HN21555-2450Hand Held Tag Reader

P/N x-xxxx49-01 Sabre 1555 Laser Scanner & RFID Reader/Programmer Getting Started Guide Anleitung für Einsteiger Guia de IniciaçãoGuide de Démarrage Guida IntroduttivaGuía de Iniciación 2 Introduction Use this Getting Started Guide to set up the Sabre 1555 laser scanner and RFID reader/ programmer for most terminal connections and symbologies. If necessary, use the EasySet setup software or Installation Manual for additional configuration possibilities and terminal connections. Basic setup Configuración básica Configuration de base Grundkonfiguration Configurazione di base Getting Started Guide EasySet Full setup Configuración completa Configuration complète Vollständige Konfiguration Configurazione completa Configuração completa EasySet setup software (on the CD-ROM or to order) Installation Manual Operating Uso Utilisation Betrieb Utilizzazione Operator’s Guide Interactive Programming (need translations to other languages) Interactive Programming Guide 3 Connect scanner cable (standard version shown) Scanner cable depends on your terminal Cables Accessories 4 RFID reader/programmer reading distance RFID reader/programmer operation Sabre 1555 2450 MHz Sabre 1555 915 MHz 2.5 cm - 200 cm (1" - 80") 1 cm - 60 cm (0.4" - 24") "beep" 5 Scanner reading distance Scanner operation "beep" Sabre 1555 Standard Range Sabre 1555 Long Range 6 cm - 34 cm (2.5" - 13.5") 28 cm - 100 cm (11" - 39") 6 Ê Ë Ì Í Î RS-232 C Connect cable Scanner power ON Direct RS-232 C cable P/N 3-604032-00 System power OFF System power ON Select standard RS-232 C (PC serial port compatible) 9600 baud, 7 data bits, even parity, 2 stop bits postamble = carriage return + line feed Ê Ë Ì Í Î 7 Customize parameters (optional) (*) = default value Ï 9600 baud (*) 19200 baud 7 data bits (*) 8 data bits No parity Postamble = Carriage Return Postamble = none Even parity (*) Odd parity Postamble = Carriage Return + Line Feed (*) 8 Ê Ë Ì Í Î RS-232 TTL Connect cable Scanner power ON System power OFF System power ON Select RS-232 TTL 9600 baud, 7 data bits, even parity, 2 stop bits postamble = carriage return + line feed Ê Ë Ì Í Î Direct RS-232 TTL cable P/N x-xxxxxx-xx 9 Customize parameters (optional) (*) = default value Ï 9600 baud (*) 19200 baud 7 data bits (*) 8 data bits No parity Postamble = Carriage Return Postamble = none Even parity (*) Odd parity Postamble = Carriage Return + Line Feed (*) 10 Ê Ë Ì Í Î Universal Serial Bus (USB) Connect cable Scanner power ON Direct USB cable P/N x-xxxxxx-xx System power OFF System power ON Select standard USB (PC serial port compatible) 9600 baud, 7 data bits, even parity, 2 stop bits postamble = carriage return + line feed Ê Ë Ì Í Î 11 Customize parameters (optional) (*) = default value Ï Intermec representative needs to supply USB symbologies when the symbols are available. 12 EAN 13 1234567890128 Code 128 CODE-128 Code 39 CODE-39 UPC-A, UPC-E, EAN-8, EAN-13 (UPC-A -> EAN-13) UPC-A, UPC-E, EAN-8, EAN-13 (UPC-A -> UPC-A) Code 39 Code 128 / EAN 128 Symbology Disable all symbologies Ê Select symbology Ë Test Ì UPC-A 13 EasySet Online setup Reset Connect RS-232 C cable (P/N 3-604032-00) Scanner power ON System power OFF System power ON Start EasySet software Scan EasySet setup code Ê Ë Ì Í Î Ï 14 CAUTION – Use of controls or adjustments or performance of procedures other than those specified herein result in hazardous laser light. VORSICHT – Bei einer anders als hier beschriebenen Verwendung der Bedienelemente oder Veränderungen oder einer anderen Ausführung der Arbeitsabläufe entsteht gefährliches Laserlicht. ATTENTION – L’utilisation de contrôles/commandes ou de réglages ou l’exécution de procédures autres que ceux précisés par le présent document provoquent