DZL201758Cordless Mouse

Installation 1 © 2004 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. © 2004 Logitech. Tous droits réservés. Logitech, le logo Logitech et les autres marques Logitech sont la propriété exclusive de Logitech et sont susceptibles d’être des marques déposées. Toutes les autres marques sont la propriété exclusive de leurs détenteurs respectifs. Logitech décline toute responsabilité en cas d'erreurs dans ce manuel. Les informations énoncées dans le présent document peuvent faire l’objet de modifications sans avis préalable. 623412-0403.A www.logitech.com English Turn OFF computer. Español Apague el ordenador. Français Mettez l’ordinateur hors tension. Português Desligue o computador. 2 English Plug AC cable into back of Base Station. Plug AC adapter into outlet. Español Conecte el cable CA a la parte posterior de la estación base. Conecte el adaptador CA a la toma de alimentación. Français Branchez le cordon d'alimentation électrique sur le panneau arrière de la base. Branchez l’adaptateur secteur dans la prise électrique. Português Ligue o cabo CA à parte de trás da central. Ligue o adaptador CA à tomada de parede. OFF 3 English Place Base Station away from electrical devices. Avoid metallic surfaces. Español NO coloque la estación base cerca de dispositivos eléctricos. Evite las superficies metálicas. Français Eloignez la base de tout appareil électrique. Evitez toute surface métallique. Português Coloque a central longe de aparelhos eléctricos. Evite superfícies metálicas. 7 English Turn ON computer. Español Encienda el ordenador. Français Mettez l’ordinateur sous tension. Português Ligue o computador. ON 8 English To enjoy all the features of the mouse, you must install the software. Español Para disponer de todas las funciones del ratón, debe instalar el software. Français Pour profiter pleinement de toutes les fonctions de la souris, vous devez installer le logiciel. Português Para utilizar todas as funções do rato, deve instalar o software. 6 5 4 Macintosh ® USB PC—USB English Plug Base Station cable into computer. PC desktops use green PS/2 adapter. PC notebooks AND Macintosh use black USB connector. Español Conecte al ordenador el cable de la estación base. Los PC de sobremesa usan el adaptador PS/2 verde. Los PC portátiles Y los ordenadores Macintosh usan sólo el conector USB negro. Français Branchez le câble de la base sur l’ordinateur. Les ordinateurs de bureau utilisent l'adaptateur PS/2 vert. Les ordinateurs portables PC ET Macintosh utilisent le connecteur USB noir. Português Ligue o cabo da central ao computador. PCs de secretária utilizam um adaptador PS/2 verde. Os PCs portáteis E Macintosh utilizam um conector USB preto. PC—PS/2 8 in. 20 cm English Turn on mouse and place in Base Station to charge internal batteries. Français Mettez la souris sous tension et placez-la dans sa base pour recharger les piles internes. Español Encienda el ratón y colóquelo en la estación base para cargar las pilas internas. Português Ligue o rato e coloque-o na central para carregar as baterias internas. English Charging: Initially, all mouse LEDs blink green in sequence. Charged: All LEDs turn solid green. Low Battery: First LED at bottom turns red. Important: For full capacity, make one full charge. Español Carga en curso: al principio, todos los indicadores luminosos del ratón parpadean en verde de forma secuencial. Carga completada: todos los indicadores luminosos permanecen verdes. Pila descargada: el primer indicador luminoso en la parte inferior emite una luz roja. Importante: para cargar las pilas al máximo, realice un proceso de carga completa. Français Chargement en cours: au début tous les témoins de la souris clignotent en vert les uns à la suite des autres. Chargement terminé: tous les témoins verts restent allumés en continu. Piles faibles: le témoin situé en bas devient rouge. Important: pour parvenir à une charge totale, il convient d'effectuer un cycle de chargement complet. Português A carregar: Inicialmente, todas as luzes dos LEDs do rato piscam a verde em sequência. Carregado: Todas as luzes dos LEDs ficam verdes. Baterias fracas: A luz do primeiro LED na parte inferior fica vermelha. Importante: Para a capacidade máxima, é necessário um carregamento completo. Cordless Mouse 1000 Laser Logitech ®

