F5313WTK5504PWireless Touchscreen Keypad for Alarm System

WTK5504 v1.0 Touchscreen User Manual WARNING: This manual contains information on limitations regarding product use, function and information on the limitation as to liability of the manufacturer. The entire manual should be carefully read. 1 Read and save these instructions! Follow all warnings and instructions specified within this document and/or on the equipment. Always ensure you obtain the latest version of the User Guide. Updated versions of this User Guide are available by contacting your distributor . Use these instructions in conjunction with the Installation Manual of the alarm panel with which this equipment is intended to be used. IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electric shock and/or injury, observe the following: • Do not spill any type of liquid on the equipment. • Do not attempt to service this product yourself. Opening or removing the cover may expose you to dangerous voltage or other risk. Refer servicing to qualified service personnel. Never open the device yourself. • Do not touch the equipment and its connected cables during an electrical storm; there may be a risk of electric shock. • Do not use the Alarm System to report a gas leak if the system is near a leak. REGULAR MAINTENANCE AND TROUBLESHOOTING Keep your WTK5504 Touchscreen keypad in optimal condition by following all the instructions that are included within this manual and/or marked on the product. HANDLING PRECAUTIONS • Do not subject the touchscreen to mechanical shock (e.g., dropping or striking). Mechanical shock could damage the glass display. • If the touchscreen glass is damaged, the liquid crystal fluid inside could leak out. Avoid contact with the liquid crystal fluid. If the liquid crystal fluid comes into contact with your skin or clothes, promptly wash it of f using soap and water. • Do not apply excessive force to the display surface or adjoining areas. Excessive force will distort the image on the display. • Do not use hard or sharp implements to operate the touchscreen. Operating the touchscreen with any implement harder than a finger could scratch the display. • Do not attempt to disassemble the LCD Module. CLEANING • If the display surface is contaminated, breathe on the surface and gently wipe it with a soft, dry cloth. If still not completely clean, moisten cloth with isopropyl alcohol. • Clean the touchscreen with a soft cloth and isopropyl alcohol. Use of other cleaners such as water, ketone (e.g., acetone), and/or aromatic solvents (e.g., benzene and toluene) may damage the display . Do not use abrasives, water , thinners, solvents or aerosol cleaners (spray polish), any aromatic sol- vents, ketones etc. that may enter through holes in the WTK5504 Touchscreen keypad and cause damage. TROUBLESHOOTING Occasionally, you may have a problem with your system. If this happens, your Alarm Controller will identify the problem and display an error message. Refer to the provided list when you see an error message on the display . If additional help is required, contact your distributor for service. WARNING: This equipment, the WTK5504 T ouchscreen keypad, shall be installed and used within an environment that provides the pollution degree max 2 and over -voltages category II non-hazard- ous locations, indoor only . It is designed to be installed, serviced and/or repaired by service persons only [service person is defined as a person having the appropriate technical training and experience necessary to be aware of hazards to which that person may be exposed in performing a task and of measures to minimize the risks to that person or other persons]. There are no parts replaceable by the end-user within this equipment. Never obstruct the access to the Alarm controller to which this equipment is connected. These safety instructions should not prevent you from contacting the distributor and/or the manufacturer to obtain any further clarification and/or answers to your concerns. About Your Security System Your DSC Security System has been designed to provide you with the greatest possible flexibility and convenience. Read this manual carefully and have your installer instruct you on your system's operation and on which features have been implemented in your system. All users of this system 2 should be equally instructed in its use. Fill out the “System Information” page with all of your zone information and access codes and store this manual in a safe place for future reference. NOTE: The PowerSeries, Alexor, and Impassa security systems include specific false alarm reduc- tion features and are classified in accordance with ANSI/SIA CP-01 Control Panel Standard - Features for False Alarm Reduction. Please consult your installer for further information regard- ing the false alarm reduction features built into your system as all are not covered in this manual. Carbon Monoxide Detection (must be enabled by your Installer) This equipment is capable of monitoring carbon monoxide detectors and providing a warning if carbon monoxide is detected. Please read the Family Escape Planning guidelines in this manual and instructions that are available with the carbon monoxide detector. Fire Detection (must be enabled by your Installer) This equipment is capable of monitoring fire detection devices such as smoke detectors and providing a warning if a fire condition is detected. Good fire detection depends on having adequate number of detectors placed in appropriate locations. This equipment should be installed in accordance with NFPA 72 (N.F.P.A., Batterymarch Park, Quincey MA 02269). Carefully review the Family Escape Planning guidelines in this manual. Testing To insure that your system continues to function as intended, you must test your system weekly. Please refer to the “Testing your System” section in this manual. If your system does not function properly, call your installing company for service. Monitoring This system is capable of transmitting alarms, troubles & emergency informati…

Text truncated - open the document above for the full version.

Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 www.dsc.com January 2, 2013 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Nemko Canada Inc., 303 River Road, Ottawa, Ontario, Canada K1V 1H2 to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Digital Security Controls, 3301 Langstaff Road, Concord, Ontario Canada L4K 4L2. Dated this 2nd Day of January 20 13 Agency agreement expiration date: January 2, 2014 By: Dan Nita Signature Printed Title: Approvals Manager On behalf of : Digital Security Controls Telephone: 905-760-3000, Ext. 2706

1 January 08, 2013 To Whom It May Concern: Keypad Models WTK5504-433 and WTK5504P-433 use a touchscreen LCD to display the status of the of the DSC compatible alarm control units Models PC9155(D)(G)(I)-433, SCW9055/57-433 and Power Series. The Models WTK5504-433 and WTK5504P-433 are all identical in construction and functionality with the exception of the model number. The Model WTK5500P-433 includes also a magnet for use in conjunction with the Prox Tag Model PT4 for arming and disarming of the control units. Despite the system configuration differences there should be no difference in RF performance and functionality of the WTK5504-433 and WTK5504P-433 Wireless Keypads for alarm system. Respectfully yours, Dan Nita Approvals Manager

Ja E F 7 C F P M R P d T p b D th B T O T anuary 2, 20 Equipment A Federal Com 435 Oaklan d Columbia, MD FCC ID: F531 Product Nam Models: WTK Request for Pursuant to ocuments b • Sche m • Parts • Block • Oper a These mater ublic. The enefits to o u Dated his 2 By: Title: Appr On behalf of Telephone: 013 utorisation D munications d Mills Road D 21046 13WTK5504 me: Wireless K5504P-433 Confidenti a Sections 0. e held confid matics List diagram ational Desc rials contain public discl o ur competito 2nd D Signat u rovals Mana f : D 905-760- Division s Commissio d 4P Touchscre e , WTK5504- ality .457 and 0 dential: cription trade secr e osure of thi rs. Day of Jan ure ager Digital Secu 3000, Ext. 2 on en Keypad fo -433 .459 of the ets and prop s informatio nuary Dan N urity Contro 2706 or Alarm Sys commissio prietary info on might be 2 Nita Prin t ols stem ons rules, w rmation and harmful to 20 13 ted Digital Secu 3301 Langs Concord, O Tele: 905 7 6 Toll Free: 8 www.dsc.c o we hereby r d are not cu the compan urity Controls staff Road Ontario Canada 60 3000 88 888 7838 om equest that ustomarily re ny and prov L4K 4L2 the followi eleased to t vide unjustifi ng he ed

External EUT photos

18008825R001 WTK5504-433 V1.0 Multi-Listing Label (FCC/IC/UL/ULC) December 6, 2012 Colour: Pantone Process Black Material: CLEAR UL approved Self-adhesive Mylar Type Material - on a roll Lamination: Top lamination (e.g. 1F9, or equivalent) Adhesive: Permanent adhesive backed with protective liner Cutting: Tolerance +/- 0.010” Dashed line indicates cutting - will not print Square label corners are NOT acceptable. NOTES: 1. All items must be RoHS compliant. 2. Markings on label must be PERMANENT. 3. Indelible Ink. 4. Conductive inks may not be used. 5. Non-conductive label adhesive shall be used ONLY. NOTES: 1. All UL and ULC Labels shall be printed on UL approved material. The first time the label is ordered, the artwork must be sent to UL Label Center [email: [email protected], fax: (847)509-6201] for approval. 2. All UL and ULC Labels shall be printed by a UL Listed printing facility. 12.7 mm (0.5 in) Label shown 200% of actual size DIGITAL SECURITY CONTROLS, TORONTO, CANADA MADE IN CANADA FABRIQUE AU CANADA 18008825R001 63.5 mm (2.5 in) Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 Fax: 905-760-3020 Label P/N 18008825 Top view of the back housing of the unit showing the label location (actual size) M/N: WTK5504-433 RES FIRE/BURG AND COM BURG ALARM KEYPAD For Installation refer to Manual P/N 29008569 FCC ID: F5313WTK5504P This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. IC:160A-WTK5504P This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la class B est conforme a la norme NMB-003 du Canada. FIRE ALARM AND SECURITY EQUIPMENT 89SL DIGITAL SECURITY CONTROLS, TORONTO, CANADA MADE IN CANADA FABRIQUE AU CANADA 18008825R001 M/N: WTK5504-433 RES FIRE/BURG AND COM BURG ALARM KEYPAD For Installation refer to Manual P/N 29008569 FCC ID: F5313WTK5504P This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. IC:160A-WTK5504P This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la class B est conforme a la norme NMB-003 du Canada. FIRE ALARM AND SECURITY EQUIPMENT 89SL Do not connect to a receptacle controlled by a switch. Use only DSC Battery Pack P/N 17000153 (4.8V/2.1Ah). Do not connect to a receptacle controlled by a switch. Use only DSC Battery Pack P/N 17000153 (4.8V/2.1Ah). 18008826R001 WTK5504P-433 V1.0 Multi-Listing Label (FCC/IC/UL/ULC) December 6, 2012 Colour: Pantone Process Black Material: CLEAR UL approved Self-adhesive Mylar Type Material - on a roll Lamination: Top lamination (e.g. 1F9, or equivalent) Adhesive: Permanent adhesive backed with protective liner Cutting: Tolerance +/- 0.010” Dashed line indicates cutting - will not print Square label corners are NOT acceptable. NOTES: 1. All items must be RoHS compliant. 2. Markings on label must be PERMANENT. 3. Indelible Ink. 4. Conductive inks may not be used. 5. Non-conductive label adhesive shall be used ONLY. NOTES: 1. All UL and ULC Labels shall be printed on UL approved material. The first time the label is ordered, the artwork must be sent to UL Label Center [email: [email protected], fax: (847)509-6201] for approval. 2. All UL and ULC Labels shall be printed by a UL Listed printing facility. 12.7 mm (0.5 in) Label shown 200% of actual size DIGITAL SECURITY CONTROLS, TORONTO, CANADA MADE IN CANADA FABRIQUE AU CANADA 18008826R001 63.5 mm (2.5 in) Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 Fax: 905-760-3020 Label P/N 18008826 Top view of the back housing of the unit showing the label location (actual size) M/N: WTK5504P-433 RES FIRE/BURG AND COM BURG ALARM KEYPAD For Installation refer to Manual P/N 29008569 FCC ID: F5313WTK5504P This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. IC:160A-WTK5504P This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la class B est conforme a la norme NMB-003 du Canada. FIRE ALARM AND SECURITY EQUIPMENT 89SL Do not connect to a receptacle controlled by a switch. Use only DSC Battery Pack P/N 17000153 (4.8V/2.1Ah). DIGITAL SECURITY CONTROLS, TORONTO, CANADA MADE IN CANADA FABRIQUE AU CANADA 18008826R001 M/N: WTK5504P-433 RES FIRE/BURG AND COM BURG ALARM KEYPAD For Installation refer to Manual P/N 29008569 FCC ID: F5313WTK5504P This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. IC:160A-WTK5504P This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la class B est conforme a la norme NMB-003 du Canada. FIRE ALARM AND SECURITY EQUIPMENT 89SL Do not connect to a receptacle controlled by a switch. Use only DSC Battery Pack P/N 17000153 (4.8V/2.1Ah). (REJECTED)(REJECTED)

