F5300NB906Smoke Detector

Introduction The DSC Meridian Photoelectric Smoke Detector incorporates many advanced design features to provide years of reliable operation. It is important to follow the Installation and Operation instructions on this sheet to ensure that the unit will function properly — even the best designed smoke detector will be rendered useless if it is not connected or located properly. It is very important that you understand how to test and maintain your system. Read the Instruction or User Manual for your alarm system to familiarise yourself with the Fire Alarm functions. Be sure to test your system regularly following the test procedures described in your manual. If you should ever have problems operating or testing your system, and especially if there are problems with the Fire Alarm functions, contact your Smoke Detector Installer or Dealer immediately for service. While smoke detectors and alarm systems are designed to warn you of potentially dangerous situations, no system can prevent emergencies. An alarm system is not a substitute for life and property insurance; you should always maintain appropriate insurance coverage. How the Smoke Detector Works As shown in the illustration, a light source is directed across the smoke chamber and is not normally reflected into the sensing element. When smoke enters the chamber, the light beam is scattered by the smoke and is reflected into the sensor. When enough light is detected by the sensor, an alarm is activated. On alarm, the Sounder is activated and the red LED will flash. When the smoke clears from the smoke chamber, the unit will automatically reset itself. Alarm Indications ConditionSounderIndicatorRF LightTransmission No SmokeSilentFlash everySupervision 40-50 stransmission every 12 min. SmokeAlarmFlash everyAlarm 0.67 stransmission Automatic Self TestSilentFlash everySupervision Functioning Normally40-50 s transmission every 12 min. Automatic Self TestChirp betweenFlash everyFire Trouble Insufficient Sensitivity LED flashes40-50 stransmission Push-button TestAlarmFlash everySupervision Functioning Normally0.67 stransmission every 12 min. Push-button TestSilentFlash everyFire Trouble Insufficient Sensitivity40-50 s transmission Magnet-Reed-SwitchAlarmFlash everyAlarm Test Functioning Normally0.67 stransmission Magnet-Reed-SwitchSilentFlash everyFire Trouble Test Insufficient40-50 stransmission Sensitivity Low BatteryChirp simultaneousFlash everyFire Trouble with LED flash40-50 stransmission READ THIS INSTRUCTION SHEET THOROUGHLY BEFORE INSTALLING AND USING YOUR MERIDIAN SMOKE DETECTOR Features • Advanced 90° photoelectric detection pattern and specially designed smoke chamber ** ** * for superior detection and dust resistance • Unique high signal-to-noise ratio and superior RFI immunity to prevent false alarms • Excellent smoke access provides reliable detection for all smoke flow directions and velocities • Loud 85dB piezoelectric alarm horn • Battery-powered design for easy installation and independence from house power sources • Uses six AA batteries and special circuit design to provide extra long battery life • Solid-state LED indicator light (red) • Visible flash light and audible trouble chirp for low battery warning • Equipped with an RF transmitter, WLS906 can communicate with compatible DSC Wireless Security Systems • Test Button allows user to perform sensitivity test and get a local indication of test result • Magnet-activated reed-switch allows user to perform system test • Battery removal sensor alerts user to missing battery and prevents installation of detector when no battery is installed • Automatic self-test once every 40 seconds provides an audible trouble indication if the unit has insufficient smoke sensitivity • Attractive styling for any decor ** ** * Protected under Canadian Patent No. 1452296. Other patents pending. WLS906-433 Battery-Powered Smoke Detectors For Residential Use INSTRUCTIONS FOR INSTALLATION AND USE Limitations of Smoke Detectors While the Meridian Smoke Detector has been designed for reliability, it is important to know that all smoke detectors have limitations. • Smoke detectors will not work without power. If the batteries are low, the smoke detector will not function. See “ Battery Installation” below for important information on battery use. • Smoke detectors can only generate an alarm when smoke gets inside the Smoke Chamber; anything that prevents smoke from entering the Smoke Chamber may prevent or delay an alarm. Refer to the Guidelines for Locating Smoke Detectors on this Instruction Sheet; it is important that smoke detectors be located on at least every floor of the premises, preferably in every room. It is also important to avoid obstructions, such as closed doors, that may prevent smoke from reaching the unit. A smoke detector will not detect a fire in the walls, in the chimney or on the roof of a building until smoke enters the Smoke Chamber. • Smoke detectors have certain obvious limitations: they may not provide protection for someone smoking in bed, for children playing with matches, or for sudden and violent explosions. A smoke detector is a single part of overall fire safety precautions; the smoke detector should never be seen as a substitute for a complete fire safety program. Guidelines for Locating Smoke Detectors Research has shown that all hostile fires in homes generate smoke to a greater or lesser extent. Experiments with typical fires in homes indicate that detectable quantities of smoke precede detectable levels of heat in most cases. For these reasons, smoke detectors should be installed outside of each sleeping area and on each storey of the home. The following information is for general guidance only and it is recommended that local fire codes and regulations be consulted when locating and installing smoke detectors. It is recommended that additional smoke detectors beyond those required for minimum protection be installed. Additional areas that should be protected…

