NKH2003

Installing the 16/4 CardBus Adapter Mk2 For detailed product information, see the Datasheet. The default ring speed setting for this adapter is 'auto-detect'. This means the adapter will run at the same ring speed as the network (either 16Mbps, or 4Mbps). To change the default setting, use Madge Assist. The Madge 16/4 CardBus Adapter Mk2 is not designed for connection to a Madge Local Ringhub or to a passive hub from any other vendor. 1.Read the EMC compliance statement for this adapter. 2.Connect a data-cable to the appropriate connector on the adapter: the 9-pin D-type connector for STP cabling or the RJ45 connector for UTP cabling. The 16/4 CardBus Adapter Mk2 automatically detects the type of cabling you connect to the adapter. 3.Insert the adapter into a CardBus slot in your computer. Do not force it in. If the adapter does not go in easily the slot might be for 16-bit PCMCIA adapters only. CardBus adapters are designed not to fit into 16-bit PCMCIA slots. (The slots on some computers are labelled "CB" to indicate that they are for CardBus adapters.) 4.Make sure your computer has Card Services and Socket Services loaded. The version of Card and Socket Services you are using must support CardBus adapters (not just PCMCIA adapters). Refer to the documentation supplied with your computer to check that your Card and Socket Services support CardBus adapters. For more information about Card and Socket Services, see the table below . 5.Run Madge Assist to check that the adapter and its connection are working correctly. (See Configuring and testing adapters with Madge Assist.) 6.Install driver software. If you have difficulty making your adapter work, perform troubleshooting. Note: Caution: 1 of 312/05/99 09:10 Installing the 16/4 CardBus Adapter Mk2file:///D|/Approval/Cardbus_FCCB/manual.htm The Madge 16/4 CardBus Adapter Mk2 supports hot swapping where this is allowed for by the network protocols you install and the operating system in your computer. This means that, once you have installed the hardware and the software, you can remove the adapter and then put it back without losing your network connection. Information about Card and Socket Services Operating systemNotes Windows 95/98 support To use the Madge 16/4 CardBus Adapter Mk2, your computer needs to be running Microsoft Windows 95 v4.00.950B (OSR2), or Windows 98. You can check the version number by running the System applet from the Control Panel. If you are using an earlier version of Windows 95, contact your computer supplier. Windows NT support Windows NT 3.51 does not support CardBus adapters. To use a CardBus adapter with Windows NT 4, you must use one of the solutions suggested in Extra notes for CardBus under NT 4 DOS support To use the 16/4 CardBus Adapter Mk2, we recommend you use the Card and Socket Services supplied with your computer. However, if you need support for only Madge adapters, or if you have a CardBus adapter and your Card and Socket Services do not support CardBus adapters, you can use MADGECS.EXE. MADGECS.EXE is a proprietary Card Services utility from Madge. OS/2 support To use the 16/4 CardBus Adapter Mk2, we recommend you use the Card and Socket Services supplied with your computer. However, if you need support for only Madge adapters, or if you have a CardBus adapter and your Card and Socket Services do not support CardBus adapters, you can use MADGECS.SYS. MADGECS.SYS is a proprietary Card Services utility from Madge. EMC compliance statement The statements on this page apply to the following adapter: 16/4 CardBus Adapter Mk2 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference this device must accept any interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Note: 2 of 312/05/99 09:10 Installing the 16/4 CardBus Adapter Mk2file:///D|/Approval/Cardbus_FCCB/manual.htm This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: reorient or relocate the receiving antenna increase the separation between the equipment and the receiver connect the equipment into an outlet on a circuit different from that to which the receiver is connected consult the dealer or an experienced radio/TV technician for help The user is advised that any modification to the board not expressly authorised by the manufacturer may void the user's authority to operate this device. 3 of 312/05/99 09:10 Installing the 16/4 CardBus Adapter Mk2file:///D|/Approval/Cardbus_FCCB/manual.htm

