DZLA-00005Cordless Vantage Headset

Northwest EMC TCB Compliance Opinion Rev. 9/15/03 LABT0276 Information about the Applicant Grantee (Company Name) Logitech, Inc. FCC Contact Person Bharat Shah Address 6505 Kaiser Drive City, State, Zip Fremont, CA 94555 Job Number LABT0276 Model Cordless Vantage Headset FCC ID DZLA-00005 Agent Northwest EMC, Inc. Approval Type Original Equipment Class DTS Digital Transmission System Rule Part Bluetooth Overview Bluetooth headset Confidentiality requested for allowed files. Request is properly addressed and referenced. Short term confidentiality requested. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 10/10/2007

(8) Antenna InfoA-00005 (a) Per FCC 15.203, the antenna is internal and permanently attached. It is not intended to be serviced by the customer and is, therefore only serviceable by Logitech, Inc. authorized personnel. (b)The device is an FCC 15.247 device.The main antenna has an EIRP =+4.80dBm (c) The antenna isprinted on the circuit board. SeeExhibit 5 for pictures of the printed antenna. Manufacturer:Logitech, Inc. Part Number:212713-0000 (printed circuit board) Gain (dBi):2.7dBi Description:Printed Inverted-F Antenna (PIFA) NORTHWEST EMC EUT: Windu Inverted F AntennaWork Order: LABT0277 Serial Number: UnknownDate: Customer: Logitech, Inc.Temperature: 21 Attendees: NoneHumidity: 34% Project:Barometric Pres.: 1018.5 Tested by: Rod PeloquinPower: Batter yJob Site: EV01 TEST PARAMETER S Antenna Height(s) (m) 1 - 4 Test Distance (m) 3 COMMENTS EUT OPERATING MODE S DEVIATIONS FROM TEST STANDARD Run # Configuration # Results Freq AzimuthHeightPolarity Detector EIRPEIRP (MHz) (degrees)(meters)(Watts)(dBm) 2401.880129.01.5H-HornPK3.05E-034.84 Maximum Conducted Output Power Freq Power Detector PowerPower (MHz) (mW)(Watts)(dBm) 2401.8801.6PK1.64E-032.15 Antenna Gain Antenna Gain = EIRP (dBm) - Conducted Output Power (dBm) EIRP (dBm) = 4.8 dBm Conducted Output Power (dBm) = 2.1 dBm Antenna Gain = 2.7 dBi Effective Isotropic Radiated Power 09/25/07 2 Evaluation 3 MHz RBW / 3 MHz VBW 4 No deviations. Antenna Gain PSA 2007.05.07 EMI 2006.11.29 Bluetooth Transmit mode, Low Channel, 8DPSK, 3DH5

(9) RF ExposureA-00005 Compliance with 47 CFR 15.247(i) “Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter.” The EUT is a Bluetoothheadsetthat allows cordless communication of speech and music between a Bluetooth source and the unit. It can be considered a portable transmitter per 47 CFR 2.1093. The antenna is internal to the unit and permanently attached. The antenna is aprinted inverted-F antenna (P IFA) with 2.7 dBi gain. The maximum peak conducted output power is 1.64mW. The maximum peak power is3.02mW (EIRP) for FCC ID: DZLA-00005. The transmit frequency is 2402 to 2480 MHz, therefore the EUT does not require routine SAR evaluation per “TCB Exclusions List”, footnote 3 (dated July 17, 2002). See below: The exposure category is “General Population”. The distance is < 2.5 cm.Therefore the “Low Threshold” is 24.5 mW (EIRP)– above which routine SAR evaluation would be required. Since the maximum peak power of the EUT is3.02mW (EIRP), routine SAR evaluation is not required. The applicant’s Bluetooth radio, FCC ID: DZLA-00005, is compliant withthe requirements of 15.247(i).

