K9L1003TXRemote Control Transmitter

SKYTECH 1001SR/P TH REV. 09/02 Page 1 of 6 1001SR/P TH INSTALLATION AND OPERATING INSTRUCTIONS MULIT-FUNCTION WIRELESS REMOTE CONTROL SYSTEM FOR OPERATING SERVO MOTORS VALVES OR PULSE SOLENOIDS VALVES INTRODUCTION This remote control system was developed to provide a safe, reliable, and user-friendly remote control system for gas heating appliances. The system is operated manually from the transmitter. The system operates on radio frequencies (RF) within a 20' range using non-directional signals. The system operates on one of 255 security codes that are programmed into the transmitter at the factory; the remote receiver's code must be matched to that of the transmitter prior to initial use. Review THERMO SAFETY SECTION under RECEIVER section. This high temperature safety feature shuts down the appliance when a potentially unsafe condition exists. TRANSMITTER This remote control SYSTEM offers the user a battery-operated remote control to power up to a 6 VDC servo motor or solenoid such as those used with gas valves used in some heater rated gas logs, gas fireplaces and other gas heating appliances. The servo motor or solenoid circuit uses the battery power from the receiver to operate a servo motor or solenoid. The circuit has reversing polarity software which reverses the positive (+) and negative (-) output of the receiver's battery power to drive the servo motor or solenoid forward/backward (HI/LO FLAME) or open/close (FLAME SOLENOID - ON/OFF). The SYSTEM is controlled by the remote transmitter. The transmitter operates on a (2) 1.5V AAA batteries made specifically for remote controls and electronic lighters. Before using the transmitter, remove the insulation tab protecting one end of the battery in the battery compartment. It is recommended that ALKALINE batteries always be used for longer battery life and maximum operational performance. KEY SETINGS • ON/HI -Operates unit to on position. • LO/OFF - Operates unit to off position • MODE - Changes unit from manual feature to thermo feature. • SET - Sets temperature in thermo in feature. 1. DISPLAY Indicates CURRENT room temperature . 2. 0 F OR 0 C Indicates degrees Fahrenheit or Celsius. 3. FLAME Indicates burner/valve in operation. 4. ROOM Indicates remote is in THERMO operation. 5. TEMP Appears during manual operation. 6. SET Appears during time the of setting the desired temperature in the thermo operation. ON/HI MODE LO/OFF BUTTON WALL CLIP SLOT 12V BATTERY COMPARTMENT FRONTBACK LO/OFF SET ON/HI BUTTON MODE BUTTON SET BUTTON ROOM LCD - Liquid Crystal Display TEMP 1 2 3 SET4 5 6 ON/HI MODE LO/OFF SET 1 2 3 4 SKYTECH 1001SR/P TH REV. 09/02 Page 2 of 6 SETTING 0 F / 0 C SCALE The factory setting for temperature is 0 F. To change this setting to 0 C, first • Press the ON/HI key and the LO/OFF key on the transmitter at the same time this will change from 0 F to 0 C. Follow this same procedure to change from 0 C back to 0 F. MANUAL FUNCTION To operate the system in the manual mode do the following. ON OPERATION Press and hold the ON/HI key until the appliance flame comes on and reaches the desired flame height or is at full on. During this time the LCD screen will show HI, after 3 seconds the LCD screen will default to display room temperature and the word TEMP will show. OFF OPERATION Press and hold the LO/OFF key until the appliance flame reaches the desire flame height or completely shuts off. During this time the LCD screen will show LO, after 3 seconds the LCD screen will default to display room temperature and the word TEMP will show. THERMOSTAT FUNCTION SETTING DESIRED ROOM TEMPERATURE This remote control system can be thermostatically controlled when the transmitter is in the THERMO mode (SET must be displayed on the screen). To set the DESIRED room temperature, Press the MODE key the display will show the words SET TEMP and the temperature display will began to flash. Press and hold the SET key until the desired set temperature is reached then release the SET key. Press the MODE key to disengage the thermo mode. The word ROOM on the LCD screen will not show when the thermo is not in operation. NOTE: The highest SET temperature is 99 0 Fahrenheit (32 0 Celsius) and the lowest temperature (45 0 F, or 6 0 C ). TEMP TEMPSET THERMO SET SCREEN DURING ADJUSTING TO ON SCREEN DURING ADJUSTING TO OFF TEMP SCREEN AFTER 3 SECOUND DEFAULT ROOMTEMP THERMO OFF ROOMTEMP THERMO ON TEMP SCREEN AFTER 3 SECOUND DEFAULT SKYTECH 1001SR/P TH REV. 09/02 Page 3 of 6 OPERATIONAL NOTE: TO CONSERVE BATTERY POWER, CHANGES IN ROOM TEMPERATURE ARE ONLY UPDATED EVERY TWO MINUTES. The Thermo Feature on the transmitter operates the appliance whenever the ROOM TEMPERATURE varies a certain number of degrees from the SET TEMPERATURE. This variation is called the “SWING” or TEMPERATURE DIFFERENTIAL. The normal operating cycle of an appliance may be 2-4 times per hour depending on how well the room or home is insulated from the cold or drafts. The factory setting for the “swing number” is 2. This represents a temperature variation of +/- 2 0 F (1 0 C between SET temperature and ROOM temperature, which determines when the fireplace will be activated. The transmitter has ON/HI and LO/OFF functions that are activated by pressing either button on the face of the transmitter. When a button on the transmitter is pressed, a signal light on the transmitter illuminates to verify that a signal is being sent. Upon initial use, there may be a delay of three seconds before the remote receiver will respond to the transmitter. This is part of the system's design. If the signal light does not illuminate, check the position of the transmitter's battery. POWER SETTING - 1001SR or 1001P The electronics in the remote control system have the capability of "powering" two different types of DC-powered components. The RECEIVER comes from the factory programmed to provide continuous DC voltage (4.5 VDC to 6.0 VDC) to a servo motor and is referred to as the SKYTECH 1001SR/P setting. The RECEI…

