F5301NB5132PC5132A-433 & P5132A-433 Receiver

Installation Manual PC5132-433 Version 4.0 • W A R N I N G • This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. WARNING Please Read Carefully Note to Installers This warning contains vital information. As the only individual in contact with system users, it is your responsibility to bring each item in this warn- ing to the attention of the users of this system. System Failures This system has been carefully designed to be as effective as possible. There are circumstances, however, involving fire, burglary, or other types of emergencies where it may not provide protection. Any alarm system of any type may be compromised deliberately or may fail to operate as expected for a variety of reasons. Some but not all of these reasons may be: nn nn n Inadequate Installation A security system must be installed properly in order to provide ad- equate protection. Every installation should be evaluated by a security professional to ensure that all access points and areas are covered. Locks and latches on windows and doors must be secure and operate as intended. Windows, doors, walls, ceilings and other building mate- rials must be of sufficient strength and construction to provide the level of protection expected. A reevaluation must be done during and after any construction activity. An evaluation by the fire and/or police department is highly recommended if this service is available. nn nn n Criminal Knowledge This system contains security features which were known to be effec- tive at the time of manufacture. It is possible for persons with criminal intent to develop techniques which reduce the effectiveness of these features. It is important that a security system be reviewed periodically to ensure that its features remain effective and that it be updated or replaced if it is found that it does not provide the protection expected. nn nn n Access by Intruders Intruders may enter through an unprotected access point, circumvent a sensing device, evade detection by moving through an area of insuf- ficient coverage, disconnect a warning device, or interfere with or prevent the proper operation of the system. nn nn n Power Failure Control units, intrusion detectors, smoke detectors and many other security devices require an adequate power supply for proper opera- tion. If a device operates from batteries, it is possible for the batteries to fail. Even if the batteries have not failed, they must be charged, in good condition and installed correctly. If a device operates only by AC power, any interruption, however brief, will render that device inop- erative while it does not have power. Power interruptions of any length are often accompanied by voltage fluctuations which may damage electronic equipment such as a security system. After a power inter- ruption has occurred, immediately conduct a complete system test to ensure that the system operates as intended. nn nn n Failure of Replaceable Batteries This system’s wireless transmitters have been designed to provide sev- eral years of battery life under normal conditions. The expected bat- tery life is a function of the device environment, usage and type. Am- bient conditions such as high humidity, high or low temperatures, or large temperature fluctuations may reduce the expected battery life. While each transmitting device has a low battery monitor which iden- tifies when the batteries need to be replaced, this monitor may fail to operate as expected. Regular testing and maintenance will keep the system in good operating condition. nn nn n Compromise of Radio Frequency (Wireless) Devices Signals may not reach the receiver under all circumstances which could include metal objects placed on or near the radio path or deliberate jam- ming or other inadvertent radio signal interference. nn nn n System Users A user may not be able to operate a panic or emergency switch possi- bly due to permanent or temporary physical disability, inability to reach the device in time, or unfamiliarity with the correct operation. It is important that all system users be trained in the correct operation of the alarm system and that they know how to respond when the system indicates an alarm. nn nn n Smoke Detectors Smoke detectors that are a part of this system may not properly alert occupants of a fire for a number of reasons, some of which follow. The smoke detectors may have been improperly installed or positioned. Smoke may not be able to reach the smoke detectors, such as when the fire is in a chimney, walls or roofs, or on the other side of closed doors. Smoke detectors may not detect smoke from fires on another level of the residence or building. Every fire is different in the amount of smoke produced and the rate of burning. Smoke detectors cannot sense all types of fires equally well. Smoke detectors may not provide timely warning of fires caused by carelessness or safety hazards such as smoking in bed, violent explosions, escaping gas, improper storage of flam- mable materials, overloaded electrical circuits, children playing with matches or arson. Even if the smoke detector operates as intended, there may be cir- cumstances when there is insufficient warning to allow all occu- pants to escape in time to avoid injury or death. nn nn n Motion Detectors Motion detectors can only detect motion within the designated ar- eas as shown in their respective installation instructions. They can- not discriminate between intruders and intended occupants. Mo- tion detectors do not provide volumetric area protection. They have multiple beams of detection and motion can only be detected in unobstructed areas covered by these beams. They cannot detect motion which occurs behind walls, ceilings, floor, closed doors, glass partitions, glass doors or windows. Any type of tampering whether intentional or unintentional such as masking, painting, or spraying of any material on the lenses…

Text truncated - open the document above for the full version.

