F5310WS4920Wireless Alarm Repeater

NOTE: Use these instructions in conjunction with the installation manual of the alarm panel with which this equipment is intended to be used. WARNING: READ and SAVE These Instructions! Follow All WARNINGS AND INSTRUCTIONS specified within these instruction and/or on the equipment. WS4920 v1.0 Installation Instructions 29007856R001 SAFETY INSTRUCTIONS for WS4920 WIRELESS REPEATER IMPORTANT: This equipment, WS4920 WIRELESS REPEATER 1.0 shall be used installed and used within an environment that provides the pollution degree max 2 and overvoltages category II NON HAZARDOUS LOCATIONS, indoor only. The equipment is FIXED and DIRECT PLUG IN powered from the mains; it is designed to be installed by Service Persons only; [Service Person is defined as a person having the appropriate technical training and experience necessary to be aware of hazards to which that person may be exposed in performing a task and of mea- sures to minimize the risks to that person or other persons. 1. The equipment is installed in a FIRE ENCLOSURE. 2. If during the installation a knockout is removed, it is the installer's responsibility to ensure that the same degree of protection for the enclosure is provided by the use of bushings, fittings, etc. 3. The enclosure must be secured to the building structure before operation. 4. Internal wiring must be routed in a manner that prevents: •Excessive strain on wire and on terminal connections; •Loosening of terminal; connections; •Damage of conductor insulation 5. It is the end-user and/or installer's responsibility to ensure that the disposal of the used batteries (battery pack) is made according to the waste recovery and recycling regulations applicable to the intended market. WARNING: When using equipment connected to the MAINS, always follow basic safety instructions. Refer to the SAFETY INSTRUCTIONS provided with this product; save them for (future) reference. Instruct the end-user regarding the safety precautions that shall be observed when operating this equipment. SAFETY precautions required during installation: • NEVER install this EQUIPMENT during A Lightning Storm! • NEVER touch uninsulated wires or terminals unless the Direct Plug In transformer has been disconnected • Ensure that Cables are positioned so that accidents cannot occur. Connected Cables must NOT be subject to excessive mechanical strain • Use Only the Power Supply supplied with this equipment. Use of unauthorized power supplies may cause damage the repeater!!! • The AC Socket/Outlet powering the equipment shall be located near the equipment and shall be easily accessible. • Do NOT locate this product where persons will walk on the secondary circuit cable(s). • Do NOT use extension cords to PLUG-IN the Power Supply of this equipment. • AVOID setting up the equipment near heaters, air conditioners, ventilators, and/or refrigerators • Do NOT connect to electrical outlets on the same circuit as large appliances. • Do NOT select a place exposed to direct sunlight, excessive heat, moisture, vapors, chemicals or dust. • Do NOT install this Equipment near water. (e.g., bath tub, wash bowl, kitchen/laundry sink, in a wet basement, or near swimming pool, etc.). • Do NOT install this equipment and its accessories in areas where there is a risk of explosion. • Do NOT connect this equipment to electrical outlets controlled by wall switches or automatic timers; avoid interference sources. WARNING: THIS EQUIPMENT HAS NO MAINS ON/OFF SWITCH. THE PLUG OF THE DIRECT PLUG-IN POWER SUPPLY IS INTENDED TO SERVE AS THE DISCONNECTING DEVICE IF THE EQUIPMENT MUST BE QUICKLY DISCONNECTED. IT IS IMPERATIVE THAT ACCESS TO THE MAINS PLUG AND ASSOCIATED MAINS SOCKET/OUTLET, IS NEVER OBSTRUCTED. The WS4920 is a wireless repeater designed to extend the range of DSC one-way wireless transmitters and to improve signal quality between the transmitter and the receiver. Use the WS4920 to remedy transmission problems caused by excessive noise or other interference, or by long distances between devices and receivers. Up to 4 repeaters can be installed per alarm system. The WS4920 is compatible with all DSC 433 MHz one-way wireless transmitters, receivers and alarm panels. It can also be used with 2-way alarm panels, but only for 1-way devices. Specifications • Temperature range: 0°C to +50°C (32°F-122°F) • Humidity (Max): 5% - 93% R.H. non condensing • Transformer: 16VAC, 20VA • Battery backup time: 24 hours • Battery charging rate: 80% within 24 hours • Operating frequency: 433.92 MHz • Dimensions: H6.96, W4.47, D1.33 in. • Weight: 2 lb. Unpacking Ensure your package includes the following: Controls and Indicators The WS4920 has three LEDs on the front used to communicate information. The LEDs indicate the following: In addition, the WS4920 has an internal Pro- gramming button to place the repeater into Enroll/Placement modes. It also includes a jumper to prevent RF jam troubles from being sent to the panel. When the jumper is open, RF jam troubles are not transmitted. Install the WS4920 in the following order: A. Temporarily mount in preferred location B. Connect power (battery first then AC) C. Receiver placement test (detects interference between repeater and wireless devices) Introduction • One WS4920 • One direct plug-in transformer (kit dependant) • Mounting hardware pack, including plastic wall plugs and screws • Installation instructions LEDNormal Mode (cover on) Installer Mode (cover off) GreenOn: AC present Flashing: No AC, battery good Off: No AC, low or dead battery 1 flash: Enrolled Flashing: Placement test active Red On: Battery not connected Flashing: Low battery Off: Battery good (if AC on) Flashing: Zone not enrolled Yellow On: RF jam present Off: No RF jam On: Receiver place- ment test “bad” Off: Receiver place- ment test “good” GreenYellow Red Installation Programming Button D. Enroll with alarm panel E. Placement test with alarm panel (Detects interfer- ence between repeater and panel) F. Enroll/Placement test wirele…

Text truncated - open the document above for the full version.

