MRBSATEL-TA35SATELLINE-3ASd Epic Pro 35W

User manual SATELLINE-3ASd Epic Pro/Epic Pro 35W_v.1.2 - 1 - IMPORTANT NOTICE All rights to this manual are owned solely by SATEL OY (referred to in this user guide as SATEL). All rights reserved. The copying of this manual (without the written permission from the owner) by printing, copying, recording or by any other means, or the full or partial translation of the manual to any other language, including all programming languages, using any electrical, mechanical, magnetic, optical, manual or other methods or devices is forbidden. SATEL reserves the right to change the technical specifications or functions of its products, or to discontinue the manufacture of any of its products or to discontinue the support of any of its products, without any written announcement and urges its customers to ensure, that the information at their disposal is valid. SATEL software and programs are delivered ”as is”. The manufacturer does not grant any kind of warranty including guarantees on suitability and applicability to a certain application. Under no circumstances is the manufacturer or the developer of a program responsible for any possible damages caused by the use of a program. The names of the programs as well as all copyrights relating to the programs are the sole property of SATEL. Any transfer, licensing to a third party, leasing, renting, transportation, copying, editing, translating, modifying into another programming language or reverse engineering for any intent is forbidden without the written consent of SATEL. SATEL PRODUCTS HAVE NOT BEEN DESIGNED, INTENDED NOR INSPECTED TO BE USED IN ANY LIFE SUPPORT RELATED DEVICE OR SYSTEM RELATED FUNCTION NOR AS A PART OF ANY OTHER CRITICAL SYSTEM AND ARE GRANTED NO FUNCTIONAL WARRANTY IF THEY ARE USED IN ANY OF THE APPLICATIONS MENTIONED. Salo, FINLAND 2009 Copyright: 2009 Satel Oy No part of this document may be reproduced, transmitted or stored in a retrieval system in any form or by any means without the prior written permission of Satel Oy. This document is provided in confidence and must not be distributed to third parties without the express permission of Satel Oy. User manual SATELLINE-3ASd Epic Pro/Epic Pro 35W_v.1.2 - 2 - RESTRICTIONS ON USE SATELLINE-3AS(d) Epic Pro is allowed to be used in the following countries, either on licence free channels or on channels where the operation requires a licence. More detailed information is available at the local frequency management authority. Countries*: AT, AU, BE, BG, CY, CZ, HR, DK, EE, FI, FR, DE, GR, HU, ID, IS, IE, IL, IT, LT, LV, NL, NO, OM, PL, PT, RO, RU, SI, ZA, ES, SK, SE, CH, TH, GB and US SATELLINE-3AS(d) Epic Pro 35W is allowed to be used only in countries where FCC approval is valid. It does not fulfil the ETSI specification. WARNING! Users of SATELLINE-3AS(d) Epic radio modems in North America should be aware, that due to the allocation of the frequency band 406.0 – 406.1 MHz for government use only, the use of radio modem on this frequency band without a proper permit is strictly forbidden. In addition project approvals available for IN, KZ and TW. * codes of the countries follow the ISO 3166-1-Alpha-2 standard User manual SATELLINE-3ASd Epic Pro/Epic Pro 35W_v.1.2 - 3 - PRODUCT CONFORMITY SATELLINE-3AS(d) Epic Pro Hereby, SATEL Oy declares that SATELLINE-3AS(d) Epic Pro radio modem is in compliance with the essential requirements (radio performance, electromagnetic compatibility and electrical safety) and other relevant provisions of Directive 1999/5/EC. Therefore the equipment is labelled with the following CE-marking. The notification sign informs user that the operating frequency range of the device is not harmonised throughout the market area, and the local spectrum authority should be contacted before the usage of the radio modem. 0523 User manual SATELLINE-3ASd Epic Pro/Epic Pro 35W_v.1.2 - 4 - WARRANTY AND SAFETY INSTRUCTIONS Read these safety instructions carefully before using the product: o Warranty will be void, if the product is used in any way that is in contradiction with the instructions given in this manual, or if the radio modem housing has been opened or tampered with. o The radio modem is only to be operated at frequencies allocated by local authorities, and without exceeding the given maximum allowed output power ratings. SATEL and its distributors are not responsible, if any products manufactured by it are used in unlawful ways. o The devices mentioned in this manual are to be used only according to the instructions described in this manual. Faultless and safe operation of the devices can be guaranteed only if the transport, storage, operation and handling of the devices are appropriate. This also applies to the maintenance of the products. o To prevent damage both the radio modem and any terminal devices must always be switched OFF before connecting or disconnecting the serial connection cable. It should be ascertained that different devices used have the same ground potential. Before connecting any power cables the output voltage of the power supply should be checked. User manual SATELLINE-3ASd Epic Pro/Epic Pro 35W_v.1.2 - 5 - TABLE OF CONTENTS IMPORTANT NOTICE ........................................................................................ - 1 - RESTRICTIONS ON USE .................................................................................... - 2 - PRODUCT CONFORMITY ................................................................................... - 3 - WARRANTY AND SAFETY INSTRUCTIONS ........................................................ - 4 - TABLE OF CONTENTS ....................................................................................... - 5 - 1 INTRODUCTION ...................................................................................... - 9 - 1.1 SATELLINE-3AS(d) Epic Pro technical specifications ........................... - 10 - 1.2 SATELLINE-3AS(d) Epic Pro 35 W technical specifications .................. - 11 - 1.3 Ba…