33 44 55 11 22 66 22 Reset English Mouse Does Not Work? 1. Check cable connections. 2. Keep Base Station away from electrical devices; avoid metallic surfaces. 3. Try different USB port on computer. 4. Reset mouse: press Reset button on Base Station, and then press Reset button on bottom of mouse (refer to Reset picture). Español ¿El ratón no funciona? 1. Compruebe las conexiones de los cables. 2. No coloque la estación base cerca de dispositivos eléctricos o sobre superficies metálicas. 3. Pruebe otro puerto USB en el ordenador. 4. Restablezca el ratón: pulse el botón Reset en la estación base y luego el situado en la parte inferior del ratón (consulte la ilustración relevante). Français La souris ne fonctionne pas? 1. Vérifiez les connexions des câbles. 2. Assurez-vous que la base est éloignée de tout appareil électrique et évitez les surfaces métalliques. 3. Essayez un autre port USB sur l’ordinateur. 4. Réinitialisez la souris: appuyez sur le bouton de réinitialisation de la base de chargement, puis sur le bouton de réinitialisation situé sous la souris (voir illustration correspondante). Português O rato não funciona? 1. Verifique as ligações dos cabos. 2. Coloque a central longe de aparelhos eléctricos; evite superfícies metálicas. 3. Tente uma porta USB diferente no computador. 4. Efectue a reposição do rato: prima o botão de reposição na central e, em seguida, prima o botão de reposição na parte inferior do rato (consulte a imagem Reposição). ? Europe Americas +41 (0) 21 863 54 01 (English) FAX +41 (0) 21 863 54 02 +1 702 269 3457 Location Hotline Technical HelpHotline ! English For safety and regulatory information, please refer to the Safety Guide that comes with your product. Español Si desea información sobre normativas y seguridad, consulte la guía sobre seguridad que se entrega con el producto. Français Pour en savoir plus sur les consignes de sécurité, reportez-vous au guide relatif à la sécurité livré avec votre produit. Português Para informações sobre segurança e normas, consulte o Guia de segurança fornecido com o produto. English 1. Tilt scroll wheel plus zoom. 2. Cruise Control ™ . 3. Application switch button. 4. Universal forward button. 5. Universal back button. 6. Battery LEDs. Español 1. Botón rueda inclinable y zoom. 2. Cruise Control ™ . 3. Botón de cambio de aplicaciones. 4. Botón de avance universal. 5. Botón de retroceso universal. 6. Indicadores luminosos de pila. Français 1. Roulette de défilement multidirectionnelle avec zoom. 2. Cruise Control ™ . 3. Bouton de changement d'application. 4. Bouton universel Suivant. 5. Bouton universel Précédent. 6. Témoins lumineux des piles. Português 1. Roda de deslocação, inclinação e zoom. 2. Cruise Control ™ 3. Botão de mudança de aplicações. 4. Botão Avançar universal. 5. Botão Retrocesso universal. 6. LEDs da bateria. i i 3 3 5 6 7 1 2 2 4 English 1. Vertical Scrolling: Roll wheel up to scroll up; roll wheel down to scroll down. 2. Cruise Control ™ : Press and hold up arrows button to scroll up; press and hold down arrows button to scroll down. Release either button to stop scrolling. 