F5300NB9001Receiver

Tyco Safety Products Canada Ltd.
Receiver - FCC ID F5300NB9001 - Tyco Safety Products Canada Ltd.
Click to zoom

Application Details

Equipment Class
CYY - Communications Receiver used w/Pt 15 Transmitter
Date of Grant
Mar 13, 2000
Application Purpose
Original Equipment
Date of Application
Mar 06, 2000
Equipment Note
Receiver
Frequency Range
433.92000000 - 433.92000000
Company
Tyco Safety Products Canada Ltd.
Country
Canada

Documents & Files

Select a file to view

Users Manual

↗
↗

Attestation Statements

↗

Cover Letter(s)

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Operational Description

↗
↗

Parts List/Tune Up Info

↗
↗
↗
↗
↗
↗
↗
↗
↗
↗

Test Report

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Security Products ® WARNING This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. NT9010 NT9010NT9010 NT9010 User’s Guide CC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica- tions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Re-orient the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/television techni- cian for help. The user may find the following booklet prepared by the FCC use- ful: “How to Identify and Resolve Radio/Television Interference Problems”. This booklet is available from the U.S. Government Printing Office, Washington D.C. 20402, Stock # 004-000-00345- 4. IMPORTANT INFORMATION This equipment complies with Part 68 of the FCC Rules. On the side of this equipment is a label that contains, among other information, the FCC registration number of this equip- ment. Notification to Telephone Company The customer shall notify the telephone company of the particular line to which the connection will be made, and provide the FCC registration number and the ringer equivalence of the protective circuit. FCC Registration Number: F53CAN-xxxxx-AL-E Ringer Equivalence Number: 0.xB USOC Jack: RJ31X Telephone Connection Requirements Except for the telephone company provided ringers, all connections to the telephone net- work shall be made through standard plugs and telephone com- pany provided jacks, or equivalent, in such a manner as to allow for easy, immediate disconnection of the terminal equipment. Standard jacks shall be so arranged that, if the plug connected thereto is withdrawn, no interference to the operation of the equip- ment at the customer’s premises which remains connected to the telephone network shall occur by reason of such withdrawal. Incidence of Harm Should terminal equipment or protective cir- cuitry cause harm to the telephone network, the telephone com- pany shall, where practicable, notify the customer that temporary disconnection of service may be required; however, where prior notice is not practicable, the telephone company may temporarily discontinue service if such action is deemed reasonable in the circumstances. In the case of such temporary discontinuance, the telephone company shall promptly notify the customer and will be given the opportunity to correct the situation. Additional Telephone Company Information The security con- trol panel must be properly connected to the telephone line with a USOC RJ-31X telephone jack. The FCC prohibits customer-provided terminal equipment be connected to party lines or to be used in conjunction with coin telephone service. Interconnect rules may vary from state to state. Changes in Telephone Company Equipment or Facilities The telephone company may make changes in its communications facilities, equipment, operations or procedures, where such actions are reasonably required and proper in its business. Should any such changes render the customer’s terminal equip- ment incompatible with the telephone company facilities the cus- tomer shall be given adequate notice to the effect modifications to maintain uninterrupted service. Ringer Equivalence Number (REN) The REN is useful to deter- mine the quantity of devices that you may connect to your tele- phone line and still have all of those devices ring when your telephone number is called. In most, but not all areas, the sum of the RENs of all devices connected to one line should not exceed five (5.0). To be certain of the number of devices that you may connect to your line, you may want to contact your local tele- phone company. Equipment Maintenance Facility If you experience trouble with this telephone equipment, please contact the facility indicated below for information on obtaining service or repairs. The tele- phone company may ask that you disconnect this equipment from the network until the problem has been corrected or until you are sure that the equipment is not malfunctioning. Digital Security Controls Ltd. 160 Washburn St., Lockport, NY 14094 Quick Reference Guide The following chart lists the basic functions of your system, and the keys to press for each function. Refer to the listed page number for more information. NOTE: Some functions may not be available on your system. Ask your installer for more information. To do this:Press this:Page: Turn on system (Away):[access code], leave through entry/exit door9 OR press (if enabled) Turn on system (Stay):........................ [access code], do not leave premises12 OR press (if enabled) Turn off system:................................. [access code]10 Turn on system (No Entry Time): ........ [access code]13 Turn on system (Quick, if enabled): .... (from Ready state)12 Turn on rest of system (if Stay armed): OR press (if enabled)12 Exit premises when system on: .......... OR press (if enabled)14 Turn off zones (Bypass): ..................... [two-digit z…

Text truncated - open the document above for the full version.

