LPM-10000Smart Outlet

9800 59 th Avenue North, Minneapolis, MN 55442 SLEEP NUMBER, SELECT COMFORT and the Double Arrow design are registered trademarks of Select Comfort Corporation. 121310 ©2015 Select Comfort Corporation 5/15 If you need help finding your ideal comfort or troubleshooting, please visit us at sleepnumber.com/chat to chat with a live representative 7 a.m. – 11 p.m. (Central Standard Time) daily. To speak to a representative by phone, call 1.800.472.7185 (Central Standard Time): Monday-Friday 8 a.m. – 8 p.m. Saturday 8:30 a.m. – 5 p.m. Sunday Closed Help is just a click or phone call away BED ASSEMBLY GUIDE k2 FPO GUIDE IS NOT FINAL— WORK IN PROGRESS WARNING FPO copy will go here for compliance to add appropriate copy. Not sure where these should go or how large or how many, etc. Xeruptae volorepe volendebitat quo volupta tquuntem lique volutate ant apid excea vollesti im eos volest voluptatus que voluptatem. Udis dolest ipitatur, ius volupta turescimus andit es ma quatio blande a ad mint et quist remolo od que inimus dolut facil molorro rercilliquis aut et reictemqui tem velita verum eium lique lam, omniet mosto quia que eos eaquae velenita nobisti orestibus. WARNING Endita autemolor saped quunturi tenis sape omnihil incid magnime dolorpo ratem. Itaturit vellate volore, quiducia volloremodi corestorpos sam harum quodis num nus velest que nisto tectus, que occusa sus nostibus eos sitem sit, tem conserum as etur, sit laut eumenda volorror senisciis num liquati aestotatum autae nitatusci reriae cum asperem harum, ipsam imperatatia inum que eatibus sim que volorum fugit eosa quas eosapicte volent essinti umenda eatinvel il ilique eaquasped molorum eos de nobist verat. WARNING Hitatiunt, sequas quae non plitatemped mod eaquaep udicitati cum haritenis molestius untiiscil is aut omnihiciam eum dolores eos et aut et aut resto volenisciet omnim at inihita tendunt. WARNING Acculparum, siminvendis del mo et adipsam eat eumende mpelia consed que ni ab invenes aboris sequi dus, omniscia sum si dolo teni doluptaquia in consequam, optas quibus, omnimen daectia verchilitae audit eseque es comnihita nonecum eniscit accaectem net fuga. Et laboribus deles unt eliquis inctio. Voluptia quos denim hici cumquidis repudi conetur? Ur? WARNING Hitatiunt, sequas quae non plitatemped mod eaquaep udicitati cum haritenis molestius untiiscil is aut omnihiciam eum dolores eos et aut et aut resto volenisciet omnim at inihita tendunt. WARNING Hitatiunt, sequas quae non plitatemped mod eaquaep udicitati cum haritenis molestius untiiscil is aut omnihiciam eum dolores eos et aut et aut resto volenisciet omnim at inihita tendunt. nonecum eniscit accaectem net fuga. Et laboribus deles unt eliquis inctio. Voluptia quos denim hici cumquidis repudi You’ve purchased the first kids’ bed designed to be knowing — it adjusts for their comfort because they are growing. It measures their slumber, but wait, there’s much more! They get a Sleep Number and a SleepIQ ® score. From preschool to