DZL202065Cordless keyboard

4 1 2 Logitech ® www.logitech.com 1 2 3 Installation Guide 3 6 8 7 English Test all devices. If a device does not work, repeat step 6 for that device only. Español Pruebe todos los dispositivos. Si alguno de ellos no funciona, repita el procedimiento 6 con ese dispositivo únicamente. Français Testez tous les dispositifs. Si l’un des dispositifs ne fonctionne pas, reprenez l’étape 6 pour ce dispositif uniquement. Português Teste todos os dispositivos. Se um dispositivo não funcionar, repita o passo 6 apenas para esse dispositivo. English Package Contents: 1. Keyboard 2. Mouse 3. Receiver 4. Four batteries 5. Software Español Contenido de la caja: 1. Teclado 2. Ratón 3. Receptor 4. Cuatro pilas 5. Software Français Contenu: 1. Clavier 2. Souris 3. Récepteur 4. Quatre piles 5. Logiciel Português Conteúdo do pacote: 1. Teclado 2. Rato 3. Receptor 4. Quatro pilhas 5. Software OFF English Turn OFF computer. Español Apague el ordenador. Français Mettez l'ordinateur hors tension. Português Desligue o computador. English Plug receiver cables into computer: PC desktops with PS/2 port use keyboard connector (GREEN) plus mouse connector (PURPLE). PC desktops with USB port only and PC notebooks use black USB connector only. Español Conecte al ordenador los cables del receptor: Los PC de sobremesa con puerto PS/2 usan el conector de teclado (MORADO) y el conector de ratón (VERDE). Los PC de sobremesa con puerto USB y los portátiles usan sólo el conector USB negro. Français Branchez les câbles du récepteur dans l’ordinateur: les ordinateurs de bureau avec port PS/2 utilisent le connecteur du clavier (VIOLET) et le connecteur de la souris (VERT). Les ordinateurs de bureau avec ports USB uniquement et les ordinateurs portables utilisent le connecteur USB noir uniquement. Português Ligue os cabos do receptor ao computador: PC de secretária com porta PS/2 utiliza conector de teclado(ROXO) e conector de rato (VERDE). PC de secretária somente com porta USB e PCs portáteis utilizam somente conector preto USB. USB PS/2 English Install batteries. Mouse: (1) Press button to release battery door. (2) Insert 2 AA batteries. Keyboard: (3) Insert 2 AAA batteries. Español Coloque las pilas. Ratón: (1) Pulse el botón para abrir el compartimento de las pilas. (2) Coloque 2 pilas AA. Teclado: (3) Coloque 2 pilas AAA. Français Installez les piles. Souris: (1) Appuyez sur le bouton pour ouvrir le compartiment des piles. (2) Insérez 2 piles AA. Clavier: (3) Insérez 2 piles AAAA. Português Instale as pilhas. Rato: (1) Prima o botão para liberar a porta do compartimento das pilhas. (2) Introduza as duas pilhas AA. Teclado: (3) Introduza as duas pilhas AAA. 5 ON English Turn ON computer. Español Encienda el ordenador. Français Mettez l’ordinateur sous tension. Português Ligue o computador. English Establish a connection separately for each device: 1) FIRST, press the Connect button on the receiver. 2) SECOND, press the Connect button under the device. Español Establezca una conexión para cada dispositivo: 1) PRIMERO, pulse el botón Connect del receptor. 2) A CONTINUACIÓN, pulse el botón Connect en la parte inferior del dispositivo. Français Etablissez la connexion séparément pour chaque dispositif: 1) AVANT TOUT, appuyez sur le bouton Connect du récepteur. 2) ENSUITE, appuyez sur le bouton Connect situé sous le dispositif. Português Estabeleça a ligação para cada dispositivo separadamente: 1) PRIMEIRO prima o botão Connect no receptor. 2) A SEGUIR prima o botão Connect na parte inferior do dispositivo. English To enjoy all the features of your product, you must install the software. Español Para disponer de todas las funciones del producto, debe instalar el software. Français Pour pouvoir utiliser pleinement toutes les fonctions du produit, vous devez installer le logiciel. Português Para utilizar todas as funções do produto, deve instalar o software. 1 2 1 Connect Mouse Connect Keyboard 2 3 4 5 2 1

