DZL201963Cordless tranceiver

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for permanent FCC confidentiality (FCC ID: DZL201963) Reference number: C-UX34 Date: 27 June 2005 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests permanent FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL201963 a. Block diagram b. Schematic diagrams c. Operational description d. Bill of Material Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Temporary FCC confidentiality request regarding the application for certification of FCC ID: DZL201963 Reference number: C-UX34 Date: 27 June 2005 Dear FCC TCB, Pursuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests a temporary confidential treatment for the following materials submitted in support of FCC certification application for FCC ID: DZL201963 until 45 days after the grant date of Equipment Authorization : a. Photographs of overall appearance b. Test set-up photographs c. User’s manual d. Internal photographs Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

External Photos

INTERNAL PHOTOS

Radio test report 99659031 based on: - FCC Part 15 Subpart C, sections 15.209 & 15.249 (10-1-04 Edition) - FCC Part 15 Subpart B sections 15.107 & 15.109 (10-1-04 Edition) - RSS-210, Issue 5 (Nov. 2001 edition) Logitech Cordless Transceiver C-UX34 & L-LH9 Logitech AGY 735899-0000.A0 Report number: 99659031 Contents MAIN MODULE..............................................................................................................................................3 1 INTRODUCTION......................................................................................................................................3 2 PRODUCT...............................................................................................................................................4 3 TEST SCHEDULE.....................................................................................................................................4 4 PRODUCT DOCUMENTATION...................................................................................................................5 5 OBSERVATIONS AND COMMENTS...........................................................................................................5 6 MODIFICATIONS TO THE SAMPLE............................................................................................................6 7 SUMMARY..............................................................................................................................................6 8 CONCLUSIONS........................................................................................................................................7 TEST RESULTS MODULE ...........................................................................................................................8 1 GENERAL INFORMATION........................................................................................................................8 1.1 Equipment information .....................................................................................................................8 1.2 Test conditions..................................................................................................................................8 2 EMISSION TESTS.....................................................................................................................................9 2.1 Field strength of intentional signal ...................................................................................................9 2.2 Field strength of unwanted emissions 30 - 1000 MHz ...................................................................10 2.3 Field strength of unwanted emissions > 1000 MHz .......................................................................11 2.4 Conducted emissions ......................................................................................................................17 USED TEST EQUIPMENT MODULE .......................................................................................................21 CROSS REFERENCE TABLE ....................................................................................................................22 This report comprises of four modules. The total number of pages is: 22 Main module Page: 3 of 22 Report number: 99659031 Main module 1 Introduction This report contains the result of tests performed by: Telefication bv Edisonstraat 12a 6902 PK Zevenaar The Netherlands Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:1999. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). The contents of this test report, if reproduced, shall be copied in full, unless special consent in writing for reproduction in part is granted by Telefication. Copyright of this test report is reserved to Telefication. Ordering party: Company name : Logitech Europe S.A. Address : Z.I. Moulin du Choc D Zipcode : CH-1122 City/town : Romanel sur Morges Country : Switzerland Date of order : 21 June 2005 Main module Page: 4 of 22 Report number: 99659031 2 Product A sample of the following product was submitted for testing: Product description : USB dongle & extension cable with integrated battery charger Product category : Part 15 low power transceiver & computer peripheral Manufacturer : Logitech Europe S.A. Trade mark : Logitech Cordless Transceiver Type designation : C-UX34 & L-LH9 Hardware version : -- Serial number : LZ52248 Software release : -- 3 Test schedule Tests were carried out in accordance with the specification detailed in chapter 7 “Summary” of this report. Tests were carried out at the following location: • Telefication, Zevenaar The samples of the product were received on: • 24 June 2005 Tests were carried out from: • 29 June 2005 to 13 July 2005 Main module Page: 5 of 22 Report number: 99659031 4 Product documentation For production of this report the following product documentation was used: Description: Date: Identification: Product description 06-2005 C-UX34 : Product Description Circuit diagrams 30-05-2005 SCH 221963-0000 Rev A0 Parts list 23-05-2005 C-UX34 EE BOM ver01.xls PCB layout drawings 31-05-2005 C-UX34 GER-211963-0000_A0.pdf Testing indications 24-06-2005 Testing indications for the transceiver C-UX34 The above-mentioned documentation will be filed at Telefication for a period of 10 years following the issue of this test report. 5 Observations and comments A reservation was made to perform radiated emission measurement on the following Open Area Test Site: TNO Electronic Products & Services (EPS) B.V Smidshornerweg 18 9822 TL Niekerk The Netherlands FCC listed : 90828 Industry Canada : IC3501 Since the exploratory measurements revealed no emissions in the frequency range 30 - 1000 MHz…