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Madge Networks Ltd. Cardbus Mk2 To: FCC Part 15: 1997 Class B Test Report Serial No: RFI/EMCB1/RP38646A This Test Report Is Issued Under The Authority Of Brian Watson Technical Director: Checked By: Tested By:Release Version No: PDF01 Issue Date: 6 May 1999Test Date: 1 April 1999 to 5 April 1999 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP38646A EMC DepartmentPage 2 of 28 Issue Date: 6 May 1999 Test Of:Madge Networks Ltd. Cardbus Mk2 To:FCC Part 15: 1997 Class B This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP38646A EMC DepartmentPage 3 of 28 Issue Date: 6 May 1999 Test Of:Madge Networks Ltd. Cardbus Mk2 To:FCC Part 15: 1997 Class B Table of Contents 1. Client Information..........................................................................................................4 2. Equipment Under Test (EUT)........................................................................................5 3. Test Specification, Methods & Procedures..................................................................8 4. Deviations From The Test Specification....................................................................10 5. Operation Of The EUT During Testing........................................................................11 6. Summary Of Test Results...........................................................................................12 7. Measurements, Examinations And Derived Results.................................................13 8. Measurement Uncertainty...........................................................................................17 Appendix 1. Test Equipment Used..................................................................................18 Appendix 2. Measurement Methods................................................................................19 Appendix 3. Test Configuration Drawings......................................................................21 Appendix 4. Graphical Test Results................................................................................25 Appendix 5. Photographs of EUT....................................................................................27 RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP38646A EMC DepartmentPage 4 of 28 Issue Date: 6 May 1999 Test Of:Madge Networks Ltd. Cardbus Mk2 To:FCC Part 15: 1997 Class B 1. Client Information Company Name: Madge Networks Ltd. Address: Wexham Springs Framewood Road Wexham Slough SL3 6PJ Berks Contact Name: Mr Charlie Blackham. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP38646A EMC DepartmentPage 5 of 28 Issue Date: 6 May 1999 Test Of:Madge Networks Ltd. Cardbus Mk2 To:FCC Part 15: 1997 Class B 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name Madge Networks Ltd Model Name or Number Cardbus Mk2 Unique Type Identification PCB-01 Serial Number 002152 Country Of Manufacture UK F.C.C. ID Number Not applicable Date Of Receipt 1 April 1999 2.2. Description Of EUT The card (EUT) provides an interface between a personal computer and a token ring network. 2.3. Modifications Incorporated In EUT None. 2.4. Additional Information Related To Testing Power Supply Requirement: Nominal 115 V, 60 Hz AC Mains Supply 13 Amp (max) Intended Operating Environment: Commercial, Light industry Weight: 100 to 200 g Dimensions: PCB 130mm x 80 mm Interface Ports: One 15-way connector supports a category 5 lode able fitted with an RJ45 plug. The EUT is internal to the Support Computer and is fitted into the cardbus slot. Cycle Time: Less than 1 sec. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP38646A EMC DepartmentPage 6 of 28 Issue Date: 6 May 1999 Test Of:Madge Networks Ltd. Cardbus Mk2 To:FCC Part 15: 1997 Class B 2.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description PC Brand Name Compaq Model Name or Number Armada 7400 Serial Number 890BXL30312 F.C.C. ID Number Tested to comply with FCC Standards - for home or office use Cable Length And Type Direct Internal Connection Connected to Port Cardbus slot Description Laptop Transformer Brand Name Compaq Model Name or Number 2912 Serial Number 00002210 F.C.C. ID Number None stated by client Cable Length And Type 2 m DC Connected to Port DC Power In on Laptop Description Printer Brand Name Hewlett Packard Model Name or Number C2164A Serial Number ES573120MV F.C.C. ID Number B94C2164X Cable Length And Type Parallel to Centronics 1.5 m Connected to Port Parallel Port on PC RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP38646A EMC DepartmentPage 7 of 28 Issue Date: 6 May 1999 Test Of:Madge Networks Ltd. Cardbus Mk2 To:FCC Part 15: 1997 Class B Support Equipment Continued Description Token Ring Hub Brand Name Madge Networks Ltd Model Name or Number SmartLAM UTP Serial Number F9A53D F.C.C. ID Number Verified Cable Length And Type 6 m UTP cable Connected to Port RJ45 Socket on EUT Description Mouse Brand Name Logitech Model Name or Number ML38 Serial Number L150716317 F.C.C. ID Number DZ…

Text truncated - open the document above for the full version.
