ENPESTEEM210CData radio modem

ESTeem MODEL 210 SERIES USER’S MANUAL Models 210C – 210M Manual Revision 1.0 November 2012 Electronic Systems Technology, Inc. 3-'F Author: Date: ame: Eric P. Marske Title: Product Support Manager Approved by: Q /..'{- Date: ,=/r/rz - z:z//1 Name: Tom L. Kirchner Title: President Electronic Systems Technology, I nc. Building Bl 415 N. Quay Street Kennewick, WA 99336 Phone: 509-783-9092 Fax: 509-783-5472 E-mail: [email protected] Web Site: www.esteem.com Copyright@ 2012by Electronic Systems Technology, Inc. All rights reserved. Printed in the United States of America. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Electronic Systems Technology. PRODUCT WARRANTY ELECTRONIC SYSTEMS TECHNOLOGY, INC. Specifications subject to change without notice 415 North Quay Street • Kennewick, WA 99336 www.esteem.com Phone (509) 735-9092 • Fax (509) 783-5475 Revised: 5 Dec 2012 Electronic Systems Technology, Inc., (hereinafter EST) expressly warrants its products as free of manufacturing defects for a period of one year from the date of sale to first user/customer. T HERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED AND THERE IS EXPRESSLY EXCLUDED ALL WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. NO OTHER WARRANTY GIVEN BY ANY EMPLOYEE, AGENT, DISTRIBUTOR OR OTHER PERSON WITH RESPECT TO THE PRODUCT SHALL BE BINDING ON EST. LIMITATION OF LIABILITY: EST's liability shall be limited to refunding of purchase price, repair or replacement of product. IN NO EVENT SHALL EST HAVE LIABILITY FOR CONSEQUENTIAL, INCIDENTAL, SPECIAL OR EXEMPLARY DAMAGES CAUSED DIRECTLY OR INDIRECTLY BY THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY INTERRUPTION OF SERVICES, LOSS OF BUSINESS OR ANTICIPATORY PROFITS. IN NO EVENT SHALL EST BE LIABLE FOR ANY DAMAGES WHATSOEVER IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT. In the event that a unit or part requires replacement or factory servicing, the follow ing conditions apply: a) Customer must obtain from EST an authorized RMA (Return Materials Authorization) Number before shipment of product or parts to EST for any reason; b) If the whole unit is shipped, it must be in its original carton and shipping components, or a carton and shipping components supplied by EST , or it parts only are shipped, they must be packaged and cushioned so as to prevent damage in transit and shipped freight prepaid; PRODUCT WILL BE CONSIDERED OUT OF WARRANTY IF: a) If the product is damaged due to improper or abnormal use, abuse, mishandling, accident or improper maintenance or failure to follow operating instruction; b) If the product is defective as a result of sand, dirt, or wa ter damage; c) If any factory-sealed enclosure has been opened or show s evidence of an attempt to be opened; d) If defects or damage are caused by the use of unauthorized parts or unauthorized service; e) If the product has had its serial numbers altered or removed. Warranty repair form must be accompanied by proof of user' s purchase of unit. Product must be shipped to the manufacturer at the following address: Electronic Systems Technology 415 North Quay Street Kennewick, Washington USA 99336 ADDITIONAL SERVICE: If EST releases an improvement update to firmware internal to the EST eem unit during the 90 day period after the unit was purchased by the first user/customer, EST will update the applicable unit with the revised version at no charge other than for UPS handling and shipping to and from your location to the EST factory. Return of any such item must be accompanied with proof of purchase. TABLE OF CONTENTS Revised: 5 Dec 12 Page 1 EST P/N AA107-210CM CHAPTER 1 – Introduction Before You Begin 1-1 Model 210 Overview 1-1 Model 210 Configuration Modes 1-1 Access Point M odes ---------------------------------------------1-2 Access Point Repeater ---------------------------------------------1-3 Self-Healing Mesh Network ---------------------------------------------1-3 Station Modes ---------------------------------------------1-4 RS-232 Serial Applicat ions ---------------------------------------------1-5 CHAPTER 2 – Starting Out Three Configuration Phases 2-1 Model 210 Hardware Description 2-1 Front Panel Layout ---------------------------------------------2-2 Antenna Connection Overview ---------------------------------------------2-2 CHAPTER 3 – Example Applications Modes of Operation Description and Examples 3-1 Ethernet Bridge Mode ---------------------------------------------3-1 Router Modes ---------------------------------------------3-3 Mobile Client Modes ---------------------------------------------3-4 Programming Examples 3-7 Using ESTeem Network Configuration (ENC) Utility ---------------------------------------------3-7 Example 1 – Point to Point Ethernet Bridge ---------------------------------------------3-9 Example 2 – Point to Point Ethernet Bridge with Repeater ---------------------------------------------3-10 Example 3 – Point to Multipoint with Mesh Repeater ---------------------------------------------3-11 Example 4 – Point to Multipoint Router Mode ---------------------------------------------3-13 Example 5 – Mobile Client Mode ---------------------------------------------3-15 Example 6 – Access Point Mode ---------------------------------------------3-16 Router Addressing Examples ---------------------------------------------3-17 CHAPTER 4 – Utilities and Features ESTeem Network Configuration (ENC) Utility --------------------------------------------- 4-1 Using ESTeem Discovery Program --------------------------------------------- 4-2 Using EtherStation Status Program --------------------------------------------- 4-5 Setting Local Time 210 --------------------------------------------- 4-6 Configuring Time Serv er --------------------------------------------- 4-7 Simple Network Management Protocol (SNMP) ------…