une lumière laser dangereuse. Laser warnings Fix these warning labels onto the product if they are not already present. The Sabre 1555 has a maximum laser output of 1mW at 630-680 nm and complies with the following safety standards: USA: CDRH - Class II Laser Product (CFR 21 Subpart J) IEC 825-1 EN 60825-1 - Class 2 Laser Product Cole as etiquetas de precaução no equipamento. Un’etichetta di avviso per il laser è da applicare sul prodotto. Collez les étiquettes d’avertissement sur votre produit. Bringen Sie Warnetiketten auf dem Produkt an. Fije la etiqueta de advertencia en el producto. 15 N309 Regulatory statements © 09/00 Intermec Technologies Corporation.1.0EditionEditionAll rights reserved. USA & Canada: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. This device requires a radio license, unless it is used totally inside of a building. (The user must obtain this license.) Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Cet appareil exige une license radio à moins d’être entièrement installé dans un bâtiment. (L’utilisateur doit obtenir cette license.) This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment is intended for operation in a commercial environment, in compliance with the requirements for a Class A digital device, pursuant to Part 15 of the FCC Rules, and it must not be used in a residential environment. It generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instruction manual, it may cause interference to radio communications. If this equipment causes interference, the user will be required to correct the interference at the user’s own expense. To maintain compliance with the FCC Rules, the input/output (I/O) cables that interconnect between the device and any peripheral (such as a reader) must be as specified by Intermec. Operator Warning: FCC regulations limit expos…

Text truncated - open the document above for the full version.

P/N x-xxxx49-00 Sabre 1555 Laser Scanner & RFID Reader/Programmer Operator’s Guide Bedieneranleitung Guida dell'operatore Guía del Usuario Guia do Utilizador Guide de l'Opérateur 2 RFID reader/programmer reading distance RFID reader/programmer operation Sabre 1555 2450 MHz Sabre 1555 915 MHz 2.5 cm - 200 cm (1" - 80") 1 cm - 60 cm (0.4" - 24") Sabre 1555 915 MHz Sabre 1555 2450 MHz "beep" "beep" 3 Scanner reading distance Scanner operation "beep" Sabre 1555 Standard Range Sabre 1555 Long Range 6 cm - 34 cm (2.5" - 13.5") 28 cm - 100 cm (11" - 39") 4 CAUTION – Use of controls or adjustments or performance of procedures other than those specified herein result in hazardous laser light. VORSICHT – Bei einer anders als hier beschriebenen Verwendung der Bedienelemente oder Veränderungen oder einer anderen Ausführung der Arbeitsabläufe entsteht gefährliches Laserlicht. ATTENTION – L’utilisation de contrôles/commandes ou de réglages ou l’exécution de procédures autres que ceux précisés par le présent document provoquent une lumière laser dangereuse. Laser warnings Fix these warning labels onto the product if they are not already present. The Sabre 1555 has a maximum laser output of 1mW at 630-680 nm and complies with the following safety standards: USA: CDRH - Class II Laser Product (CFR 21 Subpart J) IEC 825-1 EN 60825-1 - Class 2 Laser Product Collez les étiquettes d’avertissement sur votre produit. Bringen Sie Warnetiketten auf dem Produkt an. Fije la etiqueta de advertencia en el producto. Cole as etiquetas de precaução no equipamento. Un’etichetta di avviso per il laser è da applicare sul prodotto. 5 USA & Canada: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. This device requires a radio license, unless it it used totally inside a building. (The user must obtain this license.) Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Cet appareil exige une license radio à moins d’être entièrement installé dans un bâtiment. (L’utilisateur doit obtenir cette license.) This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment is intended for operation in a commercial environment, in compliance with the requirements for a Class A digital device, pursuant to part 15 of the FCC Rules and it must not be used in a residential environment; however, it has also been tested and found to comply with the more stringent requirements for a class B device, pursuant to Part 15 of the FCC rules. It generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause interference to radio communications. If this equipment causes interference, the user will be required to correct the interference at the user’s own expense. To maintain compliance with the FCC Rules, the I/O cables that interconnect between the device and any peripheral (such as a reader) must be as specified by Intermec. This product complies with the American National Standards Institute NCIT 256-1999 standard for RFID Item Management. Operator Warning: FCC regulations limit exposure to radio frequency (RF) radiation. To comply with these regulations, the operator of this device must maintain a distance of at least 4 cm (2 inches) from the front part of the device to any bystanders under normal operating conditions. While the device is on, the operator’s body and parts of the body, such as eyes, hands, or head, must be 4 cm (2 inches) or farther from the front of the device. This device is UL listed (UL 1950/C22.2 No. 950) for safety when powered by a host system or by one of the following external Intermec power supplies: Catalog No. and P/N 043230 ~100V, 50/60 Hz or Catalog No. and P/N 047793 ~120V, 60 Hz. This device is CSA certified. Intermec hereby declares that the Sabre 1555 has been tested and found compliant with the below listed standards as required by the EMC Directive 89/336/EEC as amended by 92/31/EEC and by the Low Voltage Directive 73/23/EEC as amended by 93/68/EEC: EN55022, EN50082-2, EN60950 This device is TÜV GS licensed (EN 60950 and EN 60825-1) for safety when powered by a host system or by the following external Intermec power supply: Catalog No. and P/N 047795 ~230V, 50 Hz. For 240V applications use the power supply: Catalog No. 047794 (P/N 5014UK) ~240V, 50 Hz. The device is CSA certified. Australia-New Zealand: This equipment has been tested and found to conform to the Australian EMC framework concerning Class B digital devices, prescribed by the Australian and New-Zealand standard AS/NZS 3548. Mexico: Este equipo cumple con la certificatión NOM. The information contained in this document is for informational purposes only and is subject to change without notice. No part of this document may be copied or reproduced in any manner without the prior written permission of Intermec Technologies Corporation. Sabre products are covered by patents issued or pending in the USA and other countries. The word Intermec, the Intermec logo, Sabre and EasySet are either trademarks or registered trademarks of Intermec. Throughout this document, trademarked names may be used. Rather than put a trademark (™ or ®) symbol in every occurrence of a trademarked name, we state that we are using the names only in an editorial fashion, and to the benefit of the trademark owner, with no intention of infringement. Caution Changes or modifications not expressly approved by Intermec could void the user's authority to operate this equipment. North America / Asia Pacific / Latin America • 6001 36th Avenue West, PO Box 4280, Everett, WA 98203-9280 Tel: +1 425 348 2600 • Fax: +1 425 348 2833 • U.S. …

Text truncated - open the document above for the full version.

