LPM-1000GAdjustable Foundation Remote

7 Remote Control Function A Low Battery If low battery indicator is lit up, batteries need to be changed. B Remote Troubleshooting Pressing and holding both Head Massage Down button and Foot Massage Down button for 3 seconds will force the remote into a self-test mode. If LCD displays either “1” or “2” error code, the remote needs to be replaced. 1 – Radio error 2 – Battery circuit error C Position Timer Press to set the current position timer in 15-minute increments up to 180 minutes. Once it reaches 180 minutes, the next increment goes back to 0. Once timer has expired, the foundation will return to the flat position. If a position other than flat is desired, press and hold Custom Preset 1 as you set the position timer. Once the timer has expired, the foundation will return to the Custom Preset 1 position. D Massage Timer Press to set the current massage timer in 15-minute increments up to 180 minutes. Once it reaches 180 minutes, the next increment goes back to 0. Massage timer does not activate the massage feature. Once massage feature is activated and massage timer has expired, the massage feature will stop. Activating the massage timer and setting it to 0 will not turn off the massage. E Custom Preset 1 Press and hold for more than 3 seconds to set current position or function (massage or wave) as the programmed position and/or function. The LCD display will show “1” to indicate that the position and/or function has been set. Press Custom Preset 1 to return the bed to the custom programmed position and/or function. LCD display will show “1” and bed animation of both head and foot sections. F Raise Head/Lower Head Press and hold to raise or lower the head section to reach desired position. LCD will display animation of the head section. G Raise Foot/Lower Foot Press and hold to raise or lower the foot section. H Lounge Press Lounge – the head and foot sections rise to a lounge position. LCD will display bed animation of both head and foot sections. I Flat Press Flat – the head and foot sections go to the flat position and both massage and position timers reset to 0. Pressing the Flat button will automatically turn off all massage features. J Zero Gravity Press Zero Gravity – the head and foot sections raise to 7 degrees. K Head Massage Press and hold for more than 3 seconds to turn the head massage feature on or off. Press the up arrow to increase massage intensity; press the down arrow to decrease massage intensity. LCD display will light up. L Wave Massage Press and hold for more than 3 seconds to turn the wave massage feature on or off. Press the up arrow to increase massage intensity; press the down arrow to decrease massage intensity. LCD display will light up. M Foot Massage Press and hold for more than 3 seconds to turn the foot massage feature on or off. Press the up arrow to increase massage intensity; press the down arrow to decrease massage intensity. LCD display will light up. FlexFit Plus ™ Adjustable Base E C F H K L B A D G I J M 8 Remote Control Function FlexFit ™ Adjustable Base A Raise Head/Lower Head Press and hold to raise or lower the head section to reach desired position. LCD will display animation of the head section. B Custom Preset 1 Press and hold for more than 3 seconds to set current position as the programmed position. The LCD display will show “1” to indicate that the position has been set. Press Custom Preset 1 to return the bed to the custom programmed position. LCD display will show “1” and bed animation of both head and foot sections. C Raise Foot/Lower Foot Press and hold to raise or lower the foot section. D Flat Press Flat – the head and foot sections go to the flat position. A B C D 9 Remote Programming FLAT BuTTOn RAIsE HEAD BuTTOn 2 Program One Remote to an Adjustable Base Before beginning, make certain the bed is plugged into a working, grounded electrical outlet. Locate the receiver unit (power down box) and press the Learn button on the power down box for 1 second then release. Press and hold both the Flat and Raise Head buttons on the remote simultaneously for more than 5 seconds. The remote LCD display will blink a few times. The LED on the power down box will flash slowly at first then rapidly to indicate that the remote has been programmed to operate a bed. If programming fails, initiate the programming procedure a second time. 1 Power Down Box In case of a power outage, press and hold the Learn button on the receiver unit (power down box) to lower the bed to the flat position. This function is only for lowering the bed and will not move the bed to any other position. Once the bed is flat replace the (2) 9 volt batteries. 3 Program One Remote Control to Two Beds Before beginning, make certain the beds are plugged into a working, grounded electrical outlet. Locate the power down box for bed 1 and press the Learn button on the power down box for 1 second then release. Press and hold both the Flat and Raise Head buttons on the first remote simultaneously for more than 5 seconds. The remote LCD display will blink a few times. The LED on the first power down box will flash slowly at first then rapidly to indicate the remote has been programmed to operate the first bed. Repeat these steps with bed 2. One remote is now programmed to operate two beds. If programming fails, initiate the programming procedure a second time. 4 Program Two Remote Controls to Two Beds Before beginning, make certain the beds are plugged into a working, grounded electrical outlet. Locate the power down box for bed 1 and press the Learn button on the power down box for 1 second then release. Press and hold both the Flat and Raise Head buttons on the first remote simultaneously for more than 5 seconds. The remote LCD display will blink a few times. The LED on the first power down box will flash slowly at first then rapidly to indicate the remote has been programmed to operate the first bed. Repeat these steps with remote 2, then locate the power down box for bed 2 and …

