DZL131836Cordless Keyboard

Installation 1 2 3 4 5 6 7 OFF (HORS TENSION) ON (SOUS TENSION) English Turn OFF computer. Español Apague el ordenador. Français Mettez l’ordinateur  hors tension. Português Desligue o computador. English Plug receiver cables into computer: PC desktops use keyboard connector (purple) plus mouse connector (green).  PC notebooks use black USB connector only. Español Conecte al ordenador los cables del receptor: Los PC de sobremesa usan el conector de teclado (morado) y el conector de ratón (verde). Los PC portátiles usan sólo el conector USB (negro). Français Branchez les câbles du récepteur dans l’ordinateur: les ordinateurs de bureau utilisent le connecteur du clavier (violet)  et le connecteur de la souris (vert). Les ordinateurs portables utilisent un seul connecteur USB noir. Português Ligue os cabos do receptor ao computador: PCs de secretária utilizam conector do teclado (roxo) e conector do rato (verde). PCs notebook utilizam somente o conector preto USB. English To enjoy all the features of the keyboard and mouse, you must install  the software. Español Para disponer de todas las funciones del teclado y el ratón, debe instalar el software. Français Pour profiter pleinement de toutes les fonctions du clavier et de  la souris, vous devez installer le logiciel. Português Para utilizar todos os recursos do teclado e do mouse,  é necessário instalar o software. English Install the batteries: the mouse uses 2 AA batteries; the keyboard uses 2 AA batteries. Follow the diagram for battery orientation. Français Insérez les piles: la souris utilise 2 piles AA, le clavier utilise 2 piles AA.  Reportez-vous au schéma pour la disposition des piles. Español Coloque las pilas: el ratón utiliza dos 2 pilas AA; el teclado utiliza 2 pilas AA.  El diagrama muestra la posición correcta. Português Introduza as pilhas: o rato utiliza 2 pilhas AA; o teclado utiliza 2 pilhas AA.  Siga o diagrama para a posição das pilhas. English Try the keyboard and mouse. If they work, then install the software in Step 7. If they don't work, press Connect button on receiver, and then press Connect button under mouse. Wait 20 seconds.  Press Connect button on receiver, and then press Connect button  under keyboard. Español Pruebe el teclado y el ratón. Si funcionan, instale el software (paso 7). Si no funcionan, pulse el botón Connect del receptor  y luego el botón Connect situado en la parte inferior del ratón.  Espere 20 segundos. Pulse el botón Connect del receptor y luego  el botón Connect situado en la parte inferior del teclado. Français Testez la souris et le clavier. S’ils fonctionnent,  alors installez le logiciel à l’Etape 7. Sinon, appuyez sur le bouton Connect du récepteur puis sur le bouton Connect sous la souris. Patientez 20 secondes. Appuyez sur le bouton Connect du récepteur, puis sur le bouton Connect situé sous le clavier. Português Tente utilizar o teclado e o rato. Caso funcionem, instale o software no passo 7. Caso não funcionem, prima o botão Bonnect  no receptor e, em seguida, prima o botão Connect na parte inferior  do rato. Aguarde 20 segundos. Prima o botão Connect no receptor e, em seguida, prima o botão Connect na parte inferior do teclado. English Place receiver away from electrical devices. Avoid metallic surfaces. Español NO coloque el receptor cerca de dispositivos eléctricos.  Evite las superficies metálicas. Français Eloignez le récepteur  de tout appareil électrique. Evitez tout contact avec une surface métallique. Português Coloque o receptor longe de aparelhos eléctricos. Evite superfícies metálicas. English Turn ON computer. Español Encienda el ordenador. Français Mettez l’ordinateur sous tension. Português Ligue o computador. 20 sec.20 sec. 1 3 2 4