P/N 3-740049-01 Sabre 1555 Laser Scanner & RFID Reader/Programmer Getting Started Guide Anleitung für Einsteiger Guia de IniciaçãoGuide de Démarrage Guida IntroduttivaGuía de Iniciación Untitled-24/30/01, 1:30 PM1 2 Introduction Use this Getting Started Guide to set up the Sabre 1555 Laser Scanner and RFID Reader/Programmer for most terminal connections and symbologies. If necessary, use the EasySet setup software for additional configuration possibilities and terminal con- nections. Basic setup Configuración básica Configuration de base Grundkonfiguration Configurazione di base Getting Started Guide EasySet Full setup Configuración completa Configuration complète Vollständige Konfiguration Configurazione completa Configuração completa EasySet setup software Operating Uso Utilisation Betrieb Utilizzazione Operator’s Guide Interactive Programming Guide Interactive Programming Untitled-24/30/01, 1:30 PM2 3 Connect scanner cable Scanner cable depends on your terminal Cables Accessories Standard Version PDT Version Untitled-24/30/01, 1:30 PM3 4 ™ š › œ RS-232 C Connect cable Scanner power ON Direct RS-232 C cable (1555 57D) P/N 3-614032-00 System power OFF System power ON Select standard RS-232 C (PC serial port compatible) ™ š › œ 19200 baud, 7 data bits, even parity, 2 stop bits, postamble = carriage return + line feed Power supply P/N 070826 ž  Switch to Barcode Read Mode (PDT version shown) Standard version -- press mode button, read display PDT version -- press mode button + pull trigger, read display Untitled-24/30/01, 1:30 PM4 5 Customize parameters (optional) (*) = default value 9600 baud 19200 baud (*) 7 data bits (*) 8 data bits No parity Postamble = Carriage Return Postamble = none Even parity (*) Odd parity Postamble = Carriage Return + Line Feed (*) Ÿ Untitled-24/30/01, 1:30 PM5 6 ™ š › œ RS-232 TTL Connect cable System power OFF System power ON Select RS-232 TTL ™ š › œ Direct RS-232 TTL cable P/N 3634032-01 Scanner power ON 19200 baud, 7 data bits, even parity, 2 stop bits, postamble = carriage return + line feed ž  Switch to Barcode Read Mode (PDT version shown) Standard version -- press mode button, read display PDT version -- press mode button + pull trigger, read display Untitled-24/30/01, 1:30 PM6 7 Customize parameters (optional) (*) = default value 9600 baud 19200 baud (*) 7 data bits (*) 8 data bits No parity Postamble = Carriage Return Postamble = none Even parity (*) Odd parity Postamble = Carriage Return + Line Feed (*) Ÿ Untitled-24/30/01, 1:30 PM7 8 EAN 13 1234567890128 Code 128 CODE-128 Code 39 CODE-39 UPC-A, UPC-E, EAN-8, EAN-13 (UPC-A -> EAN-13) UPC-A, UPC-E, EAN-8, EAN-13 (UPC-A -> UPC-A) Code 39 Code 128 / EAN 128 Symbology Disable all symbologies ™ Select symbology š Test › UPC-A Untitled-24/30/01, 1:31 PM8 9 EasySet Direct RS-232 C cable (1555 57D) P/N 3-614032-00 Power supply P/N 070826 Online setup Reset Connect RS-232 C cable Scanner power ON System power OFF System power ON Start EasySet software ™ š › œ  Untitled-24/30/01, 1:31 PM9 10 CAUTION – Use of controls or adjustments or performance of procedures other than those specified herein result in hazardous laser light. VORSICHT – Bei einer anders als hier beschriebenen Verwendung der Bedienelemente oder Veränderungen oder einer anderen Ausführung der Arbeitsabläufe entsteht gefährliches Laserlicht. ATTENTION – L’utilisation de contrôles/commandes ou de réglages ou l’exécution de procédures autres que ceux précisés par le présent document provoquent une lumière laser dangereuse. Laser warnings Fix these warning labels onto the product if they are not already present. The Sabre 1555 has a maximum laser output of 1mW at 630-680 nm and complies with the following safety standards: USA: CDRH - Class II Laser Product (CFR 21 Subpart J) IEC 825-1 EN 60825-1 - Class 2 Laser Product Cole as etiquetas de precaução no equipamento. Un’etichetta di avviso per il laser è da applicare sul prodotto. Collez les étiquettes d’avertissement sur votre produit. Bringen Sie Warnetiketten auf dem Produkt an. Fije la etiqueta de advertencia en el producto. Untitled-24/30/01, 1:31 PM10 11 N309 Regulatory statements USA & Canada: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. This device requires a radio license, unless it it used totally inside a building. (The user must obtain this license.) Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Cet appareil exige une license radio à moins d’être entièrement installé dans un bâtiment. (L’utilisateur doit obtenir cette license.) To prevent radio interference to the licensed service, this device is intended to be operated indoors only and should be kept away from windows to provide maximum shielding. This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment is intended for operation in a commercial environment, in compliance with the requirements for a Class A digital device, pursuant to part 15 of the FCC Rules and it must not be used in a residential environment; however, it has also been tested and found to comply with the more stringent requirements for a class B device, pursuant to Part 15 of the FCC rules. It generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause interference to radio communications. If this equipment causes interference, the user will be required to correct the interference at the user’s own expense. To maintain compliance with the FCC Rules, the I/O cables that interconnect between the device and any peripheral (such as a reader…

Text truncated - open the document above for the full version.

