F5325LC203424Dual Technology Motion Sensor

Installation Instructions LC-224 1 ISTISJCELC224 0.0 1. INTRODUCTION The LC-224 detector represents the best choice for residential and industrial installations in the security sector. It only use digital PIRs which bypass the conversion that usually must be done with traditional detectors where an analog PIR is amplified and converted to digital. The FULLY digital technology helps the detector more accurately detect intrusions and not be affected of alterations in white light, ultraviolet light, temperature and air movement caused by heating/cooling systems. It is also fully immune to radiated and conducted electromagnetic interference. The LC-224 detector is equipped with lenses designed by Johnson Controls and are manufactured by Fresnel Technologies, Inc. LODIFF ® optic creation technology combined with POLY IR ® materials make it a product of the highest quality and efficiency. The LC-224 detector is pet immune (feature not evaluated by UL/ULC) and have a 15 m range and a 100-degree detection range. The LC-224 is equipped with latest generation microwave modules, with very low background noise. 2. INSTALLATION - Using a thin screwdriver, loosen the bottom screw and open the cover (see Fig 1) - Remove the board from the plastic base by removing the screw on the board (see Fig 2) - Open the knockouts needed for mounting onto the wall or use the optional swivel (not UL/ULC evaluated) - Open the knockouts for removal protection and fix the anchor to the wall (see Fig 2) - Recommended height is from 1.8 m to 2.5 m - Run the connection cables through the bottom of the container and out the top - Connect the wires on the board as described below 3. MEANING OF THE LEDS During normal operation, the LED signals are: - GREEN LED = PIR Alarm - YELLOW LED = MW Alarm - RED LED = General Alarm (both PIR and MW) NOTE: Do not partially or completely cover the detector’s field of vision LC-224 DUAL TECHNOLOGY DETECTOR POLY IR ® 4 Plastic Material for Detection Stability POLY IR ® lens material. This materials offers a better combination of transmittance, environmental stability and color than any other polymer on the market. Materials are available for the 8-14 micron infrared region. LODIFF ® and POLY IR ® are registered trademarks of Fresnel Technologies, Inc. LODIFF ® Fresnel Technology Lenses This lens series is made by tiling LODIFF ® lens pieces. These lenses offer significantly improved performance over the typical constant-bandwidth Fresnel lens. LODIFF ® and POLY IR ® are registered trademarks of Fresnel Technologies, Inc. High RFI Protection The detector has very high RFI immunity due to the complete lack of traditional amplifiers. White Light Protection Pet Immunity Thanks to a new lens design and the digital analysis system, all of our detectors are immune to pets weighing up to 15 kg. The detector has no analog components, and the fully digital PIR interfaces directly with the microprocessor. Fully Digital PIR The detector