J26520005-1MDS-MMDS Transceiver, Model 520005-1

C+A 1 C+A TRANSCEIVER INSTALLATION GUIDE ____________________________________________________ The installation of California Amplifier products should only be attempted by qualified personnel, and should be under the direct guidelines of the system operator. These installation instructions apply to California Amplifier products only. Use of these instructions to install other manufacturer’s products may result in unknown hazards, damage and/or unacceptable performance. The information contained in this applications note is intended to assist the operator in developing a set of installation guidelines and operating practices for the field personnel skilled in installing roof top subscriber equipment. California Amplifier accepts no responsibility for claims of injury, death, destruction of property or loss of television service related to improper installation, or installation of equipment by staff not skilled in installing roof top cable television equipment. 460 Calle San Pablo, Camarillo, California 93012 USA PH: (805) 987-9000 Fax (805) 987-8359 C+A 2 GENERAL INSTALLATION INSTRUCTIONS FOR MDS-MMDS TRANSCEIVER NOTE to System Operator: The AirStream Transceiver has been designed for installation by a licensed or qualified installer with experience in installing wireless antennas. NOTE to Installer: The authority to operate this device requires its operation and installation, including antennas, to comply with the FCC-adopted radio frequency (RF) exposure limits. It is in the responsibility of the installer to install this device and associated antennas so that RF exposures to people do not exceed 1.0mW/cm 2 . The power output near of this transceiver at the antenna exceeds the FCC adopted RF exposure limits for people. When used with an antenna with a maximum gain of 17 dBi the exposure limit is satisfied if the antenna is at least 30 centimeters or 12 inches away from all people. INSTALLATION PRACTICES In a customer installation, there are several factors that must be considered before the installation can take place: Signal contour strength and direction of the transmitting source, seasonal interference’s such as foliage and trees, aesthetics of the outdoor installation, system performance and overall customer satisfaction with the final product. In each case the customer wants the very best signal quality with a minimum of construction and aesthetic impact to their home or business. This will dictate the use of a variety of antenna configurations in order to perform the task of providing adequate signal strength while maintaining low visual impact. The order of visual impact follows the height and size of the antenna. A wall or gutter mount will present a very low visual profile. This if followed by a short roof or chimney mount. When higher gain or foliage clearance is needed, then a tree mount or mast mount should be considered. The following mounts are described and their general application: Wall or Standoff Mount: These are used in high signal density areas where antenna aesthetics is of concern. It offers great flexibility in mounting angles and locations. The stand-off arms mount from the wall and or the eave and support the mast in the vertical position. The mast may be short in length so as to place the antenna above the roof C+A 3 line or a telescoping mast may be used in conjunction with a ground plate to extend the antenna height to above the roof peak. Roof Mounts: The same basic hardware used for wall and eave mounts is used for a roof mount. This mounting bracket and pole is adjustable in the vertical plane and will raise the antenna about 24” above the mounting location. The bracket must be secured into a structural member, not simply into siding or shingles. All points of attachment must be properly waterproofed. Chimney Mounts: Chimney mounts are one of the easiest types of mounts to install. In the application of brick-type chimneys, a dual band strap mount is best. The proper strap will securely fasten the mounting bracket and antenna. For wood over metal construction chimney, a version of the wall mount is best. Make sure the anchor bolts attach to a supporting stud member and not just the fascia board. C+A 4 Tripod Mount: The tripod mount offers ease of installation, stable mounting structure, and signal visibility. It is however, bulky and not very aesthetic. The tripod mount comes in 3, 5, 10 and 15-foot sections. As with the roof mount installation, the mounting bolts must always be attached to roof joists and be properly sealed. Tree Mounts: In regions of the country with heavy foliage, tree mounts are popular. This is a highly specialized installation and is beyond the scope of this installation guide. Specific instructions and practices can only be formatted by the individual operator in their region (not pictured). Every installation must adhere to company policies, applicable specifications and drawings of the system operator. This requirement includes: the choice of antennas, the weatherproofing of all connections, all penetrations into the building and all grounding procedures, both at the antenna mount and at the point of drop entry into the building. C+A 5 INSTALLATION PLANNING In addition to meeting the highest standards of quality and workmanship, another valid goal is to minimize the amount of time spent on a customer’s property, thus minimizing any disruption of a customer’s schedule. Good planning helps an installer to be efficient and productive on each installation. Site Survey Although the general receive location may have been previously surveyed by a signal crew, a detailed, on-site survey is usually required prior to beginning an install. During this survey, signal readings must be recorded on the installation work order. The exact components that were used as well as the mast height should be noted at this time. You should also create a simple drawing of the antenna installation, including structural supports and ground system relative to…

Text truncated - open the document above for the full version.