11 N309 Regulatory statements USA & Canada: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. This device requires a radio license, unless it it used totally inside a building. (The user must obtain this license.) Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Cet appareil exige une license radio à moins d’être entièrement installé dans un bâtiment. (L’utilisateur doit obtenir cette license.) To prevent radio interference to the licensed service, this device is intended to be operated indoors only and should be kept away from windows to provide maximum shielding. This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment is intended for operation in a commercial environment, in compliance with the requirements for a Class A digital device, pursuant to part 15 of the FCC Rules and it must not be used in a residential environment; however, it has also been tested and found to comply with the more stringent requirements for a class B device, pursuant to Part 15 of the FCC rules. It generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause interference to radio communications. If this equipment causes interference, the user will be required to correct the interference at the user’s own expense. To maintain compliance with the FCC Rules, the I/O cables that interconnect between the device and any peripheral (such as a reader) must be as specified by Intermec. This product complies with the American National Standards Institute NCIT 256-1999 standard for RFID Item Management. Operator Warning: FCC regulations limit exposure to radio frequency (RF) radiation. To comply with these regulations, the operator of this device must maintain a distance of at least 5 cm (2 inches) from the front part of the device to any bystanders under normal operating conditions. While the device is on, the operator’s body and parts of the body, such as eyes, hands, or head, must be 5 cm (2 inches) or farther from the front of the device. This device is UL listed (UL 1950/C22.2 No. 950) for safety when powered by a host system or by one of the following external Intermec power supplies: Catalog No. and P/N 043230 ~100V, 50/60 Hz or Catalog No. and P/N 047793 ~120V, 60 Hz. This device is CSA certified. Intermec hereby declares that the Sabre 1555 has been tested and found compliant with the below listed standards as required by the EMC Directive 89/336/EEC as amended by 92/31/EEC and by the Low Voltage Directive 73/23/EEC as amended by 93/68/EEC: EN55022, EN50082-2, EN60950 This device is TÜV GS licensed (EN 60950 and EN 60825-1) for safety when powered by a host system or by the following external Intermec power supply: Catalog No. and P/N 047795 ~230V, 50 Hz. For 240V applications use the power supply: Catalog No. 047794 (P/N 5014UK) ~240V, 50 Hz. The device is CSA certified. Australia-New Zealand: This equipment has been tested and found to conform to the Australian EMC framework concerning Class B digital devices, prescribed by the Australian and New-Zealand standard AS/NZS 3548. Mexico: Este equipo cumple con la certificatión NOM. The information contained in this document is for informational purposes only and is subject to change without notice. No part of this document may be copied or reproduced in any manner without the prior written permission of Intermec Technologies Corporation. Sabre products are covered by patents issued or pending in the USA and other countries. The word Intermec, the Intermec logo, Sabre and EasySet are either trademarks or registered trademarks of Intermec. Throughout this document, trademarked names may be used. Rather than put a trademark (™ or ®) symbol in every occurrence of a trademarked name, we state that we are using the names only in an editorial fashion, and to the benefit of the trademark owner, with no intention of infringement. To comply with RF exposure limits, bystanders should stay away from the front of this product, at least 5 cm (2 in) for the 2450 MHz version and 4 cm (1.5 in) for the 915-MHz version, when it is in operation. This product complies with all other RF exposure requirements while the unit is in operations, including specific absorption rate (SAR) limits for the user's hand. Changes or modifications not expressly approved by Intermec could void the user's authority to operate this equipment. 1555gs PC.p655/10/01, 3:11 PM11