Installation English Turn OFF computer. Español Apague el ordenador. Français Mettez l’ordinateur  hors tension. Português Desligue o computador. English Plug receiver cables into computer: PC desktops use keyboard connector (purple) plus mouse connector (green).  PC notebooks use black USB connector only. Español Conecte al ordenador los cables del receptor: Los PC de sobremesa usan el conector de teclado (morado) y el conector de ratón (verde). Los PC portátiles usan sólo el conector USB (negro). Français Branchez les câbles du récepteur dans l’ordinateur: les ordinateurs de bureau utilisent le connecteur du clavier (violet)  et le connecteur de la souris (vert). Les ordinateurs portables utilisent un seul connecteur USB noir. Português Ligue os cabos do receptor ao computador: PCs de secretária utilizam conector do teclado (roxo) e conector do rato (verde). PCs notebook utilizam somente o conector preto USB. English To enjoy all the features of the keyboard and mouse, you must install  the software. Español Para disponer de todas las funciones del teclado y el ratón, debe instalar el software. Français Pour profiter pleinement de toutes les fonctions du clavier et de  la souris, vous devez installer le logiciel. Português Para utilizar todos os recursos do teclado e do mouse,  é necessário instalar o software. English Install the batteries: the mouse uses 2 AA batteries; the keyboard uses 2 AA batteries. Follow the diagram for battery orientation. Français Insérez les piles: la souris utilise 2 piles AA, le clavier utilise 2 piles AA.  Reportez-vous au schéma pour la disposition des piles. Español Coloque las pilas: el ratón utiliza dos 2 pilas AA; el teclado utiliza 2 pilas AA.  El diagrama muestra la posición correcta. Português Introduza as pilhas: o rato utiliza 2 pilhas AA; o teclado utiliza 2 pilhas AA.  Siga o diagrama para a posição das pilhas. English Try the keyboard and mouse. If they work, then install the software in Step 7. If they don't work, press Connect button on receiver, and then press Connect button under mouse. Wait 20 seconds.  Press Connect button on receiver, and then press Connect button  under keyboard. Español Pruebe el teclado y el ratón. Si funcionan, instale el software (paso 7). Si no funcionan, pulse el botón Connect del receptor  y luego el botón Connect situado en la parte inferior del ratón.  Espere 20 segundos. Pulse el botón Connect del receptor y luego  el botón Connect situado en la parte inferior del teclado. Français Testez la souris et le clavier. S’ils fonctionnent,  alors installez le logiciel à l’Etape 7. Sinon, appuyez sur le bouton Connect du récepteur puis sur le bouton Connect sous la souris. Patientez 20 secondes. Appuyez sur le bouton Connect du récepteur, puis sur le bouton Connect situé sous le clavier. Português Tente utilizar o teclado e o rato. Caso funcionem, instale o software no passo 7. Caso não funcionem, prima o botão Bonnect  no receptor e, em seguida, prima o botão Connect na parte inferior  do rato. Aguarde 20 segundos. Prima o botão Connect no receptor e, em seguida, prima o botão Connect na parte inferior do teclado. 1 2 3 English Place receiver away from electrical devices. Avoid metallic surfaces. Español NO coloque el receptor cerca de dispositivos eléctricos.  Evite las superficies metálicas. Français Eloignez le récepteur  de tout appareil électrique. Evitez tout contact avec une surface métallique. Português Coloque o receptor longe de aparelhos eléctricos. Evite superfícies metálicas. 4 English Turn ON computer. Español Encienda el ordenador. Français Mettez l’ordinateur sous tension. Português Ligue o computador. 5 6 7 20 sec.20 sec. 1 3 2 @ 1 ! 3 # 4 $ 5 % 6 ^ 7 & 8 * 9 ( 0 ) _ = + Backspace O P [ { ] } L ; : ' " | \ U I K J R T Y F G H Q W E A S D Tab Shift Num Lock – + Enter Home Pg Up 9 87 6 5 4 End Pg Dn 3 2 1 Ins 0 Delete . HomeEnd DeletePg Up Pg Dn Enter Caps Lock Z X C V B M N , < > . / ? Shift Ctrl Start Alt Alt Ctrl Esc F1F2F3F4F5F6F7F8F9F10F11F12 S y s R q P r t S c r S c r L c k In s e r t B r e a k P a u s e My Home Back Volume E Mail Calc 2 4 OFF (HORS TENSION) ON (SOUS TENSION)

