MESMSC3GSmart Card (SIM) Copier

FCC ID: MESMSC3G Page 1/2 USER MANUAL This is a copy of the user’s manualwhere the FCC statement is included: FCC ID: MESMSC3G Page 2/2 Detail view of the FCC statement:

FCC ID: MESMSC3G Page 1/1 1BLOCK DIAGRAM OF EQUIPMENT 1.1Clock list of the MySIM COPIER 3Gproduct 6 MHz – 1.5MHz 1.2Block diagram of the MySIM COPIER 3G product CPU CARD Interface 1.5 MHz Clock 6 MHz CARD Interface I/O I/O LCD Keys Power Supply 3 x 1.5V 3 batteries LR44

FCC ID: MESMSC3G Page 1/3 EXTERNAL PHOTOS OF TESTED EUT MySIM COPIER 3G photos General view, front face General view, rear face FCC ID: MESMSC3G Page 2/3 Detail view, left and right sides Detail view, upperside Detail view, lower side FCC ID: MESMSC3G Page 3/3 Detail view, SIM cards drawer

FCC ID: MESMSC3G Page 1/2 1PRODUCT LABELING 1.1FCC ID label This is copy of the label specification: Detail view FCC ID: MESMSC3G Page 2/2 1.2Location of the label on EUT Thelabel is set on the rear side of the equipment.

FCC ID: MESMSC3G Page 1/2 INTERNAL PHOTOS OF TESTED EUT 1.1General view General view, cover opened. Inside view, PCB removed. FCC ID: MESMSC3G Page 2/2 1.2PCB view

FCC ID: MESMSC3G Page 1/3 OPERATIONAL DESCRIPTION 1.1.Product description of the MySIM COPIER 3G FCC ID: MESMSC3G Page 2/3 FCC ID: MESMSC3G Page 3/3 1.2.Related Submittal(s) / Grant(s) All host equipment used in the test configuration are FCC granted, when relevant. 1.3.Tested System Details The FCC IDs for all equipment, plus description of all cables used in the tested system are: *:Equipment under test 1.4.Test Methodology Radiated testing wasperformed according to the procedures in ANSI C63.4-2003, FCC Part 15 Subpart B. Radiated testing was performed at an antenna to EUT distance of 10 meters.Equipment was tested on three orthogonal axes. (Portable equipment) No conducted testing was performed on the equipment. 1.5.Test facility Tests have been performed on February 28 th , 2005. The test facility used to collect all the test data is the SMEE Actions Mesuresfacility, located ZI des Blanchisseries, 38500 VOIRON, France. This test facility has been fully described in a report and accepted by FCC as compliant with the radiated and AC line conducted test site criteria in ANSI C63.4-2000 in a letter dated July 19, 2002 (registration number94821). This test facility has also been accredited by COFRAC (French accreditation authority for European union test lab accreditation organization) according to NF EN ISO/IEC 17025, accreditation number 1-0844 as compliant with test site criteria and competence in 47 CFR Part 15/ANSI C63.4 and EN55022/CISPR22 norms for 89/336/EEC European EMC Directive application. All pertinent data for this test facility remains unchanged. Trade Mark – Model Number (Serial number) FCC IDDescriptionCable description MySIM COPIER 3G * (sn:none ) MESMSC3GSmart card (SIM) copier No cable 2x GEMPLUS SIM cards (sn:none) NoneSIM cards