Text truncated - open the document above for the full version.

Correspondence 38343 11.11.2009 / MaritaL P.O.Box 142, FIN-24101 SALO, Finland Street: Meriniitynkatu 17, FIN-24100 SALO, Finland Tel +358 2 777 7800, Fax +358 2 777 7810, E-mail [email protected] www.satel.com Correspondence Reference Number: 38343 Form 731 Confirmation Number: EA457880 Dear Ms. Diane Poole Thanks for your email addressed to Mrs Marita Latovehmas at SATEL Oy. Referring to the items of your request, the following information has been prepared. Emission designator 20K0F1D: There is a false statement. The right ones are: SATELLINE-3ASd Epic Pro 35W/125: 10K7F1D SATELLINE-3ASd Epic Pro 35W/250: 20K3F1D The Emission designator has been defined referring NTIA manual (“Red Book”) /Annex J/Table: Multilevel Frequency Shift Keying: DK S R B n 2 log 2 += (K ≤ 0.89) SATELLINE-3AS Epic Pro 35W, 12.5 kHz channel spacing: R = 9600 bps D = 3.3 kHz S = 4 K = 0.89 71089.0*3.3*2 4log 9600 2 KkHz bps =+ Correspondence 38343 11.11.2009 / MaritaL P.O.Box 142, FIN-24101 SALO, Finland Street: Meriniitynkatu 17, FIN-24100 SALO, Finland Tel +358 2 777 7800, Fax +358 2 777 7810, E-mail [email protected] www.satel.com SATELLINE-3AS Epic Pro 35W/250: R=19200 bps D=6.0 kHz S=4 K=0.89 32089.0*0.6*2 4log 19200 2 KkHz bps =+ F1D has been defined as: F= Frequency modulation 1= One channel containing digital information, no subcarrier D= Telemetry If any further information is needed for the application procedure, please do not hesitate to contact us at Satel. Kind Regards, Satel Oy Marita Latovehmas

ATTESTATION LETTER According to KDB 634817... SATEL OY, as a manufacturer of SATEL-TA35 applies the certification to contiguous frequency range based on the facts below. 1. All devices delivered to USA do not end to usage in US markets. The local Satel distributor delivers SATEL-TA35 also further to third countries. 2. SATEL Oy acknowledges that it is violation of FCC rules if the device operates on unauthorized frequencies. Also end users are informed about this in user manuals. 3. The operation within frequency band 406-406.1 MHz is disabled by the manufacturer. 4. The list of frequencies covering applied frequency range and their authorized/non- authorized use. SATEL-TA35 complies with part 90 rules. 400.05 - 400.15 - time-signal only 401 - 402 - no conflict with other service rules 402 - 406 - part 95 406 - 406.1 - parts 95,87,80 locators only 406.1 - 410 - part 90 (FCC may be fixed only) 410 - 420 - part 90 (FCC may be fixed only) 420 - 450 - parts 90 and 97 450 - 454 - parts 90 and 74 454 - 455 - parts 22 and 80 455 - 456 - part 74 456 - 462.5375 - parts 90,80,22 462.5375 - 462.7375 - part 95 462.7375 - 467.5375 - part 90 467.5375 - 467.7375 - part 95 467.7375 - 470 - part 90 Salo, Finland, January 21 st , 2010 Marita Latovehmas SATEL Oy Type Approval Engineer