November 11, 2010 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Nemko Canada Inc., 303 River Road, Ottawa, Ontario, Canada K1V 1H2 to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Digital Security Controls, 3301 Langstaff Road, Concord, Ontario Canada L4K 4L2. Dated this 11th Day ofNovember 20 10 Agency agreement expiration date: November 10, 2011 By: Dan Nita Signature Printed Title: Approvals Manager On behalf of : Digital Security Controls Telephone: 905-760-3000, Ext. 2706

November 11 th , 2010 Equipment Authorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: F5310WS4920 Product Name: DSC Wireless Alarm Repeater Model: WS4920 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Parts List • Block diagram • Operational description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 11 th Day ofNovember 20 10 By: Dan Nita Signature Printed Title: Approval Manager On behalf of : Digital Security Controls Telephone: 905-760-3000, Ext. 2706

18008536R001 WS4920 FCC/IC Label November 2, 2010 Digital Security Controls ISO9001 Registered 3301 Langstaff Road, Concord Ontario, Canada L4K 4L2 Phone: 905-760-3000 Toll Free: 1-888-888-7838 Fax: 905-760-3020 9.5 mm Label shown 200% of actual size Colour: Pantone Process Black Material: CLEAR Durable Semi-gloss Self-adhesive Material - on a roll Lamination: Top gloss finish lamination (e.g. 1F9, or equivalent) Adhesive: Permanent adhesive backed with protective liner Cutting: Tolerance +/- 0.010” Dashed line indicates cutting - will not print NOTES: 1. All items must be RoHS compliant. 2. Markings on label must be PERMANENT. 3. Indelible ink. 4. Conductive inks must not be used. 44.5 mm FCC ID: F5310WS4920 Model: WS4920 DIGITAL SECURITY CONTROLS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. IC:160A-WS4920 MADE IN CANADA 18008536R001 FCC ID: F5310WS4920 Model: WS4920 DIGITAL SECURITY CONTROLS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus meets all requirements of the ICES-003. Cet appareil numérique de la classe B respecte toutes les exigences du ICES-003. IC:160A-WS4920 MADE IN CANADA 18008536R001 The label is to be located on the top of the back housing of the unit as shown above. Label 18008536

www.nemko.com Nemko Canada Inc., 303 River Road, R.R. 5, Ottawa, Ontario, Canada, K1V 1H2 Report number: 161041-1TRFWL Apparatus: Wireless Alarm Repeater Applicant: Digital Security Controls, a Division of Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, ON, Canada L4K 4L2 FCC ID: F5310WS4920 Test specification: Title 47-Telecommunication Chapter I - Federal Communications Commission Subchapter A - General Part 15 - Radio Frequency Devices Subpart C - Intentional Radiators §15.231- Periodic operation in the band 40.66–40.70 MHz and above 70 MHz Reviewed by: Signature Date: November 22, 2010 Richard Brazeau, Laboratory Manager Tested by: Kevin Ma, Technical Assessor Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any suffered by any third party as a result of decisions made or actions based on this report. This report shall not be reproduced except in full without the written approval of the testing laboratory. Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation. Report Number: 161041-1TRFWL Nemko Canada Inc., 303 River Road, R.R. 5, Ottawa, Ontario, Canada, K1V 1H2 Specification: FCC 15.231 Page 2 of 23 Table of contents Section 1: Report summary.....................................................................................................................3 Section 2: Equipment under test.............................................................................................................4 2.1 Identification of equipment under test (EUT)...............................................................................4 2.2 Accessories and support equipment...........................................................................................4 2.3 EUT description...........................................................................................................................4 2.4 Technical specifications of the EUT............................................................................................4 2.5 EUT setup diagram.....................................................................................................................5 2.6 Operation of the EUT during testing............................................................................................5 2.7 Modifications incorporated in the EUT........................................................................................5 Section 3: Test conditions.......................................................................................................................6 3.1 Deviations from laboratory tests procedures...............................................................................6 3.2 Test conditions, power source and ambient temperatures..........................................................6 3.3 Measurement uncertainty............................................................................................................7 3.4 Test equipment............................................................................................................................7 Section 4: Result summary......................................................................................................................8 4.1 FCC Part 15 Subpart C, 15.231: Test results..............................................................................8 Appendix A: Test results..........................................................................................................................9 Clause 15.31(e) Variation of the power source..................................................................................9 Clause 15.203 Antenna requirement...................................................................................................10 Clause 15.207(a) Conducted limits.....................................................................................................11 Clause 15.231(a) Conditions for intentional radiators to comply with periodic operation....................14 Clause 15.231(b) Field strength of emissions.....................................................................................17 Clause 15.231(c) Emission bandwidth................................................................................................22 Appendix B: Block diagrams of test set-ups........................................................................................23 Section 1: Report summary Report Number: 161041-1TRFWL Nemko Canada Inc., 303 River Road, R.R. 5, Ottawa, Ontario, Canada, K1V 1H2 Specification: FCC 15.231 Page 3 of 23 Section 1: Report summary This report contains an assessment of apparatus against specifications based upon tests carried out on samples submitted at Nemko Canada Inc. Test specification: FCC Part 15 Subpart C, 15.231 Periodic operation in the band 40.66–40.70 MHz and above 70 MHz. Compliance status: Complies Exclusions: None Non-compliances: None Report release history: Original release Test location: Nemko Canada Inc. 303 River Road, R.R. 5, Ottawa, Ontario, Canada, K1V 1H2 Registration number: 176392 (3 m Semi anechoic chamber) Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its …

Text truncated - open the document above for the full version.
