F5300SS5501Z32Spread Spectrum Receiver

Installation Manual LCD5501Z32-900 WARNING: Please refer to the System Installation Manual for information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. version 1.0 LIMITED WARRANTY Digital Security Controls Ltd. warrants the original purchaser that for a period of twelve months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use. During the warranty period, Digital Security Controls Ltd. shall, at its option, repair or replace any defective product upon return of the product to its factory, at no charge for labour and materials. Any replacement and/or repaired parts are warranted for the remainder of the original warranty or ninety (90) days, whichever is longer. The original owner must promptly notify Digital Security Controls Ltd. in writing that there is defect in material or workmanship, such written notice to be received in all events prior to expiration of the warranty period. International Warranty The warranty for international customers is the same as for any cus- tomer within Canada and the United States, with the exception that Digital Security Controls Ltd. shall not be responsible for any customs fees, taxes, or VAT that may be due. Warranty Procedure To obtain service under this warranty, please return the item(s) in ques- tion to the point of purchase. All authorized distributors and dealers have a warranty program. Anyone returning goods to Digital Security Controls Ltd. must first obtain an authorization number. Digital Security Controls Ltd. will not accept any shipment whatsoever for which prior authorization has not been obtained. Conditions to Void Warranty This warranty applies only to defects in parts and workmanship relating to normal use. It does not cover: • damage incurred in shipping or handling; • damage caused by disaster such as fire, flood, wind, earthquake or light- ning; • damage due to causes beyond the control of Digital Security Controls Ltd. such as excessive voltage, mechanical shock or water damage; • damage caused by unauthorized attachment, alterations, modifications or foreign objects; • damage caused by peripherals (unless such peripherals were supplied by Digital Security Controls Ltd.); • defects caused by failure to provide a suitable installation environment for the products; • damage caused by use of the products for purposes other than those for which it was designed; • damage from improper maintenance; • damage arising out of any other abuse, mishandling or improper application of the products. Digital Security Controls Ltd.’s liability for failure to repair the product un- der this warranty after a reasonable number of attempts will be limited to a replacement of the product, as the exclusive remedy for breach of warranty. Under no circumstances shall Digital Security Controls Ltd. be liable for any special, incidental, or consequential damages based upon breach of warranty, breach of contract, negligence, strict liability, or any other legal theory. Such damages include, but are not limited to, loss of profits, loss of the product or any associated equipment, cost of capital, cost of substitute or replacement equipment, facilities or services, down time, purchaser’s time, the claims of third parties, including customers, and injury to property. Disclaimer of Warranties This warranty contains the entire warranty and shall be in lieu of any and all other warranties, whether expressed or implied (including all implied warranties of merchantability or fitness for a particular pur- pose) And of all other obligations or liabilities on the part of Digital Security Controls Ltd. Digital Security Controls Ltd. neither assumes nor authorizes any other person purporting to act on its behalf to modify or to change this warranty, nor to assume for it any other warranty or liability concerning this product. This disclaimer of warranties and limited warranty are governed by the laws of the province of Ontario, Canada. WARNING: Digital Security Controls Ltd. recommends that the entire system be completely tested on a regular basis. However, despite fre- quent testing, and due to, but not limited to, criminal tampering or elec- trical disruption, it is possible for this product to fail to perform as ex- pected. Out of Warranty Repairs Digital Security Controls Ltd. will at its option repair or replace out-of- warranty products which are returned to its factory according to the fol- lowing conditions. Anyone returning goods to Digital Security Controls Ltd. must first obtain an authorization number. Digital Security Controls Ltd. will not accept any shipment whatsoever for which prior authorization has not been obtained. Products which Digital Security Controls Ltd. determines to be repair- able will be repaired and returned. A set fee which Digital Security Con- trols Ltd. has predetermined and which may be revised from time to time, will be charged for each unit repaired. Products which Digital Security Controls Ltd. determines not to be repair- able will be replaced by the nearest equivalent product available at that time. The current market price of the replacement product will be charged for each replacement unit. FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment. This equipment generates and uses radio frequency energy and if not installed and used properly, in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for Class B device in accordance with the specifications in Subpart “B” of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in any residential installation. However, there is no guarantee that interference will not occur in a…

Text truncated - open the document above for the full version.