digitally filters white light components. - Fig 1 - - Fig 2 - DIP Switch Trimmer Anchor Installation Instructions LC-224 2 ISTISJCELC224 0.0 Technical Features RANGE15 m HORIZONTAL COVERAGE100° LENSES LODIFF ® Fresnel Lens POLY IR ® 4 material LEDgreen, yellow, red ALARM DURATION2 s SELF-DIAGNOSTIC- WALK TEST LEDYES MICROWAVE FREQUENCY10.525 Ghz MAXIMUM RADIO- FREQUENCY POWER +14 dBm SOLID STATE RELAYYES INTERNAL EOL RESISTORS - CREEP ZONE DEVICEYES CASE TAMPERYES BACK TAMPERYES ANTI-MASKING- PULSE COUNTERYES RFI PROTECTION30 V/m HEAT COMPENSATION YES FULLY DIGITALYES SWIVELYES POWER SUPPLY 9-15 VDC / 56 mA UL/ULC tested: 10.6-13 VDC / 56 mA COVER MATERIALABS PET IMMUNITYYES OPERATING TEMPERATURE0°C to 49°C HUMIDITY93% RH DIMENSIONS114 x 63 x 40 mm 101W. MORNINGSIDE DR. FORT WORTH, TX 76110, U. S. A. (817) 926-7474, FAX:(817)926-7146 fresnel technologies inc. 2003 SIDE VIEW: 2.1m (6.8ft) TOP VIEW: 10m (33ft) (50ft) 15m FRONT VIEW: (50ft) 15m 5m (16ft) jay WP 0.9 GI 6 T1 PET IMMUNE ARRAY (28.2ft) 8.6m (15.7ft) 4.8m (6.8ft) 2.1m 35.6mm (1.4 in) 49.8 mm (1.96 in) 12.5 mm (0.49 in) 95° 5m (16ft) 10m (33ft) (50ft) 15m 0 Figure 7 101W. MORNINGSIDE DR. FORT WORTH, TX 76110, U. S. A. (817) 926-7474, FAX:(817)926-7146 fresnel technologies inc. 2003 SIDE VIEW: 2.1m (6.8ft) TOP VIEW: 10m (33ft) (50ft) 15m FRONT VIEW: (50ft) 15m 5m (16ft) jay WP 0.9 GI 6 T1 PET IMMUNE ARRAY (28.2ft) 8.6m (15.7ft) 4.8m (6.8ft) 2.1m 35.6mm (1.4 in) 49.8 mm (1.96 in) 12.5 mm (0.49 in) 95° 5m (16ft) 10m (33ft) (50ft) 15m 0 Figure 7 4. CONNECTION AND SETUP Dip LED --> off = LED off - on = LED on Dip RANGE --> off = 15 m - on =7 m range Dip PULSE --> off = 1 pulse - on = 2 pulses Dip OR-AUTO* --> off-off = AND; on-off = OR; on-on = auto OR Trimmer RANGE = used only for microwave. NOTE: The RANGE trimmer may need to be adjusted to the maximum position in order to achieve maxi- mum area of coverage as indicated in Figure 3. TAMPER terminals: Normally closed contact that opens when you open the detector cover or remove the detector from the wall NC terminals: Normally closed contact that opens when the detector goes into alarm status NO terminals: Normally open contact that closes when the detector goes into alarm status SUPPLY terminals: Power supply 9-15 VDC / 56 mA. UL/ULC tested: 10.6-13 VDC / 56 mA. NOTE: For UL/ULC installations the detector shall be provided with minimum of 4 hours of standby power from either a listed compatible control unit or power supply. Output contacts ratings: 28 VDC / 100 mA. Use only resistive loads on the outputs. Note: Incorrect connections may result in failure or improper operation. Inspect wiring and ensure connections are correct before turning on the power. * For UL/ULC installations use the OFF-OFF configuration only. DEOL supervision with type C alarm contact NO (no EOL supervision) Not used on UL/ULC listed installations DEOL supervision with type C alarm contact and device tamper - Fig 3 - ZxCOM – + TAMPER NONC LC-224 SUPPLY – + CTAMPER 5.6 kohm5.6 kohm Negative …