high school, SleepIQ ® will give you knowledge. It can even go with them as they head off to college. It’s the bestest beginning for your boy or girl. Tonight starts this bedtime, tomorrow the world. Welcome to 2 6 8 8 9 10 11 12 18 20 21 22 26 BED FE ATURES GETTING STARTED ACCOUNT ACTIVATION SYSTEM SETUP BEFORE YOU BEGIN WHAT’S INCLUDED ASSEMBLING SLEEP TIPS PRODUCT CARE MOVING YOUR BED QUESTIONS? WARRANTY KIDS BEDDING contents 30 Family Connected, sleep perfected SleepIQ ® technology lets you see how the whole family is sleeping. Lifts them up when they’re down Head tilt feature for reading in bed or relieving stuffy heads. Know the comfort they’re getting The bed adjusts and grows with them — their Sleep Number ® setting. Monsters be gone! Sleepyheads rest easy with a fearless monster detector. Night bright, night light You can turn lights off remotely– when they’re sleeping tight. No more kiddos jumping out of bed Alerts you when your child is out of bed or restless. Twinkle, tinkle Soft under-bed light for when they get up during the night. Stars for young dreamers Make bedtime fun again with rewards for good sleep. Your SleepIQ Kids ™ k2 Bed Features 67 Getting Started Setting up your new SLEEP NUMBER ® bed only takes about an hour and you’ll enjoy the benefits of better sleep for years to come. You won’t need any tools and, although it’s nice to have a helper, you can do it by yourself. Activate Your SleepIQ ® Account Welcome to SleepIQ Kids ™ ! If you haven’t already, please activate your SleepIQ ® account. It’s simple and easy to do! You can activate your account on your mobile phone, tablet or desktop computer. • If you received an email from SLEEP NUMBER with account setup instructions, follow these instructions to activate your account. • You can also activate your account by visiting sleepiq.sleepnumber.com/register. You’ll need to provide your email address and the order number found on your purchase receipt. Set Up Your SleepIQ ® System It will take about 10-20 minutes to set up your SleepIQ ® system. If you have any questions, please call us at 888-484-9263. What you’ll need • An iOS or Android device (mobile phone or tablet) with Bluetooth low energy • An active SleepIQ ® account • The SleepIQ ® app from the App Store or Google Play. • Your home Wi-Fi network name and password (case sensitive). • Locate the box with the Firmness Control ™ system with SleepIQ ® technology and identify each of the following components: SleepIQ ® Firmness Control ™ system, power cord. (A SleepIQ ® USB flash drive is included, but not needed for iOS or Android installation.) Connecting your Firmness Control ™ system to your home Wi-Fi network 1. Turn on your device’s Bluetooth. 2. Ensure that the SleepIQ ® Firmness Control ™ system is NOT plugged into a power source. 3. Open the SleepIQ ® app on your device and log in with the SleepIQ ® account information you previously set up at sleepiq.sleepnumber.com. 4. Continue with mattress setup before plugging in the S…