Text truncated - open the document above for the full version.

6 Nov. 2012 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent FCC On our behalf, I appoint Michelle Furrow, Nemko USA, Inc. at 802 N Kealy Avenue, Lewisville TX 75057 to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides (company name and address). Dated this6 Day of November 20 12 Agency agreement expiration date:1 Nov. 2013 By:Todd Elliott Signature Printed Title: Sr. Engineer On behalf of :Electronic Systems Technology Telephone:509-735-9092 ELECTRONIC SYSTEMS TECHNOLOGY, INC. 415 North Quay St. • Kennewick, WA 99336 Phone (509) 735-9092 • Fax (509) 783-5475 1 of 1

6 November 2012 Nemko Canada Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 FCC ID: ENPESTEEM210C Product Name: 210c Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics file: 210c_schematic.pdf Block diagram file: 210c Block Diagram v5.pdf Bill of Materials file: 210c_bill_of_materials.pdf Theory of Operation file: 210c_theory_of_operation.pdf These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this5th Day ofNovember 20 12 By:Todd Elliott Signature Printed Title:Sr. Engineer On behalf of :Electronic Systems Technology Telephone:509-735-9092 ELECTRONIC SYSTEMS TECHNOLOGY, INC. 415 North Quay St. • Kennewick, WA 99336 Phone (509) 735-9092 • Fax (509) 783-5475 1 of 1

August 27th, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: 210C Frequency Bands of Operation per FCC Guidance 634817 To Whom I t May Concern, The 210c is programmed by the manufacturer to operate only on frequency channel assignments in the private land mobile services as specified in CFR 47, Part 90 and in CFR 47, Part 2.927(b), in the frequency band 450 - 470 MHz. The user can only select pre-programmed channels. The frequencies available are 450 - 454 MHz, 456 - 462.5375 MHz, 462.7375 - 467.5375 MHz, and 467.7375 MHz - 470 MHz. Sincerely, Engineer ELECTRONIC SYSTEMS TECHNOLOGY, INC. 415 North Quay St. • Kennewick, WA 99336 Phone (509) 735-9092 • Fax (509) 783-5475 1 of 1