PRODUCT INFORMATION SATELLINE-3AS Epic Pro 35W 18.05.2009 O:\EPIC PRO 35W\PDF\Calculation_of_Necessary_Bandwidth-3AS_Epic_Pro_35W.doc SATEL Oy, P.O.Box 142, FIN-24101 Salo, Finland Street: Meriniitynkatu 17, FIN-24100 Salo, Finland Tel: +358 2 777 7800, Fax: +358 2 777 7810, E-mail: [email protected] www.satel.com Calculation of the Necessary Bandwidth for SATELLINE-3AS(d) Epic Pro 35W Radio Modem SATELLINE-3AS Epic Pro 35W radio modem uses frequency modulation and the signal is modulated with digital information. Based on these facts, the necessary bandwidth is calculated according to the formula in the section §2.202 (g) part III-A/1. Calculation for 12.5 kHz channel spacing B n = 2M+2DK , M = B/2 , K = 1.2 B = 4800 bauds => M = 2400 s -1 D = 3.3 kHz B n = 2 x 2400 Hz + 2 x 3300 Hz x 1.2 = 12.7 kHz -> 12K7 Calculation for 25 kHz channel spacing B n = 2M+2DK , M = B/2 , K = 1.2 B = 9600 bauds => M = 4800 s -1 D = 6 kHz B n = 2 x 4800 Hz + 2 x 6000 Hz x 1.2 = 24 kHz -> 24K0 Note! Due to the fact that the maximum deviation never occurs simultaneously with the maximum modulation frequency, the real bandwidth of the emitted signal is lower than the ones calculated according to the formula above.

PRODUCT INFORMATION SATELLINE-3AS Epic Pro 35W 18.05.2009 O:\EPIC PRO 35W\PDF\Modulation_Characteristics_Epic.doc SATEL Oy, P.O.Box 142, FIN-24101 Salo, Finland Street: Meriniitynkatu 17, FIN-24100 Salo, Finland Tel: +358 2 777 7800, Fax: +358 2 777 7810, E-mail: [email protected] www.satel.com Modulation Characteristics of SATELLINE-3AS(d) Epic Pro 35W Radio Modem SATELLINE-3AS Epic radio data modem uses CML FX919B integrated circuit for encoding the data to the Tx modulator and further to the other stages of the transmitter. The encoder block of the FX919B circuit translates the binary data to 4-level symbols. Each symbol contains the information of two bits. After encoding, the data symbols are passed through a linear-phase lowpass filter with a ‘Root Raised Cosine’ (RRC) frequency response defined by the function H(f) = 1 for 0 ≤ f < (1-b)/(2T) = square root of {0.5 [1 – sin(πT (f – 0.5/T)/b)]} for (1-b)/(2T) ≤ f ≤ (1+b)/(2T) = 0 for (1+b)/(2T) < f , where b = 0.2 and T = 1/symbol rate, to eliminate the high frequency components of the modulating signal. Source of information: Document no. D/919B/1 July 1997, CML Semiconductor Products Ltd.