Text truncated - open the document above for the full version.

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size B Date: 17-Sep-2002 Sheet of File: C:\WINDOWS\..\proced ure.sch Drawn By: MCU. Key input Temperature Lcd Driver Set timer RF output & clock Lcd display Procedure

MAX LIGHT Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab MAX LIGHT Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab

MAX LIGHT Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab MAX LIGHT Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab

Skytech 1101 Remote 1. Rf signal is generated by micro controller unit: EM78P257A. It sent a series of pulse to RF circuit. 2. RF circuit is used RLC oscillator with capacitor variable. 3. When MCU. sent signal to RF circuit,the RLC will occur ASK format signal to antenna. 4. There are 4 keys in Skytech and the main functions of key are : Mode,Set,Up,Down, 5. There are over 7 kinds codes in different keys.

123456 A B C D 654321 D C B A Title NumberRevisionSize B Date:19-Sep-2002Sheet of File:C:\WINDOWS\Desktop\skytech1001.schDrawn By: 1 PAD1 B+ 1 PAD2 B- E1 47uF/10V VCC R1 200K R2 503 C1 103J Sky 1001 SR/P TH IN I GND G OUT O U1 HT7024A VCCVIN R3 47K R4 470R C2 3P C4 2P C5 11P C6 103 L1 1UH ANT1 VC1 3P N2 N3 N4 N5 C3 2P Q1 C3838 RF N1 REFSNR R5 1M CRG CC2 1 VO15N 2 VEE 3 COM0 4 COM1 5 COM2 6 COM3 7 SEG0 8 SEG1 9 SEG2 10 SEG3 11 SEG4 12 SEG5 13 SEG6 14 SEG7 15 SEG8 16 SEG9 17 SEG10 18 SEG11 19 SEG12 20 SEG13 21 SEG14 22 SEG15 23 SEG16 24 SEG17 25 SEG18 26 SEG19 27 SEG20 28 SEG21 29 SEG22 30 SEG23 31 SEG24 32 SEG25 33 SEG26 34 SEG27 35 SEG28 36 SEG29 37 SEG30 38 SEG31 39 CS 40 RD 41 WR 42 DATA 43 VSS 44 OSC0 45 OSC1 46 VDD 47 IRQ 48 BZ 49 BZ 50 CC1 51 U2 HT1620 U3 32.768KHz C7 0.1uF C8 0.1uF R10 3M VCC C9 0.1uF VCC COM0COM1COM2COM3 R6 1M VCC DATA L2 1mH Q2 2N3904 D1 1N4148 C10 47uF/10v IRQ CS WR R12 5.1K VCC 1 PAD3 VCC PWM Con2/P52 1 Cin2+/P53 2 Tcc/Cin2-/P54 3 /Reset/P71 4 VSS 5 /Int/P60 6 Tcc1/Cin3-/P61 7 Cin3+/P62 8 Co3/P63 9 P64/Co4 10 P65/Cin4+ 11 P66/Cin4-/Tcc2 12 P67/Ir Out 13 VDD 14 P70/Osco 15 P55/Cin1-/Osci 16 P50/Cin1+/Tcc4 17 P51/Co1/Tcc3 18 U4 EM78P257A VCC SW1 Down SW2 Up SW3 Set SW4 Mode R13 10K VCC IRQ PWM CS0 WR DATA SNR REF CRG CS 1 CLK 2 DI 3 DO 4 VSS 5 VCC 8 U5 93C46 VCC R7 1M Vref R11 3M R8 1M RF DIO CLK CS1 R14 330K VCC R15 510K VIN C1 1 C2 2 C3 3 C4 4 S1 5 S2 6 S3 7 S4 8 S5 9 S6 10 LCD1 WK-TZ9983-FG COM0 COM1 COM2 COM3 SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 Light LED1 LED LED2 LED Light R16 2.7K R9 1M FCC ID:K9L1003TX

