another device during testing. The S-00114 was tested in a stand-alone configuration via a Cylon main PCBA. Please see conducted set-up photo.pdf and spurious set-up 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. The label position of S-00114 is clearly indicated. Please see the label.pdf Please notice that if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: DZLS00114” or “Contains FCC ID: DZLS00114” 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The S-00114 is compliant with all applicable FCC rules (47 CFR Part 15.247 and 15.212). Detail instructions are given in the Users Manual. Please see Installation guide.pdf 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). The S-00114 comply with applicable RF exposure requirements. Please see RF safety evaluation. pdf Thank you.

1 Photographs - EUT Constructional Details Test model No.: S-00114

1 Photographs - EUT Constructional Details Test model No.: S-00114
