Installation Instructions LC-203/BLC-203 and LC-204/BLC-204 1 ISTISJCEBLC2034 1.0 2012/19/EU LC-203/BLC-203 and LC-204/BLC-204 DUAL TECHNOLOGY DETECTORS 1. INTRODUCTION The new line of LC-203/BLC-203 and LC-204/BLC-204 detectors is the best choice for residential and commercial security installations: BLC-203 and BLC- 204 are not UL/ULC listed. They only use digital PIRs which bypass the conversion that usually must be done with traditional detectors where an analog PIR is amplified and converted to digital. The FULLY digital technology helps the detector more accurately detect intrusions and not be affected by alterations in white light, ultraviolet light, temperature and air movement caused by heating/cooling systems. It is also fully immune to radiated and conducted electromagnetic interference. LC-203/BLC-203 and LC-204/BLC-204 detectors are equipped with lenses designed by Johnson Controls and are manufactured by Fresnel Technologies, Inc. LODIFF ® optic creation technology combined with POLY IR ® materials make it a product of the highest quality and efficiency. LC-203/BLC- 203 and LC-204/BLC-204 detectors are pet immune (feature not evaluated by UL/ULC) and have a 15 m range and a 100-degree detection range. LC-203/BLC- 203 includes mask detection. 2. INSTALLATION - Using a thin screwdriver, loosen the bottom screw and open the cover (see Fig 1) - Remove the board from the plastic base by removing the screw on the board (see Fig 2) - Open the knockouts needed for mounting onto the wall (or use the non-certified IMQ joint) - Open the knockouts for removal protection and fix the anchor to the wall (see Fig 2) - Recommended height is 2.1 m - Run the connection cables through the bottom of the container and out the top - Connect the wires on the board as described below - Fig 1 - - Fig 2 - POLY IR ® 4 Plastic Material for Detection Stability POLY IR ® lens material. This materials offers a better combination of transmittance, environmental stability and color than any other polymer on the market. Materials are available for the 8-14 micron infrared region. LODIFF ® and POLY IR ® are registered trademarks of Fresnel Technologies, Inc. LODIFF ® Fresnel Technology Lenses This lens series is made by tiling LODIFF ® lens pieces. These lenses offer significantly improved performance over the typical constant-bandwidth Fresnel lens. LODIFF ® and POLY IR ® are registered trademarks of Fresnel Technologies, Inc. High RFI Protection The detector has very high RFI immunity due to the complete lack of traditional amplifiers. White Light Protection Pet Immunity Thanks to a new lens design and the digital analysis system, all of our detectors are immune to pets weighing up to 15 kg. The detector has no analog components, and the fully digital PIR interfaces directly with the microprocessor. Fully Digital PIR 3. MEANING OF THE LEDS During normal operation, the LED signals are: GREEN LED = PIR Alarm; YELLOW LED = MW Alarm; RED LED = General Alarm (both PIR and MW) - LC-203/BLC-203: In the case of detector masking, the LED corresponding to the masked technology will flash, and the MASK alarm contacts open LC-203/BLC-203 VERSION The LC-203/BLC-203 provides continuous detector self-testing, in the case of an anomaly lasting longer than 15 seconds, the detector will report: - POWER SUPPLY ABOVE THE NOMINAL THRESHOLDS: Alternating flashing of YELLOW and GREEN LEDs and opening of the MASK contact - INFRARED SELF-TEST FAILURE Flashing of GREEN LED and opening of the MASK contact - MICROWAVE SELF-TEST FAILURE Flashing of YELLOW LED and opening of the MASK contact NOTE: Do not partially or completely cover the detector's field of vision NOTE: the pet function is not IMQ certified The detector digitally filters white light components. Jumpers DIP Switch Trimmer Anchor Installation Instructions LC-203/BLC-203 and LC-204/BLC-204 2 ISTISJCEBLC2034 1.0 LC-203/BLC-203/LC-204/BLC-204 Microwave frequency: 10.525GHz 4. CONNECTION AND SETUP Dip LED --> off = LED off - on = LED on* Dip HIGH/LOW --> off = 7m - on = 15m range Dip NORM/PULSE --> off = 1 pulse - on = 2 pulse Dip AND/OR-AUTO** --> off-off = AND; on-off = OR; on-on = auto OR Trimmer RANGE = used only for microwave. NOTE: The RANGE trimmer may need to be adjusted to the maximum position in order to achieve maximum area of coverage as indicated in Figure 3. Technical Features RANGE15 m HORIZONTAL COVERAGE100° LENSES LODIFF ® Fresnel Lens POLY IR ® 4 Material LEDgreen, yellow, red ALARM DURATION2 s SELF-DIAGNOSTICS- LED WALK TESTYES MICROWAVE FREQUENCY10.525 GHz MAXIMUM RADIO- FREQUENCY POWER +14 dBm SOLID STATE RELAYYES EOL RESISTANCEYES CREEP ZONE DEVICEYES CASE TAMPERYES BACK TAMPERYES ANTI-MASKINGLC-203/BLC-203 DOUBLE PULSEYES RFI PROTECTION30 V/m HEAT COMPENSATIONYES FULLY DIGITALYES JOINTYES POWER SUPPLY 9-15 VDC / 56 mA UL/ULC tested: 10.6-13 VDC / 56 mA COVER MATERIALABS PET IMMUNITYYES OPERATING TEMPERATURE -10°C to +40°C UL/ULC tested: 0°C to 49°C HUMIDITY93% RH DIMENSIONS114 x 63 x 40 mm Jumpers T - A - EOL open = NC contacts without resistors (not for UL/ULC applications) Jumpers T - A - EOL closed = DEOL supervision with internal resistors SUPPLY terminals: Power supply 9-15 VDC / 56 mA. UL/ULC tested: 10.6-13 VDC / 56 mA. Note: For UL/ULC installations the detector shall be provided with minimum of 4 hours of standby power from either a listed compatible control unit or power supply. Output contacts ratings: 28 VDC / 100 mA. Use only resistive loads on the outputs. MASK terminals = antimasking terminals present on LC-203/BLC-203 only DEOL supervision (internal resistors/closed jumpers) LC-203/LC-204: DEOL supervision (external resistors/ open jumpers) NC (no EOL supervision/ open jumpers) Not used on UL/ULC listed installations 101W. MORNINGSIDE DR. FORT WORTH, TX 76110, U. S. A. (817) 926-7474, FAX:(817)926-7146 fresnel technologies inc. 2003 SIDE VIEW: 2.1m (6.8ft) TOP VIEW: 10m (33ft) (50ft) 15m FRONT VIEW: (50ft) 15m 5m (16ft) jay WP 0.9 GI 6 T…

