K9L3003TRTXRemote Control System

3003TR User’s Manual This remote control SYSTEM offers the user a battery-operated remote control that operates most millivolt gas valves used in some heater rated gas logs, gas fireplaces and other gas heating appliances. The transmitter operates on (2) 1.5V AAA batteries. It is recommended that ALKALINE batteries always be used for longer battery life and maximum operational performance. Before using the transmitter， install the (2) AAA transmitter batteries into the battery compartment. (Use caution that batteries are installed in the proper direction) KEY SETINGS MODE – Changes unit to ON / Thermo / OFF mode position. UP / DOWN – Changes temperature, time(r) and other functions’ value. TIMER / FAN / FLAME / LIGHT - Changes each function to enable or disable. OK - Sets temperature, time(r) and other functions. LCD 1. ON / THERMO / OFF Indicates current mode. 2. ROOM °F OR °C Indicates current room temperature. 3. LIGHT Indicates light/valve in operation. 4. AUX Indicates auxiliary function enable/disable.. 5. FLAME Indicates burner/valve in operation. 6. SET °F OR °C Appears the desired temperature to indicate setting room temperature during the time of setting in the thermo operation. 7. Battery icon Indicates the battery is low or not. 8. FAN Indicates fan/valve in operation. 9. TIMER / TIME Appears the time and the countdown timer. MANUAL FUNCTION Initial Setup Press the “ “ key and the “LIGHT” key on the transmitter at the same time. this will into the initial setup mode. Each function scale setting is changed by “UP” or “DOWN” key. 1. Setting °F / °C Scale The setting is for changing temperature °F / °C. 2. Setting Swing Scale The setting is for swing temperature. 3. Setting Gas Type The setting is for gas type NG / LP. 4. Setting Time The setting is for time. Mode To operate the system in the manual “MODE” does the following. ON OPERATION Press the “MODE” key into the ON mode. The appliance flame and fan will come on. During this time the screen will show ON. All the functions, FAN / FLAME / TIMER, will be active. THERMO OPERATION Press the “MODE” key into the THERMO mode. The transmitter will check the ROOM temperature and SET temperature to decide the situation THERMO ON or THERMO OFF. After 2 seconds the LCD screen will display the situation by temperature detected that is comparing with the SWING temperature scale. OFF OPERATION Press the “MODE” key into the OFF mode. The appliance flame and fan will shut off. During this time the screen will show OFF. All the functions, FAN / FLAME / TIMER, will be shut down exception of LIGHT function. THERMOSTAT FUNCTION SETTING DESIRED ROOM TEMPERATURE This remote control system can be thermostatically controlled when the transmitter is in the THERMO mode. To set the THERMO MODE and DESIRED room temperature， During the THERMO mode, Press “Up” / “DOWN” key the LCD screen set numbers will increase / decrease between 45° and 99°(*) then loop the temperature. THERMO ON situation During this mode the screen will display the set flame/valve and fan/value at the same time enable the functions setting. THERMO OFF situation During the situation the functions, FAN / FLAME / TIMER, will be shut down exception of LIGHT function NOTE: (*) The highest SET temperature is 99° Fahrenheit (32° Celsius) and the lowest temperature is (45° Fahrenheit (6° Celsius) ¾ FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

Page:5/6 Report Number: MLT0704P15001 Page:6/6 Report Number: MLT0704P15001

Date: 19 September 2007 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: K9L3003TRTX To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: Block Diagrams Schematics Operational Descriptions The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Christopher Flick / CEO _____________________________ (Signature) (Notice: Must be signed by applicant contact cited as technical or non-technical contact on the 731 form provided to ATCB, or by the authorized agent if an appropriate authorized agent letter has bee provided. Letters Signed by applicant should be placed on applicant letterhead.)

