N6SGCMContactless Smart Card Interface

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: N6SGCM IC: 827B-GCM FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0087.W06.11.A Manufacturer: Gilbarco, Inc. Model: FlexPay Contactless Manual MDE-4939 FlexPay™ Contactless Module Installation and Service Manual · May 2011Page 1 P rel i m i nary 05 / 05/ 1 1 Introduction Purpose This document provides instructions to mount the FlexPay ™ Contactless Module and to install the Contactless Interface Board on Secure Card Reader 2 (SCR2). This equipment has been tested and found to comply with the limits pursuant to Part 15 of the Federal Communications Commission (FCC) Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and radiates radio frequency energy. This equipment must be installed and used in accordance with the instruction manual to avoid harmful interference to radio communications. Operation of this equipment in a residential area may cause harmful interference. In this case the user has to correct the interference at his own expense. Any change or modification must be approved by the manufacturer to allow the user to operate this equipment safely. The long term characteristics or the possible physiological effects of radio frequency electromagnetic fields have not been investigated by Underwriters’ Laboratories, Inc. (UL ® ). IMPORTANT INFORMATION Industry Canada Regulation: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: • This device may not cause interference • This device must accept any interference including interference that may cause undesired operation of the device. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. IMPORTANT INFORMATION MDE-4939 FlexPay ™ Contactless Module Installation and Service Manual May 2011 Introduction P re l im i na ry Page 2 MDE-4939 FlexPay™ Contactless Module Installation and Service Manual · May 2011 Table of Contents TopicPage Introduction1 Important Safety Information5 Mounting the FlexPay Contactless Module on Encore S Enhanced Dispenser Equipped with SPOT EMV CRIND7 Mounting the FlexPay Contactless Module on The Advantage Series Dispensers10 Mounting the FlexPay Contactless Module on Encore 300 and Encore 500 Dispensers11 Mounting the Contactless OTI Module on Encore 300 (Pre-EMV) Dispensers12 Mounting the FlexPay Contactless Module on Encore 500 S Dispensers12 Mounting the FlexPay Contactless Module on Eclipse Dispensers13 Mounting the FlexPay Contactless Module on FlexPay OPT Dispensers13 Installing the Contactless Interface Board on SCR 214 Configuring SPOT EMV CRIND for FlexPay Contactless Module19 Verifying Functionality of FlexPay Contactless Module Through CRIND Diagnostics (Generic CRIND)22 Affixing FlexPay Contactless FCC Label25 Required Tools The following tools are required for installation of the Contactless Interface Board: • Phillips ® Screwdriver • Small Channel Locks or Pliers • 1/4-inch Nut Driver or Socket Parts List Encore ® S Enhanced Dispensers - M12027K001 The following table lists the parts included in the M12027K001 kit: ItemDescriptionPart NumberQuantity 1Contactless Antenna AssemblyM11697A0011 2Contactless Antenna SpacerM12032B0011 3Thread Forming ScrewQ11677-244 4Nylon WasherM12184B0014 5TRIND ® E-CIM LensM07698B0011 6Gasket TRIND LensM07715B0021 7Thread Forming ScrewM00419B3114 8Cable<<Please provide the required part number.>> 1 9Graphic<<Please provide the required part number.>> 1 The Advantage ® Series Dispensers - M12024K001 The following table lists the parts included in the M12024K001 kit: ItemDescriptionPart NumberQuantity 1Contactless Antenna AssemblyM11697A0011 2Contactless Antenna BracketM11800B0011 3Contactless Antenna SpacerM12032B0011 MDE-4939 FlexPay™ Contactless Module Installation and Service Manual · May 2011Page 3 Introduction Pr e li m in a ry Encore 300 and Encore 500 Dispensers - M12025K001 The following table lists the parts included in the M12025K001 kit: ItemDescriptionPart NumberQuantity 1Contactless Antenna AssemblyM11697A0011 2Contactless Antenna BracketM11802B0011 3Contactless Antenna SpacerM12032B0021 4Thread Forming ScrewQ11677-242 5Screw Phillips Pan Head Sems MetricQ12845-364 6Hex Nut MetricM01114B0014 7Lens TRIND Display WindowM01234B0011 8TRIND Blanking Panel GasketM01160B0011 9Thread Forming ScrewM00419B1174 10Nylon WasherM12184B0014 11Cable<<Please provide the required part number.>> 1 Encore 300 (Pre-EMV) Dispensers - M12025K002 The following table lists the parts included in the M12025K002 kit: ItemDescriptionPart NumberQuantity 1Contactless Antenna AssemblyM11697A0011 2Contactless Antenna BracketM11802B0011 3Thread Forming ScrewQ11677-242 4Screw Phillips Pan Head Sems MetricQ12845-364 5Hex Nut MetricM01114B0014 6Lens TRIND Display WindowM01234B0011 7TRIND Blanking Panel GasketM01160B0011 8Thread Forming ScrewM00419B1174 9Nylon WasherM12184B0014 10Cable<<Please provide the required part number.>> 1 11Cable<<Please provide the required part number.>> 1 Encore 500 S Dispensers - M12026K001 The following table lists the parts included in the M12026K001 kit: 4Thread Forming ScrewQ11677-244 5Screw Phillips Pan Head Sems MetricQ12845-364 6Hex Nut MetricM01114B0014 7Nylon WasherM12184B0014 8Cable<<Please provide the required part number.>> 1 ItemDescriptionPart NumberQuantity 1Contactless Antenna AssemblyM11697A0011 2Contactless Antenna BracketM11803B0011 3Contactless…

Text truncated - open the document above for the full version.