Product : Remote Control Transmitter Applicant : Skytech II, Inc. FCC ID : K9L1003TX Model : SKY-1001SR / P TH Report No. : MLT0209P15003 Test Date : September 19, 2002 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-363-2447 Fax: 886-2-363-2597 T T h h e e t t e e s s t t r r e e p p o o r r t t c c o o n n s s i i s s t t s s o o f f 2 2 8 8 p p a a g g e e s s i i n n t t o o t t a a l l . . I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . MAX LIGHT MAX LIGHT MEASUREMENT REPORT Page: 2/28 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab Table of Contents : MAX LIGHT MAX LIGHT MEASUREMENT REPORT Page: 3/28 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab CERTIFICATIONCERTIFICATION We here by verify that :We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-1992. All test were conducted by MLT (Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with radiated emission limit of FCC Rules Part 15 Subpart C Section 15.231. EUT : Remote Control Transmitter Applicant : Skytech II, Inc. 9230 Conservation Way, Ft. Wayne, IN46809, U.S.A Manufacturer : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN- SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Model No : SKY-1001SR / P TH FCC ID : K9L1003TX Prepared by : Approved by : Country Huang Roger Chen MAX LIGHT MAX LIGHT MEASUREMENT REPORT Page: 4/28 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab 1.1 Introduction The following measurement report is submitted on behalf of Skytech II, Inc. In support of an Intentional Periodic Radiator certification in accordance with Part 2 Subpart J and Part 15 Subpart A And C of the Commission’s and Regulations. 1.2 Description of EUT EUT : Remote Control Transmitter Applicant : Skytech II, Inc. 9230 Conservation Way, Ft. Wayne, IN46809, U.S.A Manufacturer : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN- SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Model No : SKY-1001SR / P TH FCC ID : K9L1003TX Power Type : Powered by DC 1.5V AAA Battery X 2 The EUT(SKY-1001SR) is Remote Control of Mulit-Function Controller. The operation frequency is 318.79 Mhz. Press the button on remote transmitter, can set the ON/OFF & HI/MED/LO button. MAX LIGHT MAX LIGHT MEASUREMENT REPORT Page: 5/28 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab 1.3 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. 1.4 Configuration of System Under Test 1.5 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4-1992 "Measurement of Intentional Radiators." EUTEUT MAX LIGHT MAX LIGHT MEASUREMENT REPORT Page: 6/28 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab 1.6 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. MAX LIGHT MAX LIGHT MEASUREMENT REPORT Page: 7/28 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab The EUT operates solely by the battery. According to the rule of Section 15.207(c), the EUT exempt to the power line conducted test. MAX LIGHT MAX LIGHT MEASUREMENT REPORT Page: 8/28 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab 3.1 General Configuration: Prior to open-field testing, the EUT was placed in a shielded enclosure and scanned at a close distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration which produced the highest emissions was noted so it could be reproduced later during the open-field tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. 3.2 General Configuration: Final radiation measurements were made on a three-meter, open-field test site. The EUT system was placed on a nonconductive turntable which is 0.8 meters height, top surface 1.0 x 1.5 meter. The spectrum was examined from 250 MHz to 4 GHz in order to cover the whole spectrum below10th harmonic which could generate from the EUT. During the test,EUT was set to transmit continuously and the switch was positioned to yield the maximum duty cycle which had measured before radiated emissions test. A nonconductive material surrounded the EUT to supporting the EUT for standing on tree orthogonal planes. At each condition, the EUT was rotated 360 degrees, and the antenna was raised and lowered from one to four meters to find the maximum emission levels. Measurements were taken using both horizontal and vertical antenna polarization. The fie…

Text truncated - open the document above for the full version.

MAX LIGHT MEASUREMENT REPORT Page: 11/24 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab 3.4 Test Configuration: Front View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 12/24 Report Number: MLT0209P15003 FCC ID: K9L1003TX Technology Lab Rear View of The Test Configuration