Text truncated - open the document above for the full version.

Northwest EMC TCB Compliance Opinion Rev. 7/1/10 SECF0006 Information about the Applicant Grantee (Company Name) Select Comfort Corporation FCC Contact Person Jeffrey Barnum Address 9800 59th Avenue North City, State, Zip Minneapolis, MN 55442 Job Number SECF0006 Model Adjustable Foundation Remote FCC ID LPM1000G Agent Approval Type Original Equipment Class DXX Part 15, Low Power Communication Device Transmitter Rule Part 15.231 Overview This application is for original approval of Select Comfort's Adjustable Foundation Remote, FCC ID: LMP-1000G, operating at 310 MHz. The device is battery operated only. The antenna is a single PCB etch antenna. No. Application did not request confidentiality. No short term confidentiality requested. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature Dave Tolman, TCB Committee 6/4/2012

FCC Image Location The image below shows a sample of the FCC ID location. FCC ID: LPM‐1000G This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference and (2) This device must accept any interference received including interference that may cause undesired operation The image below shows the location of the FCC ID label in the plastics.

RFM TRC105 Radio 310MHz Antenna 310MHz Antenna

310MHz Trace Antenna Information 1) Describe compliance of the device with the antenna requirements of paragraph 15.203 of the FCC rules (see attachment) The antenna used in FCC certification is an embedded trace antenna and is not user configuration. Therefore the DUT is designed to ensure that no other antenna configurations are possible. 2) A list of antennas to be used with the transmitter. Include manufacturer, model number, gain (dBi), and description (e.g. dipole, yagi, patch, etc.) Manufacturer: N/A, Custom trace antenna Model Number: N/A, Custom trace antenna Gain (dBi): N/A, Description: The DUT uses a single, custom 310MHz embedded monopole trace antenna. 3) Drawing or photograph unless clear photos appear in the external photos exhibit