February 21, 2000 Office of Engineering & Technology Federal Communications Commission Washington, D.C. 20554 Subject:Request for continuous confidentiality of technical information per sections 0.459 and 0.457 (d) (2) ( I) of CFR 47. FCC ID:F5300SS5501Z32 Dear Sir or Madam: Digital Security Controls Canada Ltd. is hereby filing this request for continuous confidentiality of the specified items submitted with the application for certification ( Form731 ) with proposed identifier F5300SS5501Z32. The technical documentation for which continuous confidentiality is sought is: (1) Schematic diagrams: This technical documentation is a part of the material supporting the Form 731 application for certification, which this request for confidentiality accompanies. The schematic diagrams disclose proprietary information and technical data which Digital Security Controls Ltd. would guard from its competitors and would not make available to the public. This proprietary information constitutes a trade secret and is not a part of the product documentation that would be made available to the customers of Digital Security Controls Ltd. It would be potentially injurious to Digital Security Controls Ltd. and to its investment in the development of this innovative proprietary product to make available for public disclosure the trade secret technical information specified in this request. If there are any questions about this request for continuous confidentiality regarding trade secrets and proprietary information embodied in the technical documentation filed in support of this Form 731 application, then please contact me via our toll-free telephone number. Yours truly, Kevin Harris Approval Services Manager Tel: 905-760-3000 Ext. 2378

FCC/ICES-003 LABELING FOR LCD5501Z32-900 KEYPAD File: [lcd5501z32-900 fcc&ices lb 1800xxxx.cdr] Feb 22, 2000 UNDERSIDE OF KEYPAD UNIT SHOWING PLACEMENT OF LABEL (ACTUAL SIZE) ! ! ! Dashed line indicates cut edge of label Label to be printed on self-adhesive material Label shown 250% of actual size 35 mm 12.7 mm Digital Security Controls Ltd. ISO9001 Registered 3301 Langstaff Road, Concord Ontario, Canada L4K 4L2 Phone: 905-760-3000 Toll Free: 1-888-888-7838 Fax: 905-760-3030 TM LCD5501Z32-900 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful in- terference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: F5300SS5501Z32 IC: RSS/CNR210 CANADA 160 XXX XXXX MADE IN CANADA1800XXXX R001 This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003.

