F5301NB925LWLS925L-433NA & PWLS925L-433NA

WLS925L-433Mini Door/Window ContactInstallation InstructionsRemove CoverAt the notched location on the cover, insert the flat blade of a small screwdriverbetween the base and the cover and twist the screwdriver to pop the cover off.Install BatteryUse care when installing the battery and observe the correct polarity (see dia-gram below). Use only the Eveready Lithium Energizer No. EL123AP or TeckcellCR123A battery.WARNING!: Battery may explode if mistreated. Do not recharge, disassemble or dispose of in fire. Locate TransmitterSelect the location where the transmitter is to be mounted. Perform the ModulePlacement Test to ensure that the selected location is in range of the wirelessreceiver (see receiver Installation Manual for instructions). Remove Circuit BoardBefore mounting the unit, remove the circuit board. At the notched location onthe base which is on the same side as the reed switch, insert the blade of asmall screwdriver between the base wall and the bottom of the circuit boardand pry the circuit board up.NOTE: Do not touch the coils on the circuit board as this may dam-age the unit.Mount Transmitter and MagnetMount the backplate of the transmitter using the screws provided and replacethe circuit board. The head of the screw must be below the circuit board so thatthe sensor is not shorted out. Use flat-headed screws only.Mount the magnet no more than ¼” from the transmitter. Use the spacers pro-vided. Once the unit and magnet are mounted, open and close the window/door to ensure that none of the parts interfere with this movement. Only onemagnet can be used per transmitter.Using External ContactsThe external contact terminals can be used to connect external contacts orother switches/devices to the universal transmitter. Install the additional deviceas per the manufacturer’s instruction. Connect the device to the contact termi-nals of the WLS925L.The input is normally closed and is not supervised.For UL installations, the wires connecting the external device to the input termi-nals must not exceed 36" (90.5 cm) in length. The contact and transmitter mustalso be in the same room.For non-UL installations, the wires connecting the external device to the inputterminals can be any length provided that the resistance of the wire does notexceed 100 Ohms. Only one contact can be used. If an external contact isused, do not install the magnet.NOTE: When installing the WLS925L-433 with the use of the externalcontact, ensure that the terminal block wiring is kept away from theantenna. WLS925L-433Contact miniature pour Porte/Fenêtre Instructions d’InstallationEnlevez le couvercleVis-à-vis l’encoche dans le couvercle, insérez la lame d’un petit tournevis plat entrela base et le couvercle et tournez le tournevis de façon à faire ouvrir le couvercle.Installez la pileInstallez minutieusement la pile en prenant soin de respecter la polarité (voir figureci-dessous). Utilisez seulement une pile de marque Eveready Lithium Energizer No.EL123AP ou Teckcell CR123A.AVERTISSEMENT!: La pile peut exploser si elle n’est pas utilisée cor- rectement. Ne pas recharger, démonter ou jeter au feu.Positionnez le transmetteurPlacez le transmetteur à l’endroit où vous souhaitez l’installer. Exécutez un Testd’emplacement pour vous assurer que l’endroit choisi est à l’intérieur de la portée durécepteur (pour plus de détails, référez-vous au manuel d’installation du récepteur).Retirez le circuit Avant de fixer l’unité, retirez le circuit électronique. Insérez la lame d’un petittournevis plat entre la base et le bas du circuit vis-à-vis l’encoche du côté du com-mutateur à lames. Ensuite, soulevez le circuit à l’aide du tournevis.NOTE: Ne touchez pas aux selfs sur le circuit, cela pourrait endom-mager l’unité.Fixez le transmetteur et l’aimant Fixer la plaque arrière du transmetteur avec les vis fournies et replacez le circuit.Pour éviter les courts-circuits, la tête des vis doit être plus basse que le circuit. Uti-lisez seulement des vis à tête plate.Ne fixez pas l’aimant à plus de ¼” du transmetteur. Utilisez les separateurs fournis.Une fois que l’unité et l’aimant sont installés, ouvrez et fermez la porte/fenêtrepour vous assurer qu’aucune chose n’interfère avec le mouvement. Un seul aimantpeut être utilisé par transmetteur.Usage d’un contact externeLes bornes de contact externe peuvent être utilisées pour raccorder des contacts oud’autres dispositifs externes au transmetteur universel. Installez les dispositifs addi-tionnels en suivant les instructions du fabricant. Raccordez le dispositif aux bornespour contact externe du WLS925L. L’entrée est normalement fermée et n’est passupervisée.Pour les installations UL, la longueur du fil utilisé pour raccorder le dispositifexterne aux bornes d’entrée ne doit pas excéder 36" (90.5 cm). Le contact et letransmetteur doivent également être dans la même pièce. Pour les installations quine sont pas UL, le fil raccordant le dispositif aux bornes d’entrée peut être den’importe quelle longueur pourvu que la résistance du fil n’excède pas 100 Ohms.Un seul contact peut être utilisé; si un contact externe est utilisé, n’installez pasl’aimant du transmetteur.NOTE: Lorsque vous utilisez le WLS925L avec un contact externe,assurez-vous d’installer le fil à l’écart de l’antenne.” WLS925L-433Mini Contacto de Puerta/VentanaInstrucciones de InstalaciónRemover la CubiertaEn la ubicación dentada de la cubierta, inserte la cabeza plana de un destornilladorpequeño entre la base y la cubierta y mueva el destornillador para abrir la cubierta.Instalarla BateríaTenga cuidado cuando esté instalando la batería y observe la polaridad correcta (veael siguiente diagrama). Use solamente baterías Eveready de Litio Energizer No.EL123AP o Teckcell CR123A.ADVERTENCIA!: Las baterías puede explotar si son maltratada. No recar- gar, desmontar o botar en fuego.Colocar TransmisorEstablezca el lugar donde el transmisor va a ser colocado. Efectúe la Prueba de ubi-cación del Módulo para asegurarse que la ubicación selecci…

