F5323NB937NB-937 NBIOT SMOKE CO HEAT COMBO with NB-IOT/Cat M1 communication

D-308989 NBIoT Smoke/CO/Heat Combo Installation Guide NBIoT Smoke, Carbon Monoxide and Heat Combination Detector Installation Guide ATTENTION: This manual should be read prior to use and retained for further information. 1. GENERAL INFORMATION The NBIoT Smoke, Carbon Monoxide and Heat Combination Detector is a 2xCR123A battery powered narrowband internet of things (NBIoT) detector intended for use with a smartphone application or compatible wireless alarm system. The detector consists of a photoelectric smoke sensor, thermistor heat sensor and electrochemical carbon monoxide sensor coupled to a wireless transmitter, which communicates with the cloud and user application. When fire or carbon monoxide is detected, the detector sounds a loud local alarm and the built-in transmitter sends a signal to the DM server. The NBIoT Smoke, Carbon Monoxide and Heat Combination Detector contains an integrated fixed 41°F (5°C) temperature freeze sensor that will send a warning signal based on temperature detected. This detector is designed to provide protection with 70ft (21m) spacing capability. The detector can send alarm, tamper and battery condition messages to the cloud and user application. The detector has an operational life of 10 years. After 10 years of operation the detector will provide audio visual trouble indication and must be replaced. WARNING: This product is intended for use in ordinary indoor residential areas. It is not designed to measure compliance with Occupational Safety & Health Administration (OSHA) commercial and industrial standards. 2 2. DETECTOR OVERVIEW 2.1 DETECTOR FRONT Figure 1 - Detector Front 2.2 DETECTOR BACK Figure 2 - Detector Back CO Test Button Indicator LEDs Fire Test Button CO Sensor Gas Entry Port Anti-Tamper Lock Release Sounder Tamper Switch Mechanism Anti-Tamper Lock Mechanism Battery Compartment D-308989 NBIoT Smoke/CO/Heat Combo Installation Guide 2.3 DETECTOR MOUNTING BASE Figure 3 - Mounting Base 3. CONTENTS OF BOX • NBIoT Smoke, Carbon Monoxide and Heat Combination Detector with mounting base • Installation guide • Pack of screws and anchors • Labels or decals as appropriate • 2 CR123A Panasonic batteries 4. ENROLLING THE DEVICE 1. Download the AlarmInstall mobile application from Google Play or the App Store. 2. Remove the battery pull-tab to power on the device and begin the auto-enrollment process (See Figure 4). If the battery pull-tab is not available or if the device does not automatically enroll, remove and re-insert the batteries (See Section 7.2). 3. Leave the battery cover open. 4. Follow the instructions in the mobile application to enroll and register the device. Note: You can find your 15-digit IMEI number and PIN code printed on the box of the device when prompted by the application. Note: Only install the device in locations with Excellent or Good Link Quality. Use the LinkQualityTest mobile application to measure and verify the signal strength. 5. CONFIGURING THE DEVICE NOTE: In order to send event notifications to the server or perform upgrades the device needs to be successfully connected to a DM server. The NBIoT device credentials configure automatically or manually. To manually configure the device, complete the following steps: 1. Power on the device and keep the mounting base Tamper open 2. Open the BLE application and pair the device. 3. In the BLE application, configure the following: • The server target and address to connect to • The specific endpoint name, identity, and secret key for the device to connect to the server NOTE: If the device repeatedly fails to connect to the network, check the network quality in your location. If the device repeatedly fails to connect to the server, check that you are using the correct credentials which are configured on the server for this device. Anti-Tamper Locking Tab Tamper Switch Mechanism Screw Mounting Holes 4 6. OPERATION The NBIoT Smoke, Carbon Monoxide and Heat Combination Detector contains a sounder which generates ANSI S3.41 Temporal-3 pattern when fire is detected or ANSI S3.42 Temporal-4 pattern when Carbon Monoxide is detected. During an alarm condition, pressing either of the FIRE or CO test/hush buttons will silence the sounder for a short period (see LED and sounder operating modes table). A multi-color LED indicator provides visual indication for the detector operating modes and states. In general, RED is used to indicate ALARM conditions, YELLOW is used to indicate FAULT conditions and GREEN is used for normal operation (see Detector Status LED & Sounder operating modes table). 6.1 DETECTOR STATUS LED & SOUNDER OPERATING MODES Status Description LEDs Sounder Smoke Alarm Smoke has been detected 3 RED flashes in time with sounder Temporal-3 BEEP-BEEP-BEEP-pause (press either button to hush for 7 minutes) Heat Alarm Heat has been detected 3 RED flashes in time with sounder Temporal-3 BEEP-BEEP-BEEP-pause CO Alarm Carbon Monoxide has been detected 4 RED flashes in time with sounder Temporal-4 PIP-PIP-PIP-PIP-long pause (press either button to hush for 5 minutes) CO Alarm Extended The CO level remains above the alarm threshold after 4 minutes 4 RED flashes every 6 seconds Temporal-4 PIP-PIP-PIP-PIP-long pause (press either button to hush for 5 minutes) CO GO/NO- GO Test Test mode for checking Carbon 1 GREEN flash followed by None Monoxide functionality with test gas 1 BLUE flash every 12 seconds General Fault A sensor has failed or some other fault has occurred 1 YELLOW flash every 4 seconds Chirp every 48 seconds CO Fault The CO cell has reached the end of its useable life or a fault has occurred with the CO detection portion of the detector 2 YELLOW flashes every 8 seconds Chirp every 48 seconds End Of Life The detector has been operational for 10 years and must be replaced 5 YELLOW flashes every 12 seconds Chirp every 48 seconds Sensitivity Drift/Dirty Fault The detector may no longer alarm within the smoke sensitivity limits on the back of the device and must be cleaned 1…

