DZL221829Logitech ViewPort AV 100

Installation ViewPort AV 100 Logitech ® Step up to advanced precision Installation 623631-0403_Elkhorn-US.book Page 1 Tuesday, September 7, 2004 5:19 PM ii 623631-0403.A0 FCC Compliance and Advisory Statement. This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the equipment and the receiver; 3) connect the equipment to an outlet on a circuit different from that to which the receiver is connected; 4) consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. Canadian DOC Statement. This digital device does not exceed the Class B limits for radio noise emissions from digital apparatus specified in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications. This device complies with RSS-210 of Industry and Science Canada. Operation is subject to the following two conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including interference that may cause undesired operation of the device. Déclaration FCC. Cet équipement a été testé et déclaré conforme à la section 15 du règlement de la FCC. Son fonctionnement est soumis aux conditions suivantes: 1) l'équipement concerné ne doit pas causer d'interférences dangereuses, et 2) il doit accepter toute interférence reçue, y compris les interférences risquant d'engendrer un fonctionnement indésirable. Cet équipement a été testé et déclaré conforme aux limitations prévues dans le cadre de la catégorie B des appareils numériques défini par la section 15 du règlement de la FCC. Ces limitations sont stipulées aux fins de garantir une protection raisonnable contre les interférences gênantes en installation résidentielle. Cet équipement génère, utilise et diffuse des ondes radio, et s'il n'est pas installé ni utilisé en conformité avec les instructions dont il fait l'objet, peut causer des interférences gênantes avec les communications radio. Cependant, nous ne pouvons vous garantir qu'une interférence ne se produira pas dans une installation particulière. Si cet équipement produit des interférences graves lors de réceptions radio ou télévisées qui peuvent être détectées en allumant et en éteignant l'équipement, vous êtes invités à les supprimer de plusieurs manières: 1) Réorienter ou déplacer l'antenne de réception; 2) Augmenter la distance séparant l'équipement et le récepteur; 3) Connecter l'équipement à un circuit différent de celui auquel le récepteur est connecté; 4) Contacter votre revendeur ou un technicien radio/TV qualifié. Toutes modifications ou tous changements effectués sans l'accord exprès de la partie responsable de la conformité aux normes pourraient contraindre l'utilisateur à ne plus utiliser son équipement. Afin d'assurer la conformité avec les règlements FCC, les câbles d'interface blindés fournis avec le produit doivent être utilisés, ainsi que tout autres composants ou accessoires également spécifiés, lors de l'installation du produit. Déclaration du Ministère des Communications Canadien. Cet appareil numérique est conforme aux limitations concernant l'émission d'interférences radio par des appareils numériques de catégorie B, telles que stipulées dans le cadre de la norme Appareils numériques ICES-003 édictée par le Ministère canadien de l’Industrie. Cet équipement a été déclaré conforme à la norme RSS-210 édictée par le Ministère canadien des Sciences et de l'Industrie. Son fonctionnement est soumis aux conditions suivantes: 1) l'équipement concerné ne doit pas causer d'interférences, et 2) il doit accepter toute interférence reçue, y compris les interférences risquant d'engendrer un fonctionnement indésirable. 623631-0403_Elkhorn-US.book Page 2 Tuesday, September 7, 2004 5:19 PM iii Contents English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 623631-0403_Elkhorn-US.book Page 3 Tuesday, September 7, 2004 5:19 PM English 1 Camera and Headset Features Camera lens Video streaming status LED Headset Headset battery charging LED Bluetooth link LED Start button Pause/mute LED Pau…

Text truncated - open the document above for the full version.

Request for non-disclosure RF_501_02 Date: November 11, 2004 From: Bharat Shah Logitech Inc. 6505 Kaiser Drive, Fremont, CA 94555 510-713-4777 To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for non-disclosure (FCC ID:DZL221829 Reference number: ###### Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), <name applicant> hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID: (DZL221829) a. Schematic diagrams b. Operational description c. Bill of Material d. PCB layout Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. <Name applicant> understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Bharat Shah

LABEL SAMPLE: LABEL LOCATION:

Radio Test Report: 99594831 Applicant: Logitech Europe SA Z.I. Moulin du Choc CH-1122 Romanel Morges, Switzerland Equipment Under Test: V-UAN17 FCC ID: DZL221829 In Accordance With: FCC Part 15, Subpart C, 15.247 (10-1-03 edition) Frequency Hopping Transmitters Tested By: Telefication bv Edisonstraat 12a 6902 PK Zevenaar The Netherlands Tested by: _________________________________ ing. P.A. Suringa, Senior Engineer Radio/EMC Reviewed by: _________________________________ ing. J.C. le Clercq, Test Engineer Authorized by: _________________________________ J.P. van de Poll, Co-ordinator Test Group Date: 8 December 2004 Total Number of Pages: 42 Logitech AGY-735235-0000 Logitech AGY-735235-0000 Report number.: 99594831 Page 2 of 42 Table of Contents Section 1. Summary of Test Results ....................................................................................... 3 Section 2. Equipment Under Test (E.U.T.)............................................................................. 5 Section 3. Channel Separation ................................................................................................ 8 Section 4. Pseudorandom Hopping Algorithm ....................................................................... 9 Section 5. Time of Occupancy.............................................................................................. 10 Section 6. Occupied Bandwidth............................................................................................ 11 Section 7. Peak Power Output .............................................................................................. 14 Section 8. Spurious Emissions (Antenna conducted) ........................................................... 15 Section 9. Spurious Emissions (Radiated, exploratory) ....................................................... 19 Section 10. Spurious Emissions (Radiated, compliance) ....................................................... 21 Section 11. Spurious Emissions (Restricted bands Radiated) ................................................ 22 Section 10. AC power conducted emissions........................................................................... 33 Section 11. Test Equipment List ............................................................................................. 35 Annex A Test details............................................................................................................. 36 Logitech AGY-735235-0000 Report number.: 99594831 Page 3 of 42 Section 1. Summary of Test Results Manufacturer: Logitech inc., 6505 Kaiser Drive, 94555 Fremont, CA USA Model No.: V-UAN17 Serial No.: Not applicable Date Received In Laboratory: 23 November 2004 These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.247 for Frequency Hopping Spread Spectrum devices. Tests were conducted in accordance with Public Notice DA 00-705, issued in March 2000. New Submission Production Unit Class II Permissive Change Pre-Production Unit Family Listing THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Telefication bv authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Telefication bv accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. Telefication complies with the accreditation criteria for test laboratories as laid down in ISO/IEC 17025:1999. The accreditation covers the quality system of the laboratory as well as the specific activities as described in the authorized annex bearing the accreditation number L021 and is granted on 30 November 1990 by the Dutch Council For Accreditation (RvA: Raad voor Accreditatie). Logitech AGY-735235-0000 Report number.: 99594831 Page 4 of 42 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. MEAS. RESULT Powerline Conducted Emissions 15.207(a) 48 dBμV 45.9 dBμV PASS Channel Separation 15.247(a)(1) Greater than 25 kHz or 20 dB bandwidth 1 MHz PASS Pseudorandom Hopping Algorithm 15.247(a)(1) Bluetooth -- PASS Time of Occupancy 15.247(a)(1)(ii) ≤ 0.4 sec in 30 sec 18 msec PASS 20 dB Occupied Bandwidth 15.247(a)(1) N.A. 0.875 MHz N.A. Peak Power Output 15.247(b) 1 Watt 1.0 mW PASS Spurious Emissions (Antenna Conducted) 15.247(c) ≤ -20 dBc ≤ - 51.66 dBc PASS Spurious emissions (Radiated) 15.209 Table 15.209(a) ≤ 39.0 dBμV/m PASS Spurious Emissions in restricted bands as defined in 15.205(a) (Radiated) 15.247(c) Table 15.209(a) 45.2 dBμV/m (Av) 63.9 dBμV/m (Pk) PASS Test Conditions: Indoor Temperature: 22 °C Humidity: 45 % Outdoor Temperature: 4.3 °C Humidity: -- Test locations: Section 15.209 only: • TNO Electronic Products & Services (EPS) B.V Smidshornerweg 18 9822 TL Niekerk The Netherlands FCC listed : 90828 Industry Canada : IC3501 Other applicable sections: • Telefication bv, Zevenaar Note: During testing, use has been made of a test tool named Blue Test issued by CSR Ltd. By means of this test tool, the power was set to its maximum (pwr int = 63). Logitech AGY-735235-0000 Report number.: 99594831 Page 5 of 42 Section 2. Equipment Under Test (E.U.T.) General Equipment Information Frequency Band: 2400 – 2483.5 MHz Rated power: 4 dBm (conducted) Number of Channels: 79 Channel Spacing: 1 MHz Emissions Designator: 1M00F1D Logitech AGY-735235-0000 Report number.: 99594831 Page 6 of 42 Description of Modification for Modification Filing Not applicable Family List Rational Not applicable Logitech AGY-735235-0000 Report number.: 99594831 Page 7 of 42 Description of EUT The V-UAN17 contains a spread spectrum frequency hoppin…

Text truncated - open the document above for the full version.
