User Manual Guide de l’utilisateur Logitech ® Z-5450 Digital/Numériques Z-5450_manual_AMR.indd 110/12/2005 10:10:42 AM English  English  Important Safety InformatIon CaUtIon eLeCtr IC SHoCK H aZar D • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not push objects into apparatus vents or slots because fire or electric shock hazards could result. • Maintain a minimum distance of at least 6 inches around apparatus for sufficient ventilation. • Ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table clothes, curtains, etc. • No naked flame sources, such as lighted candles, should be placed on or near the apparatus. • Place apparatus in a stable location so it will not fall causing product damage or bodily harm. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one wider than the other. The wide blade is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Operate the apparatus only from the low level audio line output jack of the computer or of an audio device. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Unplug this apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. • The apparatus shall be disconnected from the mains by placing the power/standby switch in the standby position and unplugging the power cord of the apparatus from the AC mains receptacle. • The socket-outlet shall be installed near the equipment and shall be easily accessible. Warn InG: to re DUC e tHe rISK of fIre or eLeCtr IC SH oCK, Do not eXpo Se tHIS apparatUS to ra In or mo IS tUre . Dolby® Digital is the universal standard for 5.1 digital sound. DVDs, PlayStation®2, Xbox™, digital cable, satellite TV, and HDTV all use Dolby® Digital. Dolby ProLogic II transforms any high-quality stereo source into a full 5.1 experience. Dolby ProLogic II brings new life to the playback of CDs, MP3s, video games, and other stereo content. The Z-5450 Digital includes a hardware Dolby® Digital decoder and Dolby Pro Logic II for full, rich 5.1 sound. THX Certified Multimedia THX brings high quality entertainment to the desktop. Developed to optimize stereo and multi-channel (5.1, 6.1, and 7.1) desktop audio performance, THX Certified multimedia duction, as well as easy set-up and configuration. With THX Certified multimedia, PC systems are transformed into high fidelity, digital entertainment centers – bringing movies, music and games to life. DTS® Digital Surround delivers 5.1 digital sound that rivals master soundtracks. DTS® soundtracks are included in many DVD videos, DVD audio discs and PlayStation®2 games. The Z-5450 Digital includes a hardware DTS® decoder for master-quality sound. The Z- 5450 also includes support for DTS® 96/24 - an enhanced, higher-resolution, studio-quality format available on many DVD video and DVD Audio discs.* Thank you for purchasing the Logitech® Z-5450 Digital multimedia speaker system with dual wireless rear speakers. We’ve worked hard to meet the rigid standards of THX™ Certified Multimedia and have included the latest Dolby® Digital and DTS® technologies in order to give you a superior digital audio experience for your PC, gaming, or home theater needs. Technology Safety *For wireless transmission to the rear channels, Logitech introduces the world’s first THX®-certified wireless rear speaker system that features independent rear channels (no wires between rear speakers or a receiver box). This proprietary digital wireless technology offers state of the art clarity and reliability with adaptive channel hopping, redundant transmission of music streams, and low latency using 48kHz sample rates. 96kHz audio streams are re-sampled to 48kHz in the rear channels only. Z-5450_manual_AMR.indd 1-210/12/2005 10:10:42 AM English  English  Initial Setup Overview: 1. Front Satellite Speakers Before attaching the cables, position the two front satellite speakers on either side of your computer monitor or television about the same distance from each other as from you. Angle them to face you. Place the two rear speakers behind you and about the same distance apart as the front speakers. Your Logitech® Z-5450 speaker satellites are wall mountable. Unscrew the satellite stand from the satellite speaker base, exposing the stability pins on the base. Rotate the speaker stand 180 degrees and reattach the stand to the base, ensuring the stability pins line up with the openings provided. Do not over tighten the screw. Mount the speakers using appropriate wall anchors through the holes in the stands. For a pro-audio look, remove the cloth grilles by pulling them straight off. Removing the grilles will not affect sound quality. 2. Center Channel Speaker Depending on your configuration, place your center channel speaker on your desk (angled up), on top of your monitor or television (angled down), or wall-mounted (angled down). Your Logitech® Z-5450 speaker satellites are wall mountable. Unscrew the satellite stand from the satellite speaker base, …

Text truncated - open the document above for the full version.

