K9L1030THRXRCAF-1030 Receiver

RCAF-1030 主機操作說明 遙控功能: 1． 裝入4個AA電池。 2． 確實將滑動開關切至Remote 3． 按下Learn鍵﹐ 一長Beep﹐此時主機進入學習模式。 4． 發射器按On﹐ 主機連續Beeb 5次標示學習成功。 手動開關: 1. 裝入電池後將滑動開關切至ON或OFF。 Remote Function: 1. Install 4*AA batteries. 2. make sure sliding switch is positioned at Remote 3. Press Learn button, unit enters learning mode after one long beep 4. Press On key on the remote, Rx will alarm 5 beeps indicating learning complete. Manual On/Off 1. Move the sliding switch to On/Off for activation or turn the unit off.

Date: 10 September 2007 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: K9L1030THRX To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: Block Diagrams Schematics Operational Descriptions Other (If any, mentioned below) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Bruce / President _____________________________ (Signature) (Notice: Must be signed by applicant contact cited as technical or non-technical contact on the 731 form provided to ATCB, or by the authorized agent if an appropriate authorized agent letter has bee provided. Letters Signed by applicant should be placed on applicant letterhead.)

AmericanTCB, Inc. 6731 Whittier Avenue, Suite C110 • McLean, Virginia 22101 Ph: (703) 847-4700 • Fax: (703) 847-6888 • www.AmericanTCB.com Date 2007.09.04 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Max Light Technology Co., Ltd Laboratory is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Applicant: Skytech II, Inc. Signature _____________________ Bruce Chang/ President • [email protected] 061306 - 1

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 1, 2007 RE: ATCB005423 FCC ID: K9L1030THRX 1. The operational description does not explain anything about the circuitry involved (i.e., please provide operational description, circuitry description of this device). 2. The manual is for a transmitter and has nothing about the receiver in it. Please provide a revised manual. 3. The manual is listed as confidential in the file name but FCC part 15 manuals CANNOT be confidential. Please revise the confidential request letter. 4. Please provide a more detailed block diagram. FCC policy requires that a block diagram show the frequencies of all crystals, VCOs, clocks and other frequency generating circuitry. 5. The schematic seems incomplete, such as we could not find where is the jumper T9 at U1B connect to? Please provide complete schematics. ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ ~ George Chen ~ mailto:[email protected] ~ Taiwan Mobile: +886 930600123 ~ SKYPE: georgeshirley ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page:3/7 Report Number: MLT0707CS03001 PHOTOGRAPHS OF EUT Page:4/7 Report Number: MLT0707CS03001

Report Number: MLT0707CS03001 Label Format: Label Position: Equipment Label 5.9cmX2.0cm This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received , including Interference that may cause undesired operation. Model No. : RCAF-1030 RX / RCAF-1030TH RX IC : 2439A-1030THRX Rear View

Page:5/7 Report Number: MLT0707P15002 Page:6/7 Report Number: MLT0707P15002 Page:7/7 Report Number: MLT0707P15002

Page: 1/11 Report Number: MLT0707CS03001 (ICES-003: 2004 / ANSI C63.4-2003) Product :Receiver Trade Name :SKYTECH II Model No. :RCAF-1030 RX / RCAF-1030TH RX Applicant :Skytech II, Inc. Applicant Address :9230 Conservation Way,Ft. Wayne, IN 46809, U.S.A. Page: 2/11 Report Number: MLT0707CS03001 Report Number MLT0707CS03001 Applicant Skytech II, Inc. Product Receiver Sample Received Date 2007/07/20 Report Prepared By Jesse Tien Signature Date Prepared 2007/07/23 ～ 2007/08/28 Report Authorized By Roger Chen Signature Date Authorized 2007/09/07 Test By Max Light Technology Co., Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Office : Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 Lab. : Tel: 886-2-2663-3486 Fax: 886-2-2663-3582 I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . Page: 3/11 Report Number: MLT0707CS03001 Table of Contents : I. General 5. II. Conducted Emissions Requirements 7. III. Radiated Emissions Requirements 8. Appendix I (EUT Test Setup) 11. Page: 4/11 Report Number: MLT0707CS03001 CERTIFICATION We here by verify that : The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003. All test were conducted by MLT (Max Light Technology Co., Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with radiated and conducted emission limit of ICES-003: 2004. Applicant Name Skytech II, Inc. Applicant Address 9230 Conservation Way,Ft. Wayne,IN 46809,U.S.A. Manufacturer Name FEGO Precision Industrial Co.,Ltd Manufacturer Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. Equipment Receiver Model No RCAF-1030 RX / RCAF-1030TH RX IC 2439A-1030THRX Report Prepared By Jesse Tien Signature Report Authorized By Roger Chen Signature Page: 5/11 Report Number: MLT0707CS03001 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Skytech II, Inc. In support of a Class B Digital Device certification in accordance with ICES-003: 2004 of the Commission’s and Regulations. 1.2 Customer Details Applicant Name Skytech II, Inc. Applicant Address 9230 Conservation Way,Ft. Wayne,IN 46809,U.S.A. Manufacturer Name FEGO Precision Industrial Co., Ltd. Manufacturer Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. 1.3 Technical data of EUT Equipment Receiver Model No RCAF-1030 RX / RCAF-1030TH RX IC 2439A-1030THRX Power Type Powered by 6V Battery (AA Size 1.5V X 4). 1.4 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. Page: 6/11 Report Number: MLT0707CS03001 1.5 Configuration of System Under Test 1.6 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4: 2003 "Measurement of Intentional Radiators." 1.7 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests were chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. EUT Page: 7/11 Report Number: MLT0707CS03001 II. Conducted Emissions Requirements The EUT operates solely by the battery. According to the rule, the EUT exempt to the power line conducted test. Page: 8/11 Report Number: MLT0707CS03001 III. Radiated Emissions Requirements 3.1 General & Setup: Prior to open-field testing, the EUT was placed in a shielded enclosure and scanned at a close distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration which produced the highest emissions was noted so it could be reproduced later during the open-field tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. Final radiation measurements were made on a 3-meter, open-field test site. The EUT system was placed on a nonconductive turntable which is 0.8 meters height, top surface 1.0 x 1.5 meter. The spectrum was examined from 30 MHz to 1000 MHz using an Hewlett Packard 8591EM Spectrum Analyzer, EMCO Biconilog Antenna (Model 3142C ) for 30-1000MHz. At each frequency, the EUT was rotated 360 degrees, and the antenna was raised and lowered from one to four meters to find the maximum emission levels. Measurements were taken using both horizontal and vertical antenna polarization. Appropriate preamplifiers were used for improving sensitivity and precautions were taken to avoid overloading or desensitizing the spectrum analyzer. No post-detector video filters were used in the test. The spectrum analyzer's 6 dB bandwidth was set to 120 KHz, and the analyzer was operated in the quasi-peak detection mode. The highest emission amplitudes relative to the appropriate limit were measured and recorded in paragraph 3.3. 3.2 Test Equipment List: Item Mfr/Brand Instruments Serial No. Model/Type N…

Text truncated - open the document above for the full version.

Page:1/7 Report Number: MLT0707CS03001 Radiated Measurement Photos Front View of The Test Configuration Page:2/7 Report Number: MLT0707CS03001 Rear View of The Test Configuration
