F5300NB904Wireless Motion Detector

Each WLS904 motion detector should be located so that it provides optimal coverage of the intended area. Refer to Changing Motion Detector Lenses below for information on the four lenses available for the WLS904 Motion Detector. When locating motion detectors, observe the following: • For the Wall-to-Wall, Corridor and Curtain Lenses, the Mounting Height should be 6-10 ft./ 2-3 m from the floor. The nominal mounting height is 7.5 ft./ 2.3 m. • For the Pet Alley Lens only, the Mounting Height should be 4-5 ft./1.2-1.5m from the floor. • Do not aim the detector at reflective surfaces such as mirrors or windows. This may distort the coverage pattern or reflect sunlight directly onto the detector. Avoid locations where the detector may be exposed to direct or reflected sunlight. • Avoid locations that are subject to direct air flow, such as near an air duct outlet. • Do not locate the detector near sources of steam or oil vapor, such as a stove or fryer. • Do not obscure the Detector’s coverage pattern with large objects within the detection area. If you can’t see the detector, it can’t see you. • For indoor use only • Dead zone 6”/15 cm NOTE: No detector should be mounted without first performing a module placement test to determine that it is in range of the wireless receiver. See the Placement Test instructions in the Instruction Sheet for your receiver, or in the installation manual for your system. When a location has been determined, remove the plastic from the mounting holes and locate the backplate on the wall and mark screw locations. It is suggested that wall anchors be used for all screw locations. Secure the backplate to the wall, and then secure the enrolled Detector to its backplate. ©1999 Digital Security Controls Ltd. Printed in Canada 29003038 R001 INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Battery Installation •This system is designed to work with Eveready Alkaline Energizer Batteries. Do not install any other type. The reliability of the security system depends on its batteries, and “no name” or generic brand batteries may not provide the best quality and dependability. • Use fresh batteries. Most batteries have a “best before” date printed on their packaging or on the batteries themselves. Buy batteries that have a “best before” date of two years or more from your purchase date. • When disposing of used batteries, follow the instructions and precautions printed on the batteries. Many cities and communities have collection sites or services for used household batteries. Contact your municipal offices for information on the disposal of used batteries. Remove the motion detector from its mounting plate by holding the sensor by its sides and pushing up. Install four fresh Eveready Alkaline Energizer AAA batteries. Be sure to insert the batteries in the proper orientation. Replace the sensor on its mounting plate, making sure it snaps into place. After all the batteries are installed, the detector will take 60 seconds to warm up. During this time the LED will flash slowly. Limited Warranty Digital Security Controls Ltd. warrants that for a period of twelve months from the date of purchase, the product shall be free of defects in material and workmanship under normal use and that in fulfilment of any breach of such warranty, Digital Security Controls Ltd. shall, at its option, repair or replace the defective equipment upon return of the equipment to its repair depot. This warranty applies only to defects in parts and workmanship and not to damage incurred in shipping or handling, or damage due to causes beyond control of Digital Security Controls Ltd. such as lightning, excessive voltage, mechanical shock, water damage, or damage arising out of abuse, alteration or improper application of the equipment. The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties, whether express or implied and of all other obligations or liabilities on the part of Digital Security Controls Ltd. This warranty contains the entire warranty. Digital Security Controls Ltd. neither assumes, nor authorizes any other person purporting to act on its behalf to modify or to change this warranty, nor to assume for it any other warranty or liability concerning this product. In no event shall Digital Security Controls Ltd. be liable for any direct , indirect or consequential damages, loss of anticipated profits, loss of time or any other losses incurred by the buyer in connection with the purchase, installation or operation or failure of this product. Warning: Digital Security Controls Ltd. recommends that the entire system be completely tested on a regular basis. However, despite frequent testing, and due to but not limited to, criminal tampering or electrical disruption, it is possible for this product to fail to perform as expected. • W A R N I N G • Please refer to the System Installation Manual for information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. CORNER MOUNTING KNOCKOUTS ENSURE PROPER ORIENTATION OF BACKPLATE. MOUNTING HOLE KNOCKOUTS Motion Detector Backplate WLS904-418 WLS904-433 Wireless Motion Detector Changing Motion Detector Lenses Each motion detector is supplied with the Wall-to-Wall lens; three additional lenses are available for the WLS904 motion detector. The charts on this page illustrate the range and coverage patterns of each lens. To change the lens, first open the motion detector by removing the screw in the bottom of the battery compartment. With the screw removed, pull the back of the detector away from the front case. NOTE: The coils and antenna on the motion detector circuit board are very sensitive components precisely adjusted for maximum performance. Do not touch the coils or antenna! Even minor distortions can affect the performance of the motion dete…

Text truncated - open the document above for the full version.

