F5300NB914Dual PIR Motion Detector

Battery Installation• This system is designed to work with EvereadyAlkaline Energizer Batteries. Do not install any other type. The reliability of the security system depends on itsbatteries, and “no name” or generic brand batteries maynot provide the best quality and dependability. • Use fresh batteries. Most batteries have a “best before” date printed on their packaging or on the batteries them-selves. Buy batteries that have a “best before” date of twoyears or more from your purchase date. • When disposing of used batteries, follow the instructions and precautions printed on the batteries. Many cities andcommunities have collection sites or services for usedhousehold batteries. Contact your municipal offices forinformation on the disposal of used batteries. Remove the motion detector from its mounting plate by holding the sensor by itssides and pushing up. Install four fresh Eveready Alkaline Energizer AA batteries. Besure to insert the batteries in the proper orientation. Replace the sensor on its mount-ing plate, making sure it snaps into place. After the batteries are installed, the detec-tor will take 60 seconds to warm up. During this time the LED will flash. FCC Compliance StatementCAUTION : Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment.This equipment generates and uses radio frequency energy and if not installed and used properly, in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for Class B device in accordance with the specifications in Subpart “B” of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in any residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to tel e- vision or radio reception, which can be determined by turning the equipment off and on, the user is encouraged to try to cor-rect the interference by one or more of the following measures:• Re-orient the receiving antenna• Relocate the alarm control with respect to the receiver• Move the alarm control away from the receiver • Connect the alarm control into a different outlet so that alarm control and receiver are on different circuits.If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the FCC helpful: “How to Identify and Resolve Radio/Television Interfer-ence Problems”. This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402, S tock # 004- 000-00345-4.Limited WarrantyDigital Security Controls Ltd. warrants that for a period of twelve months from the date of purchase, the product shall be free of defects in material and workmanship under normal use and that in fulfilment of any breach of such warranty, Digital Security Controls Ltd. shall, at its option, repair or replace the defective equipment upon return of the equipment to its repa ir depot. This warranty applies only to defects in parts and workmanship and not to damage incurred in shipping or handling, or damage due to causes beyond control of Digital Security Controls Ltd. such as lightning, excessive v oltage, mechanical shock, water damage, or damage arising out of abuse, alteration or improper application of the equipment.The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties, whe ther express or implied and of all other obligations or liabilities on the part of Digital Security Controls L td. This warranty contains the entire warranty. Digital Security Controls Ltd. neither assum es, nor authorizes any other person purporting to act on its behalf to modify or to change this warranty, nor to assume for it any other warranty or liability concerning this product.In no event shall Digital Security Controls Ltd. be liable for any direct , indirect or consequential damages, loss of anticipa ted profits, loss of time or any other losses incurred by the buyer in connection with the purchase, installation or operation or failure of this product. ©2000 Digital Security Controls Ltd.Toronto, CanadaTech. Line 1-800-387-3630www.dscgrp.comPrinted in Canada 29004697 R003 WLS914Wireless Dual PIR Motion DetectorINSTALLATION INSTRUCTIONS The WLS914 is the wireless version of DSC’s highly successful Bravo6 PIR which fea-tures 2 dual element PIRs for superior intrusion detection and true pet immunity. TheWLS914 is equipped with a specially designed lens*, which enables the detector to dis-criminate between humans and small to mid-sized pets.Multi-Level Signal Processing**, temperature compensation and large multi-beam lensdesign mean the human target will not slip by unnoticed even on a hot summer day.Our WLS914 with its 5 year warranty is your assurance of a trouble-free installation.Specifications• Power requirement: 4AA alkaline batteries (supplied)• Operating temperature: 32 o F to 122 o F (0 o C to 50 o C) • Operating humidity: 5% to 85% RH non-condensing• Static immunity: 10 kV• Walk detection speed: 0.5ft/s to 10ft/s (0.15m/s to 3m/s)• Coverage angle (wall/wall lens): 100 o maximum • Mounting heights: 7.5ft (2.3m)• Dimensions: 4.9"H x 2.8"W x 2.7"D (124.5mm x 70mm x 67mm)• Color: white with white lensSelecting a Mounting LocationEach motion detector should be located so that it provides optimal coverage of thearea to be protected. When selecting locations for motion detectors, observe thefollowing:• The mounting height should be 7.5 ft./ 2.3 m.• Do not aim the detector at a stairway which a pet has access to. Do not place objects that pets can climb on higher than 3 ft (0.9m) closer than 6 ft (1.8m) tothe detector (e.g. a cat on a couch). • Do not aim the detector at reflective…

Text truncated - open the document above for the full version.

