DZL221407Wireless Keyboard

1 Logitech ® Mouse , Trackball, and Keyboard User’s Guide for MouseWare ® and iTouch ™ ® ™ 2 Welcome! Welcome! Congratulations on your purchase of your Logitech ® product. Your mouse, trackball, or keyboard is part of the Logitech family of interactive desktop products, which make your time at the computer, or on the Internet, more productive, comfortable, and enjoyable. Logitech has been designing, manufacturing, and marketing computer peripherals for over 18 years. These products form the bridge between people and computers, a link so intuitive that the digital world feels like a natural extension of your senses. To help you get the most from your Logitech product, this manual was written to be used either online or as a printed document. It is a down- loadable file, which is copied to your hard drive automatically during software installation. You can quickly view the contents of this manual by clicking one of the topics you see listed on the left. Or you can print this manual by clicking “File” then “Print” in the menu bar above. To use this manual effectively, you must first install your Logitech product by connecting the hardware and installing the software. To install your Logitech product, please refer to the printed Getting Started Guide that comes with your product. This document tells you everything you need to know in order to get started right away. After you have finished installation, refer to this document to learn more about the following topics: • Comfort Guidelines • MouseWare ® , Logitech’s Premier Pointing Device Software for Windows and Macintosh ® • Button Assignments for Your Mouse or Trackball • Scrolling and Zooming (Zooming in Windows ® Only) in Documents with Your Mouse or Trackball • WebWheel ™ , Logitech’s Easy-to-Use and Intuitive Web Interface • iTouch ™ Software, Logitech’s Innovative Keyboard and Internet Software • Product Maintenance • Troubleshooting • Logitech ® Addresses and Telephone Numbers • Product Warranties 3 Comfort Guidelines Comfort Guidelines Important Ergonomic Information Feels Good, Feels Better... Whether you spend five minutes or five hours using your keyboard, mouse, or trackball, these suggestions can help you stay comfortable and productive. Some research suggests that • long periods of repetitive motion, • using an improperly set up work space, • incorrect body position, and • poor work habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, tingling, weakness, swelling, burning, cramping, or stiffness in your hands, wrists, arms, shoulder, neck, or back, see a qualified health professional. Follow the guidelines in this booklet to maximize your comfort and lessen the chance of injury. 4 Comfort Guidelines Make sure that your workspace is set up properly... Your keyboard and monitor should be directly in front of you with your mouse or trackball next to it. Place your mouse or trackball within easy reach so that your elbow can remain next to your side when using them. DO place materials on your desk according to their frequency of use: • Frequent - Put materials you use the most closest to you. • Occasional - Put materials that you use occasionally no farther than an arm's length away. • Infrequent - Put your infrequently used materials further away, but consider convenience. DO place documents you need while typing close to the monitor to reduce frequent head turning and change of eye focus. You can use a document holder to help. DO •DO adjust the height of your chair and table as to have the keyboard, mouse, or trackball at or below elbow height. •DO use the adjustment mechanism on the keyboard, if necessary to obtain the proper keyboard height. •DO remember, if you use a mouse pad, take its thickness into consideration when making the height adjustments. •DO have your feet well supported and your shoulders relaxed. 5 Comfort Guidelines Keep your shoulders, arms, wrists, and hands relaxed and comfortable as you work... To keep your shoulders, arms, wrists, and hands relaxed as you work, let them hang loosely at your sides for a moment, allowing them to dangle toward the floor and to become relaxed. Try to maintain this relaxed feeling while you work. DO If you have a wrist rest or a palm rest, use it between keying tasks, not while typing. Using it while typing may increase pressure against the hand and increase the chance of injury. When you use your keyboard, mouse, or trackball, avoid placing or supporting your wrists on sharp edges or on your desktop. As you use your keyboard, mouse, or trackball, make sure that your elbow is next to your side. Keep your wrist relaxed and straight–don't bend it up, down, or to either side. Keep your shoulders relaxed. Do not hunch or shrug. DON’T rest your wrist on sharp edges. DON’T bend your wrist. 6 Comfort Guidelines Practice good work habits... • Take frequent short breaks. Get up and walk around at least a couple of times every hour. • Vary your tasks throughout the day. Do something different with your hands and arms for a while. • Use a light touch on the keyboard and for better control of the mouse or trackball. • Use software features to customize your mouse or trackball to help you reduce stress to your arm, wrist, or hand by minimizing repetitive or awkward motions. Be alert to signs of discomfort... If at any time during or after typing you feel pain, weakness, numbness, or tingling in your hands, wrists, elbows, shoulders, neck, or back, or if you have any reason to believe that you might be experiencing discomfort as a result of typing or from using the mouse, you should consult a qualified health professional. Getting information... Please review this entire booklet for suggestions regarding work habits and workspace arrangement. For information regarding strategies or customizations which might increase your comfort when using the other parts of your computer system (monitor, CPU, etc.), please consult the lit…

Text truncated - open the document above for the full version.

