F53143G4010Cellular Alarm communicator

3G4010 3G (HSPA) WIRELESS ALARM COMMUNICATOR INSTALLATION MANUAL V4.0 WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manu- facturer. The entire manual should be carefully read. i Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Identification of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Installing the 3G4010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Connecting the 3G4010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Status LEDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Operating Principles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Simulated Landline Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Panel Transmission Monitoring (PTM) . . . . . . . . . . . . . . . . . . . . . . . . .6 Wireless Communications Sequence . . . . . . . . . . . . . . . . . . . . . . . . .6 Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Activating the Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Swinger Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Hardware Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Low Power Radio Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 CONNECT 24 Remote Programming . . . . . . . . . . . . . . . . . . . . . . . . .8 Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 3G4010 Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 TABLE OF CONTENTS ii IMPORTANT The equipment is fixed, wall-mounted and shall be installed in the position specified in these instructions. The equipment enclosure must be fully assembled and closed, with all the necessary screws/tabs and secured to a wall before operation. Internal wiring must be routed in a manner that prevents: - Excessive strain on wire and on terminal connections - Loosening of terminal; connections - Damage of conductor insulation WARNING: Never install this equipment during a lightning storm! Instruct the end-user to: - Not attempt to service this product. Opening or removing covers may expose the user to dangerous voltages or other risks. Any servicing shall be referred to trained service persons only. - Use authorized accessories only with this equipment. Do not dispose of the battery in fire or water. Disposing of the battery in a fire will cause rupture and explosion. Do not dispose of the waste battery as unsorted municipal waste. Consult your local regulations and /or laws regarding recycling with regard to this lithium battery pack. Doing so will help protect the environment. Some of the materials that are found within the bat- tery could become toxic if not disposed of properly and may affect the environment . Introduction 1 The 3G4010 is a wireless communicator that sends alarm system information to an Sur-Gard System I, II, III or IV receiver through a 3G (HSPA) or 2G (GPRS) wireless network. This wireless communicator can be used with UL/ULC Listed compatible control units, as indicated in the manufacturer's installation instruc- tions. NOTE: The 3G4010 is designed to work with SIA and the Contact ID communication format as described in SIA DC-05 Standard. Before completing the field installation of the alarm monitoring system please ensure communication with the supervising central station is successful by sending several events and getting confirmation that they have been received. Features • Compatible with 4-digit or 10-digit Contact ID communication format as described in SIA DC-05 Standard. Example of suitable compatible alarm panels: DSC Models PC1864, PC1832, PC1616, PC4020. • Simulates landline • Switches automatically to the 3G (HSPA) or 2G (GPRS) network in the event of landline trouble (e.g., line down) • Wireless Signal Indicator • Four programmable outputs • Contains one 12V - 1.2 Ah battery • Case Tamper Output • Landline overvoltage protection • Tri-band UMTS/HSPA; Quad-Band GSM/EDGE Radio • Four programmable inputs • 3G (HSPA)/2G (GPRS) / Internet communication with Sur- Gard System I / II / III / IV • Panel transmission monitoring for up to four phone numbers Technical Specifications The input voltage to the 3G4010 can be drawn from the UL/ULC Listed control panel or provided by an external UL/ULC Listed power supply rated for the application (external power-limited source). NOTE: The power supply must be Class 2, Power Limited. For residential applications a suitable power adap- tor is model DSC ADP1310-NAU (for USA) a nd model DSC ADP1310-NA (for Canada). Ratings Power Supply Ratings - Input Voltage (for long-term operation) CON5-OFF with internal battery: . . . . . . . . . . . . . . . . . . . . . . . . . . 13.8V DC required CON5-ON without internal battery: . . . . . . . . . . . . . . . . . . . . . 13.8V DC recommended NOTE: When the input voltage drops below 13.5VDC, the internal battery supplied with the 3G4010 will not be charged. In order to maintain a charged level for the internal battery, the power supply must have a minimum voltage of 13.5V DC …

Text truncated - open the document above for the full version.