September 08, 2000 Office of Engineering & Technology Federal Communications Commission Washington, D.C. 20554 Subject:Request for continuous confidentiality of technical information per sections 0.459 and 0.457 (d) (2) ( I) of CFR 47. FCC ID:F5300NB914 Dear Sir or Madam: Digital Security Controls Canada Ltd. is hereby filing this request for continuous confidentiality of the specified items submitted with the application for certification ( Form731 ) with proposed identifier F5300NB914. The technical documentation for which continuous confidentiality is sought is: (1) Schematic diagrams: This technical documentation is a part of the material supporting the Form 731 application for certification, which this request for confidentiality accompanies. The schematic diagrams disclose proprietary information and technical data which Digital Security Controls Ltd. would guard from its competitors and would not make available to the public. This proprietary information constitutes a trade secret and is not a part of the product documentation that would be made available to the customers of Digital Security Controls Ltd. It would be potentially injurious to Digital Security Controls Ltd. and to its investment in the development of this innovative proprietary product to make available for public disclosure the trade secret technical information specified in this request. If there are any questions about this request for continuous confidentiality regarding trade secrets and proprietary information embodied in the technical documentation filed in support of this Form 731 application, then please contact me via our toll-free telephone number. Yours truly, Kevin Harris Approval Services Manager 905-760-3000 Ext. 2378 Email: [email protected]

Digital Security Controls Ltd.ISO9001 Registered3301 Langstaff Road, ConcordOntario, Canada L4K 4L2Phone: 905-760-3000Toll Free: 1-888-888-7838Fax: 905-760-3030 ® DASHED LINE INDICATESCUT EDGE OF LABELLABEL TO BE PRINTEDON SELF-ADHESIVE MATERIALLABEL SHOWN 250% ACTUAL SIZE 44.5 mm 9.5 mm FCC + ICES-003 Labeling for PWLS914-433 Wireless Pet Immunity Infrared Motion Detector File: [pwl s914-433_fcc+ices-003_lb_1800xxxx.cdr] May 9, 2000 Top of the unit showing placement of label (Actual size) FCC ID: F5300NB914 Model: PWLS914-433 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-ditions: (1) This device may not cause harmful interference, and (2) this device must accept anyinterference received, including interference that may cause undesired operation. 1800XXXX R001 IC: RSS/CNR210 CANADA: XXX XXX XXXX MADE IN CANADAThis Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numériquede la classe B respecte toutes les exigences du ICES-003.

Digital Security Controls Ltd.ISO9001 Registered3301 Langstaff Road, ConcordOntario, Canada L4K 4L2Phone: 905-760-3000Toll Free: 1-888-888-7838Fax: 905-760-3030 TM DASHED LINE INDICATESCUT EDGE OF LABELLABEL TO BE PRINTEDON SELF-ADHESIVE MATERIALLABEL SHOWN 250% ACTUAL SIZE 44.5 mm 9.5 mm FCC + ICES-003 Labeling for WLS914-433 Wireless Pet Immunity Infrared Motion Detector File: [wls 914-433_fcc+ices-003_lb_1800xxxx.cdr] May 5, 2000 Top of the unit showing placement of label (Actual size) FCC ID: F5300NB914 Model: WLS914-433 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-ditions: (1) This device may not cause harmful interference, and (2) this device must accept anyinterference received, including interference that may cause undesired operation. 1800XXXX R001 IC: RSS/CNR210 CANADA: XXX XXX XXXX MADE IN CANADAThis Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numériquede la classe B respecte toutes les exigences du ICES-003.

CIRCUIT DESCRIPTION Device: Narrow Band Transmitter Model: WLS914NB ESI Identifier: Schematic Diagram: Description: The narrow band pet immune transmitter sends the sensor status information encoded appropriately to the control unit of the wireless security system. It features dual PIR sensors incorporating High Density Digital Analysis and multi-level signal processing with a vertically interleaving beam pattern for superior intruder detection while being immune to pets weighing up to 851bs/38kg. This unit consists of two main circuit sections. A control section with a microprocessor & digital logic and the RF transmitter. The control section receives sensor inputs and unit status information that is then coded to produce the ASK modulation signal. This section also controls transmitter’s activity. The transmitter consists of a crystal reference oscillator, a divide-by-64 prescaler, and a phase detector forming a phase-lock-loop ( PLL )system. The phase comparator compares the reference frequency and the divide-by-64 output signal frequency, if there is any difference, it will produce an error voltage to lock the free running VCO to 433.92MHz. A matching network provides the output signal to the antenna.