Text truncated - open the document above for the full version.

How the Smoke Detector Works Normally, light pulses in the Smoke Chamber do not reach the light sensor. Smoke in the Smoke Chamber deflects light into the light sensor, triggering an alarm. As shown in the illustration, a light source is directed across the smoke chamber and is not normally reflected into the sensing element. When smoke enters the chamber, the light beam is scattered by the smoke and is reflected into the sensor. When enough light is detected by the sensor, an alarm is activated. On alarm, the sounder is activated and the red LED will flash. When the smoke clears from the smoke chamber, the unit will automatically reset itself. Alarm Indications ConditionSounderIndicatorRF LightTransmission No smokeSilentFlash everySupervision transmission 40-50 severy 12 min. for Europe / every 64 min. for North America SmokeAlarmFlash everyAlarm 0.67 stransmission Automatic self testSilentFlash everySupervision transmission functioning normally40-50 severy 12 min. for Europe / every 64 min. for North America Automatic self testChirp betweenFlash everyFire Trouble insufficient sensitivity LED flashes40-50 stransmission Push-button testAlarmFlash everySupervision transmission functioning normally0.67 severy 12 min. for Europe / every 64 min. for North America Push-button testSilentFlash everyFire Trouble insufficient sensitivity40-50 s transmission Magnet/reed switchAlarmFlash everyAlarm test functioning normally0.67 stransmission Magnet/reed switchSilentFlash everyFire Trouble test insufficient40-50 stransmission sensitivity Low batteryChirp simultaneousFlash everyFire Trouble with LED flash40-50 stransmission Limitations of Smoke Detectors While the Meridian smoke detector has been designed for reliability, it is important to know that all smoke detectors have limitations. •Smoke detectors will not work without power. If the batteries are low, the smoke detector will not function. See ‘Battery Installation’ below for important information on battery use. •Smoke detectors can only generate an alarm when smoke gets inside the smoke chamber; anything that prevents smoke from entering the smoke chamber may prevent or delay an alarm. Refer to the ‘Guidelines for Locating Smoke Detectors’ on this Instruction Sheet; it is important that smoke detectors be located on at least every floor of the premises, preferably in every room. It is also important to avoid obstructions, such as closed doors, that may prevent smoke from reaching the unit. A smoke detector will not detect a fire in the walls, in the chimney or on the roof of a building until smoke enters the smoke chamber. READ THIS INSTRUCTION SHEET THOROUGHLY BEFORE INSTALLING AND USING YOUR MERIDIAN SMOKE DETECTOR Features •Advanced 90° photoelectric detection pattern and specially designed smoke chamber ∗∗ for superior detection and dust resistance •Unique high signal-to-noise ratio and superior RFI immunity to prevent false alarms •Excellent smoke access provides reliable detection for all smoke flow directions and velocities •Loud 85dB piezoelectric alarm horn •Battery-powered design for easy installation and independence from house power sources •Uses six AA batteries and special circuit design to provide extra long battery life •Solid-state LED indicator light (red) •Visible flash light and audible trouble chirp for low battery warning •Equipped with an RF transmitter, WLS906 can communicate with compatible DSC Wireless Security Systems •Test Button allows user to perform sensitivity test and get a local indication of test result •Magnet-activated/reed switch allows user to perform system test •Battery removal sensor alerts user to missing battery and prevents installation of detector when no battery is installed •Automatic self-test once every 40 seconds provides an audible trouble indication if the unit has insufficient smoke sensitivity •Attractive styling for any decor ∗∗ Protected under Canadian Patent No. 1452296. Other patents pending. Introduction The DSC Meridian photoelectric smoke detector incorporates many advanced design features to provide years of reliable operation. It is important to follow the installation and operation instructions on this sheet to ensure that the unit will function properly — even the best designed smoke detector will be rendered useless if it is not connected or located properly. It is very important that you understand how to test and maintain your system. Read the Instruction or User Manual for your alarm system to familiarize yourself with the fire alarm functions. Be sure to test your system regularly following the test procedures described in your manual. If you should ever have problems operating or testing your system, and especially if there are problems with the fire alarm functions, contact your smoke detector installer or dealer immediately for service. While smoke detectors and alarm systems are designed to warn you of potentially dangerous situations, no system can prevent emergencies. An alarm system is not a substitute for life and property insurance; you should always maintain appropriate insurance coverage. TM WLS906-433 Battery-Powered Smoke Detectors For Residential Use INSTRUCTIONS FOR INSTALLATION AND USE •Smoke detectors have certain obvious limitations: they may not provide protection for someone smoking in bed, for children playing with matches, or for sudden and violent explosions. A smoke detector is a single part of overall fire safety precautions; the smoke detector should never be seen as a substitute for a complete fire safety program. Guidelines for Locating Smoke Detectors On smooth ceilings, detectors may be spaced 9.1m (30 feet) apart as a guide. Other spacing may be required depending on ceiling height, air movement, the presence of joists, uninsulated ceilings, etc. Consult National Fire Alarm Code NFPA 72, CAN/ULS-S553- M86 or other appropriate national standards for installation recommendations. Do not locate smoke detectors at the top of peaked or gabled ceil…