131908/2C+A 1 C+A TRANSCEIVER INSTALLATION GUIDE ____________________________________________________ The installation of California Amplifier transceiver products should only be done by qualified personnel, and should be under the direct guidelines of the system operator. These installation instructions apply to California Amplifier products only. Use of these instructions to install other manufacturer’s products may result in unknown hazards, damage and/or unacceptable performance. The information contained in this applications note is intended to assist the operator in developing a set of installation guidelines and operating practices for the field personnel skilled in installing roof top subscriber equipment. California Amplifier accepts no responsibility for claims of injury, death, destruction of property or loss of television service related to improper installation, or installation of equipment by staff not skilled in installing roof top cable television equipment. 460 Calle San Pablo, Camarillo, California 93012 USA PH: (805) 987-9000 Fax (805) 987-8359 131908/2C+A 2 GENERAL INSTALLATION INSTRUCTIONS FOR TRANSCEIVER NOTE to System Operator: California Amplifier family of Transceiver products has been designed for installation by a licensed or qualified installer with experience in installing wireless antennas. NOTE to INSTALLER: 1. Installation and operation of this family of Transceiver products require full compliance with FCC-adopted radio frequency exposure limits. It is in the responsibility of the installer to install these devices and their associated antennas so that RF exposure does not exceed 1.0mW/cm 2 . The following table summarizes the minimum distance required to satisfy these requirements. Limits, Minimum P/NIntegrated Planar (17 dBi)Standalone (when used with 24 dBi) 520005-1N/A26 in. (66 cm) 520004-1N/A 48 in. (122 cm) 520007-212 in. (30 cm)N/A 520024-212 in. (30 cm)N/A 520004-222 in. (55 cm)N/A 2. When installing a standalone Transceiver, orient the FCC RF exposure label so that it is facing the front of the Antenna This is a mandatory requirement by the FCC to comply with RF exposure compliance requirements. The label should not be obstructed when installation is complete. This will allow the warning label to be visible and readable. This is a mandatory requirement by the FCC to comply with RF exposure compliance requirements 131908/2C+A 3 INSTALLATION PRACTICES In a customer installation, there are several factors that must be considered before the installation can take place: Signal contour strength and direction of the transmitting source, seasonal interference’s such as foliage and trees, aesthetics of the outdoor installation, system performance and overall customer satisfaction with the final product. In each case the customer wants the very best signal quality with a minimum of construction and aesthetic impact to their home or business. This will dictate the use of a variety of antenna configurations in order to perform the task of providing adequate signal strength while maintaining low visual impact. The order of visual impact follows the height and size of the antenna. A wall or gutter mount will present a very low visual profile. This if followed by a short roof or chimney mount. When higher gain or foliage clearance is needed, then a tree mount or mast mount should be considered. The following mounts are described and their general application: Wall or Standoff Mount: These are used in high signal density areas where antenna aesthetics is of concern. It offers great flexibility in mounting angles and locations. The stand-off arms mount from the wall and or the eave and support the mast in the vertical position. The mast may be short in length so as to place the antenna above the roof line or a telescoping mast may be used in conjunction with a ground plate to extend the antenna height to above the roof peak. Roof Mounts : The same basic hardware used for wall and eave mounts is used for a roof mount. This mounting bracket and pole is adjustable in the vertical plane and will raise the antenna about 24” above the mounting location. The bracket must be secured into a structural member, not simply into siding or shingles. All points of attachment must be properly waterproofed. 131908/2C+A 4 Chimney Mounts: Chimney mounts are one of the easiest types of mounts to install. In the application of brick-type chimneys, a dual band strap mount is best. The proper strap will securely fasten the mounting bracket and antenna. For wood over metal construction chimney, a version of the wall mount is best. Make sure the anchor bolts attach to a supporting stud member and not just the fascia board. 131908/2C+A 5 Tripod Mount : The tripod mount offers ease of installation, stable mounting structure, and signal visibility. It is however, bulky and not very aesthetic. The tripod mount comes in 3, 5, 10 and 15-foot sections. As with the roof mount installation, the mounting bolts must always be attached to roof joists and be properly sealed. Tree Mounts: In regions of the country with heavy foliage, tree mounts are popular. This is a highly specialized installation and is beyond the scope of this installation guide. Specific instructions and practices can only be formatted by the individual operator in their region (not pictured). Every installation must adhere to company policies, applicable specifications and drawings of the system operator. This requirement includes: the choice of antennas, the weatherproofing of all connections, all penetrations into the building and all grounding procedures, both at the antenna mount and at the point of drop entry into the building. INSTALLATION PLANNING In addition to meeting the highest standards of quality and workmanship, another valid goal is to minimize the amount of time spent on a customer’s property, thus minimizing any disruption of a customer’s schedule. Good planning helps an installer to be efficient and productive…