Users Manual

Security Products ® NT9010 NT9010 NT9010 NT9010 v1.0 v1.0v1.0 v1.0 Installation Manual DLS-3 v1.2 and higher with Driver Pack WARNING This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. CC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Secu- rity Controls Ltd. could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installa- tion. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the inter- ference by one or more of the following measures: ‘ Re-orient the receiving antenna. ‘ Increase the separation between the equipment and receiver. ‘ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‘ Consult the dealer or an experienced radio/television technician for help. The user may find the following booklet prepared by the FCC useful: “How to Iden- tify and Resolve Radio/Television Interference Problems”. This booklet is available from the U.S. Government Printing Office, Washington D.C. 20402, Stock # 004- 000-00345-4. IMPORTANT INFORMATION This equipment complies with Part 68 of the FCC Rules. On the side of this equipment is a label that contains, among other information, the FCC regis- tration number of this equipment. Notification to Telephone Company The customer shall notify the telephone company of the particular line to which the connection will be made, and pro- vide the FCC registration number and the ringer equivalence of the protective circuit. FCC Registration Number: F53CAN-xxxx-AL-E Ringer Equivalence Number: 0.xB USOC Jack: RJ31X Telephone Connection Requirements Except for the telephone company pro- vided ringers, all connections to the telephone network shall be made through standard plugs and telephone company provided jacks, or equivalent, in such a manner as to allow for easy, immediate disconnection of the terminal equipment. Standard jacks shall be so arranged that, if the plug connected thereto is with- drawn, no interference to the operation of the equipment at the customer’s pre- mises which remains connected to the telephone network shall occur by reason of such withdrawal. Incidence of Harm Should terminal equipment or protective circuitry cause harm to the telephone network, the telephone company shall, where practicable, notify the customer that temporary disconnection of service may be required; however, where prior notice is not practicable, the telephone company may temporarily dis- continue service if such action is deemed reasonable in the circumstances. In the case of such temporary discontinuance, the telephone company shall promptly notify the customer and will be given the opportunity to correct the situation. Additional Telephone Company Information The security control panel must be properly connected to the telephone line with a USOC RJ-31X telephone jack. The FCC prohibits customer-provided terminal equipment be connected to party lines or to be used in conjunction with coin telephone service. Interconnect rules may vary from state to state. Changes in Telephone Company Equipment or Facilities The telephone com- pany may make changes in its communications facilities, equipment, operations or procedures, where such actions are reasonably required and proper in its busi- ness. Should any such changes render the customer’s terminal equipment incom- patible with the telephone company facilities the customer shall be given adequate notice to the effect modifications to maintain uninterrupted service. Ringer Equivalence Number (REN) The REN is useful to determine the quantity of devices that you may connect to your telephone line and still have all of those devices ring when your telephone number is called. In most, but not all areas, the sum of the RENs of all devices connected to one line should not exceed five (5.0). To be certain of the number of devices that you may connect to your line, you may want to contact your local telephone company. Equipment Maintenance Facility If you experience trouble with this telephone equipment, please contact the facility indicated below for information on obtaining service or repairs. The telephone company may ask that you disconnect this equipment from the network until the problem has been corrected or until you are sure that the equipment is not malfunctioning. Digital Security Controls Ltd. 160 Washburn St., Lockport, NY 14094 AVIS: L’étiquette de l’Industrie Canada identifie le matériel homologué. Cette étiquette certifie que le matériel est conforme à certaines normes de protection, d’exploitation et de sécurité des réseaux de télécommunications. Industrie Canada n’assure toutefois pas que le matériel fonctionnera à la sat- isfaction de l’utilisateur. Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le raccorder aux installations de l’entreprise locale de télécommunication. Le matériel doit également être installé en suivant une méthode acceptée de raccordement. L’abonné ne doit pas oublier qu’il est possible que la confor- mité aux conditions énoncées ci-dessus n’empêchent pas la dégradation du service dans certaines situations. Les réparations de matériel homologué doivent être effectuées par un…

Text truncated - open the document above for the full version.

