DZLCUBC342.4GHz cordless USB Transceiver

www.logitech.com/support WWW Czech Republic+420 239 000 335 English: +41-(0)21 863 54 01 +36-177-74 853 Poland+48-22-854 11 51 Russia +7(095)-641 3460 South Africa Dutch: n.a.; English: n.a. Japan +81-(3)3543 21 22 Asia Pacific Headquarters Hsinchu, Taiwan +886-(2)746-6601; x2206 Australia +61-(02)9804-69 68; BBS +61(02)9972 35 61 Corp. Hq. Fremont, USA and Canada +1-510-795 81 00 Euopean., Mid. East., & African Hq. Romanels/ Morges, Switzerland English: +41-(0)21-863 5401 Fax: +41-(0)21-863 5402 Help/Dépannage English Español Français Português English Important Ergonomic Information. Long periods of repetitive motion using an improperly set-up workspace, incorrect body position, and poor work habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, weakness, swelling, burning, cramping, or stiffness in your hands, wrists, arms, shoulders, neck, or back, see a qualified health professional. For more information, please read the Comfort Guidelines located on the Logitech® web site at http://www.logitech.com/comfort, or on the Logitech ® Software. International Standards and Safety. This optical device complies with International Standard IEC 60825-1: 2001-08, Class 1 Laser Product, and also complies with 21 CFR 1040.10 and 1040.1, except for deviations pursuant to Laser Notice Nr. 50, dated July 26, 2001: 1) Emission of a parallel beam of infrared user-invisible light; 2) Maximum power of 716 microwatts CW, wavelength range 832 — 865 nanometers; 3) Operating temperature between 0°C (32°F) to 40°C (104° F). CAUTION: This optical device has no serviceable parts. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Safety and Usage Guidelines. 1) Do not point infrared beam at eye. 2) In the absence of proper operation and if customer-initiated troubleshooting is unsuccessful, switch off device and call Logitech“ technical support. 3) Do not disassemble your product or expose it to liquid, humidity, moisture, or temperatures outside the specified operating range of 0°C (32°F) to 40°C (104° F). 4) If your product is exposed to out-of-range temperatures, switch it off and allow the temperature to return to the normal operating range. End-of-life Battery Disposal Instructions. This device contains an internal, lithium-ion rechargeable battery that is non-replaceable. In general, the life expectancy of such batteries is dependent upon usage. Heavy daily use will result in shorter battery life. Casual use will extend battery life. If you suspect that the lithium-ion rechargeable battery inside your device may be drained (has a low charge), try charging it. If the battery does not recharge after several attempts, it may be non-operational. Should this be the case, you will need to dispose of your device in accordance with the laws and regulations in your area that specify the proper disposal of non-functioning electronic devices. If there are no such laws or regulations, please dispose of your device in a waste bin for spent electronic gear. CAUTION: The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not disassemble, expose to heat above 70° C (158° F), incinerate, or immerse in water or liquid of any kind. Do not use or charge the battery if it appears to be leaking, discolored, deformed, or in any way abnormal. Do not leave your battery discharged or unused for extended periods of time. When the battery is misused, it may explode or leak, causing burns and personal injury. If the battery leaks, use normal precaution and discard it immediately following the laws and regulations governing battery disposal in your area. Remember that a leaking battery can cause skin burns or other personal injury. Keep this and all batteries out of the reach of children. Power Supply Warning. The power supply for this product is for indoor use only. Use the power supply that comes with your product; do not use any other power supply. Do not use a damaged power supply or attempt to repair one that is damaged. Do not immerse the power supply in water or subject it to physical abuse. Inspect the power supply regularly for damage to its cable, plug, and body. Compliance and UL Testing. Your product is UL tested and should only be used with other UL listed devices. Your product is FCC and CE compliant. For compliance information, go to http://www.logitech.com/compliance. Warranty. Your product comes with a limited warranty. Refer to the software help system for more information. Español Información sanitaria importante: Realizar tareas repetidas durante largos periodos de tiempo, una disposición inadecuada del lugar de trabajo, una posición incorrecta del cuerpo y hábitos de trabajo deficientes pueden ocasionar cansancio y lesiones físicas en nervios, tendones y músculos. Ante cualquier síntoma de dolor, rigidez, debilidad, inflamación, quemazón, calambre o agarrotamiento de manos, muñecas, brazos, hombros, cuello o espalda, consulte a un profesional sanitario titulado. Para más información, consulte las Recomendaciones para evitar el cansancio en la página Web de Logitech ® : http://www.logitech.com/comfort, o en el CD del software Logitech ® . Normativa internacional y seguridad. Este dispositivo óptico cumple con la normativa internacional IEC 60825-1: 2001-08, Producto láser de clase 1, y con 21 CFR 1040.10 y 1040.1, excepto en lo relacionado con el aviso de láser número 50, del 26 de julio de 2001: 1) Emisión de un haz paralelo de luz infrarroja invisible para el usuario; 2) Potencia máxima de 716 microvatios en funcionamiento continuo; intervalo de longitud de onda entre 832 y 865 nanómetros; 3) Temperatura de funcionamiento entre 0º C y 40º C. PRECAUCIÓN: Este dispositivo óptico no incluye piezas que puedan repararse o sustituirse. La utilización de controles, ajustes o procedimientos no especificados en este documento pued…