April 12, 2000 Office of Engineering & Technology Federal Communications Commission Washington, D.C. 20554 Subject:Request for continuous confidentiality of technical information per sections 0.459 and 0.457 (d) (2) ( I) of CFR 47. FCC ID:F5300NB904 Dear Sir or Madam: Digital Security Controls Canada Ltd. is hereby filing this request for continuous confidentiality of the specified items submitted with the application for certification ( Form731 ) with proposed identifier F5300NB904. The technical documentation for which continuous confidentiality is sought is: (1) Schematic diagrams: This technical documentation is a part of the material supporting the Form 731 application for certification, which this request for confidentiality accompanies. The schematic diagrams disclose proprietary information and technical data which Digital Security Controls Ltd. would guard from its competitors and would not make available to the public. This proprietary information constitutes a trade secret and is not a part of the product documentation that would be made available to the customers of Digital Security Controls Ltd. It would be potentially injurious to Digital Security Controls Ltd. and to its investment in the development of this innovative proprietary product to make available for public disclosure the trade secret technical information specified in this request. If there are any questions about this request for continuous confidentiality regarding trade secrets and proprietary information embodied in the technical documentation filed in support of this Form 731 application, then please contact me via our toll-free telephone number. Yours truly, Kevin Harris Approval Services Manager 905-760-3000 Ext. 2378 Email: [email protected]

Offices In Hull (UK), Ottawa (Canada), Dallas (USA) And Arnhem (The Netherlands) April 14, 2000 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, Maryland 21046 USA KTL 3325 River Road RR #5 Ottawa, Ontario Canada K1V 1H2 Tel: 613-737-9680 Fax: 613-737-9691 Toll Free: 1-800-563-6336 Email: [email protected] Internet: www.ktl.com Dear Sir/Madam:Our File Ref. 9R02127 FCC ID: F5300NB904 Applicant: Digital Security Controls Ltd. Equipment: WLS904NB433 Wireless Motion Detector FCC Confirmation no.: EA97358 We have successfully electronically filed all the required documentation for an application for certification in accordance with FCC Part 15 on the above mentioned equipment, April 14, 2000. Enclosed, please find a copy of FCC Remittance Form 159 (Paid electronically by VISA), a copy of the FCC Form 731 confirmation number and a copy of the list of exhibits. If you require additional information, please do not hesitate to contact me at 1-800-563-6336 (extension 232). Thank you in advance for your assistance in this matter. Sincerely, Ruby Dulmage Regulatory Submissions Clerk KTL Ottawa Inc. [email protected] Encl.

Digital Security Controls Ltd.ISO9001 Registered3301 Langstaff Road, ConcordOntario, Canada L4K 4L2Phone: 905-760-3000Toll Free: 1-888-888-7838Fax: 905-760-3030 TM FCC/IC Labeling for Transmitter WLS904NB433 PIR TOP OF THE UNIT SHOWING PLACEMENT OF LABEL (ACTUAL SIZE) (THE UNIT SHOWN ATTACHED TO MOUNTING BRACKET) File: [wls904nb433 fcc+ic lb 1800XXXX r001.cdr] March 10, 2000 FCC ID: F5300NB904 Model: WLS904NB433 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-ditions: (1) This device may not cause harmful interference, and (2) this device must accept anyinterference received, including interference that may cause undesired operation.IC: RSS/CNR210 CANADA: 160 XXX XXXX MADE IN CANADA 1800XXXX R001 This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numériquede la classe B respecte toutes les exigences du ICES-003. DASHED LINE INDICATESCUT EDGE OF LABELLABEL TO BE PRINTEDON SELF-ADHESIVE MATERIALLABEL SHOWN 250% ACTUAL SIZE 44.5 mm 9.5 mm