Text truncated - open the document above for the full version.

How the Smoke Detector Works As shown in the illustration, a light source is directed across the smoke chamber and is not normally reflected into the sensing element. When smoke enters the chamber, the light beam is scattered by the smoke and is reflected into the sensor. When enough light is detected by the sensor, an alarm is activated. On alarm, the sounder is activated and the red LED will flash. When the smoke clears from the smoke chamber, the unit will automatically reset itself. Alarm Indications ConditionSounderIndicatorRF LightTransmission No smokeSilentFlash everySupervision transmission 40-50 severy 12 min. for Europe / every 64 min. for North America SmokeAlarmFlash everyAlarm 0.67 stransmission Automatic self testSilentFlash everySupervision transmission functioning normally40-50 severy 12 min. for Europe / every 64 min. for North America Automatic self testChirp betweenFlash everyFire Trouble insufficient sensitivity LED flashes40-50 stransmission* Push-button testAlarmFlash everySupervision transmission functioning normally0.67 severy 12 min. for Europe / every 64 min. for North America Push-button testSilentFlash everyFire Trouble insufficient sensitivity40-50 s transmission* Magnet/reed switchAlarmFlash everyAlarm test functioning normally0.67 stransmission Magnet/reed switchSilentFlash everyFire Trouble test insufficient40-50 stransmission* sensitivity Low batteryChirp simultaneousFlash everyFire Trouble with LED flash40-50 stransmission* * The fire trouble transmission will be sent only one time, once the event has been initiated. The status of the trouble indication will be updated with the supervisory transmission. The fire trouble restoral transmission will be sent on the next supervisory transmission once the trouble is no longer present. Limitations of Smoke Detectors While the Meridian smoke detector has been designed for reliability, it is important to know that all smoke detectors have limitations. • Smoke detectors will not work without power. If the batteries are low, the smoke detector will not function. See ‘Battery Installation’ below for important information on battery use. • Smoke detectors can only generate an alarm when smoke gets inside the smoke chamber; anything that prevents smoke from entering the smoke chamber may prevent or delay an alarm. Refer to the ‘Guidelines for Locating Smoke Detectors’ on this Instruction Sheet; it is important that smoke detectors be located READ THIS INSTRUCTION SHEET THOROUGHLY BEFORE INSTALLING AND USING YOUR MERIDIAN SMOKE DETECTOR Features • Advanced 90° photoelectric detection pattern and specially designed smoke chamber ∗∗ ∗∗ ∗ for superior detection and dust resistance • Unique high signal-to-noise ratio and superior RFI immunity to prevent false alarms • Excellent smoke access provides reliable detection for all smoke flow directions and velocities • Loud 85dB piezoelectric alarm horn • Battery-powered design for easy installation and independence from house power sources • Uses six AA batteries and special circuit design to provide extra long battery life • Solid-state LED indicator light (red) • Visible flash light and audible trouble chirp for low battery warning • Equipped with an RF transmitter, WLS906 can communicate with compatible DSC Wireless Security Systems • Test Button allows user to perform sensitivity test and get a local indication of test result • Magnet-activated reed switch allows user to perform system test • Battery removal sensor alerts user to missing battery and prevents installation of detector when no battery is installed • Automatic self-test once every 40 seconds provides an audible trouble indication if the unit has insufficient smoke sensitivity • Attractive styling for any decor ∗∗ ∗∗ ∗ Protected under Canadian Patent No. 1452296. Other patents pending. Introduction The DSC Meridian photoelectric smoke detector incorporates many advanced design features to provide years of reliable operation. It is important to follow the installation and operation instructions on this sheet to ensure that the unit will function properly — even the best designed smoke detector will be rendered useless if it is not connected or located properly. It is very important that you understand how to test and maintain your system. Read the Instruction or User Manual for your alarm system to familiarize yourself with the fire alarm functions. Be sure to test your system regularly following the test procedures described in your manual. If you should ever have problems operating or testing your system, and especially if there are problems with the fire alarm functions, contact your smoke detector installer or dealer immediately for service. While smoke detectors and alarm systems are designed to warn you of potentially dangerous situations, no system can prevent emergencies. An alarm system is not a substitute for life and property insurance; you should always maintain appropriate insurance coverage. WLS906-433 Battery-Powered Smoke Detectors For Residential Use INSTRUCTIONS FOR INSTALLATION AND USE on at least every floor of the premises, preferably in every room. It is also important to avoid obstructions, such as closed doors, that may prevent smoke from reaching the unit. A smoke detector will not detect a fire in the walls, in the chimney or on the roof of a building until smoke enters the smoke chamber. •Smoke detectors have certain obvious limitations: they may not provide protection for someone smoking in bed, for children playing with matches, or for sudden and violent explosions. A smoke detector is a single part of overall fire safety precautions; the smoke detector should never be seen as a substitute for a complete fire safety program. Guidelines for Locating Smoke Detectors On smooth ceilings, detectors may be spaced 9.1m (30 feet) apart as a guide. Other spacing may be required depending on ceiling height, air movement, the presence of joists, uninsulated ceilings, etc. Consult National Fire …