Text truncated - open the document above for the full version.

Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 June 5, 2007 RE: 15.19 Statement ( FCC ID: DZLCUBC34) TO WHOM IT MAY CONCERN Due to the small size of the equipment the statement specified in Section 15.19 can not be placed in the equipment. This statement is placed in a prominent location on the CD along with software. Please contact me if there is any information you may need. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, P.A. Bharatkumar Shah Sr. Compliance Engineer Logitech Inc. 6505 Kaiser Drive, Fremont, 94555 California, USA TEL: +1-510-795 85 00 FAX: +1-510-792 89 01

Met Laboratories 914 West Patapsco Ave. Baltimore, MD 21230 June 5, 2007 RE: Permanent and Short Term Confidentiality Request To Whom It May Concern: Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Logitech Inc. requests confidentiality for the following product: FCC ID Number Product Title/Model DZLCUBC34 2.4GHz cordless USB transceiver / C-UBC34 For the product stated above, we request that the following information be held permanent confidential: 1) Circuit diagrams 2) Block Diagrams 3) Bill of materials 4) Operational Description For the product stated above, we request that the following information be held limited confidential for a period of 45 days after grant is issued: 5) External and internal photographs 6) User’s manual 7) Test set-up photos No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Logitech Inc. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our Bluetooth devices. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, P.A. Mr. Bharat Shah Senior compliance engineer Logitech Inc. 6505 Kaiser Drive, Fremont, CA 94555, USA Phone: +1 510 795 85 00 E-mail: [email protected]

