F5300NB907Wireless Door/Window Contact

INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Remove Cover To remove the cover of the WLS907 universal transmitter, insert a small screwdriver in the slot on the end of the unit. Push the tab to release the cover. Install Batteries Use care when installing the batteries. Follow the guidelines below: 1. Observe the correct polarity (see Figure 1). 2. Install the batteries positive (+) side first (see Figure 2). Use only Eveready Alkaline Energizer batteries. Only replace low batteries with fresh ones. Always replace all three batteries at the same time. Figure 1Figure 2 Find a Location for the Transmitter Locate where the transmitter is to be mounted. Perform the Module Placement Test to ensure that the selected location is in range of the wireless receiver (see receiver Installation Manual for instructions). Determine where the magnet will be placed. In order to activate the reed switch, the magnet must line up with the end of the transmitter OR the dot on the magnet must line up with the dot on the edge of the cover(see Figure 3). Remove Circuit Board Before mounting the unit, remove the circuit board. Pull the tab located next to the battery compartment. Gently lift the circuit board out of the plastic (see Figure 1). NOTE: Do not touch the coils on the circuit board as this may damage the unit. Mount Transmitter and Magnet Mount the backplate of the transmitter using the screws provided and replace the circuit board. The head of the screw must be below the circuit board so that the sensor is not shorted out. Use flat-headed screws only. Use wall anchors if necessary. Replace the cover carefully, so as not to damage the antenna. Mount the magnet no more than ¼” from the transmitter. Use the spacers provided (see Figure 4). Once the unit and magnet are mounted, open and close the window/door to ensure that none of the parts interfere with this movement. Only one magnet can be used per transmitter. Metal will block/reflect a wireless signal. DO NOT mount the WLS907, or any other wireless component, on or near large metal objects (i.e. metal doors, metal window blinds). Instead, find a close location that provides ‘good’ test results and use the external contacts instead of the built-in reed switch. Try to avoid mounting the wireless receiver in a basement or near large metal surfaces (i.e. metal ductwork) as this can reduce the range. Using External Contacts The external contact terminals can be used to connect external contacts or other switches/devices to the universal transmitter. Install the additional device as per the manufacturer’s instruction. Connect the device to the contact terminals of the WLS907. The input is normally closed and is not supervised. The wires connecting the external device to the input terminals can be any length provided that the resistance of the wire does not exceed 100 WW WW W. Only one contact can be used. If an external contact is used, do not install the magnet. Tamper Switches There are two tamper switches on the WLS907 board. Both removing the cover and/or removing the WLS907 from its mounting location will cause a zone tamper. See your panel installation manual for more information on trouble conditions. Enrolling a WLS907 On the back of the door contact housing, there will be two serial numbers, a five digit and six digit. Please refer to your receiver installation manual for information on which serial number should be enrolled. FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment. This equipment generates and uses radio frequency energy and if not installed and used properly, in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for Class B device in accordance with the specifications in Subpart “B” of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in any residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to television or radio reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Re-orient the receiving antenna • Relocate the alarm control with respect to the receiver • Move the alarm control away from the receiver • Connect the alarm control into a different outlet so that alarm control and receiver are on different circuits. If necessary, the user should consult the dealer or an experienced radio/television technician for additional sugges- tions. The user may find the following booklet prepared by the FCC helpful: “How to Identify and Resolve Radio/ Television Interference Problems”. This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402, Stock # 004-000-00345-4. Limited Warranty Digital Security Controls Ltd. warrants that for a period of twelve months from the date of purchase, the product shall be free of defects in material and workmanship under normal use and that in fulfillment of any breach of such warranty, Digital Security Controls Ltd. shall, at its option, repair or replace the defective equipment upon return of the equipment to its repair depot. This warranty applies only to defects in parts and workmanship and not to damage incurred in shipping or handling, or damage due to causes beyond control of Digital Security Controls Ltd. such as lightning, excessive voltage, mechanical shock, water damage, or damage arising out of abuse, alteration or improper application of the equipment. The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties, whet…

Text truncated - open the document above for the full version.

Offices In Hull (UK), Ottawa (Canada), Dallas (USA) And Arnhem (The Netherlands) February 3, 2000 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, Maryland 21046 USA KTL 3325 River Road RR #5 Ottawa, Ontario Canada K1V 1H2 Tel: 613-737-9680 Fax: 613-737-9691 Toll Free: 1-800-563-6336 Email: [email protected] Internet: www.ktl.com Dear Sir/Madam:Our File Ref. 9R02129 FCC ID: F5300NB907 Applicant: Digital Security Controls Ltd. Equipment: WLS907NB433 Wireless Door/Window Contact FCC Confirmation no.: EA96694 We have successfully electronically filed all the required documentation for an application for certification in accordance with FCC Part 15 on the above mentioned equipment, February 3, 2000. Enclosed, please find a cheque in the amount of $940.00 US, a copy of FCC Remittance Form 159, a copy of the FCC Form 731 confirmation number and a copy of the list of exhibits. PLEASE NOTE THE CHANGE OF ADDRESS AND CONTACT NAME FOR THIS COMPANY. Digital Security Controls Ltd. 3301 Langstaff Road Vaughan, ON L4K 4L2 Contact: Kevin Harris, Approval Services Manager Tel: 905-760-3000 ext 378 Fax: 905-760-3020 e-mail: [email protected] If you require additional information, please do not hesitate to contact me at 1-800-563-6336 (extension 232). Thank you in advance for your assistance in this matter. Sincerely, Ruby Dulmage Regulatory Submissions Clerk KTL Ottawa Inc. [email protected] Encl.