December 22, 2000 Office of Engineering & Technology Federal Communications Commission Washington, D.C. 20554 Subject:Request for continuous confidentiality of technical information per sections 0.459 and 0.457 (d) (2) ( I) of CFR 47. FCC ID:F5301NB5132 Dear Sir or Madam: Digital Security Controls Canada Ltd. is hereby filing this request for continuous confidentiality of the specified items submitted with the application for certification ( Form731 ) with proposed identifier F5301NB5132. The technical documentation for which continuous confidentiality is sought is: (1) Schematic diagrams: (2) Block Diagram This technical documentation is a part of the material supporting the Form 731 application for certification, which this request for confidentiality accompanies. The schematic diagrams disclose proprietary information and technical data which Digital Security Controls Ltd. would guard from its competitors and would not make available to the public. This proprietary information constitutes a trade secret and is not a part of the product documentation that would be made available to the customers of Digital Security Controls Ltd. It would be potentially injurious to Digital Security Controls Ltd. and to its investment in the development of this innovative proprietary product to make available for public disclosure the trade secret technical information specified in this request. If there are any questions about this request for continuous confidentiality regarding trade secrets and proprietary information embodied in the technical documentation filed in support of this Form 731 application, then please contact me via our toll-free telephone number. Yours truly, Kevin Harris Approval Services Manager 905-760-3000 Ext. 2378 Email: [email protected]

Digital Security Controls Ltd.ISO9001 Registered3301 Langstaff Road, ConcordOntario, Canada L4K 4L2Phone: 905-760-3000Toll Free: 1-888-888-7838Fax: 905-760-3030 ® FCC/IC Labeling for P5132A-433 SIDE OF TRANSMITTER UNIT SHOWING PLACEMENT OF LABEL(ACTUAL SIZE) File: [p5132a-433_fcc+ic_lb_1800xxxx_r001.cdr] January 4, 2001 FCC ID: F5301NB5132 Model: P5132A-433 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-ditions: (1) This device may not cause harmful interference, and (2) this device must accept anyinterference received, including interference that may cause undesired operation.IC: RSS/CNR210 CANADA: 160 XXX XXXX MADE IN CANADA 1800xxxx R001 This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numériquede la classe B respecte toutes les exigences du ICES-003. DASHED LINE INDICATESCUT EDGE OF LABELLABEL TO BE PRINTEDON CLEAR SELF-ADHESIVEMATERIALLABEL SHOWN 250% ACTUAL SIZE 44.5 mm 9.5 mm

Digital Security Controls Ltd.ISO9001 Registered3301 Langstaff Road, ConcordOntario, Canada L4K 4L2Phone: 905-760-3000Toll Free: 1-888-888-7838Fax: 905-760-3030 ® FCC/IC Labeling for PC5132A-433 SIDE OF TRANSMITTER UNIT SHOWING PLACEMENT OF LABEL(ACTUAL SIZE) File: [pc5132a-433_fcc+ic_lb_1800xxxx_r001.cdr] January 4, 2001 FCC ID: F5301NB5132 Model: PC5132A-433 Digital Security Controls Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-ditions: (1) This device may not cause harmful interference, and (2) this device must accept anyinterference received, including interference that may cause undesired operation.IC: RSS/CNR210 CANADA: 160 XXX XXXX MADE IN CANADA 1800xxxx R001 This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numériquede la classe B respecte toutes les exigences du ICES-003. DASHED LINE INDICATESCUT EDGE OF LABELLABEL TO BE PRINTEDON CLEAR SELF-ADHESIVEMATERIALLABEL SHOWN 250% ACTUAL SIZE 44.5 mm 9.5 mm

CIRCUIT DESCRIPTION Device: Narrow Band Receiver Model: PC 5132/4164 LC ETSI Identifier: Schematic Diagram: Description: This is a description of the receiver section for the PC 5132 product. The receiver of the PC 5132 is a narrow band ASK design meant for 433.92MHz signal reception. It receives signals in the area of coverage, demodulate the signals then have those signals processed and acted upon by the microprocessor and digital section of the PC 5132. The receiver can be divided into two main circuit sections, an ASK receiver and a control section which it shares with the other functions of the board. ASK Receiver: The antenna receives the incoming signals and feeds them to the RF Front End amplifiers and filter to achieve good sensitivity and selectivity. The RF signal is then fed to the mixer. The mixer combines the signals from the RF filter and the local oscillator. The oscillator circuit consists of a crystal reference oscillator, a programmable divider, and a phase detector forming a phase-lock-loop (PLL) system. The PLL is responsible for locking the free running voltage control oscillator (VCO) to 423.22MHz. After mixing, a filter centered around 10.7 MHz is used to pass the desired IF signals to the IF amplifier and the demodulator. The demodulated signal from the Receiver chip is again externally filtered and shaped to derive the digital baseband information. This information is then presented to the microprocessor for decoding. The Control Section: The digital control circuitry operates the selecting and switching of the two antennas that are terminated into the Front End of the receiver. It decodes the baseband information, makes the decision of whether or not the decoded information is a valid one and then acts upon it accordingly. It also monitors the receiver for any interference condition.