? 11 22 33 44 English Solving Setup Problems. 1. Check cable connections. 2. Place receiver away from electrical devices, and avoid metallic surfaces. 3. Check battery installation. The mouse uses 2 AA batteries; the keyboard uses 2 AA batteries. 4. Establish communications. Press Connect button on receiver, and then press Connect button under mouse. Wait 20 seconds. Press Connect button on receiver, and then press Connect button under keyboard. Español Resolución de problemas de instalación. 1. Compruebe las conexiones de los cables. 2. No coloque el receptor cerca de dispositivos eléctricos o sobre superficies metálicas. 3. Compruebe la colocación de las pilas. El ratón utiliza dos 2 pilas AA; el teclado utiliza 2 pilas AA. 4. Establezca la comunicación. Pulse el botón Connect del receptor y luego el botón Connect situado en la parte inferior del ratón. Espere 20 segundos. Pulse el botón Connect del receptor y luego el botón Connect situado en la parte inferior del teclado. Français Résolutions des problèmes d’installation. 1. Vérifiez les connexions des câbles. 2. Eloignez le récepteur des autres appareils électriques et évitez les surfaces métalliques. 3. Vérifiez que les piles sont bien installées. La souris utilise 2 piles AA et le clavier 2 piles AA. 4. Etablissez la communication. Appuyez sur le bouton Connect du récepteur, puis sur le bouton Connect situé sous la souris. Patientez 20 secondes. Appuyez sur le bouton Connect du récepteur, puis sur le bouton Connect situé sous le clavier. Português Resolvendo problemas de configuração. 1. Verifique as ligações dos cabos. 2. Coloque o receptor longe de aparelhos eléctricos e evite superfícies metálicas. 3. Verifique a instalação das pilhas. O rato utiliza 2 pilhas AA; o teclado utiliza 2 pilhas AA. 4. Estabeleça comunicações. Prima o botão Connect no receptor e, em seguida, prima o botão Connect em baixo do rato. Aguarde 20 segundos. Prima o botão Connect no receptor e, em seguida, prima o botão Connect em baixo do teclado. English 1. Navigation controls. 2. Digital media library.  3. Enhanced F-keys. 4. Media controls. 5. Real Time Communication. 6. Calculator key. 7. Suspend key.  8. Tilt wheel. 9. Quick Switch Application button.  For more information, refer to the online help system  located on your hard disk. Español 1. Controles de navegación. 2. Biblioteca digital.  3. Teclas F multiuso. 4. Controles multimedia.  5. Comunicación en tiempo real. 6. Botón Calculadora.  7. Botón de suspensión. 8. Botón rueda inclinable.  9. Botón de cambio rápido de aplicaciones.  Para más información, consulte el sistema de ayuda  en pantalla, ubicado en el disco duro. i English Important Ergonomic Information. Read the Comfort Guidelines in the software help system or at http://www.logitech.com/comfort. Warning! Read the battery warning in the software help system. Warranty and FCC. Your product comes with a limited warranty, is UL tested, and is FCC compliant. For more information, refer to the online help system on your hard disk. Español Información sanitaria importante. Lea las recomendaciones para evitar el cansancio, en el sistema de ayuda  del software o en la dirección http://www.logitech.com/comfort. ¡Advertencia! Lea la advertencia sobre las pilas en el sistema de ayuda del software. Garantía y FCC. El producto se entrega con una garantía limitada, ha pasado las pruebas UL y cumple con las normativas FCC. Para más información, consulte el sistema de ayuda en pantalla, ubicado en el disco duro. Français Informations importantes relatives au confort. Veuillez lire le guide Logitech et votre confort dans l’Aide du logiciel ou sur le site Web http://www.logitech.com/comfort. Attention! Veuillez lire l’avertissement relatif aux piles dans l’Aide du logiciel. Garantie et FCC. Votre produit, certifié UL, est livré avec une garantie limitée et est conforme aux normes FCC.  Pour de plus amples informations, consultez l’aide en ligne située sur votre disque dur. Português Informações importantes sobre ergonomia. Leia as orientações de conforto no sistema de ajuda  do software ou no endereço http://www.logitech.com/comfort. Atenção! Leia o aviso sobre pilhas no sistema de ajuda do software. Garantia e FCC. Este produto tem uma garantia limitada, foi submetido ao teste UL e está em conformidade com FCC. Para mais informações, consulte o sistema de ajuda online no seu disco rígido. © 2004 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. © 2004 Logitech. Tous droits réservés. Logitech, le logo Logitech et les autres marques Logitech sont la propriété exclusive  de Logitech et sont susceptibles d’être des marques déposées. Toutes les autres marques sont la propriété exclusive de leurs détenteurs respectifs. Logitech décline toute responsabilité en cas d'erreurs dans ce manuel. Les informations énoncées dans  le présent document peuvent faire l’objet de modifications sans avis préalable. 623455-0403.A Français 1. Contrôles de navigation. 2. Bibliothèque média numérique. 3. Touches F optimisées. 4. Contrôles média.  5. Communication en temps réel. 6. Touche Calculatrice.  7. Touche d'interruption. 8. Roulette multidirectionnelle.  9. Bouton de l’application Quick Switch.  Pour de plus amples informations, consultez l’aide  en ligne située sur votre disque dur. Português 1. Controlos de navegação. 2. Biblioteca de média digital. 3. Teclas F melhoradas. 4. Controlos de média. 5. Comunicação em tempo real. 6. Tecla Calculadora.  7. Tecla Suspender. 8. Roda de inclinação.  9. Botão da aplicação Quick Switch. Para mais informações, consulte o sistema de ajuda online no seu disco rígido. 1 2 3 5 4 6 7 8 2 @ 1 ! 3 # 4 $ 5 % 6 ^ 7 & 8 * 9 ( 0 ) _ …