LED U6 J1 X2 D2 C1 C30 ANT2 ANT3 ANT1 C38 C37 C36 C35 C34 C33 C32 X1 VB- VB+ Rev 02 SLOW FAST MADE IN CANADA DSC UA073 11SEP98 02 UA073 will cause irrepairable harm, which will be actionable by sitive and confidential nature. It is being divulged to A DATEAPPROVED BYINITIATORREVISION APPROVALS us against you. you on the understanding that any improper disclosure Controls Ltd. and contains information of a highly sen- This document is the private property of Digital Security CONFIDENTIAL DOCUMENT 00000-00- 1:1 0 Sheet/layer DWG# Scale DateDrawn by Originator FinishProject # File RevTitle ONTARIO, CANADA M3J 2J6 1645 FLINT RD, DOWNSVIEW DIGITAL SECURITY CONTROLS LTD. 3 of COMP SIDE TP76 TP77 TP29 TH1 TP30 TP28 TP27 TP26 TP25 TP24 TP23 TVB TGD TP15 TP13 TP12 TP11 TP14 TP9 TP5 TH2 TH3 TP31 TP4 TP3 TP2 TP79 TP78 TP20 TP21 TP19 TP18 TP17 TP75 TP74 TP73 TP72 TP71 TP70 TP69 TP67 TP66 TP65 TP64 TP63 TP62 TP61 TP60 TP59 TP58 TP56 TP55 TP54 TP53 TP50 TP49 TP48 TP47 TP46 TP45 TP44 TP43 TP42 TP41 TP40 TP39 TP38 TP37 TP36 TP35TP34 TP33 TP32 TP51 TP80 D5 D4 D3 U8 8 L10 8 L12 THM1 TP22 U3 U2 U5 Q5 Q4 Q1 Q8 C54 C53 C12 C24 C15 C2 C17 C21 C4 C51 C50 C49 C48 C47 C46 C45 C44 C43 C42 C41 C40 C39 C27 C31 C26 C28 C29 C3 C20 C19 C16 C18 C5 C25 C6 C7 C9 C8 C10 C14 C52 C55 C11 C56 C22 C23 R66 R62 R61 R60R59 R58 R57 R56 R55 R54 R53 R52 R51 R50 R49 R48 R47 R45 R44 R43 R42 R41 R40 R39 R38 R37 R36 R35 R34 R33 R32 R31 R28 R27 R26 R29 R22 R16 R15 R24 R1 R5 R63 R14 R21 R19 R18 R17 R4 R3R2 R20R13 R9R8 R10 R12 R11 R25 R23 R65 R64 R68 R67 10 L8 10 L13 10 L11 U1 Q7 Q6 Q2 Q9 Q3 6 L9 6 L7 6 L6 6 L4 3 L5 3 L1 3 L3 THM2 U7 U55 U4 NC C NO UA073 REV 02 02 11MAR98 UA073 will cause irrepairable harm, which will be actionable by sitive and confidential nature. It is being divulged to A DATEAPPROVED BYINITIATORREVISION APPROVALS us against you you on the understanding that any improper disclosure Controls Ltd. and contains information of a highly sen- This document is the private property of Digital Security CONFIDENTIAL DOCUMENT 00000-00-DWG# 1:10 Originator Sheet/layer Scale FinishProject # DateDrawn byFile Title Rev ONTARIO, CANADA M3J 2J6 1645 FLINT RD, DOWNSVIEW DIGITAL SECURITY CONTROLS LTD. 5 of SOLDER SIDE KK M M M X X U U U U U U U U U U U U 11SEP98 02 UA073 will cause irrepairable harm, which will be actionable by sitive and confidential nature. It is being divulged to A DATEAPPROVED BYINITIATORREVISION APPROVALS us against you. you on the understanding that any improper disclosure Controls Ltd. and contains information of a highly sen- This document is the private property of Digital Security CONFIDENTIAL DOCUMENT 00000-00- 1:1 0 Sheet/layer DWG# Scale DateDrawn by Originator FinishProject # File RevTitle ONTARIO, CANADA M3J 2J6 1645 FLINT RD, DOWNSVIEW DIGITAL SECURITY CONTROLS LTD. PALLET SIZE = 33.536 SQ.IN. PCB SIZE = 6.362 SQ.IN. ALL CIRCUIT BOARDS MUST MEET IPC CLASS 2 AND DSC INCOMING Max 0.030" Min 0.025" PCB Score line 0.018" U T PLATED THRU 0.090" P R -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 -0.003 +0.003 N 0.100" 0.100" O 0.073" M L K MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE MOUNTING HOLE J 1 of UV CURED SOLDER MASK IS NOT ACCEPTABLE. PRINTED CIRCUIT BOARD REQUIREMENTS QST 001. DRILL PATTERN MATERIAL: FR4 0.059" 1oz COPPER CENTER UNLESS OTHERWISE SPECIFIED (NOT PLATED) C B A 0.080"X 0.400 0.080"X 0.250 0.080"X 0.200 NOTE 2: NOT ON DRILL TAPE, ROUTE WITH 0.080"BIT CENTER TO 0.080" -0.005 +0.005 -0.005 +0.005 -0.005 +0.005 -0.005 +0.005 SEE NOTE #2SLOT SLOT SLOT SLOT NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU NOT PLATED THRU -0.000 +0.003 -0.000 +0.003 -0.000 +0.003 -0.000 +0.003 TOOLING HOLE TOOLING HOLE TOOLING HOLE 0.187" 0.156" 0.125" 0.125" 0.118" 0.080" 0.080" 0.066" 0.066" 0.060" 0.060" 0.047" 0.047" 0.043" 0.038" 0.032" PLATED THRU PLATED THRU VIA VIA 0.022" PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU PLATED THRU VIA0.028" REMARKTOLERANCETYPESIZESYMBOL DRILL CODE INFORMATION 0.200" 0.137" MOUNTING HOLE S 2 PLATED SLOTS (0.040x0.100)