6 Nov. 2012 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Attestation Statement This is to attest that the ESTEEM radio identified as Model 210C provides a 6.25 kHz data channel with a minimum data rate of 9 kbps and maximum data rate of 27 kbps. When operating in a 12.5 kHz channel bandwidth, the 210C transmitter provides a minimum data rate of 18 kbps (9kbps per 6.25 kHz channel) and a maximum data rate of 54 kbps (27 kbps per 6.25 kHz channel). The 210C is a data-only radio. Spectral efficiency is achieved by using QAM modulation (4QAM up to 64QAM). We therefore attest that the radio model 210C meets the spectrum efficiency requirements of 90.203(j)(5). Dated this6 Day of November 20 12 Agency agreement expiration date:1 Nov. 2013 By:Todd Elliott Signature Printed Title: Sr. Engineer On behalf of :Electronic Systems Technology Telephone:509-735-9092 ELECTRONIC SYSTEMS TECHNOLOGY, INC. 415 North Quay St. • Kennewick, WA 99336 Phone (509) 735-9092 • Fax (509) 783-5475 1 of 1

210c FCC ID Number Label Location ELECTRONIC SYSTEMS TECHNOLOGY, INC. 415 North Quay St. • Kennewick, WA 99336 Phone (509) 735-9092 • Fax (509) 783-5475 1 of 1

August 27th, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Tune-up Procedure To Whom It May Concern, The 210c is tuned during factory production and requires no additional tuning by the installer or end user. Sincerely, Engineer ELECTRONIC SYSTEMS TECHNOLOGY, INC. 415 North Quay St. • Kennewick, WA 99336 Phone (509) 735-9092 • Fax (509) 783-5475 1 of 1

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:40.7(dBm)* Maximum peak output power at antenna input terminal:11749.0(mW) Antenna gain(maximum):4.15(dBi)* Maximum antenna gain:2.60(numeric) Time Averaging:100(%)* Prediction distance:100(cm)* Prediction frequency:450(MHz)* MPE limit for uncontrolled exposure at prediction frequency:0.300(mW/cm^2) Power density at prediction frequency:0.243 (mW/cm^2) This equates to:2.43 W/m^2 2 4R PG S   Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:40.7(dBm)* Maximum peak output power at antenna input terminal:11749.0(mW) Antenna gain(maximum):6.65(dBi)* Maximum antenna gain:4.62(numeric) Time Averaging:100(%)* Prediction distance:125(cm)* Prediction frequency:450(MHz)* MPE limit for uncontrolled exposure at prediction frequency:0.300(mW/cm^2) Power density at prediction frequency:0.277 (mW/cm^2) This equates to:2.77 W/m^2 2 4R PG S   Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:40.7(dBm)* Maximum peak output power at antenna input terminal:11749.0(mW) Antenna gain(maximum):12.15(dBi)* Maximum antenna gain:16.41(numeric) Time Averaging:100(%)* Prediction distance:250(cm)* Prediction frequency:450(MHz)* MPE limit for uncontrolled exposure at prediction frequency:0.300(mW/cm^2) Power density at prediction frequency:0.245 (mW/cm^2) This equates to:2.45 W/m^2 2 4R PG S  

