DZL134041Cordless Keyboard

2 1 3 4 5 6 Installation Guide OFF ON Logitech ® www.logitech.com 1 2 3 4 5 USB PS/2 CONNECT ON / OFF English Turn OFF computer. Español Apague el ordenador. Français Mettez l'ordinateur hors tension. Português Desligue o computador. English Turn ON computer. Español Encienda el ordenador. Français Mettez l’ordinateur sous tension. Português Ligue o computador. English To enjoy all the features of your product, you must install the software. Español Para disponer de todas las funciones del producto, debe instalar el software. Français Pour pouvoir utiliser pleinement toutes les fonctions du produit, vous devez installer le logiciel. Português Para utilizar todas as funções do produto, deve instalar o software. English Package Contents: 1. Keyboard 2. Mouse 3. Receiver 4. Four AA batteries 5. Software Español Contenido de la caja: 1. Teclado 2. Ratón 3. Receptor 4. Cuatro pilas 5. Software Français Contenu : 1. Clavier 2. Souris 3. Récepteur 4. Quatre piles 5. Logiciel Português Conteúdo do pacote: 1. Teclado 2. Rato 3. Receptor 4. Quatro pilhas 5. Software English Plug receiver cables into computer: PC desktops with PS/2 port use keyboard connector (GREEN) plus mouse connector (PURPLE). PC desktops with USB port only and PC notebooks use black USB connector only. Español Conecte al ordenador los cables del receptor: Los PC de sobremesa con puerto PS/2 usan el conector de teclado (MORADO) y el conector de ratón (VERDE). Los PC de sobremesa con puerto USB y los portátiles usan sólo el conector USB negro. Français Branchez les câbles du récepteur dans l’ordinateur: les ordinateurs de bureau avec port PS/2 utilisent le connecteur du clavier (VIOLET) et le connecteur de la souris (VERT). Les ordinateurs de bureau avec ports USB uniquement et les ordinateurs portables utilisent le connecteur USB noir uniquement. Português Ligue os cabos do receptor ao computador: PC de secretária com porta PS/2 utiliza conector de teclado(ROXO) e conector de rato (VERDE). PC de secretária somente com porta USB e PCs portáteis utilizam somente conector preto USB. English Insert 2 AA batteries in the mouse and 2 AA batteries in the keyboard. Español Coloque 2 pilas AA en el ratón y 2 pilas AA en el teclado. Français Insérez deux piles AA dans la souris et deux piles AA dans le clavier. Português Introduza as duas pilhas AA no rato e as duas pilhas AA no teclado.