Text truncated - open the document above for the full version.

_________________________________________________________________________________________ Phone (805) 987-9000 Fax (805) 482-5842 California Amplifier 460 Calle San Pablo Camarillo, California 93012 USA December 21, 1999 Federal Communications Comission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This is your letter of authorization to accept our appointment of CKC Laboratories, Inc. as Agent for California Amplifier, Inc. to sign applications before the Commission on our behalf, and to receive and exchange data between our company and the commission in connection with certification of the following California Amplifier product: Model # 520005-1 Wireless Cable Modem Transceiver We, the applicant certify that, in the case of individual applicant, he or she is not subject to a denial of federal benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 853a or in the case of non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the applicant is subject to a denial of federal benefit pursuant to that action. This authorization will expire in one year from the date of this letter. Sincerely, Kris Kelkar Vice President Wireless Access Products

REVISIONS UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE: FRACTIONS DECIMALS ANGLES ±1/32 .XX ±.01 ±0°30’ XXX ± .005 USED ON elec. file: 131406A.doc MATERIAL FINISH DRAWN: CHECKED: ISSUED: TITLE DO NOT SCALE DRAWING SIZE CAGE CODE DWG NO.REV A6T925 C+A SHEET 1 OF 1 SCALE WEIGHT ITEM NO. QTY REQD IDENTIFYING NO.DESCRIPTION 11 79808LABEL, BLANK, WHITE, W/CAI LOGO NOTES: APPLICABLE STANDARDS/SPECIFICATIONS: MIL-STD-100E, ENGINEERING DRAWING PRACTICES. ANSI Y14.5M-82, DIMENSIONS AND TOLERANCES. REVECO NO. DESCRIPTION DATEAPPROVED 131406 LABEL, MARKING, MDS-MMDS TRANSCEIVER, STANDARD Made in the U.S.A. Camarillo, CA PAT. PENDING INTEGRATED MDS-MMDS TRANSCEIVER PART NO.: 520005-1 FCC ID: J26520005-1 VDC: +16 to +24 S/N: XXXXXXXXXX C+A 1/1 1 Form No: L11041/A 520005-1