Actions Mesures Z.I. des Blanchisseries – 38500 VOIRON – France – Tél. +33 (0)4 76 65 76 50 – Fax +33 (0)4 76 66 18 30 www.smee.fr S.A. au capital de 152 449,02€/ R.C. de Grenoble B 329 901 888 / SIRET 329 901 888 00035 / code APE 332 B / n°TVA :FR29 329 901 888 This test report applies only on equipment described hereafter. Proposal number:200502-2638 Date of test...................................: February 28 th , 2005 Location........................................: SMEE Actions MesuresLaboratory - 38 VOIRON Performed by................................: Laurent CHAPUS Customer......................................: GEMPLUS(Represented by Mr. Pierre André Collet) ZIAthelia III – Voie Antiope 13705 LA CIOTAT FRANCE Product.........................................: MySIM COPIER 3G (FCC ID: MESMSC3G) Type of test.................................. : Radiated Emission Test Applied standards or specification: FCC Part 15, Subpart B CISPR22 (2003) ANSI C63-4 (2003) Level............................................: CISPR 22 Class B Test objective...............................: Qualification Results.........................................: Sample tested in configuration and description presented in this test report complies with prescriptions and limits of CISPR22 standards (class B). The reproduction of this test report is authorized only under its entire form. This report contents 6 pages Written by.........................: Date : March 7 th , 2005 Laurent CHAPUSApproved by....................: Jean-Pierre ORY EMC TEST REPORT Nr 3323-FCC FCC ID : MESMSC3G Nr3323-FCCFebruary28th, 2005page 2 /6 1. System test configuration 1.1. JUSTIFICATION: The system wasconfigured for testing in a typical fashion (as a customer would normally use it). The equipment MySIMCOPIER3G permits the data transfer (copy of personal data such as number of phone, messages) from an old SIM card to a new one. 1.2. HARDWARE IDENTIFICATION: * Equipment Under Test (EUT):MySIMCOPIER3GSn: none Input/output : none Frequencies: 6MHz-1.5MHz Power supply: 3x 1.5V batteries (LR44) 1.3. AUXILIARIES: The FCC IDs for all equipment, plus description of all cables usedin the tested system are: Trade Mark – Model Number (Serial number) FCC IDDescriptionCables description MySIM COPIER 3G * (sn: none ) MESMSC3GSmart card (SIM) copier No cable 2x GEMPLUS SIM cards (sn:none) NoneSIM cards *: Equipment under test 1.4. RUNNING MODE: For testing the MySIMCOPIER3G, a special inboard soft (EMC Soft) is used to operate the equipment in a continuous way. Data from an old SIM card is transferred to a new one during the test of the equipment. 1.5. I/O CABLES: No I/O cable used for the test. 1.6. EQUIPMENT MODIFICATIONS: No equipment modification has been necessary during testing to achieve compliance to CIRPR22 Class B levels. The unit tested was representative to a production unit. 2. Radiated emission data 2.1. TEST SET-UP: The equipment under testand auxiliariesareset on a non-conducted table of 80cm height, above the ground plane. New batteries are used during the test. FCC ID : MESMSC3G Nr3323-FCCFebruary28th, 2005page 3 /6 The installation of EUT is identical for pre-characterization measures in a 3 meters full anechoic chamber and for measures on a 10 meters Open site. 2.2. TEST EQUIPMENT: Test Equipment from 30MHz to 1GHz on the 10 meters open site: EquipmentCompany ModelSerial Spectrum AnalyzerHP8568B 2732A04140 Quasi-Peak adapterHP85650A2811A01136 RF Pre-selectorHP85685A2833A00773 Biconical AntennaEMCO3104C9401-4636 Log Periodic AntennaEMCO31462178 OATS EMCO-1050, 6 meters height antenna mast & EMCO-1060, 3 meters diameter Turntable. A 10 meters Open site located in SMEE Actions Mesures- Voiron (FRANCE). Pre-scan, test Equipment from 30MHz to 1GHz: EquipmentCompany ModelSerial EMC Analyzer HP8591EM3536A00384 AmplifierHP8447F H643113A06394 Antenna (30MHz-1GHz)CHASECBL6111A1628 2.3. TEST SEQUENCE AND RESULTS: 2.3.1. Pre-characterization at 3 meters A pre-scan of all the setup has been performed in a 3 meters full anechoic chamber. The distance between EUT and antenna is 3 meters. Test is performed in horizontal (H) and vertical (V) polarization, and on 4 faces of the EUT. See below for graph example. EUT is tested in both vertical and horizontal positions. Graphs are obtained in PEAK detection. FCC ID : MESMSC3G Nr3323-FCCFebruary28th, 2005page 4 /6 Graph [30MHz-1GHz] – EUT in horizontal position (RBW is 120kHz; VBW is 300kHz) MarkerFreq.Peak [MHz][dBuV] 1 228.623.08 2 230.024.28 FCC ID : MESMSC3G Nr3323-FCCFebruary28th, 2005page 5 /6 2.3.2.Characterization on 10 meters open site from 30MHz to 1GHz The product has beentested according to ANSI C63.4 (2003) and CISPR22 (2003). Radiated emissions were measured on an open area test site. A description of the facility is on file with the FCC. The product has been tested with new batteries, at a distance of 10 meters from the antenna and compared to the CISPR 22 Class B limits. Measurement bandwidth was 120kHz from 30MHz to 1GHz. Antenna height search was performed from 1m to 4m for both horizontal and vertical polarization. Continuous linear turntable azimuth search was performed with 360 degrees range. Frequency band investigated is 30MHz to 1GHz. Equipment wasmoved to position that maximized emission. A summary of the worst case emissions found in all test configurations and modes is shown on clause 2.3.1. Frequency list has been created with anechoic chamber pre-scan results. 2.3.3. Qualification results Frequency list has been created with anechoic chamber pre-characterization results. Measurements are performed in QUASI-PEAK detection. EUT set in horizontal position: No Frequency Qpeak Limit *QpeakQpeak-LmtAngleHgtPolTot Corr.Comments (MHz)(dBμV/m)(dBμV/m)(dB)(deg)(cm)(dB) 1 228.50230.017.2 -12.8 143376H13.8 2 229.96230.018.6 -11.4 175391H13.8Worst margin EUT set in vertical position: No Frequency Qpeak Limit *QpeakQpeak-LmtAngleHgtPolTot Corr.Comments (MHz)(dBμV/m)(dBμV/m)(dB)(deg)(…

Text truncated - open the document above for the full version.

FCC ID: MESMSC3G Page 1/1 1RADIATED MEASUREMENTPHOTO 1.1Radiated emission EUT 80cm above the ground reference plane in horizontal position Detail view (EUT in horizontal and vertical position)