© 2006 Logitech. All Rights Reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. Document Part Number: The following "FCC Compliance and Advisory Statement" apply in general to all Logitech devices, and specifically to the devices listed there: Logitech 2.4 GHz devices ( power 100mW max) : Model names FCC ID Model names FCC ID M-RAB81 DZL201662 M-RAP81 DZL201828A M-RAN100 DZL201866 M-RBB93 JNZ201943 M-RBA97 DZL201945 M-RAY105 DZL201940 M-RBK93b JNZ201998 M-RBH113 DZL201966 M-RBL117 DZL201992 M-RBT105A JNZ212125 M-RBP123 DZL202163 M-RBQ124 DZL202311 M-RBR125 JNZ222167 M-RBU126 DZL202251 M-RBP123 DZL202797 M-RCH105 DZLMRCH105 M-RCJ134 DZLMRCJ134 M-RCL124 DZLMRCL124 M-RCQ142 JNZMRCQ142 Y-RM42 DZL201658 Y-RZ42 DZL201658A Y-RN43 DZL201678 Y-RAA43 DZL201678A Y-RP20 DZL201661 Y-RAH72 DZL201974 Y-RAN77 JNZ222130 Y-RAY81 DZL202343 Y-RBF91 DZLYRBF91 Y-RBG93 DZLYRBG93 Y-RBC86 JNZYRBC86 C-BM16A DZL201657 C-UJ16A DZL201657 C-BQ16A DZL201657A C-UW34 DZL201958 C-UX34 DZL201963 C-UV35 DZL201986 C-UBC34 DZLCUBC34 5021URF JNZ5021URF Logitech 27 MHz devices ( power 1 mW max): Model names FCC ID Model names FCC ID M-RY81 JNZ211596 M-RAJ89A JNZ201779 M-RAA88 DZL211647 M-RAK89B DZL201780 M-RAA89 DZL211646 M-RAJ88A JNZ201798 M-RAA93 DZL201705 M-RAJ89C JNZ201779 M-RAF95 JNZ201740 M-RAU95 JNZ201893 M-RR95 JNZ201721 M-RAG97 DZL201758 M-RAM99 DZL201843 M-RAA93a JNZ201759 M-RAT95A JNZ201892 M-RAS88A JNZ201895 M-RAK89D DZL201780 M-RAZ105 DZL201959 M-RBG112 JNZ211953 M-RBG114 JNZ202023 M-RBF111 JNZ201962 M-RBN114 JNZ212106 M-RBW112 JNZ202484 M-RBS111 JNZ202506 M-RCF112 JNZ210000037 M-RBS136 JNZ210000117 M-RCE95 JNZ201893 M-BCK135 JNZ210000056 M-UAN141 JNZMUAN141 Y-RK56 JNZRK56587 Y-RQ53 DZL131139 Y-RK56A JNZRK56587 Y-RR53 DZL131836 Y-RQ57 JNZ201774 Y-RQ52 DZL131836 Y-RX43 DZL201824 Y-RR57 DZL131836 Y-RW42 DZL201801 Y-RR54 DZL131836M Y-RK49 JNZ201587 Y-RAJ56A JNZ201997 Y-RR71 JNZYRR71 Y-RR63 JNZ201968 Y-RAK73 DZL202065 Y-RAM74 DZL134041 file:///G|/05 Projects - Proyectos/02 On Going Pr...al/FCC_Compliance-Advisory_statement_May 2007.txt (1 de 4) [30/05/2007 17:48:40] Y-RAU7 JNZ202198 Y-RAR76 JNZ212336 Y-RAP78 JNZ212175 Y-RAS79 JNZ212336 Y-RAV80 DZL135446 Y-RAZ71 JNZYRAZ71 Y-RCP140 JNZYRCP140 Y-RBA78 JNZYRBA78 R-RD8 JNZ201987 FCC Compliance and Advisory Statement. This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the equipment and the receiver; 3) connect the equipment to an outlet on a circuit different from that to which the receiver is connected; 4) consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. © 2006 Logitech. Tous droits réservés. Logitech, le logo Logitech et les autres marques Logitech sont la propriété exclusive de Logitech et sont susceptibles d’être des marques déposées. Toutes les autres marques sont la propriété exclusive de leurs détenteurs respectifs. Logitech décline toute responsabilité en cas d'erreurs dans ce manuel. Les informations énoncées dans le présent document peuvent faire l’objet de modifications sans avis préalable. La "Déclaration FCC" suivante, s'applique à tous les produits Logitech en général et spécifiquement aux produits listés ci-dessous: Produits Logitech 2.4 GHz: ( puissance émise 100mW max): Model names FCC ID Model names FCC ID M-RAB81 DZL201662 M-RAP81 DZL201828A M-RAN100 DZL201866 M-RBB93 JNZ201943 M-RBA97 DZL201945 M-RAY105 DZL201940 M-RBK93b JNZ201998 M-RBH113 DZL201966 M-RBL117 DZL201992 M-RBT105A JNZ212125 M-RBP123 DZL202163 M-RBQ124 DZL202311 M-RBR125 JNZ222167 M-RBU126 DZL202251 M-RBP123 DZL202797 M-RCH105 DZLMRCH105 M-RCJ134 DZLMRCJ134 M-RCL124 DZLMRCL124 M-RCQ142 JNZMRCQ142 Y-RM42 DZL201658 Y-RZ42 DZL201658A Y-RN43 DZL201678 Y-RAA43 DZL201678A Y-RP20 DZL201661 Y-RAH72 DZL201974 Y-RAN77 JNZ222130 Y-RAY81 DZL202343 Y-RBF91 DZLYRBF91 Y-RBG93 DZLYRBG93 Y-RBC86 JNZYRBC86 file:///G|/05 Projects - Proyectos/02 On Going Pr...al/FCC_Compliance-Advisory_statement_May 2007.txt (2 de 4) [30/05/2007 17:48:40] C-BM16A DZL201657 C-UJ16A DZL201657 C-BQ16A DZL201657A C-UW34 DZL201958 C-UX34 DZL201963 C-UV35 DZL201986 C-UBC34 DZLCUBC34 5021URF JNZ5021URF Produits Logitech 27 MHz ( puissance émise 1 mW max): Model names FCC ID Model names FCC ID Model names FCC ID Model names FCC ID M-RY81 JNZ211596 M-RAJ89A JNZ201779 M-RAA88 …

Text truncated - open the document above for the full version.