Cover Letter(s)

March 2, 2000 Office of Engineering & Technology Federal Communications Commission Washington, D.C. 20554 Subject:Request for continuous confidentiality of technical information per sections 0.459 and 0.457 (d) (2) ( I) of CFR 47. FCC ID:F5300NB9001 Dear Sir or Madam: Digital Security Controls Canada Ltd. is hereby filing this request for continuous confidentiality of the specified items submitted with the application for certification ( Form731 ) with proposed identifier F5300NB9001. The technical documentation for which continuous confidentiality is sought is: (1) Schematic diagrams: This technical documentation is a part of the material supporting the Form 731 application for certification, which this request for confidentiality accompanies. The schematic diagrams disclose proprietary information and technical data which Digital Security Controls Ltd. would guard from its competitors and would not make available to the public. This proprietary information constitutes a trade secret and is not a part of the product documentation that would be made available to the customers of Digital Security Controls Ltd. It would be potentially injurious to Digital Security Controls Ltd. and to its investment in the development of this innovative proprietary product to make available for public disclosure the trade secret technical information specified in this request. If there are any questions about this request for continuous confidentiality regarding trade secrets and proprietary information embodied in the technical documentation filed in support of this Form 731 application, then please contact me via our toll-free telephone number. Yours truly, Kevin Harris Approval Services Manager 905-760-3000 Ext. 2378 Email: [email protected]

ID Label/Location Info

2" 1" FCC REG. NO.: F53CAN-34664-AL-EREN: 0.4B FCC ID: F5300NB9001Digital Security Controls Ltd. MODEL NO.: NT9010-433MADE IN CANADA IC:RSS/CNR 210 CANADA: 160 XXX XXXX This device complies with Part 15 and Part 68 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 00844FRABS FCC REG. NO.: F53CAN-34664-AL-E REN: 0.4B FCC ID: F5300NB9001 Digital Security Controls Ltd. MODEL NO.: NT9010-433 MADE IN CANADA IC:RSS/CNR 210 CANADA: 160 XXX XXXXThis device complies with Part 15 and Part 68 of theFCC Rules. Operation is subject to the following twoconditions: (1) This device may not cause harmfulinterference, and (2) this device must accept anyinterference received, including interference that maycause undesired operation. 00844FRABS The FCC/IC labeling is to be located on the top of the rear housing (08000844) of the unit as shown above. This illustration and labeling are shown 50% of the actual size. DIGITAL SECURITY CONTROLS LTD. ISO 9001 Registered 3301 Langstaff Road, Concord Ontario, Canada L4K 4L2 Phone: 905-760-3000 Toll Free: 1-888-888-7838 Fax: 905-760-3030 TM FCC / IC Labeling for NT9010-433 Wireless Control Unit File: [NT9010-433 rear housing with fcc+ic info 08000844.cdr] March 1, 2000 Labeling shown above is 100% ofactual size

ID Label/Location Info

2" 1" FCC REG. NO.: F53CAN-34664-AL-EREN: 0.4B FCC ID: F5300NB9001Digital Security Controls Ltd. MODEL NO.: PNT9010-433MADE IN CANADA IC:RSS/CNR 210 CANADA: 160 XXX XXXX This device complies with Part 15 and Part 68 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC REG. NO.: F53CAN-34664-AL-E REN: 0.4B FCC ID: F5300NB9001 Digital Security Controls Ltd. MODEL NO.: PNT9010-433 MADE IN CANADA IC:RSS/CNR 210 CANADA: 160 XXX XXXXThis device complies with Part 15 and Part 68 of theFCC Rules. Operation is subject to the following twoconditions: (1) This device may not cause harmfulinterference, and (2) this device must accept anyinterference received, including interference that maycause undesired operation. The FCC/IC labeling is to be located on the top of the rear housing of the unit as shown above. This illustration and labeling are shown 50% of the actual size. DIGITAL SECURITY CONTROLS LTD. ISO 9001 Registered 3301 Langstaff Road, Concord Ontario, Canada L4K 4L2 Phone: 905-760-3000 Toll Free: 1-888-888-7838 Fax: 905-760-3030 TM FCC / IC Labeling for PNT9010-433 Wireless Control Unit File: [PNT9010-433 fcc+ic labeling.cdr] March 1, 2000 Labeling shown above is 100% ofactual size