Digital Security Controls Ltd.ISO9001 Registered3301 Langstaff Road, ConcordOntario, Canada L4K 4L2Phone: 905-760-3000Toll Free: 1-888-888-7838Fax: 905-760-3030 TM FCC/IC Labeling for Door Contact TransmitterWLS907NB433 SIDE OF TRANSMITTER UNIT SHOWING PLACEMENT OF LABEL(ACTUAL SIZE) File: [wls907nb433 fcc+ic lb 1800xxxx r001.cdr] January 26, 2000 FCC ID: F5300NB907 Model: WLS907NB433 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-ditions: (1) This device may not cause harmful interference, and (2) this device must accept anyinterference received, including interference that may cause undesired operation.IC: RSS/CNR210 CANADA: 160 XXX XXXX MADE IN CANADA 1800XXXX R001 This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numériquede la classe B respecte toutes les exigences du ICES-003. DASHED LINE INDICATESCUT EDGE OF LABELLABEL TO BE PRINTEDON SELF-ADHESIVEMATERIALLABEL SHOWN 250% ACTUAL SIZE 44.5 mm 9.5 mm

Master: ktlPT15231 Date: October 8, 1999 KTL Test Report:9R02129 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Concord, Ontario L4K 4L2 Equipment Under Test:WLS907NB433 Motion Detector (E.U.T.) FCC ID:F5300NB907 In Accordance With:FCC Part 15, Subpart C For Low Power Transmitters Operating Periodically In The Band 40.66 - 40.77 MHz And Above 70 MHz Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Russell Grant, Wireless Group Manager Date: Total Number of Pages:22 KTL OttawaFCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02129 EQUIPMENT: WLS907NB433 Motion Detector FCC ID: F5300NB907 Page 2 of 20 Table of Contents Section 1. Summary of Test Results .....................................................................................................3 Section 2. Equipment Under Test (E.U.T.) ..........................................................................................5 Section 3. Transmission Requirements ..............................................................................................10 Section 4. Radiated Emissions ............................................................................................................13 Section 5. Occupied Bandwidth..........................................................................................................16 Section 6. Block Diagrams...................................................................................................................18 Section 7.Test Equipment List ............................................................................................................20 Annex A Restricted Bands.................................................................................................................A1 KTL OttawaFCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02129 EQUIPMENT: WLS907NB433 Motion Detector FCC ID: F5300NB907 Page 3 of 20 Section 1.Summary of Test Results Manufacturer:Digital Security Controls Ltd. Model No.:WLS907NB433 Serial No.:None Date Received In Laboratory: January 17, 2000 KTL Identification No.: Item # 1 & 2 General:All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.231. All tests were conducted using measurement procedure ANSI C63.4-1992. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit DS C Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. None See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 It is recommended that the margin of compliance be improved to allow for manufacturing tolerances TESTED BY: _____________________________________ DATE: ___________________ Kevin Rose, Test Technician KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL OttawaFCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02129 EQUIPMENT: WLS907NB433 Motion Detector FCC ID: F5300NB907 Page 4 of 20 Summary Of Test Data Name of TestParagraph NumberResults Transmission Requirements15.231(a)Complies Radiated Emissions15.231(b)Complies Occupied Bandwidth15.231(c)Complies Frequency Tolerance15.231(d)Not Applicable Periodic Alternate Field Strength Requirements15.231(e)Not Applicable Powerline Conducted Emissions15.207Not Applicable Footnotes For N/A’s:This equipment is battery operated. Test Conditions: IndoorTemperature: 20 °C Humidity:20 % OutdoorTemperature: 10 °C Humidity:20 % KTL OttawaFCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02129 EQUIPMENT: WLS907NB433 Motion Detector FCC ID: F5300NB907 Page 5 of 20 Section 2.Equipment Under Test (E.U.T.) General Equipment Information Frequency Range: 433.92 MHz Operating Frequency(ies) of Sample: 433.92 MHz Type of Emission: Pulse Width Modulation Emission Designator: 42K0L1D (See Attached Graph) Supply Power Requirement: 3 x 1.5 V (AAA Batteries) Duty Cycle Calculation: -15.4 dB (See attached duty cycle description and time domain graphs) KTL OttawaFCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02129 EQUIPMENT: WLS907NB433 Motion Detector FCC ID: F5300NB907 Page 6 of 20 KTL OttawaFCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 9R02129 EQUIPMENT: WLS907NB433 Motion Detector FCC ID: F5300NB907 Page 7 of 20 Data Transmission Format The transmitted data packet is a fixed length packet. The packet contains all of the necessary information to indicate which sensor generated the packet, the type of sensor and the status of the sensor’s inputs. The data is sent at a rate of 500 μS per bit or 2 Kbits per second. Figure 1 shows the bit timing used for all bits in the packet. Where a low logic present for the 500 μS bit time represents a data logic “0” and 250 μS low then 250 μS high represents a data logic “1”. Figure 1: Bit Timing Figure 2 shows the format of the transmitted data packet. Figure 2: Data Packet Format Total Data Packet Length:48 x 0.5 ms + 5 ms = 29 ms Maximum ON Time:48 x 0.25 ms + 5 ms = 17 ms Duty Cycle:20 Log ö ç è æ 100 17 = -15.4 dB 250 μS250 μS 500 μS bit time : data logic "0" 500 μS bit time : data logic "1" 250 μS250 μS 8 bits8 bits8 bits8 bits8 bits5 ms Header Start bitStart bitStart bitStart bit4 Sync Pulses 2 ms VCO Powe…

Text truncated - open the document above for the full version.