Internal EUT photos

FCC 15.231.docx - Date: April 16, 2012 www.nemko.com Compliance test report ID 227147-1TRFWL Date of issue January 4, 2013 Title 47-Telecommunication Chapter I - Federal Communications Commission Subchapter A - General Part 15 - Radio Frequency Devices Subpart C - Intentional Radiators §15.231 - Periodic operation in the band 40.66–40.70 MHz and above 70 MHz Applicant Digital Security Controls a Division of Tyco Safety Products Canada Ltd. Product Wireless Touchscreen Keypad for Alarm System Model WTK5504P-433 Part number UA630 Rev. 01 FCC ID F5313WTK5504P Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation SCC Accredited LAB LAB Accrédité CCN TM w w w . n e m k o . c o m Report reference ID: 227147-1TRFWL Page 2 of 25 Test location Nemko Canada Inc. 303 River Road Ottawa, ON, K1V 1H2 Canada FCC test site registration number: 176392 (3 m semi anechoic chamber) Telephone +1 613 737 9680 Facsimile +1 613 737 9691 Toll free +1 800 563 6336 Website www.nemko.com Tested by David Duchesne, Senior EMC/Wireless Specialist Reviewed by January 4, 2013 Andrey Adelberg, Senior EMC/Wireless Specialist Date Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Copyright notification Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. © Nemko Canada Inc. w w w . n e m k o . c o m Report reference ID: 227147-1TRFWL Page 3 of 25 Table of Contents Table of Contents .......................................................................................................................................................................................... 3 Section 1 Report summary .................................................................................................................................................................... 4 1.1 Test specifications ............................................................................................................................................................................ 4 1.2 Statement of compliance ................................................................................................................................................................... 4 1.3 Exclusions......................................................................................................................................................................................... 4 1.4 Test report revision history ................................................................................................................................................................ 4 Section 2 Summary of test results ........................................................................................................................................................ 5 2.1 Results .............................................................................................................................................................................................. 5 Section 3 Equipment under test (EUT) details ..................................................................................................................................... 6 3.1 Applicant and manufacturer .............................................................................................................................................................. 6 3.2 Sample information ........................................................................................................................................................................... 6 3.3 EUT information ................................................................................................................................................................................ 6 3.4 Technical information ........................................................................................................................................................................ 6 3.5 EUT exercise and monitoring details ................................................................................................................................................. 6 3.6 EUT setup diagram ........................................................................................................................................................................... 7 Section 4 Engineering considerations ................................................................................................................................................. 8 4.1 Modifications incorporated in the EUT ............................................................................................................................................... 8 4.2 Technical judgment ........................................................................................................................................................................... 8 4.3 Deviations from laboratory tests procedures ..................................................................................................................................... 8 Section 5 Test conditions .............................................................…

Text truncated - open the document above for the full version.

1 Setup photos Radiated emissions setup Radiated emissions setup Setup photos, continued Conducted emissions setup Conducted emissions setup