Request for confidential 19.10.2009 / MaritaL Reference: Equipment Authorization Application (confirmation number: EA457880) of SATELLINE-3AS- Epic Pro 35W radio data modem (FCC Identification code: MRBSATEL-TA35). Background: According to the 47CFR/ §0.457/ (d)/ (ii), materials relating to applications for equipment authorizations are not routinely available for public inspection prior to the effective date of the authorization. However, at the moment any person has access via the internet to all of the exhibits attached to our pending application. Therefore we would like to request according to 47CFR/ §0.459, that part of the material will be withheld from public inspection. REQUEST FOR CONFIDENTIALITY §0.459/ (b)/ (1) Identification of the material: The following attachment files of the application no. EA457880 - EpicPro35W_block diagram.pdf - TC4qEpic _Pro_block diagram.pdf - EPA1_a_Schematics.pdf EPA_d_Schematics.pdf EPC_b_Schematics.pdf - EpicPro35W _TC4q_schematic.pdf EPS_b_Schematics.pdf EPT_d_Schematics.pdf - EPA1_a_BOTTOM.pdf EPA1_a_TOP.pdf EPA_d_BOTTOM.pdf EPA_d_TOP.pdf EPC_b_BOTTOM.pdf EPC_b_TOP.pdf EPS_b_BOTTOM.pdf EPS_b_TOP.pdf EPT_d_BOTTOM.pdf EPT_d_TOP.pdf TC4q_layout.pdf - EPA1 _a_R00_AA_07092009_TV00_LV00_LR01.pdf EPA_d_R00_AA_07092009_TV00_LV00_LR01.pdf EPC_b_R00_AA_18082009_TV00_LV01_LR01.pdf EPS_b_R00_AA_18082009_TV01_LV02_LR01.pdf EPT_d_R00_AA_24082009_TV00_LV00_LR01.pdf - Operational_Description_of_Circuitry_Epic Pro 35W.pdf (2) Identification of the Commission proceeding: The confidential information mentioned above has been submitted via Electronic Filing Site to FCC / Office of Engineering and Technology on the 19 th of October 2009, as attachments to our application no. EA457880. (3), (4) Degree of information The confidential files mentioned above contain technical details of the electronic circuitry of the product. Request for confidential 19.10.2009 / MaritaL (5) Possible harm caused by disclosure of the information Disclosure of the confidential information of the files mentioned above may result in easier ‘reverse engineering’ by the competitors, and therefore cause significant financial losses in business. (6) Preventing measures of the submitting party The applicant for the equipment authorization (SATEL Oy) has relied on the standard way how the telecommunication authorities in various states handle the product documentation in connection with equipment authorization procedures. (7) Availability of the information The confidential information mentioned above is available only to the telecommunication authorities and to the specially authorized parties e.g. local service etc. (8) Period of non-disclosure The material should be withheld from public inspection as long as the product is on the market. Yours Sincerely, SATEL Oy Marita Latovehmas Type Approval Engineer

Request for confidential 19.10.2009 / MaritaL Reference: Equipment Authorization Application (confirmation number: EA457880) of SATELLINE-3AS- Epic Pro 35W radio data modem (FCC Identification code: MRBSATEL-TA35). Background: According to the 47CFR/ §0.457/ (d)/ (ii), materials relating to applications for equipment authorizations are not routinely available for public inspection prior to the effective date of the authorization. However, at the moment any person has access via the internet to all of the exhibits attached to our pending application. Therefore we would like to request according to 47CFR/ §0.459, that part of the material will be withheld from public inspection. REQUEST FOR CONFIDENTIALITY §0.459/ (b)/ (1) Identification of the material: The following attachment files of the application no. EA457880 - EpicPro35W_block diagram.pdf - TC4qEpic _Pro_block diagram.pdf - EPA1_a_Schematics.pdf EPA_d_Schematics.pdf EPC_b_Schematics.pdf - EpicPro35W _TC4q_schematic.pdf EPS_b_Schematics.pdf EPT_d_Schematics.pdf - EPA1_a_BOTTOM.pdf EPA1_a_TOP.pdf EPA_d_BOTTOM.pdf EPA_d_TOP.pdf EPC_b_BOTTOM.pdf EPC_b_TOP.pdf EPS_b_BOTTOM.pdf EPS_b_TOP.pdf EPT_d_BOTTOM.pdf EPT_d_TOP.pdf TC4q_layout.pdf - EPA1 _a_R00_AA_07092009_TV00_LV00_LR01.pdf EPA_d_R00_AA_07092009_TV00_LV00_LR01.pdf EPC_b_R00_AA_18082009_TV00_LV01_LR01.pdf EPS_b_R00_AA_18082009_TV01_LV02_LR01.pdf EPT_d_R00_AA_24082009_TV00_LV00_LR01.pdf - Operational_Description_of_Circuitry_Epic Pro 35W.pdf (2) Identification of the Commission proceeding: The confidential information mentioned above has been submitted via Electronic Filing Site to FCC / Office of Engineering and Technology on the 19 th of October 2009, as attachments to our application no. EA457880. (3), (4) Degree of information The confidential files mentioned above contain technical details of the electronic circuitry of the product. Request for confidential 19.10.2009 / MaritaL (5) Possible harm caused by disclosure of the information Disclosure of the confidential information of the files mentioned above may result in easier ‘reverse engineering’ by the competitors, and therefore cause significant financial losses in business. (6) Preventing measures of the submitting party The applicant for the equipment authorization (SATEL Oy) has relied on the standard way how the telecommunication authorities in various states handle the product documentation in connection with equipment authorization procedures. (7) Availability of the information The confidential information mentioned above is available only to the telecommunication authorities and to the specially authorized parties e.g. local service etc. (8) Period of non-disclosure The material should be withheld from public inspection as long as the product is on the market. Yours Sincerely, SATEL Oy Marita Latovehmas Type Approval Engineer