AGENCY AUTHORIZATION LETTER To whom it may concern: We, the undersigned Skytech II, Inc., hereby authorize Max Light Technology Co. Ltd. (MLT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15 approval and any communication needed with the national authority. Any and all acts carried out by MLT on our behalf shall have the same effects as acts of our own. For questions regarding the authorization, please contact us. Thank you! Sincerely yours, _____________________________________ (Signature) Original written signature of authorized signer: Christopher Flick / CEO Printed name of authorized signer / Title Date: September 19, 2007

Attn: Director of Certification Authority to Act as Agent I appoint Max Light Technology Co., Ltd to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by American TCB, still resides with SKYTECH II, INC. 9230 CONSERVATION WAY, Ft. WAYNE, IN 46809, U.S.A . Dated this 25 day of October 20 07 . Agency Agreement Expiration Date: (Typically 8-12 months) By: __________________________ Christopher Flick (Signature) (Print name) Title: CEO On behalf of: SKYTECH II, INC. (Company Name) Telephone: 260-459-1703

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 24, 2007 RE: ATCB005545 FCC ID: K9L3003TRTX & IC: 2439A-3003TRTX for Skytech II, Inc. I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1. Please provide a better operational description for this device. In particular, how does each mode for this transmitter operate? I need a better operational description to determine if this transmitter meets the limitations against sending data or temperature and does it meet the limitations for automatic transmissions in Section 15.231 of the FCC Rules and Annex 1 of RSS-210. I fail to understand how the Thermostat Mode will not transmit automatically to shut off the fireplace when the desired room temperature is reached. 2. Please provide more internal photos that show the construction of the device. No LCD screen is shown in the internal photos but one is clearly visible in the external photos. How is the device connected to the external switch controls? Three buttons are clearly visible on the external photos but only two possible switches are shown in the internal photos. 3. On the submitted FCC 731 Form Section IV Item 1 must have the “yes box” checked or we cannot issue a grant of Certification. On the submitted form, this box is empty. Please provide a corrected FCC 731 Form. 4. Please provide an IC label for each model number being approved for Industry Canada. You only provided one IC label and there are two different model numbers. There is also no Trade name on the IC label provided as required by Section 5.2 of RSS-Gen Issue 2 dated June 2007. IC requires the certification number, the model number and trade name or company number to be either on the IC label or the device itself. 5. Please provide a description of the differences between the two model numbers as required by Section 5.2 of RSP-100 Issue 9 dated June 2007 where different model numbers must be electrically identical or differ only by Class I permissive changes defined in Section 6.2 of this document. 6. Please upload a confidentiality letter for the IC portion of this filing. On September 10, 2007, IC started requiring all exhibits in any filing to be uploaded to their Website. As a result, the applicant or his authorized agent must request confidentiality of exhibits that are considered trade secret. Please see the ATCB IC application form on our Website. It has been updated to include a sample confidentiality letter for IC that you may use. 7. For your information – The IC test report references the wrong version or RSS-210. On page 4 of the test report you reference Issue 5 of RSS-210. Issue 7 of RSS-210 has been in effect since June of 2007. Please make a note of this and if testing was completed before June of 2007, the test report does not need to be modified. Otherwise, I’d refer to the Issue 7 version of RSS-210. Also the boilerplate language of your test report states that average measurements were made in two different ways. On page 8 it states that average values were obtained with a 10 Hz VBW. On page 9 it states that average values were obtained by applying a duty cycle correction factor. It appears you used the page 9 methods but your test  Page 2 October 24, 2007 description should match your measurements. Please be more careful about using boilerplate or canned test descriptions in your test reports. Richard Fabina Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page:3/6 Report Number: MLT0704P15001 PHOTOGRAPHS OF EUT Page:4/6 Report Number: MLT0704P15001

Page:5/8 Report Number: MLT0704P15001 Page:6/8 Report Number: MLT0704P15001 Page:7/8 Report Number: MLT0704P15001 Page:8/8 Report Number: MLT0704P15001

Report Number: MLT0704P15001 Label Format: Label Position: Equipment Label 5.9cmX2.0cm This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received , including Interference that may cause undesired operation. Model No. : 3003TR TX FCC ID: K9L3003TRTX Rear View

Page:3/8 Report Number: MLT0704P15001 PHOTOGRAPHS OF EUT Page:4/8 Report Number: MLT0704P15001