Date: Au gust 7, 2014 Authorisation letter We, Te lit Communic ations S.p.A. located in Via Stazione di Prosecco, 5/B, 34010 Sgonico [TS], Italy, authorize: AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 29590 Campanillas Málaga · España www.at4wireless.com C.I.F. A29 507 456 on behalf of: Digital Se curity Controls a division of Tyco Safety Products Canada Ltd., 3301 Langstaff Rd., Concord, ON L4K4L2 Canada to use the following doc uments related to Telit Module UE910-N AR (FCC ID: RI7UE910NA and IC: 5131A-UE910NA): • Internal photographs (ANNEX 2 UE910-NAR MODULE PHOTOS Rev.0 2013/03/14) • Block d iagrams (ANNEX 7 UE910-NAR MODULE BLOCK DIAGRAMS Rev.0 2013/03/14)      • Bi ll of materials (ANNEX 6 UE910-NAR MODULE PARTS LIST Rev.0 2013/03/14) • Schematics (ANNEX 3 UE910-NAR MODULE SCHEMATICS Rev.0 2013/03/14) • Tune up procedure (Power Tune up procedure for UE910 Products Family, code: 30412NT11152A) • Test report part 22&24 V2 • Test setup photo for Part 22&24 In order to apply for FCC and IC approval s of the following devices: Type: Cellular alarm communicator Mode l names: 3G4010, 3G4111DF (FCC ID: G53143G4111, IC: 160A-3G4021) Sincerely, Mr. Brian Tucker Phone: +1-919-439-7977 Fax: +1-919-840-0337 e- mail: [email protected]

Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 www.dsc.com TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Date: August 28, 2014 Authorisation letter We, Digital Security Controls Ltd. having an address at 3301 Langstaff Rd., Concord, ON L4K4L2 Canada , hereby authorize AT4 wireless, S.A. Parque Tecnológico de Andalucía C/ Severo Ochoa nº 2 29590 Campanillas - Malaga Spain Ricardo Orejas Phone: +34952619317 e-mail: [email protected] to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. The present authorization considers the development of documents on behalf of the client, written under his own letterhead and related to the necessary information to be provided on his behalf to complete the certification process. This authorisation is applicable to the product: Type of product: Cellular Alarm Communicator Brand: DSC Model: 3G4010, 3G4010CF FCC ID: F53143G4010 IC: 160A-3G4010 This agreement expires one year from the current date. Sincerely, By: Dan Nita ________________________ Title: Approvals Manager (Signature) Company: Digital Security Controls Ltd. Telephone / Fax: 905-760-3000/905-760-3020 e-mail: [email protected]

Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 www.dsc.com TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Date: August 28, 2014 Ref: Permanent Confidentiality request for FCC ID: F53143G4010 FCC ID: Title/model: F53143G4010 cellular alarm communicator / 3G4010, 3G4010CF To whom it may concern: Pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, Digital Security Controls Ltd. hereby request permanent confidentiality to avoid release of sensitive information of the product to the public. For the product stated above, we request that the following information be withheld from public disclose: - Schematics - Operational description - Block diagrams - Tune-up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to Digital Security Controls Ltd and provide unjustified benefits to our competitors. Digital Security Controls Ltd. understand that pursuant to §0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Sincerely, By: Dan Nita ________________________ Title: Approvals Manager (Signature) Company: Digital Security Controls Ltd. Telephone / Fax: 905-760-3000/905-760-3020 e-mail: [email protected]

Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 www.dsc.com TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Date: August 28, 2014 Ref: Short term Confidentiality request for FCC ID: F53143G4010 FCC ID: Title/model: F53143G4010 cellular alarm communicator / 3G4010, 3G4010CF To whom it may concern: Pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, Digital Security Controls Ltd. hereby request short-term confidentiality to avoid premature release of sensitive information prior to marketing or release of the product to the public. For the product stated above, we request that the following information be temporarily withheld from public disclose for an initial period of 180 days: - External photographs - Internal photographs - Test setup photographs - User’s guide It is understood that no extensions of the short-term confidentiality may be requested. Sincerely, By: Dan Nita ________________________ Title: Approvals Manager (Signature) Company: Digital Security Controls Ltd. Telephone / Fax: 905-760-3000/905-760-3020 e-mail: [email protected]

Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 www.dsc.com TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Date: Oct. 29, 2014 REF: Declaration about test reports applicable to 3G4010, 3G4010CF (FCC ID: F53143G4010 and IC: 160A-3G4010) Dear Sir or Madam: Digital Security Controls Ltd. hereby declares that the products 3G4010, 3G4010CF with FCC ID: F53143G4010 and IC: 160A-3G4010 integrates the module Telit UE920-NAR with FCC ID: RI7UE910NA and IC: 5131A-UE910NA. We haven’t changed the RF part and simply have integrated the module in our products. The following test results of the module are valid, applicable and representative for the compliance of these products: - Test report number: T130225W02-RP o Tested standards:
Parts 22,24
RSS-132 Issue 2
RSS-133 Issue 5 This report is valid as prove of compliance to latest IC standards RSS-132 Issue 3 and RSS-133 Issue 6, as the modifications included in the updated versions do not change the testing requirements of the previous versions. As verification of the compliance of the devices, the following testing has been performed: 1. Output power 2. Occupied Bandwidth 3. Conducted spurious emissions 4. Radiated Spurious Emissions Sincerely, By: Dan Nita ________________________ Title: Approvals Manager (Signature) Company: Digital Security Controls Ltd. Telephone / Fax: 905-760-3000/905-760-3020 e-mail: [email protected]