Text truncated - open the document above for the full version.

How the Smoke Detector Works As shown in the illustration, a light source is directed across the smoke chamber and is not normally reflected into the sensing element. When smoke enters the chamber, the light beam is scattered by the smoke and is reflected into the sensor. When enough light is detected by the sensor, an alarm is activated. On alarm, the sounder is activated and the red LED will flash. When the smoke clears from the smoke chamber, the unit will automatically reset itself. Alarm Indications ConditionSounderIndicatorRF LightTransmission No smokeSilentFlash everySupervision transmission 40-50 severy 12 min. for Europe / every 64 min. for North America SmokeAlarmFlash everyAlarm 0.67 stransmission Automatic self testSilentFlash everySupervision transmission functioning normally40-50 severy 12 min. for Europe / every 64 min. for North America Automatic self testChirp betweenFlash everyFire Trouble insufficient sensitivity LED flashes40-50 stransmission* Push-button testAlarmFlash everySupervision transmission functioning normally0.67 severy 12 min. for Europe / every 64 min. for North America Push-button testSilentFlash everyFire Trouble insufficient sensitivity40-50 s transmission* Magnet/reed switchAlarmFlash everyAlarm test functioning normally0.67 stransmission Magnet/reed switchSilentFlash everyFire Trouble test insufficient40-50 stransmission* sensitivity Low batteryChirp simultaneousFlash everyFire Trouble with LED flash40-50 stransmission* * The fire trouble transmission will be sent only one time, once the event has been initiated. The status of the trouble indication will be updated with the supervisory transmission. The fire trouble restoral transmission will be sent on the next supervisory transmission once the trouble is no longer present. Limitations of Smoke Detectors While the Meridian smoke detector has been designed for reliability, it is important to know that all smoke detectors have limitations. • Smoke detectors will not work without power. If the batteries are low, the smoke detector will not function. See ‘Battery Installation’ below for important information on battery use. • Smoke detectors can only generate an alarm when smoke gets inside the smoke chamber; anything that prevents smoke from entering the smoke chamber may prevent or delay an alarm. Refer to the ‘Guidelines for Locating Smoke Detectors’ on this Instruction Sheet; it is important that smoke detectors be located READ THIS INSTRUCTION SHEET THOROUGHLY BEFORE INSTALLING AND USING YOUR MERIDIAN SMOKE DETECTOR Features • Advanced 90° photoelectric detection pattern and specially designed smoke chamber ∗∗ ∗∗ ∗ for superior detection and dust resistance • Unique high signal-to-noise ratio and superior RFI immunity to prevent false alarms • Excellent smoke access provides reliable detection for all smoke flow directions and velocities • Loud 85dB piezoelectric alarm horn • Battery-powered design for easy installation and independence from house power sources • Uses six AA batteries and special circuit design to provide extra long battery life • Solid-state LED indicator light (red) • Visible flash light and audible trouble chirp for low battery warning • Equipped with an RF transmitter, WLS906 can communicate with compatible DSC Wireless Security Systems • Test Button allows user to perform sensitivity test and get a local indication of test result • Magnet-activated reed switch allows user to perform system test • Battery removal sensor alerts user to missing battery and prevents installation of detector when no battery is installed • Automatic self-test once every 40 seconds provides an audible trouble indication if the unit has insufficient smoke sensitivity • Attractive styling for any decor ∗∗ ∗∗ ∗ Protected under Canadian Patent No. 1452296. Other patents pending. Introduction The DSC Meridian photoelectric