? English Solving Setup Problems. 1. Check cable connection. 2. Place receiver away from electrical devices, and avoid metallic surfaces. 3. Check battery installation. The mouse uses 2 AA batteries; the keyboard uses 2 AAA batteries. Make sure mouse is ON by pressing the Power button. 4. TEST ALL DEVICES. Establish a connection separately for each device that does not work: 1) FIRST, press the Connect button on the receiver. 2) SECOND, press the Connect button under the device that is not working. Español Resolución de problemas de instalación. 1. Compruebe las conexiones de los cables. 2. No coloque el receptor cerca de dispositivos eléctricos o sobre superficies metálicas. 3. Compruebe la colocación de las pilas. El ratón utiliza dos pilas AA; el teclado utiliza dos pilas AAA. Para asegurar que el ratón está ENCENDIDO, pulse el botón de encendido. 4. PRUEBE TODOS LOS DISPOSITIVOS. Establezca una conexión para cada dispositivo que no funcione. 1) PRIMERO, pulse el botón Connect del receptor. 2) A CONTINUACIÓN, pulse el botón Connect en la parte inferior del dispositivo en cuestión. Français Résolution des problèmes d’installation. 1. Vérifiez la connexion des câbles. 2. Eloignez le récepteur des autres appareils électriques et évitez les surfaces métalliques. 3. Vérifiez que les piles sont bien installées. La souris utilise 2 piles AA et le clavier 2 piles AAA. Vérifiez que la souris est SOUS TENSION, en appuyant sur le bouton d'alimentation. 4. TESTEZ TOUS LES DISPOSITIFS. Etablissez la connexion séparément pour chaque dispositif qui ne fonctionne pas: 1) AVANT TOUT, appuyez sur le bouton Connect du récepteur. 2) ENSUITE, appuyez sur le bouton Connect situé sous le dispositif qui ne fonctionne pas. Português Resolver problemas de configuração. 1. Verifique a ligação do cabo. 2. Coloque o receptor longe de aparelhos eléctricos e evite superfícies metálicas. 3. Verifique a instalação das pilhas. O rato utiliza 2 pilhas AA; o teclado utiliza 2 pilhas AAA. Certifique-se de que o rato está LIGADO ao pressionar o botão de ligar. 4. TESTE TODOS OS DISPOSITIVOS. Estabeleça uma ligação separadamente para cada dispositivo que não está a funcionar. 1) PRIMEIRO prima o botão Connect no receptor. 2) A SEGUIR prima o botão Connect na parte inferior do dispositivo que não está a funcionar. i www.logitech.com/comfort www.logitech.com/comfort English 1. Battery status LED (green = OK; red = replace batteries within 10 days). 2. Stand by. 3. Internet home. 4. Zoom and rotate. 5. Default media player. 6. Media transport buttons. 7. Music shuffle. 8. Volume and mute. 9. Tilt wheel. See the software help system and visit the QuickTour ™ software. Also visit www.logitech.com/comfort for more information about using your products and for ergonomics. Español 1. Diodo de estado de pilas (verde = carga suficiente; rojo = cambie las pilas en un plazo de 10 días). 2. Suspensión. 3. Inicio de Internet. 4. Zoom y giro. 5. Reproductor de medios predeterminado. 6. Botones de reproducción de medios. 7. Orden de música aleatorio. 8. Volumen y silencio. 9. Botón rueda inclinable. Consulte el sistema de ayuda del software y ejecute QuickTour ™ . En www.logitech.com/comfort encontrará más información sanitaria y sobre el uso de los productos. 8 in . 2 0 cm 1 2 3 4 USB PS/2 1 2 1 Connect Mouse Connect Keyboard 2 1 2 3 4 8 9 1 6 5 7 www.logitech.com/support Austria +43-(0)1 502 221 348 Dutch: +32-(0)2 626 89 60; French: +32-(0)2 626 89 62 Location Hotline Technical Help (Aide Technique)Hotline (Aide Technique) Denmark Eastern Europe +45-35 44 55 17 English: +41-(0)21 863 54 01 Finland France +358-(0)9 817 100 21 +33-(0)1-43 62 34 14 Germany Hungary +49-(0)69-92 032 166 English: +41-(0)21 863 54 01 Ireland Italy +353-(0)1-605 8357 +39-02-214 08 71 Netherlands Norway +31-(0)10-243 88 98 +47-(0)23 500 083 Portugal Spain +351-21 316 4124 +34 –91-375 33 69 Sweden Switzerland +46-(0)8-519 920 20 D +41-(0)21-863 54 11; F +41-(0)21-863 54 31 I +41-(0)21-863 54 61 Belgium United Kingdom+44 -(0)207-309-01 26 Other countries English: +41-(0)21 863 54 01 Americas (USA) English: +1 702 269 3457 WWW Français 1. Témoin du niveau de charge des piles (vert = OK; rouge = changer les piles sous 10 jours). 2. Veille: 3. Page d'accueil Internet. 4. Zoom et rotation. 5. Lecteur multimédia par défaut. 6. Boutons de navigation multimédia. 7. Sélection musicale aléatoire. 8. Réglage du volume et de sourdine. 9. Roulette multidirectionnelle. Reportez-vous au système d’aide logiciel et le logiciel QuickTour ™ . Pour en savoir plus sur l'utilisation des produits et leur confort, effectuez la visite guidée et accédez au site Web www.logitech.com/comfort. Português 1. LED do estado das pilhas (verde = OK; vermelho = substitua as pilhas dentro de 10 dias). 2. Suspensão. 3. Home da Internet. 4. Zoom e rotação. 5. Leitor de multimédia predefinido. 6. Botões de transporte de multimédia. 7. Shuffle de música. 8. Volume e sem som. 9. Roda de inclinação. Consulte o sistema de ajuda no software e visite o software QuickTour ™ . Visite também www.logitech.com/comfort para obter mais informações sobre como utilizar os produtos e sobre ergonomia. © 2005 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. © 2005 Logitech. Tous droits réservés. Logitech, le logo Logitech et les autres marques Logitech sont la propriété exclusive de Logitech et sont susceptibles d’être des marques déposées. Toutes les autres marques sont la propriété exclusive de leurs détenteurs respectifs. Logitech décline toute responsabilité en cas d'erreurs dans ce manuel. Les informations énoncées dans le présent document peuvent faire l’objet de modifications sans avis préalable. 623857-0403.A English Impo…