Text truncated - open the document above for the full version.

Antenna Description The differential output of the CC2451 is transformed to a single‐ended 50‐ohm signal through a passive component (capacitor/inductor) balun. The output of the balun is low‐pass filtered to reduce harmonic radiation and then connected to a board‐etched omnidirectional meandered inverted F‐Antenna (see picture below), As such, the antenna is permanently attached to the radio. The antenna structure is a replica of an FCC‐certified reference design provided by Texas Instruments. Operation “The Inverted F antenna is a variant of the monopole where the top section has been folded down so as to be parallel with the ground plane. This is done to reduce the height of the antenna, while maintaining a resonant trace length. This parallel section introduces capacitance to the input impedance of the antenna, which is compensated by implementing a short‐circuit stub. The stub’s end is connected to the ground plane through a via.” 1 The meandering of the antenna allows the antenna to resonate at the desired frequency despite being compressed into a smaller area. Gain Maximum antenna gain at 2440MHz: ‐0.4dBi Drawing 1 http://www.qsl.net/va3iul/Antenna/PIFA/PIFA_Planar_Inverted_F_Antenna.pdf

This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. This Report may only be duplicated in its entirety Select Comfort Corporation Smart Outlet P/N: 121268 FCC 2.1091:2015 Report # SECF0021 NVLAP Lab Code: 200881-0 CERTIFICATE OF EVALUATION 2014-12-10 Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Last Date of Test: May 07, 2015 Select Comfort Corporation Model: Smart Outlet P/N: 121268 Radio Equipment Testing Standards Specification Method FCC 2.1091:2015 KDB 447498 D01 General RF Exposure Guidance v05r02 Results Method Clause Test Description Applied Results Comments 7.2 Maximum Permissible Exposure Yes Pass Deviations From Test Standards None Approved By: Don Facteau, IT Manager Report No. SECF00212/9 REVISION HISTORY REV 2014.10.14 Revision Number Description Date Page Number 00 None Report No. SECF00213/9 ACCREDITATIONS AND AUTHORIZATIONS REV 2015.2.19 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC 17065 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIP / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFCA – Recognized by OFCA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ http://gsi.nist.gov/global/docs/cabs/designations.html Report No. SECF00214/9 FACILITIES REV 2015.2.19 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 Minnesota Labs MN01-08, MN10 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612)-638-5136 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 554-8214 Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 Texas Labs TX01-09 3801 E Plano Pkwy Plano, TX 75074 (469) 304-5255 Washington Labs NC01-05 19201 120 th Ave NE Bothell, WA 9801 (425)984-6600 NVLAP NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200630-0 NVLAP Lab Code:201049-0 NVLAP Lab Code: 200629-0 Industry Canada 2834B-1, 2834B-3 2834E-1 N/A 2834D-1, 2834D-2 2834G-1 2834F-1 BSMI SL2-IN-E-1154R SL2-IN-E-1152R N/A SL2-IN-E-1017 SL2-IN-E-1158R SL2-IN-E-1153R VCCI A-0029 A-0109 N/A A-0108 A-0201 A-0110 Recognized Phase I CAB for ACMA, BSMI, IDA, KCC/RRA, MIC, MOC, NCC, OFCA US0158 US0175 N/A US0017 US0191 US0157 Report No. SECF00215/9 PRODUCT DESCRIPTION 2014-12-10 Client and Equipment Under Test (EUT) Information Company Name: Select Comfort Corporation Address: 9800 59th Avenue North City, State, Zip: Minneapolis, MN 55442 Test Requested By: Nick Reynolds Model: Smart Outlet P/N: 121268 Evaluation Date: May 7, 2015 Information Provided by the Party Requesting the Test Functional Description of the EUT: Smart switchable outlet which will be controlled by the Select Comfort FCC approved smart pump, and this outlet will also be transmitting status back to the pump via Bluetooth LE. Testing Objective: To demonstrate compliance with FCC requirements for RF exposure for 2.1091 mobile devices. Report No. SECF00216/9 MAXIMUM PERMISSIBLE EXPOSURE (MPE) WTD.2014.12.17 OVERVIEW Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. ANSI C95.1-1992 specifies a minimum separation distance of 20 cm for performing reliable field measurements to determine adherence to MPE limits. If the minimum separation distance between a transmitter and nearby persons is more than 20 cm under normal operating conditions, compliance with MPE limits may be determined at such distance from the transmitter. When applicable, operation instructions and prominent warning labels may be used to alert the exposed persons to maintain a specified distance from the transmitter or to limit their exposure durations and usage conditions to ensure compliance. If the use of warning labels on a transmitter is not effective or desirable, the alternative of performing SAR evaluation with the device at its closest range to persons under normal operating conditions may be used. The field strength and power density limits adopted by the FCC are based on whole-body averaged exposure and the assumption of RF field levels relate most accurately to estimating whole-body averaged SAR. This mean…

Text truncated - open the document above for the full version.