Text truncated - open the document above for the full version.

Installation Instructions LC-203/BLC-203 and LC-204/BLC-204 1 ISTISJCEBLC2034 1.0 2012/19/EU LC-203/BLC-203 and LC-204/BLC-204 DUAL TECHNOLOGY DETECTORS 1. INTRODUCTION The new line of LC-203/BLC-203 and LC-204/BLC-204 detectors is the best choice for residential and commercial security installations: BLC-203 and BLC- 204 are not UL/ULC listed. They only use digital PIRs which bypass the conversion that usually must be done with traditional detectors where an analog PIR is amplified and converted to digital. The FULLY digital technology helps the detector more accurately detect intrusions and not be affected by alterations in white light, ultraviolet light, temperature and air movement caused by heating/cooling systems. It is also fully immune to radiated and conducted electromagnetic interference. LC-203/BLC-203 and LC-204/BLC-204 detectors are equipped with lenses designed by Johnson Controls and are manufactured by Fresnel Technologies, Inc. LODIFF ® optic creation technology combined with POLY IR ® materials make it a product of the highest quality and efficiency. LC-203/BLC- 203 and LC-204/BLC-204 detectors are pet immune (feature not evaluated by UL/ULC) and have a 15 m range and a 100-degree detection range. LC-203/BLC- 203 includes mask detection. 2. INSTALLATION - Using a thin screwdriver, loosen the bottom screw and open the cover (see Fig 1) - Remove the board from the plastic base by removing the screw on the board (see Fig 2) - Open the knockouts needed for mounting onto the wall (or use the non-certified IMQ joint) - Open the knockouts for removal protection and fix the anchor to the wall (see Fig 2) - Recommended height is 2.1 m - Run the connection cables through the bottom of the container and out the top - Connect the wires on the board as described below - Fig 1 - - Fig 2 - POLY IR ® 4 Plastic Material for Detection Stability POLY IR ® lens material. This materials offers a better combination of transmittance, environmental stability and color than any other polymer on the market. Materials are available for the 8-14 micron infrared region. LODIFF ® and POLY IR ® are registered trademarks of Fresnel Technologies, Inc. LODIFF ® Fresnel Technology Lenses This lens series is made by tiling LODIFF ® lens pieces. These lenses offer significantly improved performance over the typical constant-bandwidth Fresnel lens. LODIFF ® and POLY IR ® are registered trademarks of Fresnel Technologies, Inc. High RFI Protection The detector has very high RFI immunity due to the complete lack of traditional amplifiers. White Light Protection Pet Immunity Thanks to a new lens design and the digital analysis system, all of our detectors are immune to pets weighing up to 15 kg. The detector has no analog components, and the fully digital PIR interfaces directly with the microprocessor. Fully Digital PIR 3. MEANING OF THE LEDS During normal operation, the LED signals are: GREEN LED = PIR Alarm; YELLOW LED = MW Alarm; RED LED = General Alarm (both PIR and MW) - LC-203/BLC-203: In the case of detector masking, the LED corresponding to the masked technology will flash, and the MASK alarm contacts open LC-203/BLC-203 VERSION The LC-203/BLC-203 provides continuous detector self-testing, in the case of an anomaly lasting longer than 15 seconds, the detector will report: - POWER SUPPLY ABOVE THE NOMINAL THRESHOLDS: Alternating flashing of YELLOW and GREEN LEDs and opening of the MASK contact - INFRARED SELF-TEST FAILURE Flashing of GREEN LED and opening of the MASK contact - MICROWAVE SELF-TEST FAILURE Flashing of YELLOW LED and opening of the MASK contact NOTE: Do not partially or completely cover the detector's field of vision NOTE: the pet function is not IMQ certified The detector digitally filters white light components. Jumpers DIP Switch Trimmer Anchor Installation Instructions LC-203/BLC-203 and LC-204/BLC-204 2 ISTISJCEBLC2034 1.0 LC-203/BLC-203/LC-204/BLC-204 Microwave frequency: 10.525GHz 4. CONNECTION AND SETUP Dip LED --> off = LED off - on = LED on* Dip HIGH/LOW --> off = 7m - on = 15m range Dip NORM/PULSE --> off = 1 pulse - on = 2 pulse Dip AND/OR-AUTO** --> off-off = AND; on-off = OR; on-on = auto OR Trimmer RANGE = used only for microwave. NOTE: The RANGE trimmer may need to be adjusted to the maximum position in order to achieve maximum area of coverage as indicated in Figure 3. Technical Features RANGE15 m HORIZONTAL COVERAGE100° LENSES LODIFF ® Fresnel Lens POLY IR ® 4 Material LEDgreen, yellow, red ALARM DURATION2 s SELF-DIAGNOSTICS- LED WALK TESTYES MICROWAVE FREQUENCY10.525 GHz MAXIMUM RADIO- FREQUENCY POWER +14 dBm SOLID STATE RELAYYES EOL RESISTANCEYES CREEP ZONE DEVICEYES CASE TAMPERYES BACK TAMPERYES ANTI-MASKINGLC-203/BLC-203 DOUBLE PULSEYES RFI PROTECTION30 V/m HEAT COMPENSATIONYES FULLY DIGITALYES JOINTYES POWER SUPPLY 9-15 VDC / 56 mA UL/ULC tested: 10.6-13 VDC / 56 mA COVER MATERIALABS PET IMMUNITYYES OPERATING TEMPERATURE -10°C to +40°C UL/ULC tested: 0°C to 49°C HUMIDITY93% RH DIMENSIONS114 x 63 x 40 mm Jumpers T - A - EOL open = NC contacts without resistors (not for UL/ULC applications) Jumpers T - A - EOL closed = DEOL supervision with internal resistors SUPPLY terminals: Power supply 9-15 VDC / 56 mA. UL/ULC tested: 10.6-13 VDC / 56 mA. Note: For UL/ULC installations the detector shall be provided with minimum of 4 hours of standby power from either a listed compatible control unit or power supply. Output contacts ratings: 28 VDC / 100 mA. Use only resistive loads on the outputs. MASK terminals = antimasking terminals present on LC-203/BLC-203 only DEOL supervision (internal resistors/closed jumpers) LC-203/LC-204: DEOL supervision (external resistors/ open jumpers) NC (no EOL supervision/ open jumpers) Not used on UL/ULC listed installations 101W. MORNINGSIDE DR. FORT WORTH, TX 76110, U. S. A. (817) 926-7474, FAX:(817)926-7146 fresnel technologies inc. 2003 SIDE VIEW: 2.1m (6.8ft) TOP VIEW: 10m (33ft) (50ft) 15m FRONT VIEW: (50ft) 15m 5m (16ft) jay WP 0.9 GI 6 T…