Text truncated - open the document above for the full version.

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for permanent FCC confidentiality (FCC ID: DZL202065) Reference number: Y-RAK73 Date: 20 May 2005 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests permanent FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL202065 a. Block diagram b. Schematic diagrams c. Operational description d. Bill of Material Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

Logitech Europe S.A. Z.I Moulin du Choc D 1122 Romanel sur Morges Switzerland To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for short-term FCC confidentiality (FCC ID: DZL202065) Reference number: Y-RAK73 Date: 20 May 2005 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), Logitech Europe S.A. hereby requests short-term FCC confidentiality of the following materials submitted in support of FCC certification application for FCC ID : DZL202065 until 8 August 2005 a. Label and Label placement b. Photographs of overall appearance c. Test report d. Test set-up photographs e. User’s manual f. Internal photographs g. RF exposure/Environmental Evaluation h. Cover letters Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Logitech Europe S.A. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Pascal Bornel Compliance engineer

External Photos Y_RAK73 FCC ID: DZL202095

AIO40 (1) This device may not cause harmful inter ference, and (2) this device must accept interference received, including inter ference that may cause undesired operation. This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: F C C I D : D Z L 2 0 2 0 6 5 C a n a d a 2 1 0 R a t i n g : 3 V = = = , 1 5 m A M a d e i n C h i n a T41126 MODEL NAME: Y - RAK73 P/N: PID: PRINT TREATINGREMARKQ'T YDESCRIPTIONMAT'L TITLE SCALE DRAWN DESIGNER CHECKED APPROVED UNIT TOLERANCE UNSPECIFIED .XXX ± .XX ± .X ± . ± ANGLE ± SHEET OF DRAWING NO DRAWING FONT NO. MARKISSUEREVERDATECHECK Logitech type of document NO. Type Rev. REFER TO REMARK SK-7206/SK-7206A US warning labe R4.80(4X) 156.6 6 5 . 6 A 36-00131-02A C C