Text truncated - open the document above for the full version.

Installation Guide 1 English Package Contents: 1. Keyboard 2. Palm rest 3. Mouse 4. Receiver 5. Software 6. Four batteries Español Contenido de la caja: 1. Teclado 2. Reposamanos 3. Ratón 4. Receptor 5. Software 6. Cuatro pilas Français Contenu: 1. Clavier 2. Appuie-poignets 3. Souris 4. Récepteur 5. Logiciel 6. Quatre pilesPortuguês Conteúdo do pacote: 1. Teclado 2. Descanso para as palmas 3. Rato 4. Receptor 5. Software 6. Quatro pilhas 6 iTouch ™ 2.2 www.logitech.com Logitech 5 English Turn OFF computer. Español Apague el ordenador. Français Mettez l’ordinateur hors tension . Português Desligue o computador. OFF 2 3 English Plug receiver cables into computer: keyboard connector (purple) plus mouse connector (green). Español Conecte al ordenador los cables del receptor: el conector de teclado (morado) y el conector de ratón (verde). Français Branchez les câbles du récepteur dans l’ordinateur: le connecteur du clavier (violet) et le connecteur de la souris (vert). Português Ligue os cabos do receptor ao computador: conector do teclado (roxo) e conector do rato (verde). 4 English Place receiver away from electrical devices. Avoid metallic surfaces. Español NO coloque el receptor cerca de dispositivos eléctricos. Evite las superficies metálicas. Français Eloignez le récepteur de tout appareil électrique. Evitez tout contact avec une surface métallique. Português Coloque o receptor longe de aparelhos eléctricos. Evite superfícies metálicas. English Turn ON computer. Español Encienda el ordenador. Français Mettez l’ordinateur sous tension . Português Ligue o computador. ON English To enjoy all the features of the keyboard and mouse, you must install the software. Español Para disponer de todas las funciones del teclado y el ratón, debe instalar el software. Français Pour profiter pleinement de toutes les fonctions du clavier et de la souris, vous devez installer le logiciel. Português Para utilizar todos os recursos do teclado e do mouse, é necessário instalar o software. English Install the batteries: the mouse uses 2 large AA batteries; the keyboard uses 2 small AAA batteries. Follow the diagram for battery orientation. Español Coloque las pilas: el ratón utiliza dos 2 pilas AA grandes; el teclado utiliza 2 pilas AAA pequeñas. El diagrama muestra la posición correcta. Français Insérez les piles: la souris utilise 2 grosses piles AA, le clavier utilise 2 petites piles AAA. Suivez le schéma pour la disposition des piles. Português Introduza as pilhas: o rato utiliza 2 pilhas AA; o teclado utiliza 2 pilhas AAA. Siga o diagrama para a posição das pilhas. English Press Connect button on receiver, and then press Connect button under mouse. Wait 20 seconds. Press Connect button on receiver, and then press Connect button under keyboard. Español Pulse el botón Connect del receptor y luego el botón de conexión situado en la parte inferior del ratón. Espere 20 segundos. Pulse el botón de conexión del receptor y luego el botón de conexión situado en la parte inferior del teclado. Français Appuyez sur le bouton Connect du récepteur, puis sur le bouton Connect situé sous la souris. Patientez 20 secondes. Appuyez sur le bouton Connect du récepteur, puis sur le bouton Connect situé sous le clavier. Português Prima o botão Connect no receptor e, em seguida, prima o botão Connect em baixo do rato. Aguarde 20 segundos. Prima o botão Connect no receptor e, em seguida, prima o botão Connect em baixo do teclado. 