Text truncated - open the document above for the full version.

September 11, 2001 Office of Engineering & Technology Federal Communications Commission Washington, D.C. 20554 Subject:Request for continuous confidentiality of technical information per sections 0.459 and 0.457 (d) (2) ( I) of CFR 47. FCC ID:F5301NB925L Dear Sir or Madam: Digital Security Controls Canada Ltd. is hereby filing this request for continuous confidentiality of the specified items submitted with the application for certification ( Form731 ) with proposed identifier F5301NB925L. The technical documentation for which continuous confidentiality is sought is: (1) Schematic diagrams, PCB Layers (2) Parts List (3) Operational Description (4) Block diagrams This technical documentation is a part of the material supporting the Form 731 application for certification, which this request for confidentiality accompanies. The schematic diagrams disclose proprietary information and technical data which Digital Security Controls Ltd. would guard from its competitors and would not make available to the public. This proprietary information constitutes a trade secret and is not a part of the product documentation that would be made available to the customers of Digital Security Controls Ltd. It would be potentially injurious to Digital Security Controls Ltd. and to its investment in the development of this innovative proprietary product to make available for public disclosure the trade secret technical information specified in this request. If there are any questions about this request for continuous confidentiality regarding trade secrets and proprietary information embodied in the technical documentation filed in support of this Form 731 application, then please contact me via our toll-free telephone number. Yours truly, Kevin Harris Approval Services Manager 905-760-3000 Ext. 2378 Email: [email protected]

FCC/ICES-003 Labeling for PWLS925L-433NA Wireless Mini Door/Window Contact File: [PWLS925l-433NA_fcc+ices-003_lb_1800xxxx_r001.cdr] July 12, 2001 Dashed line indicates cut edge of label Label to be printed on self-adhesive material Label shown 250% of actual size 35 mm 12.7 mm Bottom of the unit showing placement of label (Actual size) Digital Security Controls Ltd. ISO9001 Registered 3301 Langstaff Road, Concord Ontario, Canada L4K 4L2 Phone: 905-760-3000 Toll Free: 1-888-888-7838 Fax: 905-760-3030 ® PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. 1800xxxx R001FCC + ICES-003 Labeling Label size: 35mmW × 12.7mmH 100-up PWLS925L-433NA Wireless Mini Door/Window Contact File: [PWLS925l-433NA_fcc+ices-003_lb_1800xxxx_r001.cdr] JUL1101 Die #201 PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must ac- cept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. PWLS925L-433NA Digital Security Controls Ltd.1800xxxx R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful inte…

Text truncated - open the document above for the full version.