MDS-MMDS Transceiver 520005-1 Description Of Operation This product is a two-way microwave transceiver designed to operate over the MDS band (2150- 2162 MHz) as the transmitter and over the MMDS band (2500-2686 MHz) as the receiver. The receive and transmit chains of the design are combined utilizing proper dilpexing and filtering at each respective band. There is one common RF port for both RF Receive (Rx) band, and RF Transmit (Tx) band, and one common IF port for the Rx IF band and Tx IF band. This product is designed to operate with cable-ready type Modems in order to provide high speed internet access to the consumers. Modem upstream IF band is 14.375-26.375 MHz and downstream IF band is 222-408 MHz. As an out door unit, this transceiver is connected to a directive Antenna, which is designed to cover both Rx and Tx bands. The Antenna gain of a typical installation is about 17 dBi. The transmit section in this transceiver is a dual conversion frequency translator. The modem IF input frequency band of 14.375-26.375 MHz is unconverted to an intermediate IF frequency of 116 to 128 MHz, which then gets unconverted to the desired RF transmit band of 2150-2162 MHz. The unit is capable of up to 25 dBm output 1-dB compression point at approximately 22 dB of total gain. The local oscillator (LO) used in this design is an S-Band oscillator at 2278 MHz phase locked to a highly stable Temperature Compensated Crystal Oscillator (TCXO) and exhibits a long term stability of ±10 KHz over the operating temperature range of –30 deg C to +70 deg. C. This LO is used in the second upconversion process, which yields the Tx RF band. The 142.375 MHz LO used in the first upconversion process is derived from the 2278 MHz S-Band LO by dividing it by 16. The Transmit block diagram is shown below. It shows the various gain, mixing, and filtering blocks that make up this chain. All filters were specifically designed and placed appropriately along the transmit chain to achieve the desired rejection masks in order to comply with internal and external interfering sources and emission requirements. A QPSK signal of up to 6 MHz wide within the frequency band of 14.375-26.375 MHz is provided from the Hybrid Networks modem, model number N231. The output is adjusted in 1 dB steps from 8 dBmV to 58 dBmV into the transceiver, which in turn gets up converted twice for the desired RF transmit band of 2150-2162 MHz. In order to eliminate aggregate noise power at the receive hub due to emitted broad band noise from all the subscribers connected to the service, and thus maintain adequate signal quality, the transceiver utilizes a blanking feature which allows it to turn off the Transmitter when not in use. The transmitter is enabled by a predetermined minimum signal received from the modem. A typical install at a subscriber’s site includes this modem, the transceiver, the antenna, a plug-in power supply, cables and any additional powers dividers/splitters. The installer mounts the transceiver with the Antenna at a rooftop, and aligns the antenna towards the service provider’s hub for maximum signal quality. A cable run connects the transceiver with the indoor modem. This establishes the link between the transceiver and the hub. Sufficient link budget margin should be allowed to maintain link between the subscriber’s site and the service provider’s hub. -22 dB Integrated MDS/MMDS Transceiver Block Diagram (520005-1) (Transmit/Upstream) To Downconv. Mixe r -1 dB -2 dB From Modem: - 44 to + 9 -4 dB -6 dB 2 n d LO BPF -2 dB -2 dB MGA81563 Gain: 12 Vc/Ic: 3/40 P1dB: 14 +2 dBm 7 dBm 10 dBm Gain: 12N .F: 6 OIP3: 40 2-Pole MDS BPF Gain: 1.5N .F: -1.5 OIP3: 100 3-Pole MDS BPF Power Amp RF Micro RF2126 Driver Amp RF2128 Pad Gain Adj. 2 n d Mixe r Hittite HMC272 IF AMP NE1678GV Pad Gain Adj. Pad Gain Ad j . 116-128 MHz BPF 1 st LO Notch Filter 116-128 MHz BPF 1 st Mixer Mini Ckt. Pad Gain Ad j . 14-26 MHz BPF Gain: 30N .F: 7 OIP3: 36 Gain: -3N .F: 3 OIP3: 100 Gain: -2N .F: 2 OIP3: 100 Gain: -8N .F: 8 OIP3: 16 Gain: -2N .F: 2 OIP3: 100 Pad Gain Adj. Gain: -2N .F: 2 OIP3: 100 Gain: -2N .F: 2 OIP3: 100 Gain: -2N .F: 2 OIP3: 100 Gain: 22N .F: 6 OIP3: 29 Gain: -2N .F: 2 OIP3: 100 Gain: -2N .F: 2 OIP3: 100 Gain: -6N .F: 6 OIP3: 8 Gain: -7N .F: 7 OIP3: 100 Gain: -2N .F: 2 OIP3: 100 Gain: -2N .F: 2 OIP3: 100 Pad Gain Ad j . Pad Gain Ad j . To Du p lexe r Log Amp Comparator Pad Gain Adj. Gain: -2N .F: 2 OIP3: 100 PLL ASIC NE68139 LO Buffer +12 dBm VCO TCXO To PA Blanking PA Control Powe r ÷ 4 ÷ 4 LPF 160 MHz Switch Ckt. -6 dB -1 dB -7 dB -7 dB UPB585 Pin (dBm): -15 to +5 UPB1509 Pin (dBm): -20 to -5 -14 dBm UPC2792TBGain: 20P1dB: 0 UPC2776 Gain: 22 Vc/Ic: 5.5/30 P1dB: 9 1 st LO Buff.