October 19, 2004 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern, We, the undersigned, hereby authorize Northwest EMC, Inc., to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Northwest EMC, Inc. within the scope of this authorization shall have the same affect as our own. This authorization shall expire 12 months from original date. Sincerely, Mitchell Phillipi Sr. Compliance Engineer

Northwest EMC TCB Compliance Opinion Rev. 9/15/03 LABT0140 Information about the Applicant Company Name Logitech, Inc. Grantee Mitchell Phillipi Address 1499 SE Tech Center Place Suite 350 City, State, Zip Vancouver, WA 98683 Job Number LABT0140 Model Z-5450 MN: S-0181A; 5.1 Surround Sound Speaker System - Control Pod FCC ID DZLA-0181ACP Agent Northwest EMC, Inc. Approval Type Original Equipment Class DSS Part 15, Spread Spectrum Transmitter Rule Part 15.247DSSS Overview The Logitech 5.1 Surround Sound Speaker System with wireless rear speakers, contains a radio module in the wireless rear speakers, FCC ID: DZLA-0181AS, and a radio module in the control pod, FCC ID: DZLA-0181ACP. Each radio transmits through its own antenna. The radio will be considered a mobile device per FCC 2.1091. The Logitech 5.1 Surround Sound Speaker system with wireless rear speakers will operate under FCC Part 15.247 and consists of a control pod, amplifier/subwoofer assembly, three passive speaker systems, and a pair of wireless rear speakers. The Surround Sound Speaker system is to be used in a home or office environment, and connected to information technology equipment for audio entertainment purposes. Logitech’s Surround Sound Speaker system with wireless rear speakers will be utilizing the frequency range of 2403MHz – 2480MHz and employing a GFSK/FHSS modulation scheme. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature 10/17/2005 Dean Ghizzone, TCB Committee Northwest EMC TCB Compliance Opinion Rev. 9/15/03 LABT0140 Findings Specification Finding 47 Cfr 2.1033(b)(3) Installation guide, operating instructions,user manual Finding The necessary information was not found. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Resolution New information added to the manual - Z-5450_manual_AMR.pdf Opinions Specification Requirements Description 47 Cfr 2.1033(b)(4) Operational description Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Operational Description.pdf Specification Requirements Description 47 Cfr 2.1033(b)(5) Frequency block diagram and Schematic diagram Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Block Diagram.pdf,Schematics.pdf Specification Requirements Description 47 cfr 2.1033(b)(6) Test Report Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140.pdf Specification Requirements Description 47 Cfr 2.1033(b)(6) Conversions showing how the test results were achieved Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140.pdf Specification Requirements Description 47 Cfr 2.1033(b)(7) Internal and external photos Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Internal Photos.pdf, External Photos.pdf Northwest EMC TCB Compliance Opinion Rev. 9/15/03 LABT0140 Specification Requirements Description Required Exhibit Test Setup Photo Exhibit Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140.pdf Specification Requirements Description 47 Cfr 1.1307(b),2.1091,2.1093 RF Exposure Hazzard Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference RF Exposure.pdf Specification Requirements Description 47 Cfr 15.19 Labeling Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Label.pdf Specification Requirements Description 47 Cfr 15.21 Information for user Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Z-5450_manual_AMR.pdf Specification Requirements Description 47 Cfr 15.33 Frequency range of tests Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140.pdf Specification Requirements Description 47 Cfr 15.35 Measurement detectors Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140.pdf Specification Requirements Description ANSI C63.4 EUT Ports All EUT ports populated,emissions maximized,Antenna height adjusted Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140.pdf Northwest EMC TCB Compliance Opinion Rev. 9/15/03 LABT0140 Specification Requirements Description 47 Cfr 15.203 Antenna Requirements Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Antenna Info.pdf Specification Requirements Description 47 Cfr 15.205 Restricted bands Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140.pdf Specification Requirements Description 47 Cfr 15.207 Power line Conducted emissions Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140.pdf Specification Requirements Description 47 Cfr 15.209 Spurious Emissions Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Report-LABT0140…

Text truncated - open the document above for the full version.

July 12, 2005 FCC Authorization and Evaluation Division 7434 Oakland Mills Road Columbia, MD 21046 Subject: Cover Letter To Whom It May Concern: Logitech is requesting an original certification for our unlicensed 5.1 Surround Sound Speaker System with wireless rear speakers. The Logitech 5.1 Surround Sound Speaker System with wireless rear speakers, contains a radio module in the wireless rear speakers, FCC ID: DZLA-0181AS, and a radio module in the control pod, FCC ID: DZLA-0181ACP. Each radio transmits through its own antenna. The radio will be considered a mobile device per FCC 2.1091. The Logitech 5.1 Surround Sound Speaker system with wireless rear speakers will operate under FCC Part 15.247 and consists of a control pod, amplifier/subwoofer assembly, three passive speaker systems, and a pair of wireless rear speakers. The Surround Sound Speaker system is to be used in a home or office environment, and connected to information technology equipment for audio entertainment purposes. Logitech’s Surround Sound Speaker system with wireless rear speakers will be utilizing the frequency range of 2403MHz – 2480MHz and employing a GFSK/FHSS modulation scheme. If further clarification is needed, please feel free to contact me at (360) 944-3708, via e-mail at [email protected] or fax (360) 896-2020. Sincerely, Mitchell A. Phillipi Sr. Compliance Engineer Logitech, Inc.