Master: ktlPT15BR Date: October 8, 1999 KTL Test Report:9R02256 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Vaughan, Ontario L4K 4L2 Equipment Under Test:LCD 5501Z32-900 (E.U.T.) FCC ID:F5300SS5501Z32 In Accordance With:FCC Part 15, Subpart B Radio Receivers Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: R. Grant, Wireless Group Manager Date: Total Number of Pages:16 KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 2 of 16 Table Of Contents Section 1. Summary of Test Results.............................................................................................3 Section 2. Equipment Under Test (E.U.T.).................................................................................. 5 Section 3. Radiated Emissions ..................................................................................................... 7 Section 4. Powerline Conducted Emissions............................................................................... 10 Section 5. Block Diagrams......................................................................................................... 14 Section 6. Test Equipment List..................................................................................................16 KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 3 of 16 Section 1.Summary of Test Results General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15, Subpart B. Measurement procedure ANSI C63.4-1992 was used for all tests. Radiated Emissions were measured on an open area test site. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit CYY Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Kevin Carr, Technologist KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 4 of 16 Summary Of Test Data Name Of TestPara. No.Results Antenna Conducted Emissions15.111N/A Radiated Emissions15.109Complies Powerline Conducted Emissions15.107Complies Footnotes For N/A’s: Integral Antenna Test Conditions: Indoor Temperature: 21 °C Humidity:13 % Outdoor Temperature: 10 °C Humidity:13 % KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 5 of 16 Section 2.Equipment Under Test (E.U.T.) Manufacturer:Digital Security Controls Ltd. Model No.:LCD 5501Z32-900 Serial No.:70001078 Date Received In Laboratory: February 16, 2000 KTL Identification No.: Item #4 Equipment Details Primary Power Requirement:120 VAC KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 6 of 16 Configuration of the Equipment Under Test Kepad Control Box Resistive Loads For Zones Telco Simulator KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 7 of 16 Section 3.Radiated Emissions NAME OF TEST: Radiated EmissionsPARA. NO.: 15.109(a) TESTED BY: Kevin CarrDATE: February 18, 2000 Minimum Standard: Frequency(MHz)Field Strength (dB μ μμ μ V/m @ 3m) 30 - 8840.0 88 - 21643.5 216 - 96046.0 Above 96054.0 Test Results: Complies. The worst-case emission level is 36.2 dBμV/m @ 3m at 80.0 MHz. This is 3.8 dB below the specification limit. Measurement Data: See attached table. For super-regenerative receivers the receiver is cohered using a signal generator and dipole antenna. Handheld equipment and equipment not designed to be mounted in any fixed orientation, the E.U.T. is tested in three orthogonal axis to obtain worst case results. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 8 of 16 Test Data - Radiated Emissions Test Distance (meters) : 3 Range : A Towe r Re ce ive r: ESVP H.P. 8564 RBW(kHz ): 120 1 MHz Detector: PEAK, CISPR, Q-PEAK Fre q. (M Hz) Ant. * Pol. (V/H) Ant. HGT. (m) Table (deg.) RCVD Signal (dB μ μμ μ V/m) Ant. Factor (dB)** Amp. Gain (dB)*** Dist. Corr. (dB) Fie ld Strength (dB μ μμ μ V/m) Limit (dB μ μμ μ V/m) Margin (dB) 48.0E/D1V28.73.332.040.08.0 48.0E/D1H20.93.324.240.015.8 54.86E/D1V18.45.223.640.016.4 54.83E/D1H21.05.226.240.013.8 64.0E/D2V26.55.131.640.08.4 64.0E/D2H22.45.127.540.012.5 68.5E/D2V20.85.626.440.013.6 68.5E/D2H25.45.631.040.09.0 80.0E/D2V28.07.535.540.04.5 80.0E/D2H28.77.536.240.03.8 877.32E/D4V2.534.637.146.08.9 877.37E/D4H2.834.637.446.08.6 1754.7Hrn2V56.832.3-46.542.654.011.4 1754.9Hrn2H58.832.3-46.544.654.09.4 2632.0Hrn2V54.036.0-47.842.254.011.8 2632.0Hrn2H51.136.0-47.839.354.014.7 3509.5Hrn2V46.040.6-47.139.554.014.5 3509.5Hrn2H45.840.6-47.139.354.014.7 4386.7Hrn2V46.041.9-45.942.054.012.0 4386.8Hrn2H45.241.9-45.941.254.012.8 Notes: B/C = Biconical, B/L = Biconilog, L/P = Log-Periodic, H = Horn, D/P = Dipole * Re-measured using dipole antenna. ( ) Denotes failing emission level. (1) 120 kHz, Q-Peak, (2) 10 kHz, Peak, (3) 100 kHz RGW, 300 kHz V…

Text truncated - open the document above for the full version.