.1 1~.JUN.a006 11:~1 . i ., HU i I:L liYliLU:: 1't~Ci:C r"..L Authorization Letter We, Logitech In. 6505 Kaser Drve Fremt, CA 94555 USA authori Cetecom S.A. Parque TecILologio de Andalucia CI Severo Ochoa 2 29590 Caans - Malaga Spain to act as our agent and to process on our behal all FCC approval activities in the UDited States of Amerca and all Industry Canada (IC) approval activities in Canada. This authorition is applcable to all Logitech and Labtec RF 4evices submitted for FCC and IC approval and shall remain in effect unti December 31, 2007, unless revoked in a Writig signed by authoried representatives of Logitech Juc. Effecve Date: J Ile 9, 2006 Deæm Ix ( :5 J f 2 000' Namte: Title: Pat Brueck Vice President WW Quaity ¿~ Sigatue "- C~~ .%¿'4 Signatue Name: Title: Cathere Valentie VP & General Counsel Company: Addess: Logitech Inc. 6505 Kaser Drve Fremont, CA 94555 USA Phone: FII't: +1 5107958500 +1 5107928901

C-UBC34_external 1.JPG (2048 x 1536 x 24) C-UBC34_external 2.JPG (2048 x 1536 x 24)

CCAD07LP0000T0 Kiwi _2.4GHz CMII ID:2007DJ0000 IC:1807B-CUBC34 FCC ID:DZL-CUBC34 07215000

C-UBC34_label location.JPG (1280 x 960 x 24)

C-UBC34_Internal 1.JPG (2048 x 1536 x 24) C-UBC34_Internal 2.JPG (2048 x 1536 x 24)

Met Laboratories 914 West Patapsco Ave. Baltimore, MD 21230 June 5, 2007 RE: RF exposure information FCC ID: DZLCUBC34 FCC ID Number Product Title / Model DZLCUBC34 2.4GHz cordless USB transceiver / C-UBC34 TO WHOM IT MAY CONCERN The product stated above complies with the FCC limits for Human exposure to RF emissions. This device is categorically excluded from routine environmental, because it operates at very low power level. The equipment is deemed to comply with the SAR or MPE limits without testing due to its very low power level (EIRP < 2.5 mW). Sincerely, P.A. Mr. Bharat Shah Senior compliance engineer Logitech Inc. 6505 Kaiser Drive, Fremont, CA 94555, USA Phone: +1 510 795 85 00 E-mail: [email protected]