FORM NO: 11040/A UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES: FRACTIONS DECIMALSANGLES ±1/32.XX ±.01±0°30’ .XXX ± .005 NEXT ASSY MODEL DRAWN: DATE: CHECK: DATE: ENGR: DATE: OTHER: DATE: SHEET 1 OF 2 C+A MATERIAL: FINISH: TITLE DO NOT SCALE DRAWING SIZE CAGE CODE DWG NO. REV. A 6T925 SCALE WEIGHT APPLICATION REVISIONS NEXT ASSYUSED ONREVDESCRIPTIONDATEAPPROVED 520005-1 ARELEASED PER EC0 58224 6/24/99 N. BARAKAT BREVISED UPCON SPECS/ECO#58319 8/12/99 N. BARAKAT C UPDATE UPCON SPEC /ECO#58534 11/11/99 N. BARAKAT 520005-1 A. ANGELES6/16/99 B. OJERIO8/13/99 N. BARAKAT6/24/99 MDS-MMDS TRANSCEIVER CM520005-1 ELEC. FILE: M520005-1C.doc N/A Above specifications subject to change without notice. World Headquarters: 460 Calle San Pablo, Camarillo, CA,USA 93012 Tel: 805/987-9000 Fax: 805/987-8359 Latin America Sales: California Amplifier do Brazil, Tel & Fax: 55/12-341-2264 Europe, Middle East & Africa Sales: Cal Amp sarl Paris, Tel: 33/1 49 19 89 20 Fax: 33/1 48 64 52 55 Asia and Pacific Sales: California Amplifier Thailand, Tel: 66-2-870-8333 Fax: 66-2-870-8334 SPEC FORM: M520005-1 REV: C DATE: 11/99 Form 11040/ADATE & TIME PRINTED: 4/25/01 7:47 AM C+A MDS-MMDS TRANSCEIVER PART NUMBER520005-1 Downconverter Specifications: (Rx) RF Input Frequency ......................................................................... 2500 - 2686 MHz IF Output Frequency ........................................................................ 222 - 408 MHz Gain ................................................................................................. 32 ± 6 dB (-30°C to +60°C) Gain Flatness ................................................................................... 3.5 dB typ., 4.5 dB Max. (-30°C to +60°C) Noise Figure ..................................................................................... 4.0 dB typ.; 5.5 dB Max at upper end of band IMD (Two tone test at -1 dBm each at the output) ........................... -50 dBc Max. Output 3rd Order Intercept ................................................................ 24 dBm Min. Image Rejection (PCS Band inclusive) ............................................ 85 dB Min. (60 dB is pre-LNA) WCS Rejection ................................................................................. 100 dB Min. (35 dB is pre-LNA) Out-of-Band Rejection ..................................................................... 15 dB at 2705 MHz Min. ........................................................................................... 50 dB at 2750 MHz Min. ........................................................................................... 50 dB at 2450 MHz Min. IF Rejection ...................................................................................... -85 dBc Max. In-Band Spurious ............................................................................ -80 dBm Max. Upconverter Specifications: (Tx) IF Input Frequency ............................................................................ 14.375 - 26.375 MHz RF Output Frequency ....................................................................... 2150 - 2162 MHz Gain ........................................................................................... 22 ± 5 dB (-30°C to +60°C) Gain Flatness .................................................................................... 3 dB Max. (-30°C to +60°C) Output 1-dB Compression Point ...................................................... +25 dBm Min. Output Transmit Noise ..................................................................... -122 dBm/Hz Max. Output Spurious/Harmonics (+22 dBm Tx Out) ............................... -60 dBc (Both in-band and out of Band) Output Power Blanking Threshold .................................................... -50 dBm Max. @ IF Input General Specifications: LO Frequency ................................................................................... 2278 MHz ± 10 KHz (-30°C to +60°C) Phase Noise ...................................................................................... -65 dBc/Hz @ 100 Hz ........................................................................................................... -85 dBc/Hz @ 1 KHz ........................................................................................................... -93 dBc/Hz @ 10 KHz ........................................................................................................... -98 dBc/Hz @100 KHz IF Connector (Rx out / Tx In) ............................................................ F-Type, 75 Ohm RF Connector (Rx In / Tx out) .......................................................... N-Type, 50 Ohm Tx/Rx IF Return Loss ........................................................................ Tx In: -10 dB; Rx Out: -6 dB Max. Tx/Rx RF Return Loss ..................................................................... -7 dB Max. DC Supply ......................................................................................... 16 to 24 Volts DC @ 550 mA Operating Temperature..................................................................... -30°C to +60°C Finish ................................................................................................. Chem. Film, MIL-C-5541, Class 3, Yellow Physical Dimension: Size.................................................................................................... 6.7x6.7x2.7 in., (170x170x70 mm.) Weight ............................................................................................... 36 oz. (1000 gm.) All Specifications are at 25°C unless otherwise specified.