3. Tilt Scrolling: Press wheel left and hold to scroll left; press wheel right and hold to scroll right. (Horizontal scroll bars must be present on screen.) Release wheel to stop scrolling.) 4. Zooming: Press wheel down. Roll wheel up to zoom in; roll wheel down to zoom out. Press any button to release zoom. (Not all applications support zooming.) 5. Application Switch Button: Press to switch between open documents. 6. Forward Button. 7. Back Button. Use both buttons on Internet or with applications. Español 1. Desplazamiento vertical: Gire el botón rueda hacia delante para ascender por el documento y hacia atrás para descender por él. 2. Cruise Control ™ : Mantenga pulsado el botón de las flechas hacia arriba para desplazarse hacia arriba; mantenga pulsado el de las flechas hacia abajo para desplazarse hacia abajo. Para detener el desplazamiento, suelte el botón. 3. Desplazamiento mediante el botón rueda inclinable: Mantenga inclinado el botón rueda hacia la izquierda o hacia la derecha para desplazarse en esa dirección. Las barras de desplazamiento horizontal deben ser visibles en pantalla. Para detener el desplazamiento, suelte el botón rueda. 4. Zoom: Pulse el botón rueda. Gírelo hacia delante para ampliar la vista, o hacia atrás para reducirla. Pulse un botón cualquiera para anular la función de zoom. Tenga en cuenta que algunas aplicaciones no disponen de función de zoom. 5. Botón de cambio de aplicaciones: pulse para pasar de un documento abierto a otro. 6. Botón de avance. 7. Botón de retroceso. Utilice ambos botones en Internet con aplicaciones. Français 1. Défilement vertical: faites tourner la roulette vers le haut pour faire défiler vers le haut ou faites tourner la roulette vers le bas pour faire défiler vers le bas. 2. Cruise Control ™ : appuyez sur le bouton fléché haut et maintenez-le enfoncé pour un défilement vers le haut et appuyez sur le bouton fléché bas tout en le maintenant enfoncé pour un défilement vers le bas. Relâchez le bouton pour faire cesser le défilement. 3. Défilement multi- directionnel: poussez la roulette vers la gauche et maintenez-la dans cette position pour faire défiler vers la gauche ou poussez la roulette vers la droite et maintenez-la dans cette position pour faire défiler vers la droite. (Les barres de défilement horizontal doivent apparaître à l’écran.) Relâchez la roulette pour faire cesser le défilement. 4. Zoom: appuyez sur la roulette. Faites tourner la roulette vers le haut pour zoomer vers l’avant ou vers le bas pour zoomer vers l’arrière. Appuyez sur n’importe quel bouton pour interrompre le zoom. (La fonction de zoom n’est pas prise en charge par toutes les applications.) 5. Bouton de changement d’application: appuyez sur ce bouton pour passer d’un document ouvert à un autre. 6. Bouton Suivant. 7. Bouton Précédent. Utilisez ces deux boutons sur Internet ou dans les applications. Po…