Nemko Test Report: 10230352RUS1 Applicant: Electronic Systems Technology, Inc 415 N. Quay StreetBuilding B-1 Kennewick WA 99336 Equipment Under Test: 210c (E.U.T.) Industrial RF Modem FCC ID: ENPESTEEM210C In Accordance With: FCC Part 90, Subpart I Private Land Mobile Transmitter Tested By: Nemko USA Inc. 802 N. Kealy Lewisville, TX 75057-3136 Tested By: Brian Boyea Authorized By: David Light Date: 4-Oct-2012 Total Number of Pages: 49 Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: Industrial RF Modem PROJECT NO.: 10230352RUS1 Page 2 of 49 Table of Contents Section 1.0 Summary of Test Results ....................................................................................... 3 Section 2.0 General Equipment Specification .......................................................................... 5 Section 3.0 RF Power Output ................................................................................................... 8 Section 4.0 Modulation Characteristics .................................................................................... 9 Section 4.1 Modulation Limiting ............................................................................................ 10 Section 5.0 Occupied Bandwidth ............................................................................................ 11 Section 6.0 Spurious Emissions at Antenna Terminals .......................................................... 22 Section 7.0 Field Strength of Spurious Emissions .................................................................. 29 Section 8.0 Frequency Stability .............................................................................................. 32 Section 9.0 Transient Frequency Behavior ............................................................................. 34 Section 10.0 Test Equipment List ............................................................................................. 39 ANNEX A - TEST METHODOLOGIES..................................................................................... 40 ANNEX B - TEST DIAGRAMS .................................................................................................. 46 Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: Industrial RF Modem PROJECT NO.: 10230352RUS1 Page 3 of 49 Section 1.0 Summary of Test Results Manufacturer: Electronic Systems Technology Model No.: 210c Serial No.: 14013 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 90, Subpart I. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: Industrial RF Modem PROJECT NO.: 10230352RUS1 Page 4 of 49 Summary Of Test Data NAME OF TEST PARA. NO. RESULT RF Power Output 90.205 Complies Audio Frequency Response TIA EIA-603.3.2.6 N/A 1 Audio Low-Pass Filter Response TIA EIA-603.3.2.6 N/A 1 Modulation Limiting TIA EIA-603.3.2.6 Complies Occupied Bandwidth 90.210 Complies Spurious Emissions at Antenna Terminals 90.210 Complies Field Strength of Spurious Emissions 90.210 Complies Frequency Stability 90.213 Complies Transient Frequency Behavior 90.214 Complies Footnotes: 1. The radio is data only. There are no voice or audio circuits. . Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: Industrial RF Modem PROJECT NO.: 10230352RUS1 Page 5 of 49 Section 2.0 General Equipment Specification Transmitter Supply Voltage Input: 12Vdc Frequency Range: 450 – 470 MHz Tunable Bands: 450 – 470 MHz Necessary Bandwidth: 11.25 kHz (12.5 kHz channel spacing), 6 kHz (6.25 kHz channel spacing) Type(s) of Modulation: F3E (Voice) F1D F2D D7W Other Data Rate(s) 6.25 kHz Ch. Data Rate(s) 6.25 kHz Ch. 9 kbps (4 QAM), 18 kbps (16 QAM), 27 kbps (64 QAM) 18 kbps (4 QAM), 36 kbps (16 QAM), 54 kbps (64 QAM) Internal/External Data Source: Internal data modulation circuits Emission Designator: 6K00D7W, 11K3D7W Output Impedance: 50 ohms RF Power Output (rated): 2 watts avg./10 watts pk. Channel Spacing(s): 6.25kHz and 12.5kHz Operator Selection of Operating Frequency: Software Controlled Power Output Adjustment Capability: Software Controlled Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: Industrial RF Modem PROJECT NO.: 10230352RUS1 Page 6 of 49 Receiver Frequency Range: 450 – 470 MHz Tunable Bands: 450 – 470 MHz Local Oscillator: First RX LO: 495-515 MHz, Second RX LO: 180 MHz Operator Selection of Operating Frequency: Software Controlled Modifications Made During Testing There were no modifications done during testing. Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: Industrial RF Modem PROJECT NO.: 10230352RUS1 Page 7 of 49 System Description The ESTeem Model 210C with one Ethernet port (10/100/1G) and one independent Serial RS- 232C data port is the perfect radio solution designed for the rigors of the Industrial, Public Safety, and Federal markets when the low UHF band is needed for terrain coverage. System Diagram Nemko USA FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: Industrial RF Modem PROJECT NO.: 10230352RUS1 Page 8 of 49…
