F53252RFLOCKIQ Lock-PGP, IQ Lock Touch-PGP

IQ Lock-PGP Installation and User Guide D-309633 *D-309633* 2026-05-11 © 2026 Johnson Controls. All rights reserved. 29011430R001 D-309633 Rev. 00.8.2 IQ Lock-PGP IQDLK-PGOK-SN / IQDLK-PGOK-MB / IQDLK-PGOK-ORB Safety information Safety information Read the safety information before you install the equipment. This equipment must be installed only by a skilled person. A skilled person is an installer with appropriate technical training. The installer must be aware of potential hazards during installation and measures available to minimize risks to the installer and other people. Warnings • Protect your user codes. • Restrict access to your lock and routinely check your settings to ensure they are not altered without your knowledge. • To make sure you are not locked out of your premises, monitor the smart lock batteries level and replace them when required. • Ensure you have access to the physical keys. • Always replace all batteries as a complete set, and avoid mixing different models or brands to maintain optimal performance and prevent issues. Use brand-new batteries for replacement to ensure accurate battery level reporting and proper lock functionality. • Avoid installing or operating the device near strong magnetic field as it could affect the device functionality. • Practice safety during installation, wear appropriate PPE (Personal Protective Equipment), and wash your hands if you have contact with the product during installation. Cleaning the IQ Lock-PGP To clean the IQ Lock-PGP, use a soft damp cloth. WARNING: Do not use lacquer thinner, caustic soaps, abrasive cleaners, or polishes. Introduction Note: This guide covers the following certified models: IQDLK-PGOK-SN, IQDLK-PGOK-MB and QDLK- PGOK-ORB. The generic reference IQ Lock-PGP used throughout this guide covers all these three models unless stated differently. The IQ Lock-PGP is a battery operated smart lock device that communicates with a compatible panel. The system is composed of the IQ Lock-PGP hardware, and the panel. The panel monitors and reports the IQ Lock-PGP status. Access the most recent online version of the IQ Lock-PGP installation and user guide at the following link. Accédez à la version en ligne la plus récente du guide d'installation et d'utilisation IQ Lock-PGP au lien suivant. Acceda a la versión en línea más reciente de la guía de usuario e instalación de IQ Lock-PGP en el siguiente enlace: https://bit.ly/3mnWCmx You can also scan the following QR code to access the most recent online version of the installation and user guide. Vous pouvez également scanner le code QR suivant pour accéder à la version en ligne la plus récente du guide d'installation et d'utilisation. También puede escanear el siguiente código QR para acceder a la versión en línea más reciente de la guía de instalación y del usuario. 2IQ Lock-PGP Installation and User Guide © 2026 Johnson Controls. All rights reserved. IQ Lock-PGP kit details Compatible panels For panels that are compatible with the IQ Lock-PGP, access https://bit.ly/3mnWCmx. IQ Lock-PGP kit details Before you install the smart lock, ensure the kit contains the items shown in Figure 1. Figure 1: Smart lock kit CalloutComponentQuantity AExterior assembly1 BLatch1 CMounting plate1 DLatch screws: 21 mm wood screws2 EStrike plate screws: 38 mm wood screws4 FStrike plate1 GReinforcement plate1 HMounting plate screws for door thicknesses between 1 3/8 in. and 2 1/4 in. (between 35 mm and 58 mm): 1/4-28 UNF x 65 mm 2 IInterior assembly1 3IQ Lock-PGP Installation and User Guide © 2026 Johnson Controls. All rights reserved. Specifications CalloutComponentQuantity Interior assembly screws: M4 x 6 mm3J Screw cap1 KBattery cover1 LDrive-in collar1 MTool for reset and RF setup1 NAA alkaline batteries4 OPhysical keys2 Specifications Wireless communication protocolPowerG and PowerG+, or Z-Wave Long Range Power supplyFour AA alkaline batteries Operating voltage4.6 V to 6.0 V Battery life with six user code unlock events, and ten unlocking and locking cycles, for each day PowerG mode: Minimum 12 months Z-Wave mode: Minimum 4 to 6 months Operating temperatureExterior assembly: -31ºF to 150ºF (-35ºC to 66ºC) Interior assembly: 32ºF to 140ºF (0ºC to 60ºC) Operating humidityExterior assembly: 100%, condensing Interior assembly: 20% to 95%, non-condensing Storage temperature32°F to 120°F (0°C to 49°C) Storage humidity20% to 60% IP ratingExterior assembly: IP54 DimensionsSee Smart lock dimensions Weight (without batteries)Exterior assembly: 1.3 lb (0.61 kg) Interior assembly: 1.0 lb (0.47 kg) Smart lock dimensions The following image outlines the smart lock dimensions. 4IQ Lock-PGP Installation and User Guide © 2026 Johnson Controls. All rights reserved. Prerequisites Figure 2: Smart lock dimensions Prerequisites Before you install the smart lock, ensure you meet requirements in Figure 3. CAUTION: Do not over-screw when using electronic screwdriver or it may cause the worn-out of screw threads and the installation cannot be completed correctly. Figure 3: Prerequisite check list 5IQ Lock-PGP Installation and User Guide © 2026 Johnson Controls. All rights reserved. Installing the smart lock CalloutPrerequisite ADoor hole is 1 1/2 in. or 2 1/8 in. (38 mm or 54 mm) BDoor thickness is between 1 3/8 in. and 2 1/4 in. (35 mm to 58 mm) CDoor hole backset is 2 3/8 in. or 2 3/4 in. (60 mm or 70 mm) DLatch hole is 1 in. (25.4 mm) diameter Note: Make sure the door frame is aligned with the door, and there are no obstructions stuck in the door frame. Installing the smart lock Figure 4 outlines how to install the smart lock components. Note: To install the smart lock you need a Philips head screwdriver, a flat head screwdriver, and a hammer. Figure 4: Smart lock installation overview CalloutComponent AExterior assembly BLatch CMounting plate and rubber gasket DLatch screws: 21 mm wood screws EStrike plate screws: 38 mm wood screws FStrike plate GOptional reinforcement plate HMounting plate screws: 1/4-28 UNF …