18009181R001 3G4010CF MULTI-LISTING LABEL (UL/FCC/CSFM/NYCFD/WEEE/FM) August 7, 2014 35 mm 60mm Top of metal cabinet showing label location (not actual size) DIGITAL SECURITY CONTROLS, TORONTO, CANADA MADE IN CANADA 18009181R001 M/N: 3G4010CF 3G Alarm Communicator COM FIRE and BURG ALARM TRANSMITTER Type: 3G4010 FCC ID:F53143G4010 US:F53MO00B3G4010 This device complies with Part 15 Class B and Part 68 of the FCC rules. Operation is subject to the following two conditions: (1) This device May not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 Fax: 905-760-3020 Colour: Pantone Process Black Material: White UL approved self-adhesive Mylar type material - on a roll Lamination: Top lamination (e.g. 1F9, or equivalent) Adhesive: Permanent adhesive backed with protective liner (e.g. 60# Semigloss Tire-III / 40# Liner Code: B37, or equivalent) Cutting: Tolerance +/- 0.010” Dashed line indicates cutting - will not print Square label corners are acceptable. NOTES: 1. All UL and ULC Labels shall be printed on UL approved material. The first time the label is ordered, the artwork must be sent to UL Label Center [email: [email protected], fax: (847)509-6201] for approval. 2. All UL and ULC Labels shall be printed by a UL Listed printing facility. NOTES: 1. All items must be RoHS compliant. 2. Markings on label must be PERMANENT. 3. Indelible Ink. FIRE ALARM AND SECURITY EQUIPMENT 89SL 7300-1273:XXX CONTROL UNIT ACCESSORIES DSC, 95 Bridgeland Ave. Toronto, Ontario, Canada M6A 1Y7 NYC Fire Dept Certificate of Approval #XXXX

Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 www.dsc.com TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Date: August 28, 2014 RF exposure analysis for the equipment 3G4010, 3G4010CF (FCC ID: F53143G4010; IC: 160A-3G4010) The devices 3G4010 and 3G4010CF (FCC ID: F53143G4010; IC: 160A-3G4010) are cellular alarm communicator device integrating a module 2G/3G (Telit UE920-NAR). This device is to be used only for fixed and mobile applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all the persons and must not be co-located or operating in conjunction with any other antenna or transmitter except as under the conditions described KDB 447498 D01 General RF Exposure Guidance. MPE exposure limits The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure: Frequency Range (MHz) Power density (mW/cm 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /1500 30 1500 – 100.000 1,0 30 The table below is excerpted from RSS-102, Issue 4, 4.2, titled “RF Limits for Devices used by the General Public”: Frequency Range (MHz) Power density (W/m 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /150 6 1500 – 100.000 10 6 EIRP/ERP limits For 850 MHz frequency band and according to FCC §22.913 the maximum ERP of the device is 7 W (equivalent to 11,48 W EIRP) while IC SRSP-503 defines an EIRP limit of 11,5 W. For 1900 MHz frequency band and according to FCC §24.232 and IC SRSP-510, the maximum EIRP of the device should be lower than 2 W. Using the equation 2 4R PG S π = to calculate the exposure to electromagnetic fields where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) compliance with FCC/IC MPE and EIRP limits is demonstrated following the calculations shown in the following page. Digital Security Controls 3301 Langstaff Road Concord, Ontario Canada L4K 4L2 Tele: 905 760 3000 Toll Free: 888 888 7838 www.dsc.com GPRS 850 GMS K 2 of 8 transmission slots Duty factor 1/4 824,2 31,46 25,0% 0,55 11,48 11,50 20 8,97 9,13 9,14 8,97 EGPRS 850 8PSK 2 of 8 transmission slots Duty factor 1/4 848,8 26,30 25,0% 0,57 11,48 11,50 20 14,26 14,29 14,30 14, 26 FDD V QPSK Duty factor 100% 826,4 23,21 100,0% 0,55 11,48 11,50 20 1 1,21 17,38 17,39 11,21 8,97 GPRS 1900 GMSK 2 of 8 transmission slots Duty factor 1/4 1909,8 29,05 25,0% 1,00 2,00 2,00 20 13,98 3,96 3,96 3,96 EGPRS 1900 8PSK 2 of 8 transmission slots Duty factor 1/4 1909,8 25,33 25,0% 1,00 2,00 2,00 20 17,70 7,68 7,68 7,68 FDD II QPSK Duty factor 100% 1852,4 21,24 100,0% 1,00 2,00 2,00 20 15 ,77 11,77 11,77 11,77 3,96 Maximun antenna gain for 850 MHz frequency band: Maximun antenna gain for 1900 MHz frequency band: Band Test Mode Modulation Antenna gain to meet FCC EIRP limit (dBi) Antenna gain to meet IC EIRP limit (dBi) Maximun antenna gain to meet all the limits (dBi) Evaluation distance for compliance with MPE limits (cm) Duty cicle (%) FCC/IC MPE limit (mW/cm 2 ) FCC EIRP limit per §22.913 and §24.232 (W) Maximun antenna gain to meet all the limits per frequency band (dBi) Avg burst Conducted power (dBm) Frequency (MHz) Antenna gain to meet FCC/IC MPE limit (dBi) IC EIRP limit per SRSP-503 and SRSP-510 (W) Yours sincerely, By: Dan Nita Title: Approvals Manager Company: Digital Security Controls Ltd. Telephone / Fax: 905-760-3000/905-760-3020 e-mail: [email protected]

AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 43010RRF.002 Page 1 of 102 2014-10-24 FCC LISTED, REGISTRATION NUMBER: 720267 IC LISTED REGISTRATION NUMBER IC 4621A-1 Test report No: NIE: 43010RRF.002 Test report REFERENCE STANDARD: USA FCC Part 22 & Part 24 CANADA IC RSS-132, RSS-133 Identificación del objeto ensayado ...................... : Identification of item tested 3G CELLULAR ALARM COMMUNICATOR Marca ................................................................... : Trade DSC Modelo y/o referencia tipo .................................. : Model and /or type reference Model: 3G4010, 3G4010CF Other identification of the product .................... : Commercial name: 3G CELLULAR ALARM COMMUNICATOR FCC ID:F53143G4010 and IC:160A-3G4010 Final HW version ................................................ : UA673 Rev. 02 Final SW version ................................................. : Ver. 4.0 IMEI TAC ........................................................... : 354677050032348 Características ..................................................... : Features 3G Cellular interface used for connection to Alarm Systems in order to send events to monitoring station. Use integrated Telit radio model UE910-NAR. Module can use external whip antenna. Peticionario ......................................................... : Applicant DIGITAL SECURITY CONTROLS, A DIV. OF TYCO SAFETY PRODUCTS CANADA LTD. 3301 LANGSTAFF ROAD, CONCORD, ON L4K4L2. CANADA. Contact person: Dan Nita Telephone: +905 760 3000. Ext 2706; e-mail: [email protected] Método de ensayo solicitado, norma ................... : Test method requested, standard USA FCC Part 22 10-01-13 Edition. USA FCC Part 24 10-01-13 Edition. CANADA IC RSS-132 Issue 3, Jan. 2013. CANADA IC RSS-133 Issue 6, Jan. 2013. Measurement Guidance 971168 D01 v02r01 for certification of Licensed Digital Transmitters Resultado .............................................................. : Summary IN COMPLIANCE Aprobado por (nombre / cargo y firma) ........... : Approved by (name / position & signature) A. Llamas RF Lab. Manager Fecha de realización ........................................... : Date of issue 2014-10-24 Formato de informe No. ...................................... : Report template No FDT08_15 AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 43010RRF.002 Page 2 of 102 2014-10-24 Index Competences and guarantees ......................................................................................................................... 3 G eneral conditions ......................................................................................................................................... 3 Uncertainty .................................................................................................................................................... 3 Usage of samples ........................................................................................................................................... 3 Test sample description ................................................................................................................................. 4 Test samples supplier .................................................................................................................................... 4 Testing period ................................................................................................................................................ 4 Environmental conditions .............................................................................................................................. 4 Remarks and comments ................................................................................................................................. 5 Testing verdicts ............................................................................................................................................. 7 Appendix A – Test result for FCC Part 22 & 24 ........................................................................................... 8 AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 4 3010RRF.002 Page 3 of 102 2014-10-24 Competences and guarantees AT4 wireless is a laboratory with a measurement facility in compliance with the requirements of Section 2.948 of the F C C rules and has been added to the list of facilities whose measurements data will be accepted in conjuction with applications for Certification under Parts 15 or 18 of the Commission's Rules. Registration Number: 720267. AT4 wireless is a laboratory with a measurement site in compliance with the requirements of RSS 212, Issue 1 (Provisional) and has been added to the list of filed sites of the Canadian Certification and Engineering Bureau. Reference File Number: IC 4621A-1. In order to assure the traceability to other national and international laboratories, AT4 