Gilbarco Inc. Veede r-Root Company 7300 West Friendly Avenue PO Box 22087 Greensboro, NC 27420-2087 United States Phone: 336-547-5373 Fax: 336-292-8871 Email: [email protected] www.gilbarco.com www.veeder.com April 13, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: N6SGCM to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Bob Sykes Title: EMC Engineer On behalf of: Gilbarco Inc. (Company Name) Telephone: 336-547-5373

Request for Confidentiality Date April 13, 2011 Federal Communications Commission Equipment Authorization Branch 7345 Oakland Mills Rd. Columbia Maryland 21046 Gentlemen: Gilbarco Inc. respectfully requests confidentiality of certain materials provided with the submission of model FlexPay Contactless under FCC ID: N6SGCM in accordance with FCC Regulations 0.459. The confidentiality request applies to the Schematic diagrams, System Block diagram, System functional/operation description contained in this filing and included in the following files: 11-0087 – Schematics.pdf 11-0087 – System Block Diagram.pdf 11-0087 – Theory of Operation.pdf The FlexPay Contactless has been developed at considerable effort and expense by Gilbarco/OTI. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the companies’ business advantage. I appreciate your assistance in this matter. Bob Sykes EMC Engineer Dated: April 13, 2011 Gilbarco Inc. Veeder-Root Company 7300 West Friendly Avenue PO Box 22087 Greensboro, NC 27420-2087 United States Phone: 336-547-5373 Fax: 336-292-8871 Email: [email protected] www.gilbarco.com www.veeder.com

5015 B. U. Bowman Dr. Buford, GA 30518 May 10, 2011 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: N6SGCM To Whom It May Concern: The following application is submitted on behalf of our client, Gilbarco, Inc., for evaluation of their model FlexPay Contactless for single modular approval certification under FCC Part 15.225. The FlexPay Contactless is a stand-alone module which is designed to be integrated into specific host devices. The FlexPay Contactless meets all requirements for single modular approval under Part 15.212 and was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

Gilbarco Inc. Veede r-Root Company 7300 West Friendly Avenue PO Box 22087 Greensboro, NC 27420-2087 United States Phone: 336-547-5373 Fax: 336-292-8871 Email: [email protected] www.gilbarco.com www.veeder.com Request for Modular Approval April 13, 2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Rd. Columbia Maryland 21046 RE: Certification Application FCC ID N6SGCM Dear Sir or Madam: In reference to FCC ID N6SGCM, Gilbarco is requesting Modular Approval. The numbered requirements for Modular Approval are addressed below 1. The modular transmitter must have its own RF shielding. This is intended to ensure that the module does not have to rely upon the shielding provided by the device into which it is installed in order for all modular transmitter emissions to comply with Part 15 limits. It is also intended to prevent coupling between the RF circuitry of the module and any wires or circuits in the device into which the module is installed. Such coupling may result in non-compliant operation. The Contactless reader assembly, (GVR SCI 6100) includes a formed sheet metal shield, (p/n 90007142), which was designed to provide electrical shielding and protection for the assembly when installed in a host product. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The modular transmitter uses serial communication with the host electronics. There are no commands or data rates from the host device that can change the transmit power. The serial communications can only turn the transmitter off. The module passes transponder data and authentication code to the dispenser electronics for communication to the point-of-sale (POS) system for credit verification. Once the credit is verified, the POS system instructs the transmitter module to keep the recognition LED and transmitter on or to shut it off. 3. The modular transmitter must have its own power supply regulation. This is intended to ensure that the module will comply with Part 15 requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. The INT1000 interface PCB includes a LM2594HVM voltage regulator which provides regulated 5VDC to the module. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Any antenna used with the module must be approved with the module, either at the time of initial authorization or through a Class II permissive change. The “professional installation” provision of Section 15.203 may not be applied to modules. This device employs a non-standard flat 8-pin coupler for the antenna connection. This connector also carries the LED signals. The connector is not coaxial and is unique in its application as an antenna coupler. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified or commercially available (see Section 15.31(i)). The transmitter was tested in a stand-alone configuration and not inside another device. It does not contain any ferrites that will not be marketed with the module. The device was tested with cables of a length typical of actual use that are greater than 10 centimeters long. The support equipment connected to the module via RS-232 com port for testing purposes was an unmodified Dell laptop PC. The representative power supply used for testing is commercially available, and is typical of actual usage. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. The modular transmitter will be labeled with its own FCC ID number: N6SGCM. It will be permanently affixed to the module shield Assembly. This label is not visible when it is installed inside another device, therefore an exterior label is provided with the required text. A separate file in this submission shows labels (with verbiage) as well as their locations on the products. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must pro…