Text truncated - open the document above for the full version.

MADE IN ITALY wwyy Input Rating: 10.6 - 13 Vdc / 56 mA FCC ID:F5325LC203424 IC:160A-LC203424 CAN ICES-3(B)/NMB-3(B) Refer to Installation Manual: ISTISJCELC224 0.0 ETIP1LC224 00 M/N:LC-224 COMBO PIR/MW DETECTOR RES/COM BURG INTRUSION DETECTION UNIT cambiare versione P/N se cambia qualcosa modicare settimana/anno e frequenza 10.525 GHz

www.nemko.com Nemko Canada Inc., a testing laboratory, is accredited by ANSI National Accreditation Board (ANAB). The tests included in this report are within the scope of this accreditation. The ANAB symbol is an official symbol of the ANSI National Accreditation Board, used under licence. ANAB File Number: AT-3195 (Ottawa/Almonte); AT-3193 (Pointe-Claire); AT-3194 (Cambridge) FCC 15.245 and RSS-210 F.1.docx; Date: Feb 12 2024 C h o o s e S c a n d i n a v i a n t r u s t RADIO TEST REPORT Report ID: Project number: REP104491 PRJ0083817 Type of assessment: Final product testing Applicant: Description of product: Tyco Safety Products Canada Ltd. Dual Technology Motion Sensor Model(s)/HVIN(s): Product marketing name (PMN): LC-203E, LC-204E, LC-224 LC-203, LC-204, LC-224 FCC identifier: ISED certification number: FCC ID: F5325LC203424 IC: 160A-LC203424 Specifications:  FCC 47 CFR Part 15, Subpart C, §15.245  RSS-210 Annex F.1, Issue 11, June 2024 Date of issue: December 15, 2025 Sagarkumar Patel Tested by Andrey Adelberg, Senior WL/EMC Specialist Reviewed by Signature Report reference ID: REP104491 Page 2 of 27 Lab locations Company name Nemko Canada Inc. Facilities Ottawa site: 303 River Road Ottawa, Ontario Canada K1V 1H2 Tel: +1 613 737 9680 Fax: +1 613 737 9691 Montréal site: 292 Labrosse Avenue Pointe-Claire, Québec Canada H9R 5L8 Tel: +1 514 694 2684 Fax: +1 514 694 3528 Cambridge site: 1-130 Saltsman Drive Cambridge, Ontario Canada N3E 0B2 Tel: +1 519 650 4811 Almonte site: 1500 Peter Robinson Road West Carleton, Ontario Canada K0A 1L0 Tel: +1 613 256-9117 Test site identifier Organization Ottawa/Almonte Montreal Cambridge FCC: CA2040 CA2041 CA0101 ISED: 2040A-4 2040G-5 24676 Website www.nemko.com Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contained in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Copyright notification Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. © Nemko Canada Inc. Report reference ID: REP104491 Page 3 of 27 Table of contents Table of contents .......................................................................................................................................................................................................... 3 Section 1. Report summary ................................................................................................................................................................................. 4 1.1 Test specifications .................................................................................................................................................................................................... 4 1.2 Test methods ............................................................................................................................................................................................................ 4 1.3 Exclusions ................................................................................................................................................................................................................. 4 1.4 Statement of compliance ......................................................................................................................................................................................... 4 1.5 Test report revision history ...................................................................................................................................................................................... 4 Section 2. Engineering considerations .................................................................................................................................................................. 5 2.1 Modifications incorporated in the EUT for compliance ............................................................................................................................................ 5 2.2 Technical judgment .................................................................................................................................................................................................. 5 2.3 Model variant declaration ........................................................................................................................................................................................ 5 2.4 Deviations from laboratory tests procedures ........................................................................................................................................................... 5 Section 3. Test conditions .................................................................................................................................................................................... 6 3.1 Atmospheric conditions ........................................................................................................................................................................................... 6 3.2 Power supply range .................................................................................................................................................................................................. 6 Section 4. Information provided by the applicant .................…

