JQU801350801350-TAB Transponder

This device complies with Part 90 of the FCC Rules. Modifications not expressly approved by the manufacturer may invalidate the user’s authority to operate the equipment

Mark IV Industries Corp. G3B TRANSPONDER GENERAL TECHNICAL DESCRIPTION 8 5.0 TRANSPONDER LABEL The label on the transponder will be as follows: Mark IV Industries Corp. G3B TRANSPONDER GENERAL TECHNICAL DESCRIPTION 9

Master: PT90PLMT Date: February 25, 2001 Test Report: 4W32889 Applicant: Mark IV Industries Ltd. 6020 Ambler Drive Mississauga, Ontario L4W 2P1 Equipment Under Test: Mark IV, G3B-FPT Transponder (EUT) 915.00MHz FCC ID. JQU801350 In Accordance With: FCC Part 90, Subpart M 915 MHz, LMS Systems Tested By: Nemko Canada Inc. 303 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Sim Jagpal, General Manager Date: 25 November 2004 Total Number of Pages: 14 Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 2 of 14 Table of Contents Section 1. Summary of Test Results ...................................................................................3 Section 2. General Equipment Specification......................................................................5 Section 3. RF Power Output ................................................................................................7 Section 4. Occupied Bandwidth .........................................................................................8 Section 5. Field Strength of Spurious Emissions .............................................................10 Section 6. Test Equipment List .........................................................................................13 Section 7. Test Diagrams ....................................................................................................14 Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 3 of 14 Section 1. Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 90. New Submission Production Unit Engineering Evaluation Pre-Production Unit T N B Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: _____________________________________ DATE: 25 November 2004 Glen Westwell, Wireless Specialist Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 4 of 14 Summary Of Test Data Name Of Test Para. No. Result RF Power Output 2.1046 Complies Occupied Bandwidth 2.1049 Complies Spurious Emissions at Antenna Terminals 2.1051 N/A(1) Field Strength of Spurious Emissions 2.1053 Complies Frequency Stability 2.1055 N/A(2) Notes: This Radio Module device is used in the 902-928MHz band for non-multilateration mobile transponder, LMS operations. 1. This device has an integral antenna. 2. This device is exempt from the frequency stability requirement for mobile transponders. Indoor Temperature: 22°C Humidity: 42% Outdoor Temperature: 1°C Humidity: 48% . Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 5 of 14 Section 2. General Equipment Specification Manufacturer: Mark IV Industries Ltd. Model No.: 801350-TAB Serial No.: A3 M15 Date Received In Laboratory: 4 Nov. 2004 Nemko Identification No.: #1 Transmit Frequency: 915.00MHz (fixed) Modulation: On-Off Keying (OOK) Primary Power: 3.6Vdc RF Power (Measured): 0.0001W Emission Designator: 15M0P1D Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 6 of 14 99% OBW A Att 5 dBRef -10 dBm Offset 23 dB Center 914.96 MHzSpan 50 MHz5 MHz/ LVL * RBW 200 kHz * VBW 200 kHz SWT 5 ms 1 PK VIEW -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 -10 1 Marker 1 [T1 ] -14.66 dBm 914.879871795 MHz OBW 15.064102564 MHz T1 Temp 1 [T1 OBW] -40.59 dBm 908.309358974 MHz T2 Temp 2 [T1 OBW] -43.08 dBm 923.373461538 MHz OCC BW Date: 17.NOV.2004 14:17:45 Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 7 of 14 Section 3. RF Power Output Para. No.: 2.1046 Test Performed By: Glen Westwell Date of Test: 4 Nov. 2004 Minimum Standard: 90.205 Test Results: See below The RF power output is calculated based on the measured electric field strength measured at 3m. See section 5 for the signal substitution value. Measurement Data: Maximum radiated output power at 915MHz at 3m: 60.7dBuV + 28.5dB(Ant. Fact.) =89.2dBuV/m E.R.P. (W) = V 2 R 2 /30x1.64 E.R.P. = -8.2dBm (0.00015W) Signal Substitution = -10dBm (0.0001W) Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 8 of 14 Section 4. Occupied Bandwidth Para. No.: 2.1049 Test Performed By: Glen Westwell Date of Test: 5 Nov. 2004 Minimum Standard: 90.210 Test Results: Complies. Measurement Data: See attached data. Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 9 of 14 A Att 5 dBRef -10 dBm Offset 35 dB LVL Center 914.96 MHzSpan 50 MHz5 MHz/ * RBW 100 kHz SWT 20 ms * VBW 100 kHz VIEW 1 PK -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 -10 Mark4 OCC BW Date: 17.NOV.2004 13:41:32 Nemko Canada Inc. FCC PART 90 Sub Part M, LMS Systems PROJECT NO.:4W32889 Mark IV, G3B-FPT Transponder Page 10 of 14 Section 5. Field Strength of Spurious Emissions Para. No.: 2.1053 Test Performed By: Glen Westwell Date of Test: 5 Nov. 2004 Minimum Standard: 90.210, -25dBm Test Results: Complies. Measurement Data: See attached data. This EUT was searched on 3 orthogonal axis for maximum emissions from 30MHz to 10G…

Text truncated - open the document above for the full version.

Radiated Test Set up