Logitech, Inc. Cordless Vantage Headset September 26, 2007 Report No. LABT0276 Report Prepared By www.nwemc.com 1-888-EMI-CERT © 2007Northwest EMC, Inc 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Test Issue Date: September 26, 2007 Logitech, Inc. Model: Cordless Vantage Headset Emissions Test Description Specification Test Method Pass/Fail Spurious Radiated Emissions FCC 15.247 (DTS):2006 ANSI C63.4:2003 KDB No. 558074 Pass Radiated Emissions from Digital Portion FCC 15.109(g) (CISPR 22:1997):2006 Class B ANSI C63.4:2003 Pass Occupied Bandwidth FCC 15.247 (FHSS):2006 ANSI C63.4:2003 DA 00-705:2000 Pass Output Power FCC 15.247 (DTS):2006 ANSI C63.4:2003 KDB No. 558074 Pass Band Edge Compliance FCC 15.247 (DTS):2006 ANSI C63.4:2003 KDB No. 558074 Pass Spurious Conducted Emissions FCC 15.247 (DTS):2006 ANSI C63.4:2003 KDB No. 558074 Pass Power Spectral Density FCC 15.247 (DTS):2006 ANSI C63.4:2003 KDB No. 558074 Pass Modifications made to the product See the Modifications section of this report Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 Phone: (503) 844-4066 Fax: 844-3826 This site has been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada. Approved By: Ethan Schoonover, Sultan Lab Manager NVLAP Lab Code: 200630-0 This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Northwest EMC Revision History Revision 05/05/03 Revision Number Description Date Page Number 00 None Northwest EMC Accreditations and Authorizations Revision 03/18/05 FCC: Accredited by NVLAP for performance of FCC radio, digital, and ISM device testing. Our Open Area Test Sites, certification chambers, and conducted measurement facilities have been fully described in reports filed with the FCC and accepted by the FCC in letters maintained in our files. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by the FCC as a Telecommunications Certification Body (TCB). This allows Northwest EMC to certify transmitters to FCC specifications in accordance with 47 CFR 2.960 and 2.962. NVLAP: Northwest EMC, Inc. is accredited under the United States Department of Commerce, National Institute of Standards and Technology, and National Voluntary Laboratory Accreditation Program for satisfactory compliance with the requirements of ISO/IEC 17025 for Testing Laboratories. The NVLAP accreditation encompasses Electromagnetic Compatibility Testing in accordance with the European Union EMC Directive 2004/108/EC, and ANSI C63.4. Additionally, Northwest EMC is accredited by NVLAP to perform radio testing in accordance with the European Union R&TTE Directive 1999/5/EEC, the requirements of FCC, and the RSS radio standards for Industry Canada. NVLAP LAB CODE 200629-0 NVLAP LAB CODE 200630-0 NVLAP LAB CODE 200676-0 NVLAP LAB CODE 200761-0 Industry Canada: Accredited by NVLAP for performance of Industry Canada RSS and ICES testing. Our Open Area Test Sites and certification chambers comply with RSS 212, Issue 1 (Provisional) and have been filed with Industry Canada and accepted. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by NIST and recognized by Industry Canada as a Certification Body (CB) per the APEC Mutual Recognition Arrangement (MRA). This allows Northwest EMC to certify transmitters to Industry Canada technical requirements. CAB: Designated by NIST and validated by the European Commission as a Conformity Assessment Body (CAB) to conduct tests and approve products to the EMC directive and transmitters to the R&TTE directive, as described in the U.S. - EU Mutual Recognition Agreement. TÜV Product Service: Included in TUV Product Service Group's Listing of Recognized Laboratories. It qualifies in connection with the TUV Certification after Recognition of Agent's Testing Program for the product categories and/or standards shown in TUV's current Listing of CARAT Laboratories, available from TUV. A certificate was issued to represent that this laboratory continues to meet TUV's CARAT Program requirements. Certificate No. USA0604C. TÜV Rheinland: Authorized to carryout EMC tests by order and under supervision of TÜV Rheinland. This authorization is based on "Conditions for EMC-Subcontractors" of November 1992. Northwest EMC Accreditations and Authorizations Revision 03/18/05 NEMKO: Assessed and accredited by NEMKO (Norwegian testing and certification body) for European emissions and immunity testing. As a result of NEMKO's laboratory assessment, they will accept test results from Northwest EMC, Inc. for product certification (Authorization No. ELA 119). Australia/New Zealand: The National Association of Testing Authorities (NATA), Australia has been appointed by the ACA as an accreditation body to accredit test laboratories and competent bodies for EMC standards. Accredited test reports or assessments by competent bodies must carry the NATA logo. Test reports made by an overseas laboratory that has been accredited for the relevant standards by an overseas accreditation body that has a Mutual Recognition Agreement (MRA) with NATA are also accepted as technical grounds for product conformity. The report should be endorsed with the respective logo of the accreditation body (NVLAP)…

Text truncated - open the document above for the full version.

NORTHWEST EMC photo RADIATED EMISSIONS PSA-ESCI 2007.05.07 NORTHWEST EMC Spurious Radiated Emissions PSA 2007.05.07 NORTHWEST EMC Spurious Radiated Emissions PSA 2007.05.07 NORTHWEST EMC Occupied Bandwidth XMit 2007.06.13 NORTHWEST EMC Output Power XMit 2007.06.13 NORTHWEST EMC Band Edge Compliance XMit 2007.06.13 NORTHWEST EMC Spurious Conducted Emissions XMit 2007.06.13 NORTHWEST EMC Power Spectral Density XMit 2007.06.13