Master: ktlPT15231 Date: October 8, 1999 KTL Test Report:9R02127 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Concord, Ontario L4K 4L2 Equipment Under Test:WLS904NB433 Wireless Motion Detector (E.U.T.) FCC ID:F5300NB904 In Accordance With:FCC Part 15, Subpart C For Low Power Transmitters Operating Periodically In The Band 40.66 - 40.77 MHz And Above 70 MHz Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: K. Carr, Technologist Date: Total Number of Pages:23 KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02127 EQUIPMENT: WLS904NB433 Wireless Motion Detector FCC ID: F5300NB904 Page 2 of 21 Table of Contents Section 1. Summary of Test Results.............................................................................................3 Section 2. Equipment Under Test (E.U.T.).................................................................................. 5 Section 3. Transmission Requirements ...................................................................................... 11 Section 4. Radiated Emissions ...................................................................................................14 Section 5. Occupied Bandwidth................................................................................................. 17 Section 6. Block Diagrams......................................................................................................... 19 Section 7. Test Equipment List..................................................................................................21 Annex A Restricted Bands.............................................................................................................A1 KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02127 EQUIPMENT: WLS904NB433 Wireless Motion Detector FCC ID: F5300NB904 Page 3 of 21 Section 1.Summary of Test Results Manufacturer:Digital Security Controls Ltd. Model No.:WLS904NB433 Serial No.:None Date Received In Laboratory: February 24, 2000 KTL Identification No.: Item #1 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.231. All tests were conducted using measurement procedure ANSI C63.4-1992. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit DS C Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: DATE: Russell Grant, Wireless Group Manager TESTED BY: Glen Westwell DATE: April 14, 2000 Technologist KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of s uc h thir d par ties . KT L Ottaw a Inc. accepts no responsibility f or damages , if any, s uf f er ed by any thir d par ty as a r es ult of dec is ions made or ac tions bas ed on this r epor t. T his r eport applies only to the items tested. KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02127 EQUIPMENT: WLS904NB433 Wireless Motion Detector FCC ID: F5300NB904 Page 4 of 21 Summary Of Test Data Name of TestParagraph NumberResults Transmission Requirements15.231(a)Complies Radiated Emissions15.231(b)Complies Occupied Bandwidth15.231(c)Complies Frequency Tolerance15.231(d)Not Applicable Periodic Alternate Field Strength Requirements15.231(e)Not Applicable Powerline Conducted Emissions15.207Not Applicable Footnotes For N/A’s: This equipment is battery operated. Test Conditions: Indoor Temperature: 20 °C Humidity:20 % Outdoor Temperature: 10 °C Humidity:20 % KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02127 EQUIPMENT: WLS904NB433 Wireless Motion Detector FCC ID: F5300NB904 Page 5 of 21 Section 2.Equipment Under Test (E.U.T.) General Equipment Information Frequency Range: 433.92 MHz Operating Frequency(ies) of Sample: 433.92 MHz Type of Emission: Pulse Width Modulation Emission Designator: 75K0L1D (See Attached Graph) Supply Power Requirement: 4 x 1.5 V AAA Batteries Duty Cycle Calculation: -16.6 dB (See attached description of duty cycle calculation and time domain graphs) KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02127 EQUIPMENT: WLS904NB433 Wireless Motion Detector FCC ID: F5300NB904 Page 6 of 21 KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02127 EQUIPMENT: WLS904NB433 Wireless Motion Detector FCC ID: F5300NB904 Page 7 of 21 Data Transmission Format The transmitted data packet is a fixed length, amplitude modulated packet. The packet contains all of the necessary information to indicate which sensor generated the packet, the type of sensor and the status of the sensor’s inputs. The data is sent at a rate of 500 μS per bit or 2 Kbits per second. Figure 1 shows the bit timing used for all bits in the packet. Where a low logic present for the 500 μS bit time represents a data logic “0” and 250 μS low then 250 μS high represents a data logic “1”. Figure 1: Bit Timing Figure 2 shows the format of the transmitted data packet. Bytes highlighted are bytes that are variable information that would depend on the current status, module type and serial number of the particular device. Figure 2: Data Packet Format Because these bytes are variable there is a best and worst case packet when considering ON time. 250 μ S250 μ S 500 μ S bit time : data logic "0" 500 μ S bit time : data logic "1" 250 μ S250 μ S Sync bits (4 bits) Status Byte …

Text truncated - open the document above for the full version.