smoke detector incorporates many advanced design features to provide years of reliable operation. It is important to follow the installation and operation instructions on this sheet to ensure that the unit will function properly — even the best designed smoke detector will be rendered useless if it is not connected or located properly. It is very important that you understand how to test and maintain your system. Read the Instruction or User Manual for your alarm system to familiarize yourself with the fire alarm functions. Be sure to test your system regularly following the test procedures described in your manual. If you should ever have problems operating or testing your system, and especially if there are problems with the fire alarm functions, contact your smoke detector installer or dealer immediately for service. While smoke detectors and alarm systems are designed to warn you of potentially dangerous situations, no system can prevent emergencies. An alarm system is not a substitute for life and property insurance; you should always maintain appropriate insurance coverage. WLS906-433 Battery-Powered Smoke Detectors For Residential Use INSTRUCTIONS FOR INSTALLATION AND USE on at least every floor of the premises, preferably in every room. It is also important to avoid obstructions, such as closed doors, that may prevent smoke from reaching the unit. A smoke detector will not detect a fire in the walls, in the chimney or on the roof of a building until smoke enters the smoke chamber. •Smoke detectors have certain obvious limitations: they may not provide protection for someone smoking in bed, for children playing with matches, or for sudden and violent explosions. A smoke detector is a single part of overall fire safety precautions; the smoke detector should never be seen as a substitute for a complete fire safety program. Guidelines for Locating Smoke Detectors On smooth ceilings, detectors may be spaced 9.1m (30 feet) apart as a guide. Other spacing may be required depending on ceiling height, air movement, the presence of joists, uninsulated ceilings, etc. Consult National Fire …

Text truncated - open the document above for the full version.

February 16, 2000 Office of Engineering & Technology Federal Communications Commission Washington, D.C. 20554 Subject:Request for continuous confidentiality of technical information per sections 0.459 and 0.457 (d) (2) ( I) of CFR 47. FCC ID:F5300NB906 Dear Sir or Madam: Digital Security Controls Canada Ltd. is hereby filing this request for continuous confidentiality of the specified items submitted with the application for certification ( Form731 ) with proposed identifier F5300NB906. The technical documentation for which continuous confidentiality is sought is: (1) Schematic diagrams: This technical documentation is a part of the material supporting the Form 731 application for certification, which this request for confidentiality accompanies. The schematic diagrams disclose proprietary information and technical data which Digital Security Controls Ltd. would guard from its competitors and would not make available to the public. This proprietary information constitutes a trade secret and is not a part of the product documentation that would be made available to the customers of Digital Security Controls Ltd. It would be potentially injurious to Digital Security Controls Ltd. and to its investment in the development of this innovative proprietary product to make available for public disclosure the trade secret technical information specified in this request. If there are any questions about this request for continuous confidentiality regarding trade secrets and proprietary information embodied in the technical documentation filed in support of this Form 731 application, then please contact me via our toll-free telephone number. Yours truly, Kevin Harris Approval Services Manager Tel: 905-760-3000 Ext. 2378