Operational Description

_________________________________________________________________________________ Digital Security Controls 3301 Langstaff Road, Concord Ontario, Canada. L4K 4L2 Tel: (905) 760 3000 1-888-888-7838 Fax: (905) 760-3020 February 23 rd , 2000 Equipment Description Device: NT9010-433 Description: The NT9010-433 is a self contained alarm system which have support for 32 programmable zones. These zones are all wireless with the exception of the two on board hardwire loops (Z1 and Z2 with Black as the return loop). The NT9010-433 also has a built in Communicator (terminals for Tip/Ring and T1/R1) with a four wire bus for a Remote Sounder (to be submitted at a later date). The NT9010-433 only has a single partition, with no Programmable outputs. It is intended for Mass Market installations where the amount of time required to install the product is minimal. All programming and status information is annunciated verbally via the on-board speaker. The NT9010-433 operates at 433.92 MHz narrowband. This panel is capable of DTMF, FSK, and BPS communications. _________________________________________________________________________________

Operational Description

_________________________________________________________________________________ Digital Security Controls 3301 Langstaff Road, Concord Ontario, Canada. L4K 4L2 Tel: (905) 760 3000 1-888-888-7838 Fax: (905) 760-3020 February 23 rd , 2000 Equipment Description Device: PNT9010-433 Description: The PNT9010-433 is a self contained alarm system which have support for 32 programmable zones. These zones are all wireless with the exception of the two on board hardwire loops (Z1 and Z2 with Black as the return loop). The PNT9010-433 also has a built in Communicator (terminals for Tip/Ring and T1/R1) with a four wire bus for a Remote Sounder (to be submitted at a later date). The PNT9010-433 only has a single partition, with no Programmable outputs. It is intended for Mass Market installations where the amount of time required to install the product is minimal. All programming and status information is annunciated verbally via the on-board speaker. The PNT9010-433 operates at 433.92 MHz narrowband. This panel is capable of DTMF, FSK, and BPS communications. _________________________________________________________________________________