INTERNAL PHOTOS Y-RAK73 FCC ID: DZL202096

Radio test report 99651231 based on: FCC part 15; subpart C; section 15.227 (10-1-04 edition) Cordless Keyboard Logitech Cordless Keyboard Y-RAK73 Logitech AGY 735780-0000.A0 Report number: 99651231 Logitech AGY 735780-0000.A0 Contents MAIN MODULE............................................................................................................................................3 1 I NTRODUCTION ....................................................................................................................................3 2 P RODUCT .............................................................................................................................................4 3 T EST SCHEDULE ...................................................................................................................................4 4 P RODUCT DOCUMENTATION .................................................................................................................5 5 O BSERVATIONS AND COMMENTS .........................................................................................................6 6 M ODIFICATIONS TO THE SAMPLE ..........................................................................................................6 7 S UMMARY ............................................................................................................................................6 8 C ONCLUSIONS ......................................................................................................................................7 TEST RESULTS MODULE .........................................................................................................................8 1 G ENERAL INFORMATION ......................................................................................................................8 1.1 Equipment information ...................................................................................................................8 2 E MISSION TESTS ...................................................................................................................................9 2.1 Field strength of intentional signal .................................................................................................9 2.2 Field strength of unwanted emissions...........................................................................................10 USED TEST EQUIPMENT MODULE .....................................................................................................11 This report comprises of three modules. The total number of pages is: 11 Main module Page: 3 of 11 Report number: 99651231 Logitech AGY 735780-0000.A0 Main module 1 Introduction This report contains the result of tests performed by: Telefication B.V. Edisonstraat 12a 6902 PK Zevenaar The Netherlands Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:1999. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). The contents of this test report, if reproduced, shall be copied in full, unless special consent in writing for reproduction in part is granted by Telefication. Copyright of this test report is reserved to Telefication. Ordering party: Company name : Logitech Europe S.A. Address : Z.I. Moulin du Choc D Zipcode : CH-1122 City/town : Romanel sur Morges Country : Switzerland Date of order : 19 May 2005 Main module Page: 4 of 11 Report number: 99651231 Logitech AGY 735780-0000.A0 2 Product A sample of the following product was submitted for testing: Product description : Cordless Keyboard Manufacturer : Logitech Europe S.A. Trade mark : Logitech Cordless Keyboard Type designation : Y-RAK73 FCC ID : DZL202065 Hardware version : -- Serial number : P/N 021 Software release : -- 3 Test schedule Tests were carried out in accordance with the specification detailed in chapter 7 “Summary” of this report. Tests were carried out at the following location: • TNO Electronic Products & Services (EPS) B.V Smidshornerweg 18 9822 TL Niekerk The Netherlands FCC listed : 90828 Industry Canada : IC3501 The sample of the product was received on: • 23 May 2005 Tests were carried out on: • 30 May 2005 Main module Page: 5 of 11 Report number: 99651231 Logitech AGY 735780-0000.A0 4 Product documentation For production of this report the following product documentation was used: Description: Date: Identification: Product description May 2005 Y-RAK73_Description.doc Test instructions May 2005 Y-RAK73_Test_Inst.doc Circuit diagram April 07, 2005 Y-RAK73 Schematic-rev PA4.pdf Block diagram -- Y-RAK73 blockdiagram rev0_2.pdf PCB lay out 03/15/05 Y-RAK73 Layout-rev PA4.pdf Parts list April 14, 2005 Y-RAK73 BOM-PA4.txt The above-mentioned documentation will be filed at Telefication for a period of 10 years following the issue of this test report. Main module Page: 6 of 11 Report number: 99651231 Logitech AGY 735780-0000.A0 5 Observations and comments During the tests the product was set in continuous transmit mode (CH1 & CH2 selectable), by means of a test mode. 6 Modifications to the sample No modifications were made to the sample. 7 Summary The product is intended for use in the following application area(s): • INDUCTIVE DATA TRANSMISSION APPLICATION IN THE 27 MHz BAND The samples were tested according to the following specification(s): • FCC part 15; subpart C; section 15.227 (10-1-04 edition) Main module Page: 7 of 11 Report number: 99651231 Logitech AGY 735780-0000.A0 8 Conclusions The samples of the product showed NO NON-COMPLIANCES to the specification stated in chapter 7 of this report. The results of the tests as stated in this report, are exclusively applicable to the product items as identified in this test report. Telefication does not …

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS FCC ID: DZL202095 Photograph 1: Test setup OATS < 30 MHz Photograph 2: Test setup OATS > 30 MHz