wireless has a calibration and maintenance program for its measurement equipment. AT4 wireless guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at AT4 wireless at the time of performance of the test. AT4 wireless is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: RI7UE910NA IC: 5131A-UE910NA Report No.: T130225W02-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 109 Rev.00 FCC 47 CFR PART 22 SUBPART H AND PART 24 SUBPART E & INDUSTRY CANADA RSS-132 & RSS-133 TEST REPORT For 2G,3G wireless module Model: UE910-NAR, UE910-NAD Trade Name: Telit Issued to TELIT COMMUNICATIONS S.P.A. Via Stazione di Prosecco 5/b, 34010 SGONICO, TRIESTE - ITALY Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: March 25, 2013 Compliance Certification Services Inc. FCC ID: RI7UE910NA IC: 5131A-UE910NA Report No.: T130225W02-RP Page 2 Rev.00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 March 25, 2013 Initial Issue ALL Angel Cheng Compliance Certification Services Inc. FCC ID: RI7UE910NA IC: 5131A-UE910NA Report No.: T130225W02-RP Page 3 Rev.00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 4 2. EUT DESCRIPTION .................................................................................................................... 5 3. TEST METHODOLOGY ............................................................................................................. 6 3.1 EUT CONFIGURATION.............................................................................................................. 6 3.2 EUT EXERCISE......................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES.................................................................................................. 6 3.4 DESCRIPTION OF TEST MODES................................................................................................. 7 4. INSTRUMENT CALIBRATION................................................................................................. 8 4.1 MEASURING INSTRUMENT CALIBRATION........................................................................... 8 4.2 MEASUREMENT EQUIPMENT USED .............................................................................. 9 4.3 MEASUREMENT UNCERTAINTY .................................................................................. 10 5. FACILITIES AND ACCREDITATIONS ................................................................................. 11 5.1 FACILITIES............................................................................................................................ 11 5.2 EQUIPMENT........................................................................................................................... 11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................... 12 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 13 6.1 SETUP CONFIGURATION OF EUT............................................................................................ 13 6.2 SUPPORT EQUIPMENT..................................................................................................... 13 7. FCC PART 22 & 24 REQUIREMENTS ................................................................................... 14 7.1 99% BANDWIDTH ............................................................................................................. 14 7.2 PEAK POWER......................................................................................................................... 25 7.1 AVERAGE POWER............................................................................................................... 27 7.2 ERP & EIRP MEASUREMENT .......................................................................................... 29 7.3 OCCUPIED BANDWIDTH MEASUREMENT ................................................................. 33 7.4 OUT OF BAND EMISSION AT ANTENNA TERMINALS .............................................. 44 7.5 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT ............................. 62 7.6 FREQUENCY STABILITY V.S. TEMPERATURE MEASUREMENT.......................... 100 7.7 FREQUENCY STABILITY V.S. VOLTAGE MEASUREMENT .................................... 104 Compliance Certification Services Inc. FCC ID: RI7UE910NA IC: 5131A-UE910NA Report No.: T130225W02-RP Page 4 Rev.00 1. TEST RESULT CERTIFICATION Applicant: TELIT COMMUNICATIONS S.P.A. Via Stazione di Prosecco 5/b, 34010 SGONICO, TRIESTE - ITALY Equipment Under Test: 2G,3G wireless module Tr a d e N a m e : Telit Model Number: UE910-NAR, UE910-NAD Date of Test: March 11 ~ 23, 2013 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR PART 22 SUBPART H AND PART 24 SUBPART E & IC RSS-132 Issue 2: September 2005 and IC RSS-133 Issue 5: February 2009 No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in TIA/EIA-603-C: 2004 and the energy emitted by the sample EUT tested as described in this report is i…
