JQU801210UBIQUITY Transponder

Request for Confidential Treatment of Exhibits to Mark IV Application for Equipment Authorization – EA226013 Mark IV Industries, Ltd. ("Mark IV") requests that, pursuant to Sections 0.457 and 0.459 of the Commissions Rules, certain Exhibits to its application for equipment authorization, EA 226013, be treated as confidential because these Exhibits contain proprietary and confidential technical information about Mark IV's products which would customarily be guarded from competitors. Pursuant to Section 0.459(b) of the Commission's Rules, Mark IV provides the following information in support of its request for confidential treatment: (1) Mark IV requests confidential treatment of the following Exhibits to, which are marked as confidential: • "Schematics" • "Parts List" • "Operational Description" (2) These Exhibits are submitted to the Commission in support of Mark IV's application for equipment authorization and provide the additional detail needed for the Commission's staff to properly evaluate the equipment; (3) These Exhibits contains highly confidential and proprietary technical information about the equipment design and operating characteristics; (4) Mark IV competes with a number of companies that are developing and marketing similar transponders for ITVS applications, including tolling operations. (5) Disclosure of such information to competitors could compromise Mark IV's ability to develop this technology, in that other companies could reverse engineer products using this information; (6) Mark IV has marked these Exhibits as confidential. Mark IV is careful in protecting proprietary aspects of its equipment design, including the use of confidentiality agreements with technical consultants; (7) Technical information contained in the Exhibits has not been disclosed to the public, nor disclosed to third-parties (not including counsel, independent laboratories, or consultants bound by confidentiality agreements or otherwise); June 9, 2003 Page 2 (8) Mark IV requests that this information be withheld from public disclosure until an unless Mark IV notifies the commission that such information may be publicly released. (9) Confidential treatment of these Exhibits will allow Mark IV to provide a full technical description of the equipment, which disclosure is in the public interest. Refusal to treat such documents as confidential would result in submission of insufficient information on which the FCC could base its decision to grant the authorization and delay deployment of these new and improved devices for IVDS applications. WAS1 #1186673 v1

Master: PT90PLMT Date: February 25, 2001 Test Report: 3W06286 Applicant: Mark IV Industries 6020 Ambler Drive Mississauga, Ontario L4W 2P1 Equipment Under Test: Mark IV IVHS Division, 801210 Transponder (EUT) 915.75MHz FCC ID: JQU801210 In Accordance With: FCC Part 90 902-928MHz, LMS Systems Tested By: Nemko Canada Inc. 303 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Russell Grant, Senior Technical Assessor Date: 8 May 2003 Total Number of Pages: 14 Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 2 of 14 Table of Contents Section 1. Summary of Test Results ...................................................................................3 Section 2. General Equipment Specification......................................................................5 Section 3. RF Power Output ................................................................................................6 Section 4. Occupied Bandwidth .........................................................................................7 Section 9. Field Strength of Spurious Emissions ...............................................................9 Section 12. Test Equipment List .........................................................................................12 Section 13. Test Diagrams ....................................................................................................13 Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 3 of 14 Section 1. Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 90, Sub part M. New Submission Production Unit Class II Permissive Change Pre-Production Unit L M S Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: ______________________________ DATE: 7 May 2003 Glen Westwell, Wireless Technologist Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 4 of 14 Summary Of Test Data Name Of Test Para. No. Result RF Power Output 2.1046 Complies Occupied Bandwidth 2.1049 Complies Spurious Emissions at Antenna Terminals 2.1051 N/A Field Strength of Spurious Emissions 2.1053 Complies Frequency Stability 2.1055 N/A Notes: This mobile transponder is used in the 909.75-921.75MHz (12MHz) band for non- multilateration LMS operations. This mobile transponder is not subject to frequency stability restrictions. This device incorporates an integral antenna. Indoor Temperature: 22°C Humidity: 45% Outdoor Temperature: 12°C Humidity: 70% . Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 5 of 14 Section 2. General Equipment Specification Manufacturer: Mark IV Industries Model No.: 801210 Serial No.: 106TB Date Received In Laboratory: 07 Apr 2003 Nemko Identification No.: #2 Frequency Range: 909.75-921.75MHz Transmit Frequency: 915.75MHz (fixed) RF Power Output: 0.005W (ERP) Integral Antenna Gain: 0dBi Authorized Bandwidth: 12MHz Emission Designator: 12M0P0D Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 6 of 14 Section 3. RF Power Output Para. No.: 2.1046 Test Performed By: Glen Westwell Date of Test: 5 May 2003 Minimum Standard: 90.205 (30W, ERP) Test Results: Complies. The RF power output is 7.0dBm (0.005)W. Measurement Data: Note: The field strength was measured using a 2MHz RBW. Fundamental Field Strength (maximum) E.R.P. (signal substitution) 915MHz 102.6dBuV 7.0dBm Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 7 of 14 Section 4. Occupied Bandwidth Para. No.: 2.1049 Test Performed By: Glen Westwell Date of Test: 5 May 2003 Minimum Standard: 90.210 (k)(3) Test Results: Complies Measurement Data: See Attached Plot. Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 8 of 14 Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 9 of 14 Section 9. Field Strength of Spurious Emissions Para. No.: 2.1053 Test Performed By: Glen Westwell Date of Test: 2 May 2003 Minimum Standard: 90.210, -25dBm Test Results: Complies. Measurement Data: See Attached Table. This EUT was searched on 3 orthogonal axis for maximum emissions from 30MHz to 10GHz. Only those emissions detected with in 20dB of the limit were reported. Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:3W06286 Mark IV 801210 Transponder Page 10 of 14 Test Data - Radiated Emissions Test Distance (meters) : 3 Range: A Receiver: 8565E RBW(kHz): 1000 Detector: Peak Freq. (MHz) Ant. * Pol. (V/H) RCVD Signal (dBμV/m) Conversion Factor (dB)** Cable Loss (dB) Emission Level (dBm) Limit (dBm) Margin (dB) 1830.00 Hrn2 V 81.5 -119.1 3.9 -33.7 -25 8.7 1830.00 Hrn2 H 68.7 -119.7 3.9 -47.1 -25 22.1 2745.00 Hrn2 V 67.2 -127.5 3.9 -54.6 -25 29.6 2745.00 Hrn2 H 72.5 -129.1 3.9 -50.8 -25 25.8 Notes: B/C = Biconical, B/L = Biconilog, L/P = Log-Periodic, H = Horn, D/P = Dipole * Re-measured using dipole antenna. ** Includes cable loss when amplifier is not used. *** Includes cable loss. ( …