Text truncated - open the document above for the full version.

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1- 647-480-0200 https://www.tycosafetyproducts.com U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Kiwa Nederland B.V. Wilmersdorf 50 7327 AC Apeldoorn Postbus 137 7300 AC Apeldoorn Netherlands ATTEN TION: FCC Certification – Section 2.911(d)(7) Information Desi gnated U.S. Agent Company name: Qolsys Inc. FRN: 0022572226 Contact person name: Mark Skeen Street address: 1919 S. Bascom Ave. ZIP/City/State Campbell, CA 95008, USA Telephone number: Email address: [email protected] Signature: Date: 20230316 This l etter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. The App licant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applic ant Company name: Tyco Safety Products Canada Ltd. Grantee Code: F53 Contact person name: Dan Nita Street address: 3301 Langstaff Road ZIP/City/State LK4 4L2, Concord, Ontario, Canada Telephone number: Email address: [email protected] Signature: Date: 20.3.2023 +1 (855) 476-5797 +1 (647) 8000430 Revision Record Sheet: Revision Section number Page number Date Remark(s) issued by 01 07-02-2023 1 st version RvdM 02 1 15-05-2023 Added FRN to Agent details RvdM Issued/modified by : Richard van der Meer Function : Certification assessor Revision : 02 Date : 15-02-2023 Verified by : Willem Jan Jong Function : Team Lead Date : __-02-2023 Released by : Axel Gase Function : Manager Quality Assurance Date of release: : __-02-2023

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 Tele: 1-647-480-0200 https://www.tycosafetyproducts.com Certification Application Attestation Statements Tyco Safety Products Canada Ltd. 3301 Langstaff Road L4K 4L2 Ontario, Canada To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) Tyco Safety Products Canada Ltd. certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) Tyco Safety Products Canada Ltd. (“the applicant”) certifies that, as of the date of the filing of this application, the applicant - is / - is not (3) identified on the Covered List as an entity producing “covered” equipment. Date: 29-May-23 City: Concord Name (2) : Dan Nita Function: Approvals Manager Telephone number: 1-647-480-0430 Email address: [email protected] Signature: 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK”

Tyco Safety Products Canada Ltd. 3301 Langstaff Road Concord, Ontario, Canada L4K 4L2 T ele: 1-647-480-0200 https://www.tycosafetyproducts.com Declaration of Authorization We Name: Tyco Safety Products Canada Ltd. Address: 3301 Langstaff Road City: Concord L4K 4L2 Country: Ontario, Canada Declare that: Name Representative of agent: Peysahov Sheynin Svetlana (1) Agent Company name: Hermon Laboratories Ltd. Address: Harakevet Industrial Zone City: Binyamina 30500 Country Israel is authorized to apply for Certification of the following product(s): Product description: NB-937 NBIOT SMOKE CO HEAT COMBO with NB-IOT/Cat M1 communication Type designation: Callisto Apollo combo Trademark: Johnson Controls Validity/ expiry date: May 31, 2024 on our behalf. Date: May 31, 2023 Name: Dan Nita (2) Function: Approvals Manager Signature : Notes: (1) : Required for FCC application (2) : For FCC it must be the Grantee Code “owner” or the authorized agent

FCC, Request for non-disclosure Date: 21-Nov-2018 RF_501, Issue 8 Page 1 of 1 Company Name: Tyco Safety Products Canada Ltd. Address : 3301 Langstaff Road City: Concord L4K 4L2 Country: Ontario, Conada To: Telefication B.V., Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Request for confidentiality FCC ID: F5323NB937 Reference number: 47337 Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: in order to avoid exposed of the technology to the competitors Date: May 31, 2023 Name and signature of applicant: Mr. Dan Nita Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should stated in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