Text truncated - open the document above for the full version.

IQ Lock Touch-PGP Installation and User Guide D-309632 *D-309632* 2026-05-11 © 2026 Johnson Controls. All rights reserved. 29011433R001 D-309632 Rev. 00.8.2 IQ Lock Touch-PGP IQDLK-PGONKT-SN / IQDLK-PGONKT-MB / IQDLK-PGONKT-ORB Safety information Safety information Read the safety information before you install the equipment. This equipment must be installed only by a skilled person. A skilled person is an installer with appropriate technical training. The installer must be aware of potential hazards during installation and measures available to minimize risks to the installer and other people. Warnings • Protect your user codes. • Restrict access to your lock and routinely check your settings to ensure they are not altered without your knowledge. • To make sure you are not locked out of your premises, monitor the smart lock batteries level and replace them when required. • Always replace all batteries as a complete set, and avoid mixing different models or brands to maintain optimal performance and prevent issues. Use brand-new batteries for replacement to ensure accurate battery level reporting and proper lock functionality. • Avoid installing or operating the device near strong magnetic field as it could affect the device functionality. • Practice safety during installation, wear appropriate PPE (Personal Protective Equipment), and wash your hands if you have contact with the product during installation. Cleaning the IQ Lock Touch-PGP To clean the IQ Lock Touch-PGP, use a soft damp cloth. WARNING: Do not use lacquer thinner, caustic soaps, abrasive cleaners, or polishes. Introduction Note: This guide covers the following certified models: IQDLK-PGONKT-SN, IQDLK-PGONKT-MB and IQDLK-PGONKT-ORB. The generic reference IQ Lock Touch-PGP used throughout this guide covers all these three models unless stated differently. The IQ Lock Touch-PGP is a battery operated smart lock device that communicates with a compatible panel. The system is composed of the IQ Lock Touch-PGP hardware, and the panel. The panel monitors and reports the IQ Lock Touch-PGP status. Access the most recent online version of the IQ Lock Touch-PGP installation and user guide at the following link. Accédez à la version en ligne la plus récente du guide d'installation et d'utilisation IQ Lock Touch-PGP au lien suivant. Acceda a la versión en línea más reciente de la guía de usuario e instalación de IQ Lock Touch-PGP en el siguiente enlace: https://bit.ly/3mnWCmx You can also scan the following QR code to access the most recent online version of the installation and user guide. Vous pouvez également scanner le code QR suivant pour accéder à la version en ligne la plus récente du guide d'installation et d'utilisation. También puede escanear el siguiente código QR para acceder a la versión en línea más reciente de la guía de instalación y del usuario. 