Text truncated - open the document above for the full version.

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1-647-480-0200 https://www.tycosafetyproducts.com Covered Equipment Certification Attestation Letter May 2, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: F5323LC2034 Tyco Safety Products Canada Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Tyco Safety Products Canada Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Dan Nita Title: Sr. Approvals Manager Company Name: Tyco Safety Products Canada Ltd. Date: 5/1/2023

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1-647-480-0200 https://www.tycosafetyproducts.com * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter May 2, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: F5323LC2034 Per section 2.911(d)(7) of the FCC rules, Tyco Safety Products Canada Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Qolsys Inc. Physical U.S. Company Address: 1919 S. Bascom Ave., Campbell, CA 95008, USA Agent name: Mark Skeen Agent Email Address: [email protected] FRN: 0022572226 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Dan Nita Printed name: Mark Skeen Title: Sr. Approvals Manager Title: VP Life Safety & Compliance Company Name: Tyco Safety Products Canada Ltd. Company Name: Qolsys Inc. Date: May 1, 2023 Date: May 1, 2023

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1-647-480-0200 https://www.tycosafetyproducts.com Nemko North America, Inc. 303 River Road, Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent for FCC application On our behalf, I appoint Spencer Zhong of Nemko Canada, Inc. at 303 River Road, Ottawa, Ontario, Canada K1V 1H2, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Tyco Safety Products Canada Ltd., having a business address at 3301 Langstaff Rd., Concord, ON L4K 4L2 Canada. Dated: May 2, 2023 Agency agreement expiration date: 2024-05-01 *Up to 12 months Signed by: Dan Nita Signature Print name Sr. Approvals Manager Title 647-480-0430 Phone On behalf of: Tyco Safety Products Canada Ltd. Company name

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1-647-480-0200 https://www.tycosafetyproducts.com May 2, 2023 Nemko North America, Inc. 303 River Road, Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Request for Confidentiality – FCC FCC ID: F5323LC2034 Pursuant to FCC 47 CFR 0.457(d)(1)(ii) and 0.459 and FCC guidance published in KDB 726920, we hereby request confidential treatment of information accompanying this application as outlined below. We request the exhibits selected below as long term confidential be withheld from public view permanently: Selection of exhibits for LTC Exhibit name ☒ Permanent (Long Term) Block Diagrams ☒ Permanent (Long Term) Operation Description / Theory of Operation ☒ Permanent (Long Term) Parts List & Placement / BOM ☐ Permanent (Long Term) 1 Tune-Up Procedure ☒ Permanent (Long Term) Schematics ☐ Permanent (Long Term) * 2 User’s Manual ☐ Permanent (Long Term) * Internal Photos ☐ Permanent (Long Term) SDR Software / Security Info (for SDR only) Our company has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. The above information contains trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Sincerely, Signed by: Dan Nita Signature Print name Sr. Approvals Manager Title 1 - Applicable only for licensed equipment. 2 - The asterisked items (*) require further information to be provided to TCB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and review section II, 3) regarding specific information that must accompany these requests.

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1-647-480-0200 https://www.tycosafetyproducts.com May 2, 2023 Nemko North America, Inc. 303 River Road, Ottawa, ON K1V 1H2 Canada Attn: Director of Certification FCC ID: F5323LC2034 ISED certification number: IC: 160A-LC2034 HVINs/Models: LC-203, LC-204 Family Certification request letter We hereby request Family Certification for the above mentioned HVINs/Models based on them being electrically, and physically identical apart from model name/number and the differences mentioned below: 1. Models LC-203 and LC-204 are using the same PCB assembly/layout Rev. 5.0 and the only difference is that the model LC-204 does not have populated the components for antimasking detection circuitry. 2. Model LC-203 and LC-204 use the same integrated module NJR4178 with the same antenna type and gain 3. Model LC-203 and LC-204 have the same plastic enclosure The model LC-203 that is the fully populated variant in the family has been used for testing and the results are representative also for model LC-204. Sincerely, Signed by: Dan Nita Signature Print name Sr. Approval Manager Title 647-480-0430 Phone