Offices In Hull (UK), Ottawa (Canada), Dallas (USA) And Arnhem (The Netherlands) February 16, 2000 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, Maryland 21046 USA KTL 3325 River Road RR #5 Ottawa, Ontario Canada K1V 1H2 Tel: 613-737-9680 Fax: 613-737-9691 Toll Free: 1-800-563-6336 Email: [email protected] Internet: www.ktl.com Dear Sir/Madam:Our File Ref. 9R02128 FCC ID: F5300NB906 Applicant: Digital Security Controls Ltd. Equipment: WLS906NB433 Smoke Detector FCC Confirmation no.: EA96795 We have successfully electronically filed all the required documentation for an application for certification in accordance with FCC Part 15, Subpart C on the above mentioned equipment, February 16, 2000. Enclosed, please find a copy of FCC Remittance Form 159, a copy of the FCC Form 731 confirmation number and a copy of the list of exhibits. If you require additional administrative information, please do not hesitate to contact me at 1-800-563-6336 (extension 232). Thank you in advance for your assistance in this matter. Sincerely, Ruby Dulmage Regulatory Submissions Clerk KTL Ottawa Inc. [email protected] Encl.

Digital Security Controls Ltd. 3301 Langstaff Rd. Concord, Ontario L4L 4L2 Mrs. R. Dulmage KTL Certelecom Laboratory 3325 River Road Ottawa, Ontario Re: FCC ID F5300NB906 Dear Mrs. Dulmage, We have looked into the matter related to the supervisory transmission of the Product in question and have found that the manual is incorrect. The WLS 906 NB 433 does send a supervisory transmission, of approximately 40 ms duration, every 64 minutes. The manual has been corrected and is included for re- submission to FCC. Please also make this correction to your report. We apologize for any inconvenience that this issue may have caused.. Tha nk yo u. Best Regards Sherwyn Welshman Ma na ger Wideband Wireless Design Gro up

Re: FCC ID: F5300NB906 Applicant: Digital Security Controls Limited Correspondence Reference No.: 15574 Confirmation No.: EA96795 Date of original e-mail: August 11, 2000 The life safety issues confronted by us today are very difficult and painful to address. As manufacturers, we have the legal responsibility to ensure we have done everything possible to protect the consumer who does not have the ability to understand the safety issues. Reporting low battery and insufficient sensitivity are life safety issues. Ensuring that the detectors are functioning to its specifications are just as important if not vital to the detection. Low battery and insufficient sensitivity trouble conditions are now referred to as alarms. The alarm transmissions are sent only when the event occurs and are not periodic. The low battery and insufficient sensitivity conditions are also treated as alarm transmissions, that is, transmissions only occur when the event is triggered and stops when the conditions causing the events are no longer present. Fire Marshals and Public Safety Officials are looking at various methods to prevent disasters. Soon it will be mandatory that all residences be equipped with fire/smoke detectors. Though buildings may have fire/smoke detectors, they may not be well maintained or even operational. Many fires and fatalities could have been prevented had the fire/smoke detectors been operational. Poor or faulty fire/smoke detectors with bad batteries are the most common causes of failures that could have prevented fatalities. For the above reasons, we consider low battery and insufficient sensitivity vital conditions of the fire/smoke detectors. Detectors with these vital conditions must be serviced or replaced immediately. The user is constantly reminded that their lives are in potential danger. Not attending to these vital conditions, immediately, can prove to be fatal. The detection of fire/smoke is only possible if the detector is good. Hence there are alarms for the detection of fire/smoke and there are alarms for the detection of malfunctioned detectors. Both type of alarms are equally important to prevent fatalities.

Hi Ruby, As discussed this morning, please find attached the document changes. The changes in instruction/installation sheet can be found in the highlighted notes above the "Limitations of Smoke Detectors" section…

Text truncated - open the document above for the full version.
