(SKY-4001) INSTALLATION AND OPERATING INSTRUCTIONS INTRODUCTION SKYTECH’S remote control system was developed to provide a safe, reliable and user-friendly remote control system for gas heating appliances. Its battery operation allows the system to operate independently of household current. The system operates on radio frequencies with non-directional signals. The SYSTEM’s operating range is approximately 20 feet. The system operates on one of 255 security codes programmed at the factory. COMPONENTS WARNING THE SKYTECH SKY-4001 MUST BE INSTALLED EXACTLY AS OUTLINED IN THESE INSTRUCTIONS. FOLLOW INSTRUCTIONS CAREFULLY DURING INSTALLATION. ANY MODIFICATION OF THE SKYTECH SKY-4001 OR ANY OF ITS COMPONENTS WILL VOID THE WARRANTY AND MAY POSE A FIRE HAZARD. TRANSMITTER The transmitter operates on a 3v battery (included) made specifically for remote controls and electronic lighters. Before using the transmitter, remove the insulation tab protecting one end of the battery in the battery compartment. The transmitter has ON and OFF functions that are activated by pressing either button on the face of the transmitter. When a button on the transmitter is pressed, a signal light on the transmitter illuminates briefly to verify that a signal has been sent. Upon initial use, there may be a delay of five seconds before the remote receiver will respond to the transmitter. This is part of the system’s design. If the signal light does not illuminate, check the position of the transmitter’s battery. ON OFF Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Important Note: FCC Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. To maintain compliance with FCC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
~9045592 (2176x3301x16M jpeg)
Page 1 CONSTRUCTION PHOTOS OF EUT Model no.: SKY-4001 Page 2 Page 3 Page 4 Model no.: SKY-4002 Page 5 Page 6
FCC ID Label Location (FCC ID: K9L-4001TX)
Page 7 Model no.: SKY-4001 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Model no.: SKY-4002 Page 14 Page 15 Page 16 Page 17 Page 18
FCC ID: K9L-4001TX Report No.RF940203L03 Operational Description The transmitter of the EUT (Remote control transmitter) is powered by a 3Vdc battery. The transmitter uses printed antenna and designed to operate on a fixed frequency at 433.92MHz. The other instruction, please have a look at the users manual. This 433.92MHz transmitter device is operated by manual and activate time is less than 5 second after being released.
FCC ID: K9L-4001TX Report No.: RF940203L031Report Format Version 2.0.2 FCC TEST REPORT REPORT NO.: RF940203L03 MODEL NO.: SKY-4001 (refer to page 5 for other models) RECEIVED: Feb. 03, 2005 TESTED: Feb. 14 ~ Feb. 18, 2005 ISSUED Feb. 21, 2005 APPLICANT: Skytech II, Inc. ADDRESS: 9230 Conservation Way Fort Wayne, Indiana 46809 ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 27 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: K9L-4001TX Report No.: RF940203L032Report Format Version 2.0.2 Table of Contents 1.CERTIFICATION ......................................................................................................3 2.SUMMARY OF TEST RESULTS ..............................................................................4 2.1MEASUREMENT UNCERTAINTY ...........................................................................4 3.GENERAL INFORMATION.......................................................................................5 3.1GENERAL DESCRIPTION OF EUT.........................................................................5 3.2DESCRIPTION OF TEST MODES...........................................................................6 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ...................................................... 6 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL: .......................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ..........................................8 3.4DESCRIPTION OF SUPPORT UNITS .....................................................................8 4.TEST TYPES AND RESULTS ..................................................................................9 4.1CONDUCTED EMISSION MEASUREMENT ...........................................................9 4.2DEACTIVATION TIME ..............................................................................................9 4.2.1 LIMITS OF DEACTIVATION TIME MEASUREMENT............................................... 9 4.2.2 TEST INSTRUMENTS.............................................................................................. 9 4.2.3 TEST PROCEDURES .............................................................................................. 9 4.2.4 DEVIATION FROM TEST STANDARD .................................................................... 9 4.2.5 TEST SETUP ......................................................................................................... 10 4.2.6 TEST RESULTS ..................................................................................................... 10 4.3RADIATED EMISSION MEASUREMENT ..............................................................13 4.3.1 LIMITS OF RADIATED EMISSION MEASUREMENT............................................ 13 4.3.2 TEST INSTRUMENTS............................................................................................ 15 4.3.3 TEST PROCEDURES ............................................................................................ 16 4.3.4 DEVIATION FROM TEST STANDARD .................................................................. 16 4.3.5 TEST SETUP ......................................................................................................... 17 4.3.6 EUT OPERATING CONDITIONS ........................................................................... 17 4.3.7 TEST RESULTS ..................................................................................................... 18 4.420dB OCCUPIED BANDWIDTH MEASUREMENT................................................23 4.4.1 LIMITS OF BAND EDGES MEASUREMENT ........................................................ 23 4.4.2 TEST INSTRUMENTS............................................................................................ 23 4.4.3 TEST PROCEDURES ............................................................................................ 23 4.4.4 DEVIATION FROM TEST STANDARD .................................................................. 23 4.4.5 TEST SETUP ......................................................................................................... 24 4.4.6 TEST RESULTS ..................................................................................................... 24 5.PHOTOGRAPHS OF THE TEST CONFIGURATION.............................................26 6.INFORMATION ON THE TESTING LABORATORIES ...........................................27 FCC ID: K9L-4001TX Report No.: RF940203L033Report Format Version 2.0.2 1. CERTIFICATION PRODUCT: Remote control transmitter MODEL NO.: SKY-4001 (refer to page 5 for other models) BRAND: ARC APPLICANT: Skytech II, Inc. TESTED: Feb. 14 ~ Feb. 18, 2005 TEST SAMPLE: R&D SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.231), ANSI C63.4-2003 The above equipment (model: SKY-4001) have been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Feb. 21, 2005 ( Candice Chen ) TECHNICAL ACCEPTANCE:, DATE:Feb. 21, 2005 Responsible for RF ( Gary Chang ) APPROVED BY : , DATE: Feb. 21, 2005 ( Cody Chang, Deputy Manager ) FCC ID: K9L-4001TX Report No.: RF940203L034Report Format Version 2.0.2 2. SUMMARY OF TEST RESULTS The EUT has been tested acc…
Text truncated - open the document above for the full version.
FCC ID: K9L-4001TX Report No.: RF940203L0326Report Format Version 2.0.2 5. PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
No. 19, Hwa Ya 2nd Rd., Kwei Shan Hsiang · Taoyuan Hsien · Taiwan
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231 | 433.92 MHz - 433.92 MHz | - |

Remote control transmitter
Equipment Class
DSC - Part 15 Security/Remote Control TransmitterRemote Control Transmitter
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Wireless Remote Controller (TX)
Equipment Class
DSC - Part 15 Security/Remote Control TransmitterRemote Control
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Transmiter
Equipment Class
DTS - Digital Transmission System