Correspondence 38364 24.11.2009 MaritaL Correspondence Reference Number: 38364 Form 731 Confirmation Number: EA457880 Dear Ms. Diane Poole Thanks for your email addressed to Mrs Marita Latovehmas at SATEL Oy. Referring to the items of your request, the following information has been prepared. SATEL Oy, as a manufacturer of SATELLINE-2AS Epic Pro 35W radio modems, states that this equipment is designed for operation in the 400 - 470 MHz band. The frequencies 406.0 – 406.1 MHz can be rejected by the manufacturer. The operator can’t program and transmit on frequencies, other than those programmed by the manufacturer, service or maintenance personnel. It is a violation of FCC rules if the device operates on unauthorized frequencies. Salo, Finland, November 24 th , 2009 Marita Latovehmas SATEL Oy Type Approval Engineer

Correspondence 38406 7.12.2009 MaritaL FCC ID: MRBSATEL-TA35 Correspondence Reference Number: 38406 731 Confirmation Number: EA457880 Dear Ms. Diane Poole Thanks for your email addressed to Mrs Marita Latovehmas at SATEL Oy. Referring to the items of your request, the following information has been prepared. SATEL Oy, as a manufacturer of SATELLINE-3AS Epic Pro 35W radio modems, states that the frequencies 406.0 – 406.1 MHz can be rejected by the manufacturer. When ordering modems from SATEL Oy, the customer needs to advice the country where it is going to be shipped. When the country code is US, the production does not adjust the operation frequency within frequencies 406.0 – 406.1 MHz. The end user can’t change that operation frequency afterwards. On the contrary the modem is always operating in frequency adjusted in factory. Salo, Finland, December 7 th , 2009 Marita Latovehmas SATEL Oy Type Approval Engineer

Correspondence_38401_2 FCC Identification label will be placed as shown in the photos: Correspondence_38401_2

Correspondence_38401_3 FCC Identification label will be placed as shown in the photos: Correspondence_38401_3

Correspondence 38504 13.1.2010 MaritaL FCC ID: MRBSATEL-TA35 Correspondence Reference Number: 38504 731 Confirmation Number: EA457880 Dear Ms. Diane Poole Thanks for your email addressed to undersigned. Referring to the items of your request, the following information has been prepared. According to KDB 634817... SATEL OY, as a manufacturer of SATEL-TA35 applies the certification to contiguous frequency range based on the facts below. 1. All devices delivered to USA do not end to usage in US markets. The local Satel distributor delivers SATEL-TA35 also further to third countries. 2. SATEL Oy acknowledges that it is violation of FCC rules if the device operates on unauthorized frequencies. Also end users are informed about this in user manuals. 3. The operation within frequency band 406-406.1 MHz is disabled by the manufacturer. Salo, Finland, January 13 th , 2010 Marita Latovehmas SATEL Oy Type Approval Engineer

Correspondence 38555 21.1.2010 MaritaL FCC ID: MRBSATEL-TA35 Correspondence Reference Number: 38555 731 Confirmation Number: EA457880 Dear Ms. Diane Poole Thank you for your email addressed to undersigned. Referring to the items of your request, the following information has been prepared. According to correspondence 38555 we have completed the application with the attestation letter dated January 21 st , 2010. Best Regards, Marita Latovehmas Type Approval Engineer SATEL Oy

Product photos SATELLINE-3AS Epic Pro 35W 25.9.2009 SATEL Oy, P.O.Box 142, FIN-24101 Salo, Finland Street: Meriniitynkatu 17, FIN-24100 Salo, Finland Tel: +358 2 777 7800, Fax: +358 2 777 7810, E-mail: [email protected] www.satel.com

Page 1/1 P.O.Box 142, FIN-24101 SALO, Finland Street: Meriniitynkatu 17, FIN-24100 SALO, Finland Tel +358 2 777 7800, Fax +358 2 777 7810, E-mail [email protected] www.satel.com Model: SATELLINE-3ASd Epic Pro 35W DESCRIPTION OF LABELLING for U.S. market