Text truncated - open the document above for the full version.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: N6SGCM IC: 827B-GCM FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0087.W06.11.A Manufacturer: Gilbarco, Inc. Model: FlexPay Contactless External Photos Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 2 Figure 1: External Photo Figure 2: External Photo Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 3 Figure 3: External Photo Figure 4: External Photo Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 4 Figure 5: External Photo Figure 6: External Photo Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 5 Figure 7: External Photo

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: N6SGCM IC: 827B-GCM FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0087.W06.11.A Manufacturer: Gilbarco, Inc. Model: FlexPay Contactless Label Information Gilbarco FlexPay Contactless - FCC Label Locations Module FCC Label location – Part # N23951 16 Module FCC Label details Host (fuel dispenser) FCC Labels location Host (fuel dispenser) FCC Labels details

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: N6SGCM IC: 827B-GCM FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0087.W06.11.A Manufacturer: Gilbarco, Inc. Model: FlexPay Contactless Internal Photos Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 2 Figure 1: Internal Photo Figure 2: Internal Photo Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 3 Figure 3: Internal Photo Figure 4: Internal Photo Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 4 Figure 5: Internal Photo Figure 6: Internal Photo Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 5 Figure 7: Internal Photo Figure 8: Internal Photo

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: N6SGCM IC: 827B-GCM FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0087.W06.11.A Manufacturer: Gilbarco, Inc. Model: FlexPay Contactless Test Begin Date: April 11, 2011 Test End Date: April 12, 2011 Report Issue Date: May 10, 2011 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Prepared by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 17 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE .......................................................................................................................................... 3 1.2 PRODUCT DESCRIPTION ................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS ................................................................................. 3 2 TEST FACILITIES .............................................................................................................................. 4 2.1 LOCATION ....................................................................................................................................... 4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS ................................................ 4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION .............................................................................. 5 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 5 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION ........................................................................... 7 3 APPLICABLE STANDARD REFERENCES .................................................................................... 7 4 LIST OF TEST EQUIPMENT ............................................................................................................ 8 5 SUPPORT EQUIPMENT .................................................................................................................... 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ........................................................... 9 7 SUMMARY OF TESTS ..................................................................................................................... 10 7.1 ANTENNA REQUIREMENT – FCC: CFR 47 PART 15.203 ................................................................ 10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: CFR 47 PART 15.207/ IC RSS-GEN 7.2.4 .............. 10 7.2.1 Measurement Procedure ....................................................................................................... 10 7.2.2 Measurement Results ............................................................................................................ 10 7.3 RADIATED EMISSIONS – INTENTIONAL RADIATION ....................................................................... 12 7.3.1 In-Band Emissions Limitations – FCC Part 15.225(a),(b),(c) / IC RSS-210 A2.6 ............... 12 7.3.1.1 Test Methodology ............................................................................................................................ 12 7.3.1.2 Test Results ...................................................................................................................................... 12 7.3.2 Out-of-Band Emissions – FCC Part 15.225(d) / IC RSS-Gen 7.2.5 ..................................... 13 7.3.2.1 Test Methodology ............................................................................................................................ 13 7.3.2.2 Distance Correction for Measurements Below 30 MHz – Part 15.31 ............................................... 13 7.3.2.3 Test Results ...................................................................................................................................... 14 7.3.2.4 Sample Calculation: ......................................................................................................................... 14 7.4 OCCUPIED BANDWIDTH – FCC PART 15.215(C) / IC RSS-GEN 4.6.1 ............................................ 15 7.4.1 Test Methodology ................................................................................................................. 15 7.4.2 Test Results ........................................................................................................................... 15 7.5 FREQUENCY STABILITY – FCC CFR 47 PART 15.225(E) / IC RSS-210 A2.6 ................................. 16 7.5.1 Test Methodology ................................................................................................................. 16 7.5.2 Test Results ........................................................................................................................... 16 8 CONCLUSION ................................................................................................................................... 17 Model: FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 3 1 GENERAL 1.1 Purpose The purpose of this report is to …

Text truncated - open the document above for the full version.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: N6SGCM IC: 827B-GCM FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0087.W06.11.A Manufacturer: Gilbarco, Inc. Model: FlexPay Contactless Test Setup Photos Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 2 Figure 1: Radiated Emissions Figure 2: Radiated Emissions Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 3 Figure 3: Radiated Emissions Figure 4: Conducted Emissions Model(s): FlexPay Contactless FCC ID: N6SGCM IC: 827B-GCM ACS Report: 11-0087.W06.11.A Advanced Compliance Solutions Page 4 Figure 5: Conducted Emissions