Test Report

Master: ktlPT15BR Date: October 8, 1999 KTL Test Report:9R02287 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Vaughn, Ontario L4K 4L2 Equipment Under Test:NT9010-433 & PNT9010-433 Receiver (E.U.T.) FCC ID:F5300NB9001 In Accordance With:FCC Part 15, Subpart B Radio Receivers Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: R. Grant, Wireless Group Manager Date: Total Number of Pages:16 KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02287 EQUIPMENT: NT9010-433 & PNT9010-433 Receiver FCC ID: F5300NB9001 Page 2 of 16 Table Of Contents Section 1. Summary of Test Results.............................................................................................3 Section 2. Equipment Under Test (E.U.T.).................................................................................. 5 Section 3. Radiated Emissions ..................................................................................................... 6 Section 4. Powerline Conducted Emissions................................................................................. 9 Section 5. Block Diagrams......................................................................................................... 14 Section 6. Test Equipment List..................................................................................................16 KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02287 EQUIPMENT: NT9010-433 & PNT9010-433 Receiver FCC ID: F5300NB9001 Page 3 of 16 Section 1.Summary of Test Results General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15, Subpart B. Measurement procedure ANSI C63.4-1992 was used for all tests. Radiated Emissions were measured on an open area test site. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit CYY Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Glen Westwell, Technologist KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02287 EQUIPMENT: NT9010-433 & PNT9010-433 Receiver FCC ID: F5300NB9001 Page 4 of 16 Summary Of Test Data Name Of TestPara. No.Results Radiated Emissions15.109Complies Powerline Conducted Emissions15.107Complies Footnotes For N/A’s: Test Conditions: Indoor Temperature: 24 °C Humidity:20 % Outdoor Temperature: 5 °C Humidity:30 % KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02287 EQUIPMENT: NT9010-433 & PNT9010-433 Receiver FCC ID: F5300NB9001 Page 5 of 16 Section 2.Equipment Under Test (E.U.T.) Manufacturer:Digital Security Controls Ltd. Model No.:NT9010-433 Serial No.:None Date Received In Laboratory: February 24, 2000 KTL Identification No.: Item #2 Equipment Details Frequency Range:433.92 MHz (Fixed) Number of Channels:1 Operating Frequency(ies) of Sample:433.92 MHz Crystal Frequency(ies):Local Oscillator = 423.22 MHz Primary Power Requirement:120 VAC Intermediate Frequency(ies):10.7 MHz KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02287 EQUIPMENT: NT9010-433 & PNT9010-433 Receiver FCC ID: F5300NB9001 Page 6 of 16 Section 3.Radiated Emissions NAME OF TEST: Radiated EmissionsPARA. NO.: 15.109(a) TESTED BY: Glen WestwellDATE: February 25, 2000 Minimum Standard: Frequency(MHz)Field Strength (dB μ μμ μ V/m @ 3m) 30 - 8840.0 88 - 21643.5 216 - 96046.0 Above 96054.0 Test Results: Complies. The worst-case emission level is 41.5 dBμV/m @ 3m at 846.44 MHz. This is 4.5 dB below the specification limit. Measurement Data: See attached table. For super-regenerative receivers the receiver is cohered using a signal generator and dipole antenna. Handheld equipment and equipment not designed to be mounted in any fixed orientation, the E.U.T. is tested in three orthogonal axis to obtain worst case results. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02287 EQUIPMENT: NT9010-433 & PNT9010-433 Receiver FCC ID: F5300NB9001 Page 7 of 16 Test Data - Radiated Emissions Test Distance (meters) : Range :Re ce ive r:RBW(kHz ):De te ctor: Fre q. (M Hz) Ant. * Pol. (V/H) Ant. HGT. (m) Table (deg.) RCVD Signal (dB μ μμ μ V/m) Ant. Factor (dB)** Amp. Gain (dB)*** Dist. Corr. (dB) Fie ld Strength (dB μ μμ μ V/m) Limit (dB μ μμ μ V/m) Margin (dB) 423.22E/D4V10.125.735.846.010.2 423.22E/D4H10.425.736.146.09.9 846.44E/D4V5.334.339.646.06.4 846.44E/D4H7.234.341.546.04.5 Notes: B/C = Biconical, B/L = Biconilog, L/P = Log-Periodic, H = Horn, D/P = Dipole * Re-measured using dipole antenna. ( ) Denotes failing emission level. (1) 120 kHz, Q-Peak, (2) 10 kHz, Peak, (3) 100 kHz RGW, 300 kHz VBW, Peak, (4) 300 kHz RBW, 1 MHz VBW, Peak, (5) 1 MHz RBW, 3 MHz VBW, Peak, (6) 1 MHz RBW, 10 Hz VBW, Peak Spectrum searched to 2 GHz No other emissions detected. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02287 EQUIPMENT: NT9010-433 & PNT9010-433 Receiver FCC ID: F5300NB9001 Page 8 of 16 Radiated Photographs(Worst Case Configuration) Front View Rear View KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02287 EQUIPMENT: NT9010-433 & PNT9010-433 Receiver FCC ID: F5300NB9001 Page 9 of 16 Section 4.Powerline Conducted Emissions NA…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Dan Nita(Approvals Manager)
[email protected]1-647-480-0430Fax: 1-647-480-0531

Technical Contact

KTL Ottawa Inc.Ruby C Dulmage
[email protected]1-800-563-6336

3325 River Road · Ottawa · Canada

Non-Technical Contact

KTL Ottawa Inc.Ruby C Dulmage
[email protected]1-800-563-6336

Test Firm

Nemko Canada Inc.Stuart Beck
[email protected]613-737-9680Fax: 613-737-9691

Technical Specifications

#Rule PartsFrequency RangePower Output
115B433.92 MHz - 433.92 MHz-
Confidentiality
Long Term