2IQ Lock Touch-PGP Installation and User Guide © 2026 Johnson Controls. All rights reserved. IQ Lock Touch-PGP kit details Compatible panels For panels that are compatible with the IQ Lock Touch-PGP, access https://bit.ly/3mnWCmx. IQ Lock Touch-PGP kit details Before you install the smart lock, ensure the kit contains the items shown in Figure 1. Figure 1: Smart lock kit CalloutComponentQuantity AExterior assembly1 BLatch1 CMounting plate1 DLatch screws: 21 mm wood screws2 EStrike plate screws: 38 mm wood screws4 FStrike plate1 GReinforcement plate1 3IQ Lock Touch-PGP Installation and User Guide © 2026 Johnson Controls. All rights reserved. Specifications CalloutComponentQuantity HMounting plate screws: • Two 1/4-28 UNF x 65 mm for door thicknesses between 2 in. and 2 1/4 in. (between 52 mm and 58 mm) • Two 1/4-28 UNF x 53 mm for door thicknesses between 1 5/8 in. and 2 in. (between 42 mm and 52 mm) • Two 1/4-28 UNF x 43 mm for door thicknesses between 1 3/8 in. and 1 5/8 in. (between 35 mm and 42 mm) 6 IInterior assembly1 Interior assembly screws: M4 x 6 mm3J Screw cap1 KBattery cover1 LDrive-in collar1 MTool for reset and RF setup1 NAA alkaline batteries4 Specifications Wireless communication protocolPowerG or Z-Wave Long Range Power supplyFour AA alkaline batteries Operating voltage4.6 V to 6.0 V Battery life with six user code unlock events, and ten unlocking and locking cycles, for each day PowerG mode: Minimum 12 months Z-Wave mode: Minimum 4 to 6 months Operating temperatureExterior assembly: -31ºF to 150ºF (-35ºC to 66ºC) Interior assembly: 32ºF to 140ºF (0ºC to 60ºC) Operating humidityExterior assembly: 100%, condensing Interior assembly: 20% to 95%, non-condensing Storage temperature32°F to 120°F (0°C to 49°C) Storage humidity20% to 60% IP ratingExterior assembly: IP54 DimensionsSee Smart lock dimensions Weight (without batteries)Exterior assembly: 0.73 lb (0.33 kg) Interior assembly: 1.0 lb (0.47 kg) Smart lock dimensions The following image outlines the smart lock dimensions. 4IQ Lock Touch-PGP Installation and User Guide © 2026 Johnson Controls. All rights reserved. Prerequisites Figure 2: Smart lock dimensions Prerequisites Before you install the smart lock, ensure you meet requirements in Figure 3. CAUTION: Do not over-screw when using electronic screwdriver or it may cause the worn-out of screw threads and the installation cannot be completed correctly. Figure 3: Prerequisite check list 5IQ Lock Touch-PGP Installation and User Guide © 2026 Johnson Controls. All rights reserved. Installing the smart lock CalloutPrerequisite ADoor hole is 1 1/2 in. or 2 1/8 in. (38 mm or 54 mm) BDoor thickness is between 1 3/8 in. and 2 1/4 in. (35 mm to 58 mm) CDoor hole backset is 2 3/8 in. or 2 3/4 in. (60 mm or 70 mm) DLatch hole is 1 in. (25.4 mm) diameter Note: Make sure the door frame is aligned with the door, and there are no obstructions stuck in the door frame. Installing the smart lock Figure 4 outlines how to install the smart lock components. Note: To install the smart lock you need a Philips head screwdriver, a flat head screwdriver, and a hammer. Figure 4: Smart lock …

Text truncated - open the document above for the full version.