Text truncated - open the document above for the full version.

SKY MICROWAVE SKY-DF1052D11A 46.5(mm) 40(mm) 8.5(mm) Microwave Doppler Sensor Module Module Size Not affected by temperature, humidity, airflow, noise and light etc, suitable for harsh environment; Strong anti-interference ability; No dead corner blind area, wide coverage; Can penetrate glass, wood and other non-metal obstacles; Comply with FCC, EC certification testing standards; Main features Applications The microwave module can be widely used in various sensor lamps, security, automatic sensitivity control and other products. SKY MICROWAVE CO., LTD Technical Parameters Detection range E-PlaneH-Plane # Item Parameter Electrical Characteristics 1. Operating voltage 5.0± 0.2 VDC 2. Operating current 30mA-40mA. 3. Center frequency 10.520Ghz 4. Center frequency 10.525Ghz±25Mhz 5. Frequency stability ±10 MHz max. (-30 to +80°C) 6. Output power 14dBm typ. 7. Return loss sensitivity -90dBc typ. 8. Second harmonic emission <-33dBm typ. 9. Third harmonic emission <-33dBm typ. 10. Antenna gain 9.63dBi 11. –3dB beam width (E-plane) –3dB beam width (H-plane) 38 deg. nom. 76 deg. nom. 12. IF amplitude 0~9.3mv(Fixture testing) Maximum setting 1. Work temperature -30 to +80°C 2. Storage temperature -40 to +80°C 3. Relative humidity 95 % at 35°C 4. Life cycle >50000h Others 1. Regulation for compliance ETS 300 440 2. Protection N/A 3. IP N/A 4. Certification CE\FCC