FCC Response letter for request number 19005. May 10, 2001 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant:INTERMEC TECHNOLOGIES CORPORATION 6001 36th Avenue West Everett, WA 98203-9280 Phone: (505) 856-8054 RE: Response for reference number 19212. Equipment:FCC ID: HN21555-2450 FCC Rules:Part 2 and 15.247 Gentlemen: Attached please find our response to your request for information regarding the Intermec Technology submittal application for grant of certification for HN21555-2450, EA100016. A copy of the request is included here for reference. To:Scot Rogers, Rogers Labs, Inc From:Joe Dichoso [email protected] FCC Application Processing Branch Re:FCC ID HN21555-2450 Applicant:Intermec Corporation Correspondence Reference Number:19212 731 Confirmation Number:EA100016 Expiration 6/3/01. 60 days from original request. The manual statement concerning RF Safety does not agree with the SAR report. The SAR report indicates 5 cm from the body. However, an additional statement was added to maintain 4 cm from the operators body, eyes, etc... Provide additional SAR data to reflect the new additional RF safety language. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal pursuant to Section 2.917 (c) and forfeiture of the filing fee pursuant to section 1.1108. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 l Page 2May 10, 2001 RESPONSE There was a type mistake in the operator’s manual. It erroneously stated 4cm (2 inches) and should read 5cm (2 inches). This type mistake has been corrected and a copy of the corrected page has been submitted to the FCC for approval. We apologize for the error and request you continue with the Grant of Certification. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures

Intermec Technolo gies Corporation Amtech S ystems Division 8600 Jefferson St. NE Albu querque, NM 87113 Phone: (505) 856-8059 Fax: (505) 857-0715 E-mail: [email protected] January 9, 2001 Federal Communications Commission Equipment Authorization 7435 Oakland Mills Road Columbia, MD 21046 RE:Part Lists / Tune Up Info FCC ID No: HN21555-245 Dear Sirs: Pursuant to section 2.983 (d)(6), the list of active devices and description of the function of each semiconductor and other active circuit elements are included as a portion of the operational description, and are included under a separate cover in the exhibit titled “Operational Description”. Pursuant to section 2.983(d)(9), the 2450 Hand Held Reader has no user adjustable controls. The device has no provisions for any type of alignment, therefore no tuning is required. The power level is set at the factory test and is not adjustable. Respectfully, Jerry Johnson Project Manager Amtech Systems Division Intermec Technologies Corporation

Intermec Technolo gies Corporation Amtech S ystems Division 8600 Jefferson St. NE Albu querque, NM 87113 Phone: (505) 856-8059 Fax: (505) 857-0715 E-mail: [email protected] January 9, 2001 Federal Communications Commission Equipment Authorization 7435 Oakland Mills Road Columbia, MD 21046 RE:Request for Confidential Treatment FCC ID No: HN21555-245 Dear Sirs: Intermec Technologies Corporation requests that the material in the Block diagram, Schematics, and Operational Description be withheld from public disclosure in accordance with Section 0.459 of the Commissions Rules, 47 C.F.R. 0.459 (1998), following grant of the application. In support of this request, Intermec submits the following: 1. Identification of the specific information for which confidential treatment is sought: The materials set fourth in the Operational Description, Block Diagram, and Schematics, which are segregated from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: HN21555-900. 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation and circuit diagrams, (scematics and Block diagrams). As such this material is treated as highly confidential business information. 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of Location and Monitoring Service transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Intermec’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Intermec. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Intermec and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of the modulated backscatter radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. Thus equipment is designed for commercial, industrial, and governmental transportation applications. As such, unlike most consumer equipment, this equipment will be used for more than a decade in some cases. Moreover, this equipment will be used in revenue collection (e.g. toll collections) and secure access control applications (e.g. freight ha…