This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. This Report may only be duplicated in its entirety Select Comfort Corporation Smart Outlet P/N: 121268 FCC 15.207:2015 FCC 15.247:2015 Report # SECF0021.1 NVLAP Lab Code: 200881-0 CERTIFICATE OF TEST 2014-12-10 Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Last Date of Test: May 01, 2015 Select Comfort Corporation Model: Smart Outlet P/N: 121268 Radio Equipment Testing Standards Specification Method FCC 15.207:2015 ANSI C63.10:2009 FCC 15.247:2015 ANSI C63.10:2009 Results Method Clause Test Description Applied Results Comments 6.2 Powerline Conducted Emissions Yes Pass 6.5, 6.6 Spurious Radiated Emissions Yes Pass 6.7 Band Edge Compliance Yes Pass 6.7 Spurious Conducted Emissions Yes Pass 6.9.1 Occupied Bandwidth Yes Pass 6.10.2 Output Power Yes Pass 6.11.2 Power Spectral Density Yes Pass 7.5 Duty Cycle Yes N/A Characterization of radio operation. Deviations From Test Standards None Approved By: Tim O'Shea, Operations Manager Report No. SECF0021.12/46 REVISION HISTORY REV 2014.10.14 Revision Number Description Date Page Number 00 None Report No. SECF0021.13/46 ACCREDITATIONS AND AUTHORIZATIONS REV 2015.2.19 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC 17065 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIP / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFCA – Recognized by OFCA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ http://gsi.nist.gov/global/docs/cabs/designations.html Report No. SECF0021.14/46 MEASUREMENT UNCERTAINTY TMU.2014.12.03 Measurement Uncertainty When a measurement is made, the result will be different from the true or theoretically correct value. The difference is the result of tolerances in the measurement system that cannot be completely eliminated. To the extent that technology allows us, it has been our aim to minimize this error. Measurement uncertainty is a statistical expression of measurement error qualified by a probability distribution. A measurement uncertainty estimation has been performed for each test per our internal quality document WP 342. The estimation is used to compare the measured result with its "true" or theoretically correct value. The expanded measurement uncertainty (K=2) for each test is on each data sheet. Our measurement data meets or exceeds the measurement uncertainty requirements of the applicable specification; therefore, the test data can be compared directly to the specification limit to determine compliance. The calculations for estimating measurement uncertainty are based upon ETSI TR 100 028 (or CISPR 16-4-2 as applicable), and are available upon request. The following table represents the Measurement Uncertainty (MU) budgets for each of the tests that may be contained in this report. Test + MU - MU Frequency Accuracy (Hz) 0.0007% -0.0007% Amplitude Accuracy (dB) 1.2 dB -1.2 dB Conducted Power (dB) 0.3 dB -0.3 dB Radiated Power via Substitution (dB) 0.7 dB -0.7 dB Temperature (degrees C) 0.7°C -0.7°C Humidity (% RH) 2.5% RH -2.5% RH Voltage (AC) 1.0% -1.0% Voltage (DC) 0.7% -0.7% Field Strength (dB) 4.7 dB -4.7 dB AC Powerline Conducted Emissions (dB) 2.9 dB -2.9 dB Report No. SECF0021.15/46 FACILITIES REV 2015.2.19 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 Minnesota Labs MN01-08, MN10 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612)-638-5136 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 554-8214 Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 Texas Labs TX01-09 3801 E Plano Pkwy Plano, TX 75074 (469) 304-5255 Washington Labs NC01-05 19201 120 th Ave NE Bothell, WA 9801 (425)984-6600 NVLAP NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200630-0 NVLAP Lab Code:201049-0 NVLAP Lab Code: 200629-0 Industry Canada 2834B-1, 2834B-3 2834E-1 N/A 2834D-1, 2834D-2 2834G-1 2834F-1 BSMI SL2-IN-E-1154R SL2-IN-E-1152R N/A SL2-IN-E-1017 SL2-IN-E-1158R SL2-IN-E-1153R VCCI A-0029 A-0109 N/A A-0108 A-0201 A-0110 Recognized Phase I CAB for ACMA, BSMI, IDA, KCC/RRA, MIC, MOC, NCC, OFCA US0158 US0175 N/A US0017 US0191 US0157 Report No. SECF0021.16/46 PRODUCT DESCRIPTION 2014-12-10 Client and Equipment Under Test (EUT) Informati…

Text truncated - open the document above for the full version.

POWERLINE CONDUCTED EMISSIONS WTD.2015.03.10 PSA-ESCI 2015.03.03, EmiR5 2015.03.19.1 photo SE 001.jpg SE 002.jpg SPURIOUS RADIATED EMISSIONS PSA-ESCI 2015.03.03 photo SE 003.jpg SE 004.jpg SPURIOUS RADIATED EMISSIONS PSA-ESCI 2015.03.03 XMit 2015.01.14 NEAR FIELD 001.jpg NEAR FIELD 002.jpg BAND EDGE COMPLIANCE XMit 2015.01.14 SE 001.jpg SE 002.jpg SPURIOUS CONDUCTED EMISSIONS XMit 2015.01.14 SE 003.jpg SE 004.jpg SPURIOUS CONDUCTED EMISSIONS XMit 2015.01.14 NEAR FIELD 001.jpg NEAR FIELD 002.jpg OCCUPIED BANDWIDTH photo SE 001.jpg SE 002.jpg OUTPUT POWER PSA-ESCI 2015.03.03 photo SE 003.jpg SE 004.jpg OUTPUT POWER PSA-ESCI 2015.03.03 XMit 2015.01.14 SE 001.jpg SE 002.jpg POWER SPECTRAL DENSITY XMit 2015.01.14 SE 003.jpg SE 004.jpg POWER SPECTRAL DENSITY