REVISIONS UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE: FRACTIONS DECIMALS ANGLES ±1/32 .XX ±.01 ±0°30’ XXX ± .0 0 5 USED ON elec. file: 131863c.DOC MATERIAL FINISH DRAWN: CHECKED: ISSUED: TITLE DO NOT SCALE DRAWING SIZE CAGE CODE DWG NO.REV A6T925 C+A SHEET 1 OF 1 SCALE WEIGHT ITEM NO. QTY REQD IDENTIFYING NO.DESCRIPTION 11 79969LABEL, BLANK, POLY WHITE, 2.75 X 1.56 NOTES: 1. APPLICABLE STANDARDS/SPECIFICATIONS: MIL-STD-100E, ENGINEERING DRAWING PRACTICES. ANSI Y14.5M-82, DIMENSIONS AND TOLERANCES. 2.TYPE FACE :ARIAL ROUNDED MT BOLD CHARACTER HEIGHT : 0.15 INCHES CHARACTER WIDTH : 0.06 INCHES REVECO NO. DESCRIPTION DATEAPPROVED A58675RELEASED 3/16/00N. BARAKAT B58733UPDATE FCC LABEL 3/24/00N. BARAKAT CADD NOTE 2 131863 C LABEL, MARKING, FCC ID, TRX, STANDALONE, STD PWR 1/1 Form No: L11041/A A.ANGELES3/22/00 E. EBDANE3/29/00 520005-1 FCC ID: J26520005-1 WARNING: This device must comply with FCC-adopted RF exposure safety limits. This limit is satisfied if the device is at least 66 centimeters or 26 inches from any person while transmitting, when used with 24 dBi Antenna.

REVISIONS UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE: FRACTIONS DECIMALS ANGLES ±1/32 .XX ±.01 ±0°30’ XXX ± .0 0 5 USED ON elec. file: 131864c.DOC MATERIAL FINISH DRAWN: CHECKED: ISSUED: TITLE DO NOT SCALE DRAWING SIZE CAGE CODE DWG NO.REV A6T925 C+A SHEET 1 OF 1 SCALE WEIGHT ITEM NO. QTY REQD IDENTIFYING NO.DESCRIPTION 11 79969LABEL, BLANK, POLY WHITE, 2.75 X 1.56 NOTES: 1.APPLICABLE STANDARDS/SPECIFICATIONS: MIL-STD-100E, ENGINEERING DRAWING PRACTICES. ANSI Y14.5M-82, DIMENSIONS AND TOLERANCES. 2. TYPE FACE : ARIAL ROUNDED MT BOLD CHARACTER HEIGHT : 0.15 INCHES CHARACTER WIDTH : 0.06 INCHES REVECO NO. DESCRIPTION DATEAPPROVED A58675RELEASED 3/16/00N. BARAKAT B58733UPDATE FCC LABEL 3/24/00N. BARAKAT CADD NOTE 2 131864 C LABEL, MARKING, FCC ID, TRX, PLANAR, STD PWR 1/1 Form No: L11041/A A.ANGELES3/22/00 E. EBDANE3/29/00 5200024-2 FCC ID: J26520005-1 WARNING: This device must comply with FCC-adopted RF exposure safety limits. This limit is satisfied if the device is at least 55 centimeters or 22 inches from any person while transmitting. 520007-2