Text truncated - open the document above for the full version.

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for permanent FCC confidentiality (FCC ID: DZL201758) Reference number: M-RAG97 Date: July 15, 2004 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests permanent FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL201758 a. Block diagram b. Schematic diagrams c. Operational description d. Bill of Material Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for short-term FCC confidentiality (FCC ID: DZL201758) Reference number: M-RAG97 Date: July 15, 2004 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests short-term FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL201758 a. Label and Label placement b. Photographs of overall appearance c. Test report d. Test set-up photographs e. User’s manual f. Internal photographs g. RF exposure/Environmental Evaluation h. Cover letters Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

External photographs Page 1 of 3 FCC ID: DZL201758 Photograph 1: Top view External photographs Page 2 of 3 Photograph 2: Side view External photogaphs Page 3 of 3 Photograph 3: Bottom view

Label location Page 1 of 1 Label location on bottom side of the device.

Internal photographs Page 1 of 1 FCC ID: DZL201758 Photograph 1: Internal view

Addendum: Internal photos FCC ID: DZL131139 Page 1/3

Addendum: Internal photos FCC ID: DZL131139 Page 2/3

Addendum: Internal photos FCC ID: DZL131139 Page 3/3

Radio test report 99532631 based on: FCC part 15; subpart C; section 15.227 (10-1-03 edition) Cordless Mouse Logitech Cordless Mouse M-RAG97 Logitech AGY-734658-0000.A0 Report number: 99532631 Logitech AGY-734658-0000.A0 Contents MAIN MODULE............................................................................................................................................3 1 I NTRODUCTION ....................................................................................................................................3 2 P RODUCT .............................................................................................................................................4 3 T EST SCHEDULE ...................................................................................................................................4 4 P RODUCT DOCUMENTATION .................................................................................................................4 5 O BSERVATIONS AND COMMENTS .........................................................................................................5 6 M ODIFICATIONS TO THE SAMPLE ..........................................................................................................5 7 S UMMARY ............................................................................................................................................5 8 C ONCLUSIONS ......................................................................................................................................6 TEST RESULTS MODULE .........................................................................................................................7 1 G ENERAL INFORMATION ......................................................................................................................7 1.1 Equipment information ...................................................................................................................7 2 E MISSION TESTS ...................................................................................................................................8 2.1 Field strength of intentional signal .................................................................................................8 2.2 Field strength of unwanted emissions ( > 30 MHz)........................................................................9 USED TEST EQUIPMENT MODULE .....................................................................................................11 CROSS REFERENCE TABLE RSS-FCC ................................................................................................12 This report comprises of five modules. The total number of pages exclusive of the pages enclosed in the additional information module is: 12 Main module Page: 3 of 12 Report number: 99532631 Logitech AGY-734658-0000.A0 Main module 1 Introduction This report contains the result of tests performed by: Telefication bv Edisonstraat 12a 6902 PK Zevenaar The Netherlands Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:1999. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). The contents of this test report, if reproduced, shall be copied in full, unless special consent in writing for reproduction in part is granted by Telefication. Copyright of this test report is reserved to Telefication. Ordering party: Company name : Logitech Europe S.A. Address : Z.I. Moulin du Choc D Zipcode : CH-1122 City/town : Romanel sur Morges Country : Switzerland Date of order : 4 June 2004 Main module Page: 4 of 12 Report number: 99532631 Logitech AGY-734658-0000.A0 2 Product A sample of the following product was submitted for testing: Product description : Cordless Mouse Manufacturer : Logitech Europe S.A. Trade mark : Logitech Cordless Mouse Type designation : M-RAG97 FCC ID : DZL131139 Hardware version : -- Serial number : PB2.5-222 Software release : -- 3 Test schedule Tests were carried out in accordance with the specification detailed in chapter 7 “Summary” of this report. Tests were carried out at the following location: • TNO (EPS) B.V., Niekerk (FCC listed under no. 90828; Industry Canada listed under no.IC3501) The sample of the product was received on: • 11 June 2004 Tests was carried out on the following date(s): • 15 June 2004 4 Product documentation For production of this report the following product documentation was used: Description: Date: Identification: Electrical diagram 6 May 2004 SCH-221758-0000 Testing indications for M-RAG97 11 June 2004 M-RAG97 M-RAG97 product description June, 2004 M-RAG97 Bill of Materials Not dated M-RAG97 The fore mentioned documentation would be filed at Telefication for a period of 10 years following the issue of this report. Main module Page: 5 of 12 Report number: 99532631 Logitech AGY-734658-0000.A0 5 Observations and comments None. 6 Modifications to the sample No modifications were made to the sample. 7 Summary The product is intended for use in the following application area(s): INDUCTIVE DATA TRANSMISSION APPLICATION IN THE 27 MHz BAND. The sample was tested according to the following specification(s): FCC part 15; subpart C; section 15.227 (10-1-03 edition) Main module Page: 6 of 12 Report number: 99532631 Logitech AGY-734658-0000.A0 8 Conclusions The sample of the product showed NO NON-COMPLIANCES to the specification stated in chapter 7 of this report. The results of the tests as stated in this report, are exclusively applicable to the product item as identified in this report. Telefication does not accept any responsibility for the results stated in this report, with respect to the properties of product items not involved in these tests. All tests are performed by: nam…

Text truncated - open the document above for the full version.

Photographs module FCC ID: DZL201758 Photograph 1: Test set up: EUT on turntable Photographs module Photograph 2: Test set up: magnetic radiated emissions at 3 m distance (EUT in X plane) Photographs module Photograph 3: Test set up: radiated emissions above 30 MHz at 3 m distance