FCC/ICES-003 Labeling for WLS925L-433NA Wireless Mini Door/Window Contact File: [wls925l-433NA_fcc+ices-003_lb_18007735_r001.cdr] July 12, 2001 Dashed line indicates cut edge of label Label to be printed on self-adhesive material Label shown 250% of actual size 35 mm 12.7 mm Bottom of the unit showing placement of label (Actual size) Digital Security Controls Ltd. ISO9001 Registered 3301 Langstaff Road, Concord Ontario, Canada L4K 4L2 Phone: 905-760-3000 Toll Free: 1-888-888-7838 Fax: 905-760-3030 ® WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. 18007735 R001FCC + ICES-003 Labeling Label size: 35mmW × 12.7mmH 100-up WLS925L-433NA Wireless Mini Door/Window Contact File: [wls925l-433NA_fcc+ices-003_lb_18007735_r001.cdr] JUL1101 Die #201 WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including in- terference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. WLS925L-433NA Digital Security Controls Ltd.18007735 R001 FCC ID: F5301NB925L IC: RSS/CNR210 CANADA 160 xxx xxxxMADE IN CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful …

Text truncated - open the document above for the full version.

Master:PT15231 Date: February 25, 2001 Test Report:1W04031 Applicant:Digital Security Controls Ltd. 3301 Langstaff Road Vaughan, Ontario L4K 4L2 Equipment Under Test:WLS925L-433NA (EUT)433MHz Door Contact In Accordance With:FCC Part 15, Subpart C For Low Power Transmitters Operating Periodically In The Band 40.66 - 40.77 MHz And Above 70 MHz Tested By:Nemko Canada Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: R. Grant, Wireless Group Manager Date: Total Number of Pages:24 Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 2 of 22 Table of Contents Section 1. Summary of Test Results.......................................................................................... 3 Section 2. Equipment Under Test (EUT) ................................................................................. 5 Section 3. Transmission Requirements .................................................................................. 11 Section 4. Radiated Emissions................................................................................................. 15 Section 5. Occupied Bandwidth.............................................................................................. 18 Section 6. Block Diagrams.......................................................................................................20 Section 7. Test Equipment List ............................................................................................... 22 Annex A Restricted Bands.................................................................................................... A1 Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 3 of 22 Section 1.Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.231. All tests were conducted using measurement procedure ANSI C63.4-1992. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit DS C Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: ___________________________ DATE: ___________________ Wayne Clarke, Wireless Technologist Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 4 of 22 Summary Of Test Data Name of TestPara. NumberResults Transmission Requirements15.231(a)Complies Radiated Emissions15.231(b)Complies Occupied Bandwidth15.231(c)Complies Frequency Tolerance15.231(d)N/A Periodic Alternate Field Strength Requirements15.231(e)N/A Powerline Conducted Emissions15.207N/A Footnotes For N/A’s: Test Conditions: IndoorTemperature: 23 °C Humidity:50 % OutdoorTemperature: 26 °C Humidity:78 % Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 5 of 22 Section 2.Equipment Under Test (EUT) General Equipment Information Manufacturer:Digital Security Controls Ltd. Model No.:WLS925L-433NA Serial No.:None Date Received In Laboratory:June 14, 2001 Nemko Identification No.:Item #2 Frequency Range:433 MHz Operating Frequency(ies) of Sample:433.92 MHz Type of Emission:L1D Emission Designator:45K0L1D Supply Power Requirement:Lithium CR123A Battery Duty Cycle Calculation:20 log on time ms 100 ms -18.2dB as declared by the manufacturer. Graphs confirm declaration. Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 6 of 22 Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 7 of 22 Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 8 of 22 Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 9 of 22 Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 10 of 22 Nemko Canada Inc. FCC PART 15, SUBPART C FOR LOW POWER TRANSMITTERS PROJECT NO.: 1R04031 EQUIPMENT: WLS925L-433NA 433MHz Door Contact Page 11 of 22 Section 3.Transmission Requirements Para. No.: 15.231(a) Test Performed By: Wayne ClarkeDate of Test: June 15, 2001 Minimum Standard:15.231(a) Continuous transmissions such as voice, video or data transmissions are not permitted. 15.231(a)(1) A manually operated transmitter shall employ a switch that will automatically deactivate the transmitter within not more than 5 seconds after being released. 15.231(a)(2) A transmitter activated automatically shall cease transmission within 5 seconds of activation. 15.231(a)(3) Periodic transmissions at regular pre-determined intervals are not permitted. However polling or supervisory transmissions to determine system integrity of transmitters used in security or safety…

Text truncated - open the document above for the full version.