5 6 7 8 4 M y H o m e B a c k V o l u m e E M a i l C a l c 1 2 @ 1 ! 3 # 4 $ 5 % 6 ^ 7 & 8 * 9 ( 0 ) _ = + Backspace O P [ { ] } L ; : ' " | \ U I K J R T Y F G H Q W E A S D Ta b Shift NumLock – + Enter Home Pg Up 9 8 7 6 5 4 End Pg Dn 3 2 1 Ins 0 Delete . Home End Delete Pg Up Pg Dn Enter Caps Lock Z X C V B M N , < > . / ? Shift Ctrl Start Alt Alt Ctrl Esc F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 S y s R q P r t S c r S c r L c k I n s e r t B r e a k P a u s e My Home Back Volume E Mail Calc 2 2 @ 1 ! 3 # 4 $ 5 % 6 ^ 7 & 8 * 9 ( 0 ) _ = + Backspace O P [ { ] } L ; : ' " | \ U I K J R T Y F G H Q W E A S D Ta b Shift NumLock – + Enter Home Pg Up 9 8 7 6 5 4 End Pg Dn 3 2 1 Ins 0 Delete . Home End Delete Pg Up Pg Dn Enter Caps Lock Z X C V B M N , < > . / ? Shift Ctrl Start Alt Alt Ctrl Esc F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 S y s R q P r t S c r S c r L c k I n s e r t B r e a k P a u s e My Home Back Volume E Mail Calc 3 20 sec. 20 sec. 1 3 2 4 ? 11 22 33 44 English Solving Setup Problems. 1. Check cable connections. 2. Place receiver away from electrical devices, and avoid metallic surfaces. 3. Check battery installation. The mouse uses 2 AA batteries; the keyboard uses 2 AAA batteries. 4. Establish communications. Press Connect button on receiver, and then press Connect button under mouse. Wait 20 seconds. Press Connect button on receiver, and then press Connect button under keyboard. Español Resolución de problemas de instalación. 1. Compruebe las conexiones de los cables. 2. No coloque el receptor cerca de dispositivos eléctricos o sobre superficies metálicas. 3. Compruebe la colocación de las pil as. El ratón utiliza dos 2 pilas AA; el teclado utiliza 2 pilas AAA. 4. Establezca la comunicación. Pulse el botón Connect del receptor y luego el botón Connect situado en la parte inferior del ratón. Espere 20 segundos. Pulse el botón Connect del receptor y luego el botón Connect situado en la parte inferior del teclado. Français Résolutions des problèmes d’installation. 1. Vérifiez les connexions des câbles. 2. Eloignez le récepteur des autres appareils électriques et évitez les surfaces métalliques. 3. Vérifiez que les piles sont bien installées. La souris utilise 2 piles AA et le clavier 2 piles AAA. 4. Etablissez la communication. Appuyez sur le bouton Connect du récepteur, puis sur le bouton Connect situé sous la souris. Patientez 20 secondes. Appuyez sur le bouton Connect du récepteur, puis sur le bouton Connect situé sous le clavier. Português Resolvendo problemas de configuração. 1. Verifi…

Text truncated - open the document above for the full version.

