F5300433904Wireless Motion Detector

Each WLS904L motion detector should be located so that it providesoptimal coverage of the intended area. Refer to Changing Motion DetectorLenses below for information on the four lenses available for the WLS904LMotion Detector. When locating motion detectors, observe the following:• For the Wall-to-Wall, Corridor and Curtain Lenses, the Mounting Height should be 6-10 ft./ 2-3 m from the floor. The nominal mounting height is7.5 ft./ 2.3 m. • For the Pet Alley Lens only, the Mounting Height should be 4-5 ft./1.2-1.5m from the floor. • Do not aim the detector at reflective surfaces such as mirrors or windows. This may distort the coverage pattern or reflect sunlightdirectly onto the detector. Avoid locations where the detector may beexposed to direct or reflected sunlight. • Avoid locations that are subject to direct air flow, such as near an air duct outlet.• Do not locate the detector near sources of steam or oil vapor, such as a stove or fryer. • Do not obscure the Detector’s coverage pattern with large objects within the detection area. If you can’t see the detector, it can’t see you. • For indoor use only• Dead zone 6”/15 cmNOTE: No detector should be mounted without first performing a module placement test to determine that it is in range of the wireless receiver. See the Placement Test instructions in the Instruction Sheet for your receiver, or in the installation manual for your system. When a location has been determined,remove the plastic from the mountingholes and locate the backplate on thewall and mark screw locations. It issuggested that wall anchors be used forall screw locations. Secure the backplateto the wall, and then secure the enrolledDetector to its backplate. ©2000 Digital Security Controls Ltd. Printed in Canada 29005255 R001 INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Battery Installation • Use fresh batteries. Most batteries have a “best before” date printed on theirpackaging or on the batteries themselves.Buy batteries that have a “best before”date of two years or more from yourpurchase date • When disposing of used batteries, follow the instructions and precautions printedon the batteries. Many cities andcommunities have collection sites or services for used household batteries.Contact your municipal offices for information on the disposal of usedbatteries • Do not mix old and new batteries• Remove the detector from its mounting plate• Remove the battery cover by pushing down then up on the cover• Ensure batteries are the proper orientation• Replace the battery cover Use only Energizer Lithium EL123AP batteries. L IMITED W ARRANTY Digital Security Controls Ltd. warrants that for a period of twelve months from the date of purchase, the product shall be freeof defects in material and workmanship under normal use and that in fulfilment of any breach of such warranty, Digital SecurityControls Ltd. shall, at its option, repair or replace the defective equipment upon return of the equipment to its repair depot.This warranty applies only to defects in parts and workmanship and not to damage incurred in shipping or handling, or damagedue to causes beyond control of Digital Security Controls Ltd. such as lightning, excessive voltage, mechanical shock, waterdamage, or damage arising out of abuse, alteration or improper application of the equipment.The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties, whe ther express or implied and of all other obligations or liabilities on the part of Digital Security Controls Ltd. This warranty cont ains the entire warranty. Digital Security Controls Ltd. neither assumes, nor authorizes any other person purporting to act on itsbehalf to modify or to change this warranty, nor to assume for it any other warranty or liability concerning this product.In no event shall Digital Security Controls Ltd. be liable for any direct , indirect or consequential damages, loss of anticipa ted profits, loss of time or any other losses incurred by the buyer in connection with the purchase, installation or operation or f ailure of this product. Warning: Digital Security Controls Ltd. recommends that the entire system be completely tested on a regular basis. However, despite frequent testing, and due to but not limited to, criminal tampering or electrical disruption, it is possible for this p roduct to fail to perform as expected.FCC COMPLIANCE STATEMENTCAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment.This equipment generates and uses radio frequency energy and if not installed and used properly, in strict accordance with themanufacturer’s instructions, may cause interference to radio and television reception. It has been type tested and found to com ply with the limits for Class B device in accordance with the specifications in Subpart “B” of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in any residential installation. However, there is no guarantee that interferen ce will not occur in a particular installation. If this equipment does cause interference to television or radio reception, which can be de termined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following mea sures: • Re-orient the receiving antenna • Relocate the alarm control with respect to the receiver • Move the alarm control away from the receiver • Connect the alarm control into a different outlet so that alarm control and receiver are on different circuits. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the FCC helpful: “How to Identify and Resolve Radio/Television Interference Problems”. T his boo…

Text truncated - open the document above for the full version.