July 12, 2005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern, We hereby respectfully request that under the provision of 47 CFR 0.459, the documents listed below and attached with this application for certification be provided with confidential status. • Schematics • Theory of Operation • Frequency Block Diagrams Any exhibit / information for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents listed above contain trade secrets that are treated as confidential by us. Substantial competitive harm to us could result should they be made available to the public. Sincerely, Mitchell Phillipi Sr. Compliance Engineer

Art is shown at 60% final size Front Side Art on Face Plate Art on Side Logitech Logo Size: 8.96 mm w x 8.1 mm h Placement: 4 mm down from top edge of face plate 9 mm in from left edge Power Icon Size: 6.12 mm w x 6.375 mm h Placement: Centered on button Not printed, LED backlit All Control labels Font: Praxis-Regular Size: 7pt Position: Center on control,baseline .7 mm above control Dolby DTS THX logos Size: 36 mm w x 5.25 mm h Position: Flush left with LED screen,Center between screen and bottom of edge of faceplate 9 mm Headphone IconSize: 3.7 mm w x 3.8 mm h Placement: Centered on jack, 1.5 mm away from chamfer Music IconSize: 1.87 mm w x 3.56 mm h Placement: Centered on jack, 1.5 mm away from chamfer All Art Prints PMS 877 Metallic Silver unless otherwise specified Base Color: DS 006 Finish/Texture: MT-11000 Logitech Z6 Digital Control Pod | last updated: June 17, 2005 D 6 Ch. Direct label set Total size: 35.5 mm w x 7.86 mm h Font spec: Praxis-Regular Size: 7pt Position: Center on jacks, 1 mm above jack 6 Ch. Direct label Font spec: Praxis-Regular Size: 5pt Position: Center on switch, 1 mm to the right Stereo 1-2-3 Font spec: Praxis-Regular Size: 5pt Position: Center on switch, 1 mm to the left Digital label set Total size: 40.9 mm w x 7.33 mm h Font spec: Praxis-Regular Size: 7pt Position: Center on jacks, 1 mm above jack FCC ID: DZLA-0181ACP Body Color: DS 006 Finish/Texture: MT-11000 Back Chamfer Color: DS 006 Finish/Texture: MT-11000 Bezel Trim Color: LM 567 Finish/Texture: Clear Coat High Gloss Face Plate Color: DS 006 Finish/Texture: Back Painted Button Chamfer Color: LM 567 Finish/Texture: Clear Coat High Gloss ***All Graphics: PMS 877 Metallic*** All Buttons and Knobs Color: DS 006 Finish/Texture: High Gloss IC ID: 1807D-A0181ACP Compliance label set Font spec: Praxis-Regular Size: 7pt Position: Center on antenna, 2 mm below eyelet

Per 15.203, the antenna is internal and permanently attached. It is not intended to be serviced by the customer and is, therefore only serviceable by Logitech, Inc. authorized personnel. The antenna is a quarter wave dipole with 2dBi peak gain.

Compliance with 47 CFR 15.247(i) “Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter.” The EUT is a surround sound speaker system that operates in the 2400-2483.5MHz band as a 15.247 frequency hopping transmitter.. The EUT will only be used with a separation distance of 20 centimeters or greater between the antenna and the body of the user or nearby persons and can therefore be considered a mobile transmitter per 47 CFR 2.1091(b). The antenna is a quarter wave dipole antenna that is permanently attached to the unit. The antenna has a gain of 2.0 dBi. The maximum peak conducted output power is 53.58 mW. The maximum peak power is 84.918 mW (EIRP) for FCC ID: DZLA-0181ACP. The transmit frequency is 2403 – 2478 MHz. Since the transmit frequency is greater than 1.5 GHz, and the output power is less than 3 W ERP, the EUT is categorically excluded from routine environmental evaluation per 47 CFR 2.1091(c). The MPE estimates are as follows: Table 1 in 47 CFR 1.1310 defines the maximum permissible exposure (MPE) for the general population as 1 mW/cm 2 . The exposure level at a 20 cm distance from the EUT’s transmitting antenna is calculated using the general equation: S = (PG)/4πR 2 Where: S = power density (mW/cm 2 ) P = power input to the antenna (mW) G = numeric power gain relative to an isotropic radiator R = distance to the center of the radiation of the antenna (20 cm = limit for MPE estimates) PG = EIRP Solving for S, the maximum power density 20 cm from the transmitting antenna is summarized in the following table: The power density does not exceed 0.0.17 mW/cm 2 at 20 cm; therefore, the exposure condition is compliant with FCC rules. The applicant’s radio, FCC ID: DZLA-0181ACP, is compliant with the requirements of 15.247(i). MPE Estimate Antenna Type Antenna Part No. Antenna Part No. Transmit Frequency Band Max Peak Conducted Output Power Antenna Gain Minimum Antenna Cable Loss Power Density @ 20 cm General Population Exposure Limit from 1.1310 (MHz)(mW)(dBi)(dB) (mW/cm 2 )(mW/cm 2 ) Quarter Wave dipoleUnknown Unknown240053.58200.0171 FCC ID: DZLA-0181ACP