May 4, 2000 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Logitech, Inc. hereby authorizes CKC Laboratory to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by CKC Laboratory on our behalf shall have the same effect as our own. This authorization expires on April 30, 2001 unless renewed. We, the applicant certify that, in the case of individual applicant, he or she is not subject to a denial of federal benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 853a or in the case of non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the applicant is subject to a denial of federal benefit pursant to that action. Thank you. Sincerely, Bharat Shah EMC/Safety Engineering

Y-RC14 Block Diagram LOGITECH CONFIDENTIAL 30/07/04 uProcessor Oscil- lator Ampli- fier & Tuning Keys Sleep & Battery Status Power supply : 2 x 1.5V alkaline batteries OSC En. TX Data TX Enable Loop Antenna 27.145 MHz

Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Logitech, Inc. would like the following documents regarding this submission for FCC ID: DZL1221407 to be kept confidential. 1. Page 1 of 1 of document Y-RC14: Product Description. 2. Page 1 of 1 of document Y-RC14 rev PA_A0.2 schematic drawing. 3. Pages 5 of 5 of the file named PCB Y-RC14PA1_A. The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Joyce Walker Technical Report Writer CKC Laboratories, Inc Agent for Logitech Inc

Page 1 of 27 Report No: FC00-046 CERTIFICATION TEST REPORT FOR THE CORDLESS KEYBOARD, Y-RC14 FCC PART 15 SUBPART C PART 15.227 COMPLIANCE DATE OF ISSUE: MAY 11, 2000 PREPARED FOR: Logitech, Inc. 6505 Kaiser Drive Fremont, CA 94555 W.O. No: 74296 PREPARED BY: Joyce Walker CKC Laboratories, Inc. 5473A Clouds Rest Mariposa, CA 95338 Date of test: May 4, 2000 Report No: FC00-046 DOCUMENTATION CONTROL: _____________________________ Tracy Phillips Documentation Control Supervisor CKC Laboratories, Inc. APPROVED BY: _____________________________ Dennis Ward Director of Laboratories CKC Laboratories, Inc. This report contains a total of 27 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Page 2 of 27 Report No: FC00-046 TABLE OF CONTENTS Administrative Information ............................................................................................. 3 Summary Of Results........................................................................................................ 4 Equipment Under Test (EUT) Description...................................................................... 4 Measurement Uncertainty................................................................................................ 4 Peripheral Devices ........................................................................................................... 4 Report Of Measurements................................................................................................. 5 Table 1: Fundamental Emission Levels.............................................................. 5 Table 2: Six Highest Radiated Emission Levels - 9kHz-30MHz ....................... 6 Table 3: Six Highest Radiated Emission Levels - 30MHz-1000MHz ............... 7 Table A : List Of Test Equipment ................................................................................... 8 EUT Setup .......................................................................................................................9 Test Instrumentation And Analyzer Settings................................................................... 9 Table B : Analyzer Bandwidth Settings Per Frequency Range........................... 9 Spectrum Analyzer Detector Functions............................................................... 10 Peak ......................................................................................................... 10 Quasi-Peak............................................................................................... 10 Average.................................................................................................... 10 Test Methods ................................................................................................................... 11 Radiated Emissions Testing................................................................................. 11 Occupied Bandwidth ........................................................................................... 12 Sample Calculations ........................................................................................................ 12 Appendix A : Information About The Equipment Under Test........................................ 13 I/O Ports............................................................................................................... 14 Crystal Oscillators ............................................................................................... 14 Printed Circuit Boards ......................................................................................... 14 Required EUT Changes To Comply.................................................................... 14 Equipment Configuration Block Diagram........................................................... 15 Photograph Showing Radiated Emissions ........................................................... 16 Photograph Showing Radiated Emissions ........................................................... 17 Appendix B : Measurement Data Sheets ......................................................................... 18 Occupied Bandwidth Plot Part 2.1049 ................................................................ 19 Detector Functions and Bandwidth Part 15.35 (c) .............................................. 20 Detector Functions and Bandwidth Part 15.35 (c) .............................................. 21 Modulation Characteristics Part 2.1047 .............................................................. 22 Page 3 of 27 Report No: FC00-046 CKC Laboratories, Inc. has Certificates of Accreditation from the following agencies: DATech (Germany); A2LA (USA); FCC (USA); VCCI (Japan); BSMI (Taiwan); HOKLAS (Hong Kong). CKC Laboratories, Inc. has Letters of Acceptance through an MRA for the following agencies: ACA/NATA (Australia); SABS (South Africa); SWEDAC (Sweden); TUV Rheinland-Germany; TUV Rheinland- Korea; TUV Rheinland-Russia; Radio Communication Agency (RA); NEMKO (Norway). ADMINISTRATIVE INFORMATION DATE OF TEST: May 4, 2000 PURPOSE OF TEST: To demonstrate the compliance of the Cordless Keyboard, Y-RC14, with the requirements for FCC Part 15.227 devices. MANUFACTURER: Logitech, Inc. 6505 Kaiser Drive Fremont, CA 94555 REPRESENTATIVE: Bharat Shah TEST LOCATION: CKC Laboratories, Inc. 1653 Los Viboras Road Hollister, CA 95023 TEST PERSONNEL: Art Rice TEST METHOD: ANSI C63.4 1992 FREQUENCY RANGE TESTED: 9 kHz - 1000 MHz EQUIPMENT UNDER TEST:Cordless Keyboard Manuf:Logitech, Inc. Model:Y-RC14 Serial:001 FCC ID:DZL221407 (pending) Page 4 of 27 Report No: FC00-046 SUMMARY OF RESULTS The Logitech, Inc. Cordless Keyboard, Y-RC14, was tested in accordance with ANSI C63.4 1992 for compliance with FCC Part 15.227. As received, the above equipment was found to be fully compliant with the limits of FCC Part 15.227. The results in this report apply only to the items tested, as identified herein. EQUIPMENT UNDER TEST (EU…