August 23, 2000 Office of Engineering & Technology Federal Communications Commission Washington, D.C. 20554 Subject:Request for continuous confidentiality of technical information per sections 0.459 and 0.457 (d) (2) ( I) of CFR 47. FCC ID:F5300433904 Dear Sir or Madam: Digital Security Controls Canada Ltd. is hereby filing this request for continuous confidentiality of the specified items submitted with the application for certification ( Form731 ) with proposed identifier F5300433904. The technical documentation for which continuous confidentiality is sought is: (1) Schematic diagrams: This technical documentation is a part of the material supporting the Form 731 application for certification, which this request for confidentiality accompanies. The schematic diagrams disclose proprietary information and technical data which Digital Security Controls Ltd. would guard from its competitors and would not make available to the public. This proprietary information constitutes a trade secret and is not a part of the product documentation that would be made available to the customers of Digital Security Controls Ltd. It would be potentially injurious to Digital Security Controls Ltd. and to its investment in the development of this innovative proprietary product to make available for public disclosure the trade secret technical information specified in this request. If there are any questions about this request for continuous confidentiality regarding trade secrets and proprietary information embodied in the technical documentation filed in support of this Form 731 application, then please contact me via our toll-free telephone number. Yours truly, Kevin Harris Approval Services Manager 905-760-3000 Ext. 2378 Email: [email protected]

Digital Security Controls Ltd.ISO9001 Registered3301 Langstaff Road, ConcordOntario, Canada L4K 4L2Phone: 905-760-3000Toll Free: 1-888-888-7838Fax: 905-760-3030 ® FCC/IC Labeling for Transmitter PWLS904L-433 PIR TOP OF THE UNIT SHOWING PLACEMENT OF LABEL (ACTUAL SIZE) (THE UNIT SHOWN ATTACHED TO MOUNTING BRACKET) File: [PWLS904l-433_fcc+ices-003_lb_1800XXXX.cdr] June 8, 2000 FCC ID: F5300433904 Model: PWLS904L-433 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-ditions: (1) This device may not cause harmful interference, and (2) this device must accept anyinterference received, including interference that may cause undesired operation.IC: RSS/CNR210 CANADA: XXX XXX XXXX MADE IN CANADA 1800XXXX R001 This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numériquede la classe B respecte toutes les exigences du ICES-003. DASHED LINE INDICATESCUT EDGE OF LABELLABEL TO BE PRINTEDON SELF-ADHESIVE MATERIALLABEL SHOWN 250% ACTUAL SIZE 44.5 mm 9.5 mm

Digital Security Controls Ltd.ISO9001 Registered3301 Langstaff Road, ConcordOntario, Canada L4K 4L2Phone: 905-760-3000Toll Free: 1-888-888-7838Fax: 905-760-3030 ® FCC/IC Labeling for Transmitter WLS904L-433 PIR TOP OF THE UNIT SHOWING PLACEMENT OF LABEL (ACTUAL SIZE) (THE UNIT SHOWN ATTACHED TO MOUNTING BRACKET) File: [wls904l-433_fcc+ices-003_lb_1800XXXX.cdr] June 5, 2000 FCC ID: F5300433904 Model: WLS904L-433 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-ditions: (1) This device may not cause harmful interference, and (2) this device must accept anyinterference received, including interference that may cause undesired operation.IC: RSS/CNR210 CANADA: XXX XXX XXXX MADE IN CANADA 1800XXXX R001 This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numériquede la classe B respecte toutes les exigences du ICES-003. DASHED LINE INDICATESCUT EDGE OF LABELLABEL TO BE PRINTEDON SELF-ADHESIVE MATERIALLABEL SHOWN 250% ACTUAL SIZE 44.5 mm 9.5 mm

CIRCUIT DESCRIPTION Device: Low Cost Narrow Band Standard PIR Model: WLS904NB (UA201) ESI Identifier: Description: The low cost narrowband standard PIR (LCNB STD PIR) sends the sensor status appropriately to the control unit of the wireless security system. An Infared sensor is incorporated to sense a sudden change in temperature over the range covered by the fitted lens. This unit consists of Three main circuit sections. A control section with a microprocessor, a digital controls sensor section and the RF transmitter. The control section receives status information from the sensor inputs triggered by detecting a change in temperature apart from its normal operating temperature. It is then coded to produce ASK modulation signal. This section also controls transmitter activity. The transmitter consist of an integrated chip fully implemented with a phase locked loop (PLL), divide-by-64 prescaler, a phase detector, a voltage controlled oscillator, and an automatic lock detect that disables the transmitter output when the PLL is out of lock. The external reference crystal frequency provide a complete phase-locked detector which when divide-by-64 produce the output signal frequency of 433.92MHz compensated with a matching network to antenna.