www.nemko.com Nemko Canada Inc., a testing laboratory, is accredited by ANSI National Accreditation Board (ANAB). The test results included in this report are within the scope of this accreditation. The ANAB symbol is an official symbol of the ANSI National Accreditation Board, used under licence. FCC and ISED RSS-102– MPE Calculation; Date: June 2025 RF Exposure Compliance – MPE Calculation Report C h o o s e S c a n d i n a v i a n t r u s t Applicant information: Tyco Safety Products Canada Ltd. Product information: Model number (HVIN): LC-203E, LC-204E, LC-224 Model name (PMN): LC-203, LC-204, LC-224 Product type: Mobile or Fixed Device Device category Consumer Device for General Population/Uncontrolled Exposure FCC Identification: FCC ID: F5325LC203424 ISED certification number: IC: 160A-LC203424 Date of issue: November 25, 2025 Compliance Specifications: FCC 47 CFR Part 1 Subpart I, §§1.1307, 1.1310 FCC 47 CFR Part 2 Subpart J, §§2.1091, 2.1093 FCC KDB 447498 D01 General RF Exposure Guidance v06 FCC KDB 865664 D01 RF Exposure Procedures and Equipment Authorization Policies ISED Canada RSS-102 Issue 6 December 15, 2023 MPE calculation report Product info: FCC ID: F5325LC203424 IC: 160A-LC203424 Model: LC-203E, LC-204E, LC-224 Page 2 of 7 Test locations of Nemko Canada Inc. Ottawa site Montréal site GTA Cambridge site Facility address 303 River Road Ottawa, Ontario Canada K1V 1H2 Tel: +1 613 737 9680 Fax: +1 613 737 9691 292 Labrosse Avenue Pointe-Claire, Québec Canada H9R 5L8 Tel: +1 514 694 2684 Fax: +1 514 694 3528 1-130 Saltsman Drive Cambridge, Ontario Canada N3E 0B2 Tel: +1 519 650 4811 Test site identifier - FCC CA2040 CA2041 CA0101 Test site identifier – ISED Canada 2040A-4 2040G-5 24676 ANAB File Number AT-3195 AT-3193 AT-3194 Andrey Adelberg Senior EMC/Wireless Specialist Prepared by Signature Limits of responsibility The results presented in this report apply solely to the specific device model tested and are valid only for the operating conditions and installation requirements specified herein. Testing was conducted in accordance with ISO/IEC 17025:2017 requirements, and all results fall within the scope of Nemko Canada's accreditation. This MPE evaluation is based on the maximum power levels and operating conditions specified. Any modifications to the device hardware, software, or installation that could affect RF output power or antenna characteristics may invalidate this compliance demonstration. Copyright notification This report may be reproduced by the applicant in its entirety for regulatory submission and internal use. Any use of this report by third parties, including reliance on its contents or decisions made based on it, is solely at the risk of those third parties. Nemko Canada Inc. assumes no responsibility for any damages incurred by third parties as a result of actions taken based on this report. © Nemko Canada Inc. All rights reserved. MPE calculation report Product info: FCC ID: F5325LC203424 IC: 160A-LC203424 Model: LC-203E, LC-204E, LC-224 Page 3 of 7 1. Executive Summary This report presents the Maximum Permissible Exposure (MPE) analysis for [Product Name] to demonstrate compliance with FCC and ISED RF exposure requirements. The evaluation considers both single transmitter operation and simultaneous multi-transmitter scenarios where applicable. 2. Key Findings Compliance status Complies Critical separation distances 20 cm Special conditions or limitations N/A MPE calculation report Product info: FCC ID: F5325LC203424 IC: 160A-LC203424 Model: LC-203E, LC-204E, LC-224 Page 4 of 7 MPE calculations for stand-alone transmission Device Classification Requirements Portable Device Definition (§2.1093) Devices designed for use by a person where the radiating structure is within 20 cm of the user's body require SAR evaluation rather than MPE calculation. Mobile Device Definition Devices installed in vehicles or with permanently installed antennas may use MPE calculations if minimum separation distances can be established. Fixed/Base Station Definition Stationary transmitters with controlled access to antenna locations may use MPE calculations for both occupational and general population exposure scenarios. 3. References, definitions and limits for FCC FCC §2.1091(d) (2) For operations within the frequency range of 300 kHz and 6 GHz (inclusive), the limits for maximum permissible exposure (MPE), derived from whole-body SAR limits and listed in Table 1 in paragraph (e)(1) of this section, may be used instead of whole-body SAR limits as set forth in paragraphs (a) through (c) of this section to evaluate the environmental impact of human exposure to RF radiation as specified in §1.1307(b) of this part, except for portable devices as defined in §2.1093 of this chapter as these evaluations shall be performed according to the SAR provisions in §2.1093. Table 1: §1.1310(e)(1)—Power Density Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Power density (mW/cm 2 ) Averaging time (minutes) (i) Limits for Occupational/Controlled Exposure 0.3–3.0 *(100) ≤6 3.0–30 *(900 / f 2 ) <6 30–300 1.0 <6 300–1500 f / 300 <6 1500–100000 5 <6 (ii) Limits for General Population/Uncontrolled Exposure 0.3–1.34 *(100) <30 1.34–30 *(180 / f 2 ) <30 30–300 0.2 <30 300–1500 f / 1500 <30 1500–100000 1.0 <30 Notes: f = frequency in MHz. * = Plane-wave equivalent power density. MPE calculation report Product info: FCC ID: F5325LC203424 IC: 160A-LC203424 Model: LC-203E, LC-204E, LC-224 Page 5 of 7 4. References, definitions and limits for ISED RSS-102 Section 5.3.2 The power density reference levels, and associated reference period for devices employed by the general public (uncontrolled environment) and controlled-use devices (controlled environment) are specified in table below. Note that the power density limits specified in this table apply to whole body exposure conditions. Table 2: RSS-102— Power density limits Frequency range (MHz) Power density (W/m 2 ) Power density (mW…

Text truncated - open the document above for the full version.