Request for non-disclosure RF_501_02 Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for non-disclosure (FCC ID: DZL131836) Reference number: Y-RQ52 Date: June 4,2004 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID : DZL131836 a. Schematic diagrams b. Operational description c. Bill of Material d. PCB layout e. Block diagram Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

External photographs Page: 1 of 6 FCC ID: DZL131836 Photograph 1: Y-RQ52 top view External photographs Page: 2 of 6 FCC ID: DZL131836 Photograph 2: Y-RQ52 bottom view External photographs Page: 3 of 6 FCC ID: DZL131836 Photograph 3: Y-RR53 top view External photographs Page: 4 of 6 FCC ID: DZL131836 Photograph 4: Y-RR53 bottom view External photographs Page: 5 of 6 FCC ID: DZL131836 Photograph 5: Y-RR57 top view External photographs Page: 6 of 6 FCC ID: DZL131836 Photograph 6: Y-RR57 bottom view

Label location FCC ID: DZL131836 Page 1 of 3 Label location for model Y-RQ52: Location of FCC ID: DZL131836 Label location for model Y-RR53 : Page 2 of 3 Location of FCC ID: DZL131836 Label location for model Y-RR57 : Page 3 of 3 Location of FCC ID: DZL131836

MAY/25/04 Y.NSOK MAY/25/04 Y . N S O K N . U E N O T . N K N S N.UENO A/W ,LABEL,KB ID LTTL 1/1 NEW ISSUE / KE-XXXX 132255 644717-0000 DWS A0 01 04 MAY/27/04 Y.NSOK N.UENO CHANGE / KE-XXXX 02 MAY/31/04 Y.NSOK N.UENO CHANGE / KE-XXXX 03 JUN/ Y.NSOK N.UENO CHANGE / KE-XXXX 04 02/04

Internal photographs Page: 1 of 3 FCC ID: DZL131836 Photograph 1: Y-RQ52 internal view Internal photographs Page: 2 of 3 FCC ID: DZL131836 Photograph 2: Y-RR53 internal view Internal photographs Page: 3 of 3 FCC ID: DZL131836 Photograph 3: Y-RR57 internal view

Addendum report: internal photos FCC ID: DZL131836 Page 1 of 3 Internal photos model Y-RQ52: Internal photos model Y-RR53: Page 2 of 3 Internal photos model Y-RR57: Page 3 of 3