i www.logitech.com/comfort www.logitech.com/comfort ? Connect Mouse Connect Keyboard 2 1 1 CONNECT ON / OFF 2 www.logitech.com/support WWW 1 2 3 4 5 6 6 7 8 9 10 11 12 13 Americas (USA)English: +1 702 269 3457 English 1. i Na v ™ Tilt Wheel with Cruise Control. 2. Zoom and zoom back to 100%. 3. Enhanced F-keys. 4. Digital Media Library buttons. 5. Media controls. 6. Battery LED. 7. Communication buttons. 8. Calculator. 9. Stand by. 10. Tilt wheel plus universal scroll. 11. Back 12. Forward. 13. Zoom in and out and to 100%. See the software help system and visit the QuickTour ™ software. Also visit www.logitech.com/comfort for more information about using your products and for ergonomics. Español 1. Botón rueda inclinable iNav ™ con Cruise Control. 2. Zoom y restableci- miento de valor 100% 3. Teclas F mejoradas. 4. Botones de biblioteca de medios digital. 5. Controles multimedia. 6. Diodo de estado de pila. 7. Botones de comunicación. 8. Calculadora. 9. Suspensión. 10. Botón rueda inclinable y Universal Scroll. 11. Atrás 12. Adelante. 13. Aplicar zoom y restablecer valor 100%. Consulte el sistema de ayuda del software y ejecute QuickTour ™ . En www.logitech.com/comfort encontrará más información sanitaria y sobre el uso de los productos. English Solving Setup Problems. 1. Check cable connection. 2. Place receiver away from electrical devices, and avoid metallic surfaces. 3. Check battery installation. 4. Turn ON mouse by pressing Power button for 2 seconds. Mouse is ON when LED is ON. 5. Establish connection: 1) Press Connect button on the receiver. 2) QUICKLY press Connect button (half second) under the device (LED should blink for mouse). Español Resolución de problemas de instalación. 1. Compruebe las conexiones de los cables. 2. No coloque el receptor cerca de dispositivos eléctricos o sobre superficies metálicas. 3. Compruebe la colocación de las pilas. 4. Encienda el ratón, pulsando el botón de encendido durante 2 segundos. Si el ratón está ENCENDIDO el diodo está ILUMINADO. 5. Establezca la conexión: 1) Pulse el botón Connect del receptor. 2) Pulse RÁPIDAMENTE (medio segundo) el botón Connect de la parte inferior del dispositivo (el diodo debería parpadear). Français Résolution des problèmes d’installation. 1. Vérifiez la connexion des câbles. 2. Eloignez le récepteur des autres appareils électriques et évitez les surfaces métalliques. 3. Vérifiez que les piles sont bien installées. 4. Mettez la souris sous tension en appuyant sur le bouton d'alimentation pendant deux secondes. La souris est SOUS TENSION si le témoin est ALLUME. 5. Etablissez la connexion: 1) Appuyez sur le bouton Connect du récepteur. 2) Appuyez BRIEVEMENT sur le bouton Connect (une demi-seconde) sous le dispositif (le témoin correspondant à la souris devrait clignoter). Português Resolver problemas de configuração. 1. Verifique a ligação do cabo. 2. Coloque o receptor longe de aparelhos eléctricos e evite superfícies metálicas. 3. Verifique a instalação das pilhas. 4. Ligue o rato ao premir o botão de ligar por dois segundos. O rato está LIGADO quando o LED está LIGADO. 5. Estabeleça ligação: 1) Prima o botão Connect no receptor. 2) Prima RAPIDAMENTE o botão Connect (meio segundo) na parte inferior do dispositivo (o LED do rato deve piscar). © 2005 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. © 2005 Logitech. Tous droits réservés. Logitech, le logo Logitech et les autres marques Logitech sont la propriété exclusive de Logitech et sont susceptibles d’être des marques déposées. Toutes les autres marques sont la propriété exclusive de leurs détenteurs respectifs. Logitech décline toute responsabilité en cas d'erreurs dans ce manuel. Les informations énoncées dans le présent document peuvent faire l’objet de modifications sans avis préalable. 623877-0403.A Français 1. Roulette de défilement iNav ™ avec fonction Cruise Control ™ . 2. Zoom et retour à la taille réelle (100%). 3. Touches F optimisées. 4. Boutons de la bibliothèque média numérique 5. Contrôles média. 6. Témoin lumineux des piles. 7. Touches de communication. 8. Calculatrice. 9. Veille. 10. Roulette de défilement universel. 11. Précédente 12. Suivante. 13. Zoom avant, zoom arrière et retour à la taille réelle (100%). Reportez-vous au système d’aide logiciel et le logiciel QuickTour ™ . Pour en savoir plus sur l'utilisation des produits et leur confort, effectuez la visite guidée et accédez au site Web www.logitech.com/comfort. Português 1. Roda de inclinação iNav ™ com Cruise Control. 2. Efectua zoom e retorna o zoom a 100%. 3. Teclas F melhoradas. 4. Botões de Biblioteca de média digital. 5. Controlos de média. 6. LED das pilhas. 7. Botões de comunicação. 8. Calculadora. 9. Suspensão. 10. Roda de deslocação e Universal Scroll. 11. Retrocesso 12. Avançar. 13. Aumenta e reduz o zoom e volta para 100%. Consulte o sistema de ajuda no software e visite o software QuickTour ™ . Visite também www.logitech.com/comfort para obter mais informações sobre como utilizar os produtos e sobre ergonomia. English Important Ergonomic Information: Long periods of repetitive motion using an improperly set-up workspace, incorrect body position, and poor work habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, weakness, swelling, burning, cramping, or stiffness in your hands, wrists, arms, shoulders, neck, or back, see a qualified health professional. For more information, please read the Comfort Guidelines located on the Logitech® web site at http://www.logitech.com/comfort, or on the Logitech ® Software. Warning! Read the battery warning in the software help system. Warranty. Your product comes with a limited wa…

Text truncated - open the document above for the full version.

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for short-term FCC confidentiality (FCC ID: DZL134041) Reference number: Y-RAM74 Date: 27 May 2005 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests short-term FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL134041 until August 15, 2005 a. Label and Label placement b. Photographs of overall appearance c. Test report d. Test set-up photographs e. User’s manual f. Internal photographs g. RF exposure/Environmental Evaluation h. Cover letters Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for permanent FCC confidentiality (FCC ID: DZL134041) Reference number: Y-RAM74 Date: 27 May 2005 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests permanent FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL134041 a. Block diagram b. Schematic diagrams c. Operational description d. Bill of Material Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

Page: 2 of 9 Report number: 99645931 Photograph 1: Overview of Y-RAM74 Page: 3 of 9 Report number: 99645931 Photograph 2: Rear view of Y-RAM74

APR/04/05 K.MRFS APR/04/05 K.MRFS T.KMRA T.NKGW T.KMRA A/W ,LABEL,KB ID LTHD 1/1 TEMPORARY ISSUE 134418 DWS A0 01 MAY/23/05 K.MRFS T.KMRA UPDATE CONNECTION 02 JUN/06/05 K.MRFS T.KMRA ADD FCC ID 03 03 XXXXXXXXXXXX XXXXXXXXX XXXXXXX DZL134041