Correspondence 38401 25.11.2009/MaritaL P.O.Box 142, FIN-24101 SALO, Finland Street: Meriniitynkatu 17, FIN-24100 SALO, Finland Tel +358 2 777 7800, Fax +358 2 777 7810, E-mail [email protected] www.satel.com Model: SATELLINE-3ASd Epic Pro 35W DESCRIPTION OF LABELLING for U.S. market FCC Identification label will be placed as shown in the picture:

Product photos / Intrernal SATELLINE-3AS Epic Pro 35W 25.9.2009 SATEL Oy, P.O.Box 142, FIN-24101 Salo, Finland Street: Meriniitynkatu 17, FIN-24100 Salo, Finland Tel: +358 2 777 7800, Fax: +358 2 777 7810, E-mail: [email protected] www.satel.com Product photos / Intrernal SATELLINE-3AS Epic Pro 35W 25.9.2009 SATEL Oy, P.O.Box 142, FIN-24101 Salo, Finland Street: Meriniitynkatu 17, FIN-24100 Salo, Finland Tel: +358 2 777 7800, Fax: +358 2 777 7810, E-mail: [email protected] www.satel.com

RF EXPOSURE STATEMENT SATELLINE-3ASd Epic Pro 35W radio modem FCC ID: MRBSATEL-TA35 STATEMENT November 10 th , 2009 / MaritaL Page 1 of 3 Prediction of human exposure to RF radiation during operation of SATELLINE-3ASd Epic Pro 35W radio modem Background information FCC guidelines to evaluate the environmental impact of human exposure to radiofrequency radiation are specified in the federal rules 47 CFR §1.1307(b), except portable devices that shall be evaluated according to §2.1093. Limits for maximum permissible exposure are set in the federal rules 47 CFR §1.1310. Further information on evaluating compliance with these limits is found in the FCC’s OST/OET Bulletin Number 65. Prediction methods applied Minimum safe distances have been calculated for controlled / occupational exposures and for uncontrolled / general population exposures. The following formulas are used in calculations. 2 4R PG S π = where: S = power density [mW/cm 2 ] P = power input to the antenna [mW] G = power gain of the antenna in direction of interest, relative to an isotropic radiator [numeric] R = distance to the centre of radiation of the antenna [cm] S PG R R PG S π π 4 4 2 =⇒= Applicable limits for maximum permissible exposure The operating frequency range of SATELLINE-3ASd Epic Pro 35W radio modem is 400-470 MHz, and the transmitter output power range is 1W to 35 W. Tx duty cycle, which is determined by the terminal device, can be up to 100 %. Based on the above technical parameters and the Table 1 in the federal rules 47 CFR §1.1310, the following limits of power density shall apply: a) Occupational/Controlled Exposures: f/300 mW/cm 2 (averaging time 6 minutes) b) General population/Uncontrolled Exposure: f/1500 mW/cm 2 (averaging time 30 minutes) RF EXPOSURE STATEMENT SATELLINE-3ASd Epic Pro 35W radio modem FCC ID: MRBSATEL-TA35 STATEMENT November 10 th , 2009 / MaritaL Page 2 of 3 Calculations for the minimum safe distances Minimum distance to the antenna in case of General population/Uncontrolled situation: () 9375.31500/4704 PGPG R== π Tx power can be corrected with the 30-minute average value of the Tx duty cycle. The antennas in the list have been defined to be used with SATELLINE-3AS Epic Pro 35W radio modem. *The values of power have been calculated: [W]*=(P_rated + 20% ) Tx output power [W]* Antenna system gain [dBi / numeric] Tx duty cycle [%], 30 min. average Frequency [MHz] Minimum safe distance [cm] 42 8 / 6.310 100 470 259.40 50 470 183.40 20 470 116.00 6 / 3.981 100 470 206.10 50 470 145.70 20 470 92.20 2 / 1.585 100 470 130.00 50 470 91.90 20 470 58.10 30 8 / 6.310 100 470 219.30 50 470 155.00 20 470 98.10 6 / 3.981 100 470 174.20 50 470 123.20 20 470 77.90 2 / 1.585 100 470 109.90 50 470 77.70 20 470 49.10 18 8 / 6.310 100 470 169.80 50 470 120.10 20 470 76.0 6 / 3.981 100 470 134.90 50 470 95.40 20 470 60.30 2 / 1.585 100 470 85.10 50 470 60.20 20 470 38.10 12 8 / 6.310 100 470 138.70 50 470 98.10 20 470 62.0 6 / 3.981 100 470 110.20 50 470 77.90 20 470 49.30 2 / 1.585 100 470 69.50 50 470 49.10 RF EXPOSURE STATEMENT SATELLINE-3ASd Epic Pro 35W radio modem FCC ID: MRBSATEL-TA35 STATEMENT November 10 th , 2009 / MaritaL Page 3 of 3 20 470 31.10 6 8 / 6.310 100 470 98.10 50 470 69.30 20 470 43.90 6 / 3.981 100 470 77.90 50 470 55.10 20 470 34.80 2 / 1.585 100 470 49.10 50 470 34.70 20 470 22.0 Conclusion Users of SATELLINE-3ASd Epic Pro 35W radio modem shall be advised of the above safe distances in the appropriate documentation.