Radio test report 99529331 based on: FCC part 15; subpart C; section 15.227 (10-1-03 edition) Cordless Keyboard Logitech Cordless Keyboard Y-RQ52 Y-RR53 Y-RR57 Logitech AGY-734663-0000.A0 Report number: 99529331 Logitech AGY-734663-0000.A0 Contents MAIN MODULE............................................................................................................................................3 1 I NTRODUCTION ....................................................................................................................................3 2 P RODUCT .............................................................................................................................................4 3 T EST SCHEDULE ...................................................................................................................................4 4 P RODUCT DOCUMENTATION .................................................................................................................5 5 O BSERVATIONS AND COMMENTS .........................................................................................................6 6 M ODIFICATIONS TO THE SAMPLE ..........................................................................................................6 7 S UMMARY ............................................................................................................................................6 8 C ONCLUSIONS ......................................................................................................................................7 TEST RESULTS MODULE .........................................................................................................................8 1 G ENERAL INFORMATION ......................................................................................................................8 1.1 Equipment information ...................................................................................................................8 2 E MISSION TESTS ...................................................................................................................................9 2.1 Field strength of intentional signal .................................................................................................9 2.2 Field strength of unwanted emissions ( > 30 MHz)......................................................................10 USED TEST EQUIPMENT MODULE .....................................................................................................12 This report comprises of three modules. The total number of pages is: 12 Main module Page: 3 of 12 Report number: 99529331 Logitech AGY-734663-0000.A0 Main module 1 Introduction This report contains the result of tests performed by: Telefication bv Edisonstraat 12a 6902 PK Zevenaar The Netherlands Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:1999. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). The contents of this test report, if reproduced, shall be copied in full, unless special consent in writing for reproduction in part is granted by Telefication. Copyright of this test report is reserved to Telefication. Ordering party: Company name : Logitech Europe S.A. Address : Z.I. Moulin du Choc D Zipcode : CH-1122 City/town : Romanel sur Morges Country : Switzerland Date of order : 3 March 2004 Main module Page: 4 of 12 Report number: 99529331 Logitech AGY-734663-0000.A0 2 Product A sample of the following product was submitted for testing: Product description : Cordless Keyboard Manufacturer : Logitech Europe S.A. Trade mark : Logitech Cordless Keyboard Type designation : Y-RQ52 Variant 1 : Y-RR53 Variant 2 : Y-RR57 FCC ID : DZL131836 Hardware version : -- Serial number : Y-RQ52 : 0404220072 Y-RR53 : MCC41500247 Y-RR57 : SCC42100004 Software release : -- 3 Test schedule Tests were carried out in accordance with the specification detailed in chapter 7 “Summary” of this report. Tests were carried out at the following location: • TNO Electronic Products & Services (EPS) B.V Smidshornerweg 18 9822 TL Niekerk The Netherlands FCC listed : 90828 Industry Canada : IC3501 The samples of the product were received on: • 7 June 2004 Tests were carried out between the following dates: • 9 June 2004 and 15 June 2004 Main module Page: 5 of 12 Report number: 99529331 Logitech AGY-734663-0000.A0 4 Product documentation For production of this report the following product documentation was used: Description: Date: Identification: Testing indications June 2004 Cordless Keyboard Y-RQ52 Testing indications June 2004 Cordless Keyboard Y-RR53 Testing indications June 2004 Cordless Keyboard Y-RR57 Product Description June 2004 Y-RQ52 Product Description June 2004 Y-RR53 Product Description June 2004 Y-RR57 Block diagram -- Tantalus (Y-RQ52) Block diagram -- Hercules-CR (Y-RR53) Block diagram -- Frogfish-CR (Y-RR57) PCB lay out 8 May 2004 P/No 131836 PAS, 10 pages Circuit diagram 3 June 2004 Y-RR57 FROGFISH - MAIN Circuit diagram 3 June 2004 Y-RR57 FROGFISH - RF Schematic diagram iNAV2 13 May 2002 129352 The above-mentioned documentation will be filed at Telefication for a period of 10 years following the issue of this test report. Main module Page: 6 of 12 Report number: 99529331 Logitech AGY-734663-0000.A0 5 Observations and comments The Y-RQ52 has been tested completely, whereas the Y-RR53 and the Y-RR57 have been verified at spot frequencies only. Product & product variants comparison: Keyboard main PCB (RF part w/o antenna) Antenna i-Nav matrix Multi Media matrix Y-RQ52 yes printed on membrane membrane membrane Y-RR53 same as above printed on membrane, slightly different from above PCB (only passive components) membrane Y-RR5…

Text truncated - open the document above for the full version.

Test setup photographs Page: 1 of 9 FCC ID: DZL131836 Photograph page 1: Test set up Y-RQ52: on turntable Test setup photographs Page: 2 of 9 FCC ID: DZL131836 Photograph page 2: Test set up Y-RQ52: radiated emissions at 3 m distance Test setup photographs Page: 3 of 9 FCC ID: DZL131836 Photograph page 3: Test set up Y-RR53: radiated emissions at 3 m distance Test setup photographs Page: 4 of 9 FCC ID: DZL131836 Photograph page 4: Test set up Y-RR57: radiated emissions at 3 m distance Test setup photographs Page: 5 of 9 FCC ID: DZL131836 Photograph page 5: Test set up Y-RQ52: magnetic radiated emissions (X-POS) Test setup photographs Page: 6 of 9 FCC ID: DZL131836 Photograph page 6: Test set up Y-RQ52: magnetic radiated emissions (Y-POS) Test setup photographs Page: 7 of 9 FCC ID: DZL131836 Photograph page 7: Test set up Y-RQ52: magnetic radiated emissions (Z-POS) Test setup photographs Page: 8 of 9 FCC ID: DZL131836 Photograph page 8: Test set up Y-RR53: magnetic radiated emissions (X-POS) Test setup photographs Page: 9 of 9 FCC ID: DZL131836 Photograph page 9: Test set up Y-RR57: magnetic radiated emissions (Z-POS)