REVISIONS UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE: FRACTIONS DECIMALS ANGLES ±1/32 .XX ±.01 ±0°30’ XXX ± .0 0 5 USED ON elec. file: 131907a.DOC MATERIAL FINISH DRAWN: CHECKED: ISSUED: TITLE DO NOT SCALE DRAWING SIZE CAGE CODE DWG NO.REV A6T925 C+A SHEET 1 OF 1 SCALE WEIGHT ITEM NO. QTY REQD IDENTIFYING NO.DESCRIPTION 11 79900LABEL, BLANK, 2.25 x 1.00 NOTES: 1. APPLICABLE STANDARDS/SPECIFICATIONS: MIL-STD-100E, ENGINEERING DRAWING PRACTICES. ANSI Y14.5M-82, DIMENSIONS AND TOLERANCES. 2. TYPE FACE : ARIAL ROUNDED MT BOLD CHARACTER HEIGHT : 0.15 INCHES CHARACTER WIDTH : 0.06 INCHES REVECO NO. DESCRIPTION DATEAPPROVED ARELEASED 131907 A LABEL, MARKING, FCC RF EXPOSURE WARNING 1/1 Form No: L11041/A A.ANGELES4/19/00 520004-2 520007-2 WARNING: To comply with FCC RF exposure safety limits, a minimum separation distance of 55 centimeters or 22 inches is required from any person to the Antenna 520024-2

Report No: FC00-002 Page 1 of 24 CERTIFICATION TEST REPORT FOR THE WIRELESS CABLE MODEM TRANSCEIVER, 520005-1 FCC PART 2 AND PART 21 COMPLIANCE DATE OF ISSUE: JANUARY 17, 2000 PREPARED FOR: California Amplifier, Inc. 460 Calle San Pablo Camarillo, CA 93012 P.O. No: 20574 W.O. No: 72297 PREPARED BY: Joyce Walker [email protected] CKC Laboratories, Inc. 5473A Clouds Rest Mariposa, CA 95338 Date of test: December 15-17, 1999 Report No: FC00-002 DOCUMENTATION CONTROL: _____________________________ Tracy Phillips Documentation Control Supervisor CKC Laboratories, Inc. APPROVED BY: _____________________________ Dennis Ward Director of Laboratories CKC Laboratories, Inc. This report contains a total of 24 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Report No: FC00-002 Page 2 of 24 TABLE OF CONTENTS FOR Part 2 & 21 CERTIFICATION TEST REPORT Administrative Information .............................................................................................................3 Summary Of Results........................................................................................................................4 Equipment Under Test (EUT) Description......................................................................................4 Measurement Uncertainty................................................................................................................4 EUT Operating Frequency...............................................................................................................4 Peripheral Devices ...........................................................................................................................4 2.1033(c)(5) – Frequency Range .....................................................................................................6 2.1033(c)(7) – Maximum Power Rating..........................................................................................6 2.1033(c)(14)/2.1046/21.107/21.904(b) - RF Power Output...........................................................6 2.1033(c)(14)/2.1047(a) - Modulation Characteristics - Audio Frequency Response ....................8 2.1033(c)(14)/2.1047(b) - Modulation Characteristics – Modulation Limiting Response..............8 2.1033(c)(14)/2.1049(i)/26.106(a)(2)/21.908(b) - Occupied Bandwidth ........................................9 2.1033(c)(14)/2.1051/21.106(a)(i)&(ii) - Spurious Emissions A…

Text truncated - open the document above for the full version.