WARNINGS TO USERS SATELLINE-3ASd Epic Pro 35W radio modem FCC ID: MRBSATEL-TA35 INFO LETTER November 10 th , 2009 / MaritaL Page 1 of 1 Warnings to be added to the user guide of SATEL-TA35 radio modem module° WARNING! Users of SATELLINE-3ASd Epic Pro 35W radio modems in North America should be aware, that due to the allocation of the frequency band 406.0 – 406.1 MHz for government use only, the use of radio modem on this frequency band without a proper permit is strictly forbidden. Warning – RF Exposure "Warning: To comply with FCC RF exposure compliance requirements, a separation distance of at least 22 cm must be maintained between the antenna of this device and all persons. This device must not be co-located or operating in conjunction with any other antenna or transmitter." Modification warning statement "Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment." Class B digital device statement "Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help."

Nemko Oy • P.O.Box 19, FI-02601 Espoo, Finland Street address: Perkkaantie 11, FI-02600 Espoo Telephone +358 424 5454 1 • Telefax +358 9 5489 6371 Version R3.03 09092003 TEST REPORT TEST REPORT Date: ESPOO 14.09.2009 Page: 1 (45) Appendices - Date of handing in: 17.06.2009 Number: 129599A No. 1 / 1 Tested by: Pekka Kälviäinen, Test Engineer Reviewed by: Janne Nyman, Compliance Specialist SORT OF EQUIPMENT: Transceiver MARKETING NAME: TYPE: SATELLINE ® 3ASd Epic Pro 35 W MANUFACTURER: Satel Oy, Finland SERIAL NUMBER: - CLIENT: Satel Oy ADDRESS: Meriniitynkatu 17, FIN-24100 Salo, Finland TELEPHONE: +358 2 777 7800 / Marita Latovehmas TEST LABORATORY Nemko Oy FCC REG. NO. 359859 November 26, 2008 IC FILE NO. 2040F-1 December 15, 2008 REMARKS: Tested to FCC Part 90 and RSS-119 Issue 9. The test results are valid for the tested unit only. Without a written permission of Nemko Oy it is allowed to copy this report as a whole, but not partially. Type: SATEL-TA11 FCC Part 2 & 90, RSS119 S/N: - Test report: 119457A Page 2 (45) Date 14.09.2009 Contents 1. General ............................................................................................................................................... 3 2. Summary of performed tests and test results ..................................................................................... 3 3. RF Power Output ................................................................................................................................ 4 4. 99% Occupied Bandwidth ................................................................................................................... 5 5. Spectrum Emission mask ................................................................................................................. 10 6. Transmitter Spurious Emissions (Conducted) .................................................................................. 19 7. Transmitter Spurious Emissions (Radiated) ..................................................................................... 35 8. Transient behaviour of the transmitter .............................................................................................. 37 8.1 Frequency stability .................................................................................................................. 44 9. List of measuring equipment: ............................................................................................................ 45 Type: SATEL-TA11 FCC Part 2 & 90, RSS119 S/N: - Test report: 119457A Page 3 (45) Date 14.09.2009 1. General Type: SATELLINE® 3ASd Epic Pro 35 W Alignment range: 400.0 – 470.0 MHz Switching range: One channel Measurement Serial no. - Serial no. - Serial no. Frequencies: 1) 408.0 MHz / 12.5 kHz 4) 468.0 MHz / 25 kHz ) 2) 452.0 MHz / 12.5 kHz 5) 402.0 MHz / 25 kHz 3) 428.0 MHz / 25 kHz 6) 432.0 MHz / 25 kHz Voltages: 13.2 …

Text truncated - open the document above for the full version.