Tyco Safety Products Canada Ltd. (2026.05.22) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:F53252RFLOCK) [Tyco Safety Products Canada Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Dan Nita Tyco Safety Products Canada Ltd. (2026.05.22) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:F53252RFLOCK) [Tyco Safety Products Canada Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Dan Nita

Tyco Safety Products Canada Ltd. (2026.05.22) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:F53252RFLOCK) [Tyco Safety Products Canada Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Dan Nita Tyco Safety Products Canada Ltd. (2026.05.22) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:F53252RFLOCK) [Tyco Safety Products Canada Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Dan Nita

Tyco Safety Products Canada Ltd. 1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: AOGES CO., LIMITED Contact Name: XIAOYAN LAI Address: 1624 Market St., Ste 226, #30327 Denver CO, 80202 US Telephone No: 303 623 1940 Email: [email protected] FRN: 0033947847 Applicant: Company name: Tyco Safety Products Canada Ltd. Product Description: IQ Lock-PGP, IQ Lock Touch-PGP FRN: 0006834485 Grantee code: F53 FCC ID: F53252RFLOCK Contact Name: Dan Nita Address: 3301 Langstaff Road Concord, Ontario, L4K 4L2 Canada Telephone No: 1-416-357-1409 Email: [email protected] [Tyco Safety Products Canada Ltd.] certifies that, as of the date of this filing of the application with the TCB, [AOGES CO., LIMITED] is our designated US agent for service of process for the above referenced FCC ID. [Tyco Safety Products Canada Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [AOGES CO., LIMITED] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Date: 2026.06.02 Applicant’s Name: Tyco Safety Products Canada Ltd. US Agent’s Name: AOGES CO., LIMITED Title: Approvals Manager Title: General Manager Signature Dan Nita Signature XIAOYAN LAI

Tyco Safety Products Canada Ltd. Agent Authorization Company: Tyco Safety Products Canada Ltd. Address: 3301 Langstaff Road Concord, Ontario, L4K 4L2 Canada Product Name: IQ Lock-PGP, IQ Lock Touch-PGP Model Number(s): IQDLK-PGOK-MB, IQDLK-PGOK-SN, IQDLK-PGOK-ORB, IQDLK-PGONKT-SN, IQDLK-PGONKT-MB, IQDLK-PGONKT-ORB Product Description: IQ Lock-PGP, IQ Lock Touch-PGP We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2026.05.20 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1-647-480-0200 https://www.tycosafetyproducts.com 2026.04.28 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China /Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E-mail:[email protected] This appointment is valid until further until Jan 22, 2030 Sincerely, Signature: Name: Dan Nita Title: Approvals Manager E-mail: [email protected] Company: Tyco Safety Products Canada Ltd.

Differences Description We Tyco Safety Products Canada Ltd. state: The circuit design, layout, components used and internal wiring are exactly the same, only the model name, keyboard board and appearance color are different Product Model name Description PHOTO IQ Lock-PGP IQDLK-PGOK-MB PowerG+ Smart Door Lock, Rubber Button keypad, Matte Black Note: The right keypad board is only an accessory. IQDLK-PGOK-SN PowerG+ Smart Door Lock, Rubber Button keypad, Satin Nickel Note: The right keypad board is only an accessory. IQDLK-PGOK-ORB PowerG+ Smart Door Lock, Rubber Button keypad, Oil-Rubbed Bronze Note: The right keypad board is only an accessory. IQ Lock Touch-PGP IQDLK-PGONKT-MB PowerG+ Smart Door Lock, Keyless Touch Keypad, Matte Black Note: The right keypad board is only an accessory. IQDLK-PGONKT-SN PowerG+ Smart Door Lock, Keyless Touch Keypad, Satin Nickel Note: The right keypad board is only an accessory. IQDLK-PGONKT-ORB PowerG+ Smart Door Lock, Keyless Touch Keypad, Oil-Rubbed Bronze Note: The right keypad board is only an accessory. Signature: Date: 2026.05.20 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

Tyco Safety Products Canada Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026.05.20 FCC ID: F53252RFLOCK To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name:Jiankuai Li Title:PM

Page 1 of 6 ReportNo.:STS2512547 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 6 ReportNo.:STS2512547 Photo3 Photo4 Page 3 of 6 ReportNo.:STS2512547 Photo5 Photo6 Page 4 of 6 ReportNo.:STS2512547 Photo7 Photo8 Page 5 of 6 ReportNo.:STS2512547 Photo9 Photo10 Page 6 of 6 ReportNo.:STS2512547 Photo11