Master: ktlPT15BR Date: October 8, 1999 KTL Test Report:9R02256 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Vaughan, Ontario L4K 4L2 Equipment Under Test:LCD 5501Z32-900 (E.U.T.) FCC ID:F5300SS5501Z32 In Accordance With:FCC Part 15, Subpart B Radio Receivers Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: R. Grant, Wireless Group Manager Date: Total Number of Pages:16 KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 2 of 16 Table Of Contents Section 1. Summary of Test Results.............................................................................................3 Section 2. Equipment Under Test (E.U.T.).................................................................................. 5 Section 3. Radiated Emissions ..................................................................................................... 7 Section 4. Powerline Conducted Emissions............................................................................... 10 Section 5. Block Diagrams......................................................................................................... 14 Section 6. Test Equipment List..................................................................................................16 KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 3 of 16 Section 1.Summary of Test Results General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15, Subpart B. Measurement procedure ANSI C63.4-1992 was used for all tests. Radiated Emissions were measured on an open area test site. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit CYY Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Kevin Carr, Technologist KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 4 of 16 Summary Of Test Data Name Of TestPara. No.Results Antenna Conducted Emissions15.111N/A Radiated Emissions15.109Complies Powerline Conducted Emissions15.107Complies Footnotes For N/A’s: Integral Antenna Test Conditions: Indoor Temperature: 21 °C Humidity:13 % Outdoor Temperature: 10 °C Humidity:13 % KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 5 of 16 Section 2.Equipment Under Test (E.U.T.) Manufacturer:Digital Security Controls Ltd. Model No.:LCD 5501Z32-900 Serial No.:70001078 Date Received In Laboratory: February 16, 2000 KTL Identification No.: Item #4 Equipment Details Primary Power Requirement:120 VAC KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 6 of 16 Configuration of the Equipment Under Test Kepad Control Box Resistive Loads For Zones Telco Simulator KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 7 of 16 Section 3.Radiated Emissions NAME OF TEST: Radiated EmissionsPARA. NO.: 15.109(a) TESTED BY: Kevin CarrDATE: February 18, 2000 Minimum Standard: Frequency(MHz)Field Strength (dB μ μμ μ V/m @ 3m) 30 - 8840.0 88 - 21643.5 216 - 96046.0 Above 96054.0 Test Results: Complies. The worst-case emission level is 36.2 dBμV/m @ 3m at 80.0 MHz. This is 3.8 dB below the specification limit. Measurement Data: See attached table. For super-regenerative receivers the receiver is cohered using a signal generator and dipole antenna. Handheld equipment and equipment not designed to be mounted in any fixed orientation, the E.U.T. is tested in three orthogonal axis to obtain worst case results. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 9R02256 EQUIPMENT: LCD 5501Z32-900 FCC ID: F5300SS5501Z32 Page 8 of 16 Test Data - Radiated Emissions Test Distance (meters) : 3 Range : A Towe r Re ce ive r: ESVP H.P. 8564 RBW(kHz ): 120 1 MHz Detector: PEAK, CISPR, Q-PEAK Fre q. (M Hz) Ant. * Pol. (V/H) Ant. HGT. (m) Table (deg.) RCVD Signal (dB μ μμ μ V/m) Ant. Factor (dB)** Amp. Gain (dB)*** Dist. Corr. (dB) Fie ld Strength (dB μ μμ μ V/m) Limit (dB μ μμ μ V/m) Margin (dB) 48.0E/D1V28.73.332.040.08.0 48.0E/D1H20.93.324.240.015.8 54.86E/D1V18.45.223.640.016.4 54.83E/D1H21.05.226.240.013.8 64.0E/D2V26.55.131.640.08.4 64.0E/D2H22.45.127.540.012.5 68.5E/D2V20.85.626.440.013.6 68.5E/D2H25.45.631.040.09.0 80.0E/D2V28.07.535.540.04.5 80.0E/D2H28.77.536.240.03.8 877.32E/D4V2.534.637.146.08.9 877.37E/D4H2.834.637.446.08.6 1754.7Hrn2V56.832.3-46.542.654.011.4 1754.9Hrn2H58.832.3-46.544.654.09.4 2632.0Hrn2V54.036.0-47.842.254.011.8 2632.0Hrn2H51.136.0-47.839.354.014.7 3509.5Hrn2V46.040.6-47.139.554.014.5 3509.5Hrn2H45.840.6-47.139.354.014.7 4386.7Hrn2V46.041.9-45.942.054.012.0 4386.8Hrn2H45.241.9-45.941.254.012.8 Notes: B/C = Biconical, B/L = Biconilog, L/P = Log-Periodic, H = Horn, D/P = Dipole * Re-measured using dipole antenna. ( ) Denotes failing emission level. (1) 120 kHz, Q-Peak, (2) 10 kHz, Peak, (3) 100 kHz RGW, 300 kHz V…

Text truncated - open the document above for the full version.