Report No.: 26169RET.101 Date: 2007-05-23 Page: 2 of 8 AGY-700-001004.001 FDT08_05 INDEX 1. COMPETENCE AND GUARANTEES...........................................................................................3 2. GENERAL CONDITIONS...............................................................................................................3 3. CHARACTERISTICS OF THE TEST..............................................................................................3 3.1 TEST REQUESTED..................................................................................................................3 3.2 REQUIREMENTS AND METHOD..........................................................................................4 4. IDENTIFICATION DATA SUPPLIED BY THE APPLICANT......................................................5 4.1 APPLICANT..............................................................................................................................5 4.2 REPRESENTATIVE..................................................................................................................5 4.3 TEST SAMPLES SUPPLIER....................................................................................................5 4.4 IDENTIFICATION OF ITEM/ITEMS TESTED.......................................................................5 5. USAGE OF SAMPLES, PERIOD OF TESTING AND ENVIRONMENTAL CONDITIONS.......6 5.1 USAGE OF SAMPLES..............................................................................................................6 5.2 PERIOD OF TESTING..............................................................................................................6 5.3 ENVIROMENTAL CONDITIONS...........................................................................................7 6. TEST RESULTS...............................................................................................................................8 7. REMARKS AND COMMENTS.......................................................................................................8 8. SUMMARY.......................................................................................................................................8 ANNEXES ANNEX A. TEST RESULTS ANNEX B. MEASURING RESULTS FOR ELECTROMAGNETIC EMISSION ANNEX C. PHOTOGRAPHS Report No.: 26169RET.101 Date: 2007-05-23 Page: 3 of 8 AGY-700-001004.001 FDT08_05 1. COMPETENCE AND GUARANTEES Centro de Tecnología de las Comunicaciones (AT4 WIRELESS), S.A. is a laboratory with a measurement facility in compliance with the requirements of Section 2.948 of the FCC rules and has been added to the list of facilities whose measurements data will be accepted in conjuction with applications for Certification under Parts 15 or 18 of the Commission's Rules. Registration Number: 905266. Centro de Tecnología de las Comunicaciones (AT4 WIRELESS), S.A. is a laboratory with a measurement site in compliance with the requirements of RSS 212, Issue 1 (Provisional) and has been added to the list of filed sites of the Canadian Certification and Engineering Bureau. Reference File Number: IC 4621. In order to assure the traceability to other national and international laboratories, AT4 WIRELESS has a calibration and maintenance programme for its measuring equipment. AT4 WIRELESS guarantees the reliability of the data presented in this report, which is the result of measurements and tests performed to the item under test on the date and under the conditions stated on the report and is based on the knowledge and technical facilities available at AT4 WIRELESS at the time of execution of the test. AT4 WIRELESS is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the item under test and the results of the test. 2. GENERAL CONDITIONS 1. This report only refers to the item that has undergone the test. 2. This report does not constitute or imply by its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without written approval of AT4 WIRELESS. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of AT4 WIRELESS and the Accreditation Bodies. 3. CHARACTERISTICS OF THE TEST 3.1 TEST REQUESTED 1. Measurements for short range radio equipment operating in the 2400 MHz -2483.5 MHz band, according to FCC Part 15.249. 2. Continuous conducted emission, power leads: Standard: FCC Rules and Regulations 47 CFR Part 15 Limit: Class B Method: FCC Rules and Regulations 47 CFR Part 15, Subpart C Report No.: 26169RET.101 Date: 2007-05-23 Page: 4 of 8 AGY-700-001004.001 FDT08_05 3.2 REQUIREMENTS AND METHOD 1. FCC parts 15.33, 15.35, 15.249, 15.207, 15.205, 15.209, 15.109. The testing was performed according to the procedure in ANSI C63.4: 2003. Radiated testing was performed in AT4 WIRELESS's semi-anechoic chamber. This site has been fully described in a report submitted to the FCC and was accepted in a letter dated July 25, 2002. 2. FCC Rules and Regulations 47 CFR Part 15, Subpart C: Limits and methods of measurements for radio frequency devices. Intentional radiators. The instrumentation used to perform the testing is listed below: 1. Semianechoic Absorber Lined Chamber IR 11. BS. 2. Control Chamber IR 12.BC. 3. Antenna mast EM 1072 NMT. 4. Rotating table EM 1084-4. ON. 5. Multi device controller ETS 2090. 6. Bilog antenna CHASE CBL6111. 7. Antenna tripod EMCO 11968C. 8. Double-ridge Guide Horn antenna 1-18 GHz HP 11966E. 9. Double-ridge Guide Horn antenna 18-40 GHz Agilent 119665J. 10. RF pre-amplifier Miteq JS4-12002600-30-5A. 11. Semianechoic Absorber Lined Chamber IR 11. BS. 12. RF pre-amplifier Miteq AFS5-04001300-15-10P-6. 13. Spectrum analyzer R&S ESIB 26. 14. Spectrum analyzer Agilent E4440A. 15. RF pre-amplifier Schaffner CPA 9231. 16. DC power supply R&S NGPE 40/40. 17.…

Text truncated - open the document above for the full version.

C-UBC34: Specifications Radio transmission: Bi-directional, from mouse to transceiver and vice versa. Number of channels: 24 channels but only one at one and the same time Carrier frequencies: Index RF channel Index RF channel Index RF channel Index RF channel 1 2405 MHz 7 2423 MHz 13 2441 MHz 19 2459 MHz 2 2408 MHz 8 2426 MHz 14 2444 MHz 20 2462 MHz 3 2411 MHz 9 2429 MHz 15 2447 MHz 21 2465 MHz 4 2414 MHz 10 2432 MHz 16 2450 MHz 22 2468 MHz 5 2417 MHz 11 2435 MHz 17 2453 MHz 23 2471 MHz 6 2420 MHz 12 2438 MHz 18 2456 MHz 24 2474 MHz Modulation: GFSK Data Rate: 2 Mbits/s Transmission range: 50 m typical, free space Power Consumption: 150 mW typical Maximum radiated power: 0.000676 W Antenna: PCB printed antenna quarter-wave Antenna gain: -2.8 dBi