May 29, 2023 Telefication B.V. Attn: Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Application for certification for a NB-937 NBIOT SMOKE CO HEAT COMBO with NB-IOT/Cat M1 communication, FCC ID: F5323NB937 Dear Gentlemen, Please find attached our application for certification for a NB-937 NBIOT SMOKE CO HEAT COMBO with NB-IOT/Cat M1 communication, FCC ID: F5323NB937, prepared in accordance with FCC Rules, parts 2 and 15, section 15.247(FHSS). The product testing and this application for certification were performed by Hermon Laboratories, which is recognized and accredited by FCC, Test Firm Registration Number is 927748, Designation Number is IL1001. Hermon Labs responsible person is Mr. Michael Nikishin, tel: +972 4626 8440, fax:+972 4628 8277, e-mail: [email protected]. We hope this application satisfies your requirements. Please send an invoice to Hermon Labs. Dan Nita, Approvals Manager Tyco Safety Products Canada Ltd.

Tyco Safety Products Canada Ltd. FCC ID: F5323NB937 IC: 160A-NB937 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Tyco Safety Products Canada Ltd. FCC ID: F5323NB937 IC: 160A-NB937 Page 2 of 3 Photograph No.1 Door/Window Outdoor Contact Front view Tyco Safety Products Canada Ltd. FCC ID: F5323NB937 IC: 160A-NB937 Page 3 of 3 Photograph No.2 Door/Window Outdoor Contact Rear side view

ECM Title: JCI LABEL DRAWING TBD Product Name: LABEL NB-937 NBIOT COMBO PRODUCT Date Name Document No: 4017902 17.01.2023 Albert F. Created Document Rev: Draft00 Updated Sheet 1 of 1 17.01.2023 Shay A. Approved MATERIAL: Polyester. SIZE: 63*15 mm Label location

Tyco Safety Products Canada Ltd. FCC ID: F5323NB937 IC: 160A-NB937 Page 1 of 5 INTERNAL PHOTOGRAPHS This document contains 6 photographs Tyco Safety Products Canada Ltd. FCC ID: F5323NB937 IC: 160A-NB937 Page 2 of 5 Photograph No.1 Door/Window Outdoor Contact Internal view Tyco Safety Products Canada Ltd. FCC ID: F5323NB937 IC: 160A-NB937 Page 3 of 5 Photograph No.2 Door/Window Outdoor Contact Print side of the main PCB Tyco Safety Products Canada Ltd. FCC ID: F5323NB937 IC: 160A-NB937 Page 4 of 5 Photograph No.3 Door/Window Outdoor Contact Antenna assembly Tyco Safety Products Canada Ltd. FCC ID: F5323NB937 IC: 160A-NB937 Page 5 of 5

FCC ID: F5323NB937 Page 1 of 2 Environmental evaluation and exposure limit according to FCC CFR 47part 1, §1.1307, §1.1310 The Home unit is classified as a mobile device. The Home unit includes transmitter operating according to FCC part 15 subpart C section 15.247 (DTS) and Cellular module approval under FCC ID: RI7ME310G1W1. BLE and the Cellular work together only at the installation stage. Limit for power density for general population/uncontrolled exposure is 1mW/cm 2 for 1500 -100000 MHz frequency range. The power density P (mW/cm 2 ) = P T / 4π r 2 , where PT is the transmitted power, which is equal to the peak transmitter output power 5.25 dBm plus maximum antenna gain (-13)dBi, the maximum equivalent isotropically radiated power EIRP is PT = 5.25dBm + (-13)dBi = -7.75dBm = 0.168mW 5.25 dBm is the EUT maximum output power with the tune up tolerance, -13 dBi – antenna gain. The power density at 20 cm (minimum safe distance, required for mobile devices), calculated as follows: 0.168mW / 4π (20 cm) 2 = 0.00033mW/cm 2 << 1mW/cm 2 Maximum conducted power given in FCC ID: RI7ME310G1W1 module grant is 158mW (21.99dBm) in band 2, 153mW (21.85dBm) in band 4, 138mW (21.4dBm) in band 5, 157mw (21.96dBm) in band 12, 138mW (21.4dBm) in band 13, 147mW (21.67dBm) in band 25, 145mW (21.61dBm) in band 26, 158mW (21.99dBm) in band 66, 142mW (21.52dBm) in band 71 and 129mW (21.11dBm) in band. Limit for power density is f/1500= 0.56mW/cm2 for band 5 (824-849 MHz), 0.47mW/cm2 for band 12 (699-716 MHz), 0.52mW/cm2 for band 13 (777-787 MHz), 0.56mW/cm2 for band 26 (814-849 MHz), 0.46mW/cm2 for band 71 (663-698 MHz), 0.47mW/cm2 for band 85 (698-716 MHz) and 1mW/cm2 for 1500 -100000 MHz for general population/uncontrolled exposure for bands 25, 4, 66 and 2. The gain of antennas used with the module are 11dBi for band 2 and band 25, 8dBi for band 4 and band 66, 12.4dBi for band 5, 11.6dBi for band 12, 12.1dBi for band 13, 12.3dBi for band 26, 11.6dBi for band 85 and 11.4dBi for band 71. The maximum equivalent isotropic radiated power EIRP is for band 26: PT = 21.61dBm + 12.3dBi = 33.91 dBm = 2460.36mW FCC ID: F5323NB937 Page 2 of 2 The power density at 20 cm (minimum safe distance, required for mobile devices), calculated as follows: 2460.36mW / 4π (20 cm) 2 = 0.489mW/cm 2 << 0.56mW/cm 2 Assessment of RF hazard from BLE and LTE wireless module S1/limit + S2/limit ≤ 1, i.e 0.00033/1 + 0.489/0.56 = 0.00033 + 0.8732 = 0.8735 ≤ 1 The aggregate ratio of transmit power to the relevant power limits does not exceed 100% and meets the safety requirements.