Page:5/6 Report Number: MLT0704CS03002 Page:6/6 Report Number: MLT0704CS03002

Page: 1/25 Report Number: MLT0704P15001 (FCC : Part 15 Subpart C / ANSI C63.4-2003) Product :Transmitter Trade Name :SKYTECH II Model No. :3003TR / 3003TR TX Applicant :Skytech II, Inc. Applicant Address :9230 Conservation Way,Ft. Wayne, IN 46809, U.S.A. Page: 2/25 Report Number: MLT0704P15001 Report Number MLT0704P15001 Applicant Skytech II, Inc. Product Transmitter Sample Received Date 2007/04/10 Report Prepared By Jesse Tien Signature Date Prepared 2007/04/11 ～ 2007/07/04 Report Authorized By Roger Chen Signature Date Authorized 2007/08/07 Test By Max Light Technology Co., Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Office : Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 Lab. : Tel: 886-2-2663-3486 Fax: 886-2-2663-3582 I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . Page: 3/25 Report Number: MLT0704P15001 Table of Contents : I. General 5. II. Conducted Emissions Requirements 7. III. Radiated Emissions Requirements 8. IV. Transmitter Bandwidth Measurements 17. V. Transmitter Duty Cycle Measurements 19. VI. Verification of De-activation after 5 seconds 23. Appendix I (EUT Test Setup) 25. Page: 4/25 Report Number: MLT0704P15001 CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-2003. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with radiated emission limit of FCC Rules Part 15 Subpart C Section 15.231. Applicant Name Skytech II, Inc. Applicant Address 9230 Conservation Way,Ft. Wayne,IN 46809,U.S.A. Manufacturer Name FEGO Precision Industrial Co.,Ltd Manufacturer Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. Equipment Transmitter Model No 3003TR / 3003TR TX FCC ID K9L3003TRTX Report Prepared By Jesse Tien Signature Report Authorized By Roger Chen Signature Page: 5/25 Report Number: MLT0704P15001 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of SKYTECH II, INC. In support of an Intentional Periodic Radiator certification in accordance with Part 2 Subpart J and Part 15 Subpart A And C of the Commission’s and Regulations. 1.2 Customer Details Applicant Name SKYTECH II, INC. Applicant Address 9230 Conservation Way,Ft. Wayne,IN 46809,U.S.A. Manufacturer Name FEGO Precision Industrial Co., Ltd. Manufacturer Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. 1.3 Technical data of EUT Equipment Transmitter Model No 3003TR / 3003TR TX FCC ID K9L3003TRTX Power Type Powered by 3V Battery (AAA Size 1.5V X2). The EUT (3003TR / 3003TR TX) is remote transmitter. The operation frequency is 303.8Mhz. Press the button on remote transmitter, can set the Program mode / UP / DOWN / Continuous Pilot button. 1.4 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. Page: 6/25 Report Number: MLT0704P15001 1.5 Configuration of System Under Test 1.6 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4: 2003 "Measurement of Intentional Radiators." 1.7 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. EUT Page: 7/25 Report Number: MLT0704P15001 II. Conducted Emissions Requirements The EUT operates solely by the battery. According to the rule of Section 15.207(c), the EUT exempt to the power line conducted test. Page: 8/25 Report Number: MLT0704P15001 III. Radiated Emissions Requirements 3.1 General Configuration: Prior to open-field testing, the EUT was placed in a shielded enclosure and scanned at a close distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration which produced the highest emissions was noted so it could be reproduced later during the open-field tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. 3.2 General Configuration: Final radiation measurements were made on a three-meter, open-field test site. The EUT system was placed on a nonconductive turntable which is 0.8 meters height, top surface 1.0 x 1.5 meter. The spectrum was examined from 250 MHz to 2.5 GHz in order to cover the whole spectrum below 10th harmonic which could generate from the EUT. During the test, EUT was set to transmit continuously & Measurements spectrum range from 30 MHz to5 GHz is investigated. For measurements below 1 GHz the resolution bandwidth is set to 100 kHz for peak detection measurements or 120 kHz for quasi-peak detection measurements. Peak detection is used unless otherwise noted as quasi-peak. For …

Text truncated - open the document above for the full version.

Page:1/6 Report Number: MLT0704CS03002 Radiated Measurement Photos Front View of The Test Configuration Page:2/6 Report Number: MLT0704CS03002 Rear View of The Test Configuration