Page: 4 of 9 Report number: 99645931 Photograph 3: Internal view of Y-RAM74 Page: 5 of 9 Report number: 99645931 Photograph 4: Label of Y-RAM74 Page: 6 of 9 Report number: 99645931 Photograph 5: Front view PCB of Y-RAM74 Page: 7 of 9 Report number: 99645931 Photograph 6: Rear view PCB of Y-RAM74

Radio test report 99645931 based on: FCC part 15; subpart C; section 15.227 (10-1-04 edition) Cordless Keyboard Logitech Cordless Keyboard Y-RAM74 Logitech AGY 735786-0000.A0 Report number: 99645931 Logitech AGY 735786-0000.A0 Contents MAIN MODULE............................................................................................................................................3 1 I NTRODUCTION ....................................................................................................................................3 2 P RODUCT .............................................................................................................................................4 3 T EST SCHEDULE ...................................................................................................................................4 4 P RODUCT DOCUMENTATION .................................................................................................................5 5 O BSERVATIONS AND COMMENTS .........................................................................................................6 6 M ODIFICATIONS TO THE SAMPLE ..........................................................................................................6 7 S UMMARY ............................................................................................................................................6 8 C ONCLUSIONS ......................................................................................................................................7 TEST RESULTS MODULE .........................................................................................................................8 1 G ENERAL INFORMATION ......................................................................................................................8 1.1 Equipment information ...................................................................................................................8 2 E MISSION TESTS ...................................................................................................................................9 2.1 Field strength of intentional signal .................................................................................................9 2.2 Field strength of unwanted emissions...........................................................................................10 USED TEST EQUIPMENT MODULE .....................................................................................................11 This report comprises of three modules. The total number of pages is: 11 Main module Page: 3 of 11 Report number: 99645931 Logitech AGY 735786-0000.A0 Main module 1 Introduction This report contains the result of tests performed by: Telefication B.V. Edisonstraat 12a 6902 PK Zevenaar The Netherlands Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:1999. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). The contents of this test report, if reproduced, shall be copied in full, unless special consent in writing for reproduction in part is granted by Telefication. Copyright of this test report is reserved to Telefication. Ordering party: Company name : Logitech Europe S.A. Address : Z.I. Moulin du Choc D Zipcode : CH-1122 City/town : Romanel sur Morges Country : Switzerland Date of order : 18 May 2005 Main module Page: 4 of 11 Report number: 99645931 Logitech AGY 735786-0000.A0 2 Product A sample of the following product was submitted for testing: Product description : Cordless Keyboard Manufacturer : Logitech Europe S.A. Trade mark : Logitech Cordless Keyboard Type designation : Y-RAM74 FCC ID : DZL134041 Hardware version : -- Serial number : 0504220102 Software release : -- 3 Test schedule Tests were carried out in accordance with the specification detailed in chapter 7 “Summary” of this report. Tests were carried out at the following location: • TNO Electronic Products & Services (EPS) B.V Smidshornerweg 18 9822 TL Niekerk The Netherlands FCC listed : 90828 Industry Canada : IC3501 The sample of the product was received on: • 23 May 2005 Tests were carried out on: • 30 May 2005 Main module Page: 5 of 11 Report number: 99645931 Logitech AGY 735786-0000.A0 4 Product documentation For production of this report the following product documentation was used: Description: Date: Identification: Product description May 2005 Y-RAM74_Description.doc Test instructions May 2005 Y-RAM74_Test_Inst.doc Circuit diagram 23 May 2005 HADES-KBD-Agcy rev.02.pdf Circuit diagram RFID module 23 May 2005 HADES-RFID-Agcy PA4.pdf Block diagram -- Visio-Hades Y-RAM74 Block diagram.pdf PCB lay out -- Hades-PA2_Gerber.pdf PCB lay out RFID module -- Hades-RFID-PA4.pdf User manual -- 623877-0403 Hades Front.pdf 623877-0403 Hades Back.pdf The above-mentioned documentation will be filed at Telefication for a period of 10 years following the issue of this test report. Main module Page: 6 of 11 Report number: 99645931 Logitech AGY 735786-0000.A0 5 Observations and comments During the tests the product was set in continuous transmit mode (CH1 & CH2 selectable), by means of a test mode. 6 Modifications to the sample No modifications were made to the sample. 7 Summary The product is intended for use in the following application area(s): • INDUCTIVE DATA TRANSMISSION APPLICATION IN THE 27 MHz BAND The samples were tested according to the following specification(s): • FCC part 15; subpart C; section 15.227 (10-1-04 edition) Main module Page: 7 of 11 Report number: 99645931 Logitech AGY 735786-0000.A0 8 Conclusions The samples of the product showed NO NON-COMPLIANCES to the specification stated in chapter 7 of this report. The results of the tests as stat…

Text truncated - open the document above for the full version.

Page: 8 of 9 Report number: 99645931 Photograph 7: Test setup OATS < 30 MHz Page: 9 of 9 Report number: 99645931 Photograph 8: Test setup OATS > 30 MHz