KK M M M X X 6 01 I.L UA201 18NOV99 will cause irrepairable harm, which will be actionable by sitive and confidential nature. It is being divulged to A DATEAPPROVED BYINITIATORREVISION APPROVALS us against you. you on the understanding that any improper disclosure Controls Ltd. and contains information of a highly sen- This document is the private property of Digital Security CONFIDENTIAL DOCUMENT 00000-00- 1:1 Sheet/layer DWG# Scale DateDrawn by Originator FinishProject # File RevTitle ONTARIO, CANADA M3J 2J6 1645 FLINT RD, DOWNSVIEW DIGITAL SECURITY CONTROLS LTD. PALLET SIZE = 33.536 SQ.IN. PCB SIZE = 6.362 SQ.IN. ALL CIRCUIT BOARDS MUST MEET IPC CLASS 2 AND DSC INCOMING Max 0.030" Min 0.025" PCB Score line 0.018" U T PLATED THRU 0.090" P R -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 N 0.100" 0.100" O 0.073" M L K MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE J 1 of UV CURED SOLDER MASK IS NOT ACCEPTABLE. PRINTED CIRCUIT BOARD REQUIREMENTS QST 001. DRILL PATTERN MATERIAL: FR4 0.059" 1oz COPPER CENTER UNLESS OTHERWISE SPECIFIED (NOT PLATED) C B A 0.080"X 0.400 0.080"X 0.250 0.080"X 0.200 NOTE 2: NOT ON DRILL TAPE, ROUTE WITH 0.080"BIT CENTER TO 0.080" -0.005 +0.005 -0.005 +0.005 -0.005 +0.005 -0.005 +0.005 SEE NOTE #2SLOT SLOT SLOT SLOT NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU -0.000 +0.003 -0.000 +0.003 -0.000 +0.003 -0.000 +0.003 TOOLING HOLE TOOLING HOLE TOOLING HOLE 0.187" 0.156" 0.125" 0.125" 0.118" 0.080" 0.080" 0.066" 0.066" 0.060" 0.060" 0.047" 0.047" 0.043" 0.038" 0.032" PLATED THRU PLATED THRU VIA VIA 0.022" PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU VIA0.028" REMARKTOLERANCETYPESIZESYMBOL DRILL CODE INFORMATION 0.200" 0.137" MOUNTING HOLE S C O P Y LED1 U6 J1 D5 C8 C224 C203 C202 C212 C208 C206 C211 C207 C205 C217 C216 C215 C219C218 C227 C228 C229 C226 C225 C223 C210 C209 U4 C59 C56 C57 C58 C60 C61 C62 R207 R208 R209 R204 XTL1 U5 C5 ANT2 ANT3 ANT1 VB- VB+ L201 L200 L203 L202 L204 C246 C247 Rev 01 UA201 SLOW FAST MADE IN CANADA DSC C O P Y TP89 TP79 TP78 TP77 TP56 TP55 TP51 TP50 TP49 TP47 TP46 TP45 TP44 TP43 TP37 TP36 TP35 TP34 TP33 TP32 TP31 TP30 TP29 TP28 TP27 TP26 TP25 TP24 TP23 TP22 TP21 TP20 TP19 TP18 TP17 TP16 TP15 TP14 TP13 TP12 TP11 TP10 TP9 TP8 TP7 TP6 TP5 TP4 TP3 TP2 TP1 TP97 TP96 TP93 D2 D3 D4 U2 THM1 C204 C1 C23 C24 C200 C12 C13 C14 C15 C16 C17 C18 C19 C20 C21 C22 C25 C10 C201 C213 C220 C11 C9 C6 C4 C3 C2 C53 C230 C231 Q4 Q1 R44 TH1 R13 R203 TH2 R200 R201 R202 TH3 R206 R211 R210 TP39 R23 R24 R25R26 R27 R28 R29 R30 R31 R32 R33 R34 R35 R36 R37 R38 R39 R40 R41 R42 R20 R43 TP40 R19 TP62 R49 R22 R16 R8 R7 R21 R10R11 R9 R1 R6 R5 R3 R14 R2 R12R4 TP63 TP100 NC C NO TP99 Q3 Q5 C7 THM2 U3 TP54 Q2 R17 TP60 TP58 TP59 R15 U1 TP41 TP57 TP38 TP52 TP42 TP61 TP101 TP102 TP103 TP104 TP105 TP106 TP107 TP108 TP109 TP110 TP111 TP112 TP113 TP114 UA201 Rev01 C O P Y 6 01 I.L UA201 18NOV99 will cause irrepairable harm, which will be actionable by sitive and confidential nature. It is being divulged to A DATEAPPROVED BYINITIATORREVISION APPROVALS us against you. you on the understanding that any improper disclosure Controls Ltd. and contains information of a highly sen- This document is the private property of Digital Security CONFIDENTIAL DOCUMENT 00000-00- 1:1 Sheet/layer DWG# Scale DateDrawn by Originator FinishProject # File RevTitle ONTARIO, CANADA M3J 2J6 1645 FLINT RD, DOWNSVIEW DIGITAL SECURITY CONTROLS LTD. 3 of COMP SIDE C O P Y 6 01 I.L 18NOV99 UA201 will cause irrepairable harm, which will be actionable by sitive and confidential nature. It is being divulged to A DATEAPPROVED BYINITIATORREVISION APPROVALS us against you you on the understanding that any improper disclosure Controls Ltd. and contains information of a highly sen- This document is the private property of Digital Security CONFIDENTIAL DOCUMENT 00000-00-DWG# 1:1 Originator Sheet/layer Scale FinishProject # DateDrawn byFile Title Rev ONTARIO, CANADA M3J 2J6 1645 FLINT RD, DOWNSVIEW DIGITAL SECURITY CONTROLS LTD. 5 of SOLDER SIDE C O P Y