Label IQ Lock-PGP HVIN: IQDLK-PGOK-MB FCC ID: F53252RFLOCK IC: 160A-2RFLOCK Label IQ Lock-PGP HVIN: IQDLK-PGOK-ORB FCC ID: F53252RFLOCK IC: 160A-2RFLOCK Label IQ Lock-PGP HVIN: IQDLK-PGOK-SN FCC ID: F53252RFLOCK IC: 160A-2RFLOCK Label IQ Lock Touch-PGP HVIN: IQDLK-PGONKT-MB FCC ID: F53252RFLOCK IC: 160A-2RFLOCK Label IQ Lock Touch-PGP HVIN: IQDLK-PGONKT-ORB FCC ID: F53252RFLOCK IC: 160A-2RFLOCK Label IQ Lock Touch-PGP HVIN: IQDLK-PGONKT-SN FCC ID: F53252RFLOCK IC: 160A-2RFLOCK

Page 1 of 3 ReportNo.:STS2512547 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Antenna Page 2 of 3 ReportNo.:STS2512547 Photo3 Photo4 Page 3 of 3 ReportNo.:STS2512547 Photo5

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. MPE Report Report No.:STS2512547H01 Issued for Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, L4K 4L2 Canada Product Name: IQ Lock-PGP, IQ Lock Touch-PGP Brand Name: IQ Model Name: IQDLK-PGOK-MB Series Model(s): IQDLK-PGOK-SN, IQDLK-PGOK-ORB, IQDLK-PGONKT-SN, IQDLK-PGONKT-MB, IQDLK-PGONKT-ORB FCC ID: F53252RFLOCK Test Standards: FCC 47CFR §2.1091 Page 2 of 9 Report No.: STS2512547H01 TEST REPORT Applicant’s Name ................. : Tyco Safety Products Canada Ltd. Address .................................. : 3301 Langstaff Road Concord, Ontario, L4K 4L2 Canada Manufacturer's Name .......... : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address .................................. : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China Product Description Product Name ........................ : IQ Lock-PGP, IQ Lock Touch-PGP Brand ................................... : IQ Model Number ....................... : ... : IQDLK-PGOK-MB Series Model(s) ...................... : IQDLK-PGOK-SN, IQDLK-PGOK-ORB, IQDLK-PGONKT-SN, IQDLK-PGONKT-MB, IQDLK-PGONKT-ORB Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ............................................ : Date of receipt of test item ...................... : 31 Dec. 2025 Date (s) of performance of tests.............. : 31 Dec. 2025 ~ 22 Jan. 2026 Date of Issue ........................................... : 22 Jan. 2026 Test Result ............................................... : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2512547H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2512547H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 22 Jan. 2026 STS2512547H01 ALL Initial Issue Page 5 of 9 Report No.: STS2512547H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name IQ Lock-PGP, IQ Lock Touch-PGP Brand IQ Model Name IQDLK-PGOK-MB Series Model(s) IQDLK-PGOK-SN, IQDLK-PGOK-ORB, IQDLK-PGONKT-SN, IQDLK-PGONKT-MB, IQDLK-PGONKT-ORB Model Difference The circuit design, layout, components used and internal wiring are exactly the same, only the model name, keyboard board and appearance color are different Product Description The EUT is IQ Lock-PGP-MB Operation Frequency: Power G: 912.749725~919.106495MHz Zwave LR: 912 MHz,920 MHz Zwave: 908.4MHz, 908.42MHz, 916MHz Power G: 912-920 MHz Zwave LR: 900MHz Zwave: 900MHz Modulation Type: Power G: FSK Zwave LR: OQPSK Zwave: FSK Power G: FSK Zwave LR: OQPSK Zwave: FSK Antenna gain: Power G: 1.85dBi Zwave LR: 1.86dBi Zwave: 1.85dBi Power G: 1.85dBi Zwave LR: 1.86dBi Zwave: 1.85dBi Antenna Designation: FPC external Antenna Power Rating Input: DC 6V Adapter N/A Battery N/A Hardware Version RL00543D_FL00544B Software Version V1.1.4 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2512547H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2512547H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 …
