DZL201866Cordless Mouse

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for short-term FCC confidentiality (FCC ID: DZL201866) Reference number: M-RAN100 Date: August 31,2004 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests short-term FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL201866. a. Label and Label placement b. Photographs of overall appearance c. Test report d. Test set-up photographs e. User’s manual f. Internal photographs g. RF exposure/Environmental Evaluation h. Cover letters Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for permanent FCC confidentiality (FCC ID: DZL201866) Reference number: M-RAN100 Date: August 31, 2004 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests permanent FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL201866 a. Block diagram b. Schematic diagrams c. Operational description d. Bill of Material Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

External Photos: 8 9

Labeling details for the product(s) submitted in this filing: 1. Label location: (see next page(s)) Labeling details for the product(s) submitted in this filing: 2. Label sample: (see next page(s))

Internal Photos 5 6 7 10

Radio test report 99538331 based on: FCC part 15; subpart C; sections 15.209 and 15.249 (10-1-03 edition) Cordless Mouse Logitech Cordless Mouse M-RAN100 Logitech AGY-734969-0000.A0 Report number: 99538331 Logitech AGY-734969-0000.A0 Contents MAIN MODULE............................................................................................................................................3 1 I NTRODUCTION ....................................................................................................................................3 2 P RODUCT .............................................................................................................................................4 3 T EST SCHEDULE ...................................................................................................................................4 4 P RODUCT DOCUMENTATION .................................................................................................................5 5 O BSERVATIONS AND COMMENTS .........................................................................................................5 6 M ODIFICATIONS TO THE SAMPLE ..........................................................................................................5 7 S UMMARY ............................................................................................................................................5 8 C ONCLUSIONS ......................................................................................................................................6 TEST RESULTS MODULE .........................................................................................................................7 1 G ENERAL INFORMATION ......................................................................................................................7 1.1 Equipment information ...................................................................................................................7 2 E MISSION TESTS ...................................................................................................................................8 2.1 Field strength of intentional signal .................................................................................................8 2.2 Field strength of unwanted emissions 30 –1000 MHz ...................................................................9 2.3 Field strength of unwanted emissions > 1000 MHz .....................................................................10 USED TEST EQUIPMENT MODULE .....................................................................................................11 This report comprises of three modules. The total number of pages is: 11 Main module Page: 3 of 11 Report number: 99538331 Logitech AGY-734969-0000.A0 Main module 1 Introduction This report contains the result of tests performed by: Telefication bv Edisonstraat 12a 6902 PK Zevenaar The Netherlands Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:1999. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). The contents of this test report, if reproduced, shall be copied in full, unless special consent in writing for reproduction in part is granted by Telefication. Copyright of this test report is reserved to Telefication. Ordering party: Company name : Logitech Europe S.A. Address : Z.I. Moulin du Choc D Zipcode : CH-1122 City/town : Romanel sur Morges Country : Switzerland Date of order : 27 August 2004 Main module Page: 4 of 11 Report number: 99538331 Logitech AGY-734969-0000.A0 2 Product A sample of the following product was submitted for testing: Product description : Cordless Mouse Manufacturer : Logitech Europe S.A. Trade mark : Logitech Cordless Mouse Type designation : M-RAN100 FCC ID : DZL201866 Hardware version : -- Serial number : PB3-168 Software release : -- 3 Test schedule Tests were carried out in accordance with the specification detailed in chapter 7 “Summary” of this report. Tests were carried out at the following location: Radiated measurements <1 GHz: • TNO Electronic Products & Services (EPS) B.V Smidshornerweg 18 9822 TL Niekerk The Netherlands FCC listed : 90828 Industry Canada : IC3501 All other measurements: • Telefication, Zevenaar The samples of the product were received on: • 1 September 2004 Tests were carried out from: • 2 September 2004 to 28 September 2004 Main module Page: 5 of 11 Report number: 99538331 Logitech AGY-734969-0000.A0 4 Product documentation For production of this report the following product documentation was used: Description: Date: Identification: Product description August, 2004 M-RAN100 (1 page) Testing indications for Cordless Optical Mouse August 31, 2004 M-RAN100 (4 pages) Circuit diagram August 18, 2004 SCH-221886-0000, 3 sheets Main PCB lay-out 08/17/04 1 page Led PCB lay-out 08/17/04 10 pages Bill of materials August 17, 2004 Capri Power&MCU Rev A0 Block diagram August 31, 2004 Logitech M-RAN100 Electrical diagram The above-mentioned documentation will be filed at Telefication for a period of 10 years following the issue of this test report. 5 Observations and comments None. 6 Modifications to the sample No modifications were made to the sample. 7 Summary The product is intended for use in the following application area(s): INTENTIONAL RADIATOR OPERATING IN THE FREQUENCY BAND 2400 – 2483.5 MHz The sample was tested according to the following specification(s): FCC part 15; subpart C; sections 15.209 and 15.249 (10-1-03 edition) Main module Page: 6 of 11 Report number: 99538331 Logitech AGY-734969-0000.A0 8 Conclusions The samples of the product showed NO NON-COMPLIANCES to the specification stated in chapter 7 of this report. The results of the…