Master: ktlPT15231 Date: April 5, 2000 KTL Test Report:0R02419 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Vaughan, Ontario L4K 4L2 Equipment Under Test:WLS914-433 (E.U.T.) FCC ID:F5300NB914 In Accordance With:FCC Part 15, Subpart C For Low Power Transmitters Operating Periodically In The Band 40.66 - 40.77 MHz And Above 70 MHz Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: R. Grant, Wireless Group Manager Date: Total Number of Pages:24 KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02419 EQUIPMENT: WLS914-433 FCC ID: F5300NB914 Page 2 of 22 Table of Contents Section 1. Summary of Test Results.......................................................................................... 3 Section 2. Equipment Under Test (E.U.T.) .............................................................................. 5 Section 3. Transmission Requirements .................................................................................. 11 Section 4. Radiated Emissions................................................................................................. 14 Section 5. Occupied Bandwidth.............................................................................................. 17 Section 6. Block Diagrams.......................................................................................................20 Section 7. Test Equipment List ................................................................................................ 22 Annex A Restricted Bands..................................................................................................... A1 KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02419 EQUIPMENT: WLS914-433 FCC ID: F5300NB914 Page 3 of 22 Section 1.Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.231. All tests were conducted using measurement procedure ANSI C63.4-1992. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit DS C Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Kevin Carr, Technologist KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02419 EQUIPMENT: WLS914-433 FCC ID: F5300NB914 Page 4 of 22 Summary Of Test Data Name of TestPara. NumberResults Transmission Requirements15.231(a)Complies Radiated Emissions15.231(b)Complies Occupied Bandwidth15.231(c)Complies Frequency Tolerance15.231(d)Not Applicable Periodic Alternate Field Strength Requirements15.231(e)Not Applicable Powerline Conducted Emissions15.207Not Applicable Footnotes For N/A’s: Test Conditions: Indoor Temperature: 24 °C Humidity:40 % Outdoor Temperature: 15 °C Humidity:40 % KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02419 EQUIPMENT: WLS914-433 FCC ID: F5300NB914 Page 5 of 22 Section 2.Equipment Under Test (E.U.T.) General Equipment Information Manufacturer: Digital Control Systems Model No.: WLS914-433 Serial No.: 399907 Date Received In Laboratory: April 24, 2000 KTL Identification No.: Items #2 & 4 Frequency Range: 433.92 MHz, Fixed Frequency Operating Frequency(ies) of Sample: 433.92 Type of Emission: Pulse Width Modulation Emission Designator: 387KL1D Supply Power Requirement: 3AA Batteries Duty Cycle Calculation: 20 Log ms ms 100 25.12 = -18.2 dB KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02419 EQUIPMENT: WLS914-433 FCC ID: F5300NB914 Page 6 of 22 Data Transmission Format The transmitted data packet is a fixed length, amplitude modulated packet. The packet contains all of the necessary information to indicate which sensor generated the packet, the type of sensor and the status of the sensor’s inputs. The data is sent at a rate of 500 μS per bit or 2 Kbits per second. Figure 1 shows the bit timing used for all bits in the packet. Where a low logic present for the 500 μS bit time represents a data logic “0” and 250 μS low then 250 μS high represents a data logic “1”. Figure 1 – Bit Timing Figure 2 shows the format of the transmitted data packet. Bytes highlighted in green are bytes that are variable information that would depend on the current status, module type and serial number of the particular device. Figure 2 – Data Packet Format Because these bytes are variable there is a best and worst case packet when considering ON Time. 250 μ S250 μ S 500 μ S bit time : data logic "0" 500 μ S bit time : data logic "1" 250 μ S250 μ S Sync bits (4 bits) Status Byte (8 bits) CRC Byte (8 bits) Serial Number Digits 4 and 5 (8 bits) Serial Number Digits 2 and 3 (8 bits) Module Type (4 bits) Serial Number Digit 1 (4 bits) Start bit (1 bit) Start bit (1 bit) Start bit (1 bit) Start bit (1 bit) Header (2.5 ms Constant Modulation) KTL Ottawa FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 0R02419 EQUIPMENT: WLS914-433 FCC ID: F5300NB914 Page 7 of 22 Diagram 1 – Maximum / Minimum Packet ON Times Packet Component Descriptio…

Text truncated - open the document above for the full version.