Select Comfort Corporation Adjustable Foundation Remote Report #: SECF0006 Report Prepared By Northwest EMC Inc. NORTHWEST EMC – (888) 364-2378 – www.nwemc.com California – Minnesota – Oregon – New York – Washington 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Test Last Date of Test: May 9, 2012 Select Comfort Corporation Model: Adjustable Foundation Remote Emissions Test Description Specification Test Method Pass/Fail Duty Cycle FCC 15.231:2012 ANSI C63.10:2009 Pass Occupied Bandwidth FCC 15.231:2012 ANSI C63.10:2009 Pass Field Strength of Fundamental FCC 15.231:2012 ANSI C63.10:2009 Pass Spurious Radiated Emissions FCC 15.231:2012 ANSI C63.10:2009 Pass Deviations From Test Standards None Approved By: Tim O’Shea, Operations Manager NVLAP Lab Code: 200881-0 Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 9349 W Broadway Ave. Brooklyn Park, MN 55445 Phone: (763) 425-2281 Fax: (763) 424-3469 This site has been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada (Site filing #2834E-1). This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. Revision History Revision 09/01/11 Revision Number Description Date Page Number 00 None Accreditations and Authorizations Revision 02/21/2012 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC Guide 65 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025. The scope includes radio, ITE, and medical standards from around the world. See: http://www.nwemc.com/accreditations/ Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea KCC / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Hong Kong OFTA – Recognized by OFTA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. Russia GOST – Accredited by Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC to perform EMC and Hygienic testing for Information Technology products to GOST standards. Locations Revision 2/23/12 Oregon Labs EV01-EV12 22975 NW Evergreen Pkwy, #400 Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-OC13 41 Tesla Irvine, CA 92618 (949) 861-8918 New York Labs WA01-WA04 4939 Jordan Rd. Elbridge, NY 13060 (315) 685-0796 Minnesota Labs MN01-MN08 9349 W Broadway Ave. Brooklyn Park, MN 55445 (763) 425-2281 Washington Labs SU01-SU07 14128 339 th Ave. SE Sultan, WA 98294 (360) 793-8675 VCCI C-1071, R-1025, G-84, C-2687, T-1658, R-2318 R-1943, G-85, C-2766, T-1659, G-548 R-3125, G-86, G-141, C-3464, T-1634 R-871, G-83, C-3265, T-1511 Industry Canada 2834D-1, 2834D-2 2834B-1, 2834B-2, 2834B-3 2834E-1 2834C-1 Product Description Revision 09/01/11 Client and Equipment Under Test (EUT) Information Company Name: Select Comfort Corporation Address: 9800 59th Avenue North City, State, Zip: Minneapolis, MN 55442 Test Requested By: Maxine Chen Model: Adjustable Foundation Remote First Date of Test: May 09, 2012 Last Date of Test: May 09, 2012 Receipt Date of Samples: May 09, 2012 Equipment Design Stage: Prototype Equipment Condition: No Damage Information Provided by the Party Requesting the Test Functional Description of the EUT (Equipment Under Test): Adjustable Foundation Remote Testing Objective: To demonstrate compliance to FCC 15.231 specifications. Configurations Revision 09/01/11 Configuration 1 SECF0006 EUT Description Manufacturer Model/Part Number Serial Number Adjustable Foundation Remote Select Comfort Corporation None 105 Peripherals in test setup boundary Description Manufacturer Model/Part Number Serial Number DC Power Supply EZ Power GP-4303D TPY Cables Cable Type Shield Length (m) Ferrite Connection 1 Connection 2 AC Power No .90m No AC Mains DC Power Supply DC Power No 1.10m No DC Power Supply Adjustable Foundation Remote PA = Cable is permanently attached to the device. Shielding and/or presence of ferrite may be unknown. Configuration 2 SECF0006 EUT Description Manufacturer Model/Part Number Serial Number Adjustable Foundation Remote Select Comfort Corporation None 104 Modifications Revision 09/01/11 Equipment Modifications Item Date Test Modification Note Disposition of EUT 1 5/9/2012 Duty Cycle Tested as delivered to Test Station. No EMI suppression devices were added or modified during this test. EUT remained at Northwest EMC following the test. 2 5/9/2012 Occupied Bandwidth Tested as delivered to Test Station. No EMI suppression devices were a…

Text truncated - open the document above for the full version.

Duty Cycle XMit 2012.04.06 NORTHWEST Duty Cycle EMC OB.JPG Duty Cycle Occupied Bandwidth XMit 2012.04.06 NORTHWEST Occupied Bandwidth PsaTx 2012.05.07 EMC OB.JPG Occupied Bandwidth photo SE (1).JPG SE (2).JPG Field Strength of Fundamental PSA-ESCI 2012.05.07 photo SE (3).JPG Field Strength of Fundamental PSA-ESCI 2012.05.07 photo SE (1).JPG SE (2).JPG Spurious Radiated Emissions PSA-ESCI 2012.05.07 photo SE (3).JPG Spurious Radiated Emissions PSA-ESCI 2012.05.07
