N5ORC400TR02FH433Radio transceiver module

RE FCC ID: N5ORC400TR02FH433 To the certification reviewer: We are hereby applying for full modular approval of the above-referenced FCC ID, based on compliance with all of the criteria as detailed below. Part 15 Unlicensed Single Modular Transmitter Approval Justification per 15.212 Requirement per 15.212 reference (i) The radio elements of the modular transmitter must have their own RF shielding. Shielding is provided by a metal cover over the circuitry. . (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided. All modulation and data inputs are buffered by circuitry on the transmitter module. (iii) The modular transmitter must have its own power supply regulation. Power supply regulation is provided by circuitry on the transmitter module. (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna is permanently attached. (v) The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 parameters. Testing was performed with the module extended outside of the host, as shown in the test setup photos. (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. If the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. A sample of the host label is provided as an exhibit, showing the FCC identifier of the module. (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The module complies fully with the operating requirements of Part 15 section 15.209 as demonstrated in the test report exhibit. (viii) The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. This module operates under Part 15 section 15.209, which is exempt from RF exposure evaluation owing to the very low operating power:

1(1) Attention: Application Examiner Re: Request for confidentiality Applicant: Scanreco AB, Sweden FCC ID: N50RC400TR02FH433 To whom it may concern, Request is hereby submitted by Scanreco AB, Sweden to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics/PCB circuit diagrams.  Block diagrams.  Parts lists.  Operational description. Rationale for request for confidentiality: Scanreco AB, Sweden has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Thank you for your attention to this matter Stockholm/Sweden / 2009-01-12 Kjell Leiwert

1(1) EXTERNAL PHOTOS OF SCANRECO TR02 EUT with antenna, front side EUT with antenna, back side

SCANRECO RC400 / TR 02 This device complies with part 15 of the FCC Rules. Operation is subject to following two conditions: (1) This device may not cause harmful interference, & (2) This device must accept any interference received, including interference that may cause indesired operation. FCC ID: N5ORC400TR02FH433 IC: 6476A-RC400TR02FH433 SW: XXXXXXXXXXXXXXX BN:XXXXXX XXX PartNo:

Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden Telephone +46 8 750 00 00, Fax +46 8 750 60 30, www.sweden.intertek-etlsemko.com Registered in Sweden: No SE556024059901, Registered office: As address r d f n c Test report no. 911149-2 Page 2 (15) CONTENTS Page 1. Client information.............................................................................................................................3 2. Equipment under test (EUT)...........................................................................................................3 2.1 Identification of the EUT according to the manufacturer/client declaration...................3 2.2 Peripheral equipment............................................................................................................3 2.3 Modifications during the test................................................................................................3 3. Test specifications...........................................................................................................................4 3.1 Standards................................................................................................................................4 3.2 Additions, deviations and exclusions from standards.......................................................4 3.3 Test set-up..............................................................................................................................4 3.4 Operating environment..........................................................................................................4 4.Test summary....................................................................................................................................5 8. Radiated emissions.........................................................................................................................6 8.1 Measurement uncertainty.....................................................................................................6 8.2 Test equipment.......................................................................................................................6 8.3 Measurement set-up..............................................................................................................7 8.4 Test protocol...........................................................................................................................9 Appendix I – Photos of the EUT.......................................................................................................15 Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden Telephone +46 8 750 00 00, Fax +46 8 750 60 30, www.sweden.intertek-etlsemko.com Registered in Sweden: No SE556024059901, Registered office: As address r d f n c Test report no. 911149-2 Page 3 (15) 1. CLIENT INFORMATION The EUT has been tested by request of Company: SCANRECO Industrielektronik AB BOX 47144 / Årsta Skolgränd 22 S-100 74 Stockholm Sweden Name of contact: Ramin Fardi 2. EQUIPMENT UNDER TEST (EUT) 2.1 Identification of the EUT according to the manufacturer/client declaration Equipment: Radio transceiver Type/Model: TR02 Low Power Brand name: Scanreco Serial number: No visible serial on EUT Manufacturer: SCANRECO Industrielektronik AB Rating/Supplying voltage: 6.0 - 8.0 VDC, 7.2 VDC nominal Rating RF output power: < 20 nW eirp Antenna gain: < 2 dBi External antenna connector: No Operating temperature range: -10° - 55° C degrees Frequency range: 433.1 – 434.7 MHz Number of channels: 12 Channel separation: 25 kHz Modulation characteristics: FSK Stand by mode supported: No Receiver mode supported Yes 2.2 Peripheral equipment During the test EUT was powered by external 7.2 V NiMH battery. 2.3 Modifications during the test No modifications have been made during the tests. Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden Telephone +46 8 750 00 00, Fax +46 8 750 60 30, www.sweden.intertek-etlsemko.com Registered in Sweden: No SE556024059901, Registered office: As address r d f n c Test report no. 911149-2 Page 4 (15) 3. TEST SPECIFICATIONS 3.1 Standards FCC 47 CFR part 15 (2008) Subpart C – Intentional Radiators; §15.209 Radiated emission limits Measurements methods according to ANSI C63.4-2003 - Methods of Measurements of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 3.2 Additions, deviations and exclusions from standards No additions, deviations or exclusions have been made from standards. 3.3 Test set-up Measurement set-ups for the spurious emissions test are described in corresponding sections. 3.4 Operating environment If not additionally specified, the tests were performed under the following environmental conditions: Air temperature: 22 – 23 °C Relative humidity: 23 – 53 % Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden Telephone +46 8 750 00 00, Fax +46 8 750 60 30, www.sweden.intertek-etlsemko.com Registered in Sweden: No SE556024059901, Registered office: As address r d f n c Test report no. 911149-2 Page 5 (15) 4. TEST SUMMARY The results in this report apply only to the sample tested. FCC reference Test Result Note 15.209 Intentional radiators Radiated emission limits Pass 1 1) The measured result is below the limit by a margin less than the measurement uncertainty; it is therefore not possible to state compliance based on the 95 % level of confidence. However, the result indicates that compliance is more probable than non-compliance with the specification limit. Intertek Semko AB Torshamnsgatan 43, Box 1103, SE-164 22 Kista, Sweden Telephone +46 8 750 00 00, Fax +46 8 750 60 30, www.sweden.intertek-etlsemko.com Registered in Sweden: No SE556024059901, Registered office: As address r d f n c Test report no. 911149-2 Page 6 (15) 8. RADIATED EMISSIONS 8.1 Measurement uncertainty Radiated disturbance electric field intensity, 30 – 1000 MHz: ± 4,6 dB Radiated distu…

Text truncated - open the document above for the full version.

1(1) TEST SET-UP PHOTOS MODEL: RC400-TR02 (Part 15.209) Radiated spurious emission 30-1000 MHz Radiated spurious emission 1-5 GHz