Master: ktlPT15231 Date: April 5, 2000 KTL Test Report:0R02418 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Vaughn, Ontario L4K 4L2 Equipment Under Test:WLS 904-433 (E.U.T.) FCC ID:F5300433904 In Accordance With:FCC Part 15, Subpart C For Low Power Transmitters Operating Periodically In The Band 40.66 - 40.77 MHz And Above 70 MHz Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: R. Grant, Wireless Group Manager Date: Total Number of Pages:24 KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02418 EQUIPMENT: WLS 904-433 FCC ID: F5300433904 Page 2 of 22 Table of Contents Section 1. Summary of Test Results.......................................................................................... 3 Section 2. Equipment Under Test (E.U.T.) .............................................................................. 5 Section 3. Transmission Requirements .................................................................................. 12 Section 4. Radiated Emissions................................................................................................. 15 Section 5. Occupied Bandwidth.............................................................................................. 18 Section 6. Block Diagrams.......................................................................................................20 Section 7. Test Equipment List ................................................................................................ 22 Annex A Restricted Bands.................................................................................................... A1 KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02418 EQUIPMENT: WLS 904-433 FCC ID: F5300433904 Page 3 of 22 Section 1.Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.231. All tests were conducted using measurement procedure ANSI C63.4-1992. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit DS C Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Glen Westwell. Technologist KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02418 EQUIPMENT: WLS 904-433 FCC ID: F5300433904 Page 4 of 22 Summary Of Test Data Name of TestPara. NumberResults Transmission Requirements15.231(a)Complies Radiated Emissions15.231(b)Complies Occupied Bandwidth15.231(c)Complies Frequency Tolerance15.231(d)Not Applicable Periodic Alternate Field Strength Requirements15.231(e)Not Applicable Powerline Conducted Emissions15.207Not Applicable Footnotes For N/A’s: Test Conditions: Indoor Temperature: 25 °C Humidity:24 % Outdoor Temperature: 4 °C Humidity:22 % KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02418 EQUIPMENT: WLS 904-433 FCC ID: F5300433904 Page 5 of 22 Section 2.Equipment Under Test (E.U.T.) General Equipment Information Manufacturer: Digital Security Controls Ltd. Model No.: WLS 904-433 Serial No.: 365601 Date Received In Laboratory: April 17, 2000 KTL Identification No.: Item #2 Frequency Range: 433.920 MHz (Fixed) Operating Frequency(ies) of Sample: 433.920 MHz Type of Emission: Pulse Width Modulation Emission Designator: 115KL1D Supply Power Requirement: 4 x 1.5 Vdc Batteries (6 Vdc) Duty Cycle Calculation: -18 dB (See Attached Duty Cycle Description & Time Domain Graphs) Duty Cycle = 20 Log mS mS 100 25.12 = 18.24 dB KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02418 EQUIPMENT: WLS 904-433 FCC ID: F5300433904 Page 6 of 22 KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02418 EQUIPMENT: WLS 904-433 FCC ID: F5300433904 Page 7 of 22 Data Transmission Format The transmitted data packet is a fixed length, amplitude modulated packet. The packet contains all of the necessary information to indicate which sensor generated the packet, the type of sensor and the status of the sensor’s inputs. The data is sent at a rate of 500 μS per bit or 2 Kbits per second. Figure 1 shows the bit timing used for all bits in the packet. Where a low logic present for the 500 μS bit time represents a data logic “0” and 250 μS low then 250 μS high represents a data logic “1”. Figure 1 – Bit Timing Figure 2 shows the format of the transmitted data packet. Bytes highlighted in green are bytes that are variable information that would depend on the current status, module type and serial number of the particular device. Figure 2 – Data Packet Format Because these bytes are variable there is a best and worst case packet when considering ON Time. 250 μ S250 μ S 500 μ S bit time : data logic "0" 500 μ S bit time : data logic "1" 250 μ S250 μ S Sync bits (4 bits) Status Byte (8 bits) CRC Byte (8 bits) Serial Number Digits 4 and 5 (8 bits) Serial Number Digits 2 and 3 (8 bits) Module Type (4 bits) Serial Number Digit 1 (4 bits) Start bit (1 bit) Start bit (1 bit) Start bit (1 bit) Start bit (1 bit) …