Qolsys Inc. 1919 S Bascom Ave., Suite 600 Campbell, California 95008, USA * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. ** the agent does not have an FRN because they do no other business with the FCC except for acting as a US agent for service of process, and therefore are not required to have their own FRN. U.S. Agent Designation for Service of Process - Certification Attestation Letter July 3, 2025 Nemko North America, Inc. 303 River Road Ottawa ON K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: F5325LC203424 Applicant FRN: 0006834485 This letter serves as a formal designation, pursuant to §2.911(d)(7) of the FCC Rules, of the following U.S. Agent* for Service of Process for the equipment under application: U.S. Agent for Service of Process: • Company Name: Qolsys Inc. • Physical U.S. Company Address: 1919 S Bascom Ave., Campbell, CA 95008, USA • Agent Name: Dan Nita • Agent Email Address: [email protected] • Agent FRN**: 0022572226 The above listed designated agent hereby acknowledges and accepts the obligation for service of process on behalf of the applicant signed below. The applicant further acknowledges and accepts its obligation to maintain a U.S. Agent for Service of Process for a minimum period of one year following either: • Permanent termination of all marketing and importation activities within the U.S. for the applicable equipment by the grantee. • The conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever occurs later. Qolsys Inc. 1919 S Bascom Ave., Suite 600 Campbell, California 95008, USA * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. ** the agent does not have an FRN because they do no other business with the FCC except for acting as a US agent for service of process, and therefore are not required to have their own FRN. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant) Signed: Signed: Printed name: Dan Nita Printed name: Dan Nita Title: Sr. Approvals Manager Title: Sr. Director Product Company Name: Tyco Safety Products Canada Ltd. Company Name: Qolsys Inc. Date: June 17, 2025 Date: June 17, 2025

MADE IN ITALY 2725 Input Rating: 10.6 - 13 Vdc / 56 mA FCC ID:F5325LC203424 IC:160A-LC203424 CAN ICES-3(B)/NMB-3(B) HVIN:LC-204E EN50131-1/A3 GRADE 2 / CLASS II, EN50131-2-4 Refer to Installation Manual: ISTISJCEBLC2034 1.0 European Single Point of Contact: Tyco Security Products, Voltaweg 20, 6101 XK Echt, The Netherlands ETIP1LC204 02 LC-204 COMBO PIR/MW DETECTOR RES/COM BURG INTRUSION DETECTION UNIT cambiare versione P/N se cambia qualcosa modicare settimana/anno e frequenza 9.90 GHz 9.35 GHz 10.525 GHz 10.587 GHz

MADE IN ITALY 4623 Input Rating: 10.6 - 13 Vdc / 56 mA FCC ID:F5325LC203424 IC:160A-LC203424 CAN ICES-3(B)/NMB-3(B) HVIN:LC-203E EN50131-1/A3 GRADE 3 / CLASS II, EN50131-2-4 Refer to Installation Manual: ISTISJCEBLC2034 1.0 European Single Point of Contact: Tyco Security Products, Voltaweg 20, 6101 XK Echt, The Netherlands ETIP1LC203 02 LC-203 COMBO PIR/MW DETECTOR WITH AM RES/COM BURG INTRUSION DETECTION UNIT cambiare versione P/N se cambia qualcosa 9.90 GHz 9.35 GHz 10.525 GHz 10.587 GHz modicare settimana/anno e frequenza

Product label location Label

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1-647-480-0200 https://www.tycosafetyproducts.com July 3, 2025 Nemko North America, Inc. 303 River Road, Ottawa, ON K1V 1H2 Canada Attn: Director of Certification Family Certification request letter We are writing to request Family Certification for the following models associated with our product: • FCC ID: F5325LC203424 • ISED Certification Number: IC: 160A-LC203424 • HVIN/Model number: LC-203E, LC-204E, LC-224 • PMNs/Model names: LC-203, LC…