Johnson Controls 13 Zarhin Street, Raanana 4366241, Israel 1 JCI BLE NB-937 Antenna Rev. 02 May, 2023 1. Antenna Specifications 1.1. Electrical/Functional Requirements Frequency Range: 2400-2500MHz Input Impedance: 50 Ohm nominal Peak Gain (relative to Isotropic): -13 dBi 1.2 Antenna Mechanical Design

Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Tel. +972 4628 8001 Fax. +972 4628 8277 E-mail: [email protected] Page 1 of 63 Report ID: TYCRAD_FCC.47337.doc Date of Issue: 23-May-23 Page 1 of 63 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC 47CFR part 15 subpart C §15.247 (DTS) and subpart B, RSS-247 Issue 2:2017, RSS-Gen Issue 5, ICES-003 Issue 7:2020 FOR: Tyco Safety Products Canada Ltd. NB-937 NBIOT SMOKE CO HEAT COMBO with NB-IOT/Cat M1 communication Model: Callisto Apollo Combo FCC ID: F5323NB937 IC: 160A-NB937 This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: TYCRAD_FCC.47337.doc Date of Issue: 23-May-23 Page 2 of 63 Page 2 of 63 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Test configuration .......................................................................................................................................................... 5 6.3 Changes made in EUT .................................................................................................................................................. 5 6.4 Transmitter characteristics ............................................................................................................................................ 6 7 Transmitter tests according to 47CFR part 15 subpart C and RSS-247 requirements .................................................. 7 7.1 Minimum 6 dB and 99% bandwidth ............................................................................................................................... 7 7.2 Field strength of spurious emissions ........................................................................................................................... 12 7.3 Peak output power ...................................................................................................................................................... 34 7.4 Band edge radiated emissions .................................................................................................................................... 41 7.5 Peak spectral power density ....................................................................................................................................... 47 7.6 Antenna requirements ................................................................................................................................................. 51 8 Unintentional emissions .............................................................................................................................................. 52 8.1 Radiated emission measurements .............................................................................................................................. 52 9 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 57 10 APPENDIX B Measurement uncertainties ................................................................................................................... 58 11 APPENDIX C Test equipment correction factors ........................................................................................................ 59 12 APPENDIX D Test laboratory description ................................................................................................................... 61 13 APPENDIX E Specification references........................................................................................................................ 62 14 APPENDIX F Abbreviations and acronyms ................................................................................................................. 63 Report ID: TYCRAD_FCC.47337.doc Date of Issue: 23-May-23 Page 3 of 63 Page 3 of 63 1 Applicant information Client name: Tyco Safety Products Canada Ltd. Address: 3301 Langstaff Road, Concord, Ontario L4K 4L2, Canada Telephone: 1-647-480-0430 Fax: 1-647-480-0531 E-mail: [email protected] Contact name: Mr. Dan Nita 2 Equipment under test attributes Product name: NB-937 NBIOT SMOKE CO HEAT COMBO with NB-IOT/Cat M1 communication Product type: Transceiver Model(s): Callisto Apollo Combo Serial number: NA Hardware version: 90-210356 Software release: JS-704110 Receipt date 13-Jun-22 3 Manufacturer information Manufacturer name: Tyco Safety Products Canada Ltd. Address: 3301 Langstaff Road, Concord, Ontario L4K 4L2, Canada Telephone: 1-647-480-0430 Fax: 1-647-480-0531 …