Master: ktlPT15BR Date: April 6, 2000 KTL Test Report:0R03391 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Vaughan, Ontario L4K 4L2 Equipment Under Test:P5132A-433 (E.U.T.)PC5132A-433 Receiver FCC ID:F5301NB5132 In Accordance With:FCC Part 15, Subpart B Radio Receivers Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: G. Westwell, Technologist Date: Total Number of Pages:10 KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 0R03391 EQUIPMENT: P5132A-433, PC5132A-433 Receiver FCC ID: F5301NB5132 Page 2 of 10 Table Of Contents Section 1. Summary of Test Results.......................................................................................... 3 Section 2. General Equipment Specification ........................................................................... 5 Section 3. Radiated Emissions...................................................................................................6 Section 4. Block Diagrams......................................................................................................... 9 Section 5. Test Equipment List ............................................................................................... 10 KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 0R03391 EQUIPMENT: P5132A-433, PC5132A-433 Receiver FCC ID: F5301NB5132 Page 3 of 10 Section 1.Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15, Subpart B. Measurement procedure ANSI C63.4-1992 was used for all tests. Radiated Emissions were measured on an open area test site. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit CYY Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Russell Grant, Wireless Group Manager KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 0R03391 EQUIPMENT: P5132A-433, PC5132A-433 Receiver FCC ID: F5301NB5132 Page 4 of 10 Summary Of Test Data Name Of TestPara. No.Results Antenna Conducted Emissions15.111Not Applicable Radiated Emissions15.109Complies Powerline Conducted Emissions15.107Not Applicable KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 0R03391 EQUIPMENT: P5132A-433, PC5132A-433 Receiver FCC ID: F5301NB5132 Page 5 of 10 Section 2.General Equipment Specification Manufacturer: Digital Security Controls Ltd. Model No.: P5132A-433, PC5132A-433 Date Received In Laboratory: December 18, 2000 KTL Identification No.: Item #1 Frequency Range: 433.92 MHz Fixed Number of Channels: 1 Primary Power Requirement: 12 VDC KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 0R03391 EQUIPMENT: P5132A-433, PC5132A-433 Receiver FCC ID: F5301NB5132 Page 6 of 10 Section 3.Radiated Emissions Para. No.: 15.109(a) Test Performed By: Russell Grant Date of Test: January 2, 2001 Minimum Standard: Frequency(MHz)Field Strength (dB μ μμ μ V/m @ 3m) 30 - 8840.0 88 - 21643.5 216 - 96046.0 Above 96054.0 Test Results: Complies. The worst-case emission level is 37.4 dBμV/m @ 3m at 423.22 MHz. This is 8.6 dB below the specification limit. Measurement Data: See attached table. For super-regenerative receivers the receiver is cohered using a signal generator and dipole antenna. Handheld equipment and equipment not designed to be mounted in any fixed orientation, the E.U.T. is tested in three orthogonal axis to obtain worst case results. KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 0R03391 EQUIPMENT: P5132A-433, PC5132A-433 Receiver FCC ID: F5301NB5132 Page 7 of 10 Test Data - Radiated Emissions Test Distance (meters) : 3 Range : A Towe r Re ce ive r: ESVP/8565E RBW(kHz ): 120/1000 Detector: Peak Fre q. (M Hz) Ant. * Pol. (V/H) RCVD Signal (dB μ μμ μ V/m) Ant. Factor (dB)** Amp. Gain (dB)*** Dist. Corr. (dB) Fie ld Strength (dB μ μμ μ V/m) Limit (dB μ μμ μ V/m) Margin (dB) 423.22E/D4V12.724.737.446.08.6 423.22E/D4H10.424.735.146.010.9 846.44E/D4V-13.531.317.846.028.2 846.44E/D4H-9.731.321.646.024.4 1269.66Hrn2V54.230.5-48.036.754.017.3 1269.66Hrn2H48.830.5-48.031.354.022.7 1692.88Hrn2V36.832.0-48.020.854.033.2 1692.88Hrn2H44.032.0-48.028.054.026.0 Note s: B/C =Biconical, B/L = Biconilog, L/P = Log-Periodic, H = Horn, D/P = Dipole *Re-Measured Using Dipole Antenna. ( ) Denotes Failing Emission Level. (1) 120 kHz, Q-Peak, (2) 10 kHz, Peak, (3) 100 kHz RGW, 300 kHz VBW, Peak, (4) 300 kHz RBW, 1 MHz VBW, Peak, (5) 1 MHz RBW, 3 MHz VBW, Peak, (6) 1 MHz RBW, 10 Hz VBW, Peak N.D. = Not Detected KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 0R03391 EQUIPMENT: P5132A-433, PC5132A-433 Receiver FCC ID: F5301NB5132 Page 8 of 10 Radiated Photographs Front View KTL Ottawa FCC PART 15, SUBPART B RADIO RECEIVERS PROJECT NO.: 0R03391 EQUIPMENT: P5132A-433, PC5132A-433 Receiver FCC ID: F5301NB5132 Page 9 of 10 Section 4.Block Diagrams Radiated Prescan SPECTRUM ANALYZER AND PLOTTER OR TEST RECEIVER COMPUTER ANTENNA E.U.T. SHIELDED ROOM Outdoor Test Site For Radiated Emissions The spectrum was searched up to the 10th harmonic of the fundamental frequency of operation. 3 METERS E.U.T. NON-CONDUCTING TURN-TABLE 0.8 METER VARIABLE SEARCH…
