95-31 User manual Smart Wireless Advanced PCMCIA Adapter 802.11b User Manual 95-31 User manual Copyright statement Printed in Taiwan Page1 95-31 User manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: l Reorient or relocate the receiving antenna. l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. l Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, (example – use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Page 2 95-31 User manual R&TTE Compliance Statement This equipment complies with all the requirements of the DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity(R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000. Safety EU Countries intended for use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark , Finland , France ( with Frequency channel restrictions). Germany ,Greece, Ireland , Italy , Luxembourg, Portugal , Spain , Sweden, The Netherlands, United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states Norway and Switzerland EU Countries Not intended for use None. Potential restrictive use France: Only channels 10,11,12,and13 Page 3 95-31 User manual 1. Contents 1. Contents ---------------------------------------------------------------------------------------------------------------- -------- 4 2. Introduction ------------------------------------------------------------------------------------------------------------ -------- 5 3. Wireless LAN Basics ------------------------------------------------------------------------------------------------ ------- 6 4. Installation for Windows Platform --------------------------------------------------------------------------------- ------ 7 4.1 Installation Overview -------------------------------------------------------------------------------------------- ------- 8 4.2 Installation Procedure for Windows 95/98 ------------------------------------------------------------------ ------- 9 4.3 Uninstallation Procedure for Windows 95/98 -------------------------------------------------------------- ----- 11 4.4 Installation Procedure for Windows NT 4.0 ---------------------------------------------------------------- ----- 12 4.5 Uninstallation Procedure for Windows NT 4.0 ------------------------------------------------------------ ----- 13 4.6 Installation Procedure for Windows 2000/windows ME ------------------------------------------------ ----- 14 4.7 Uninstallation Procedure for Windows 2000/windows ME -------------------------------------------- ----- 15 5. Configuration Utility-------------------------------------------------------------------------------------------------- ------ 16 6. Troubleshooting ------------------------------------------------------------------------------------------------------- ------24 7. Technical specifications of Wireless LAN ----------------------------------------------------------------------- ----- 26 Page 4 95-31 User manual 2. Introduction This manual will assist you the procedure for installation. The following items should be found in the package you have purchased: ¦ PCMCIA Adapter ¦ Quick installation guide ¦ User manual ¦ Diskette or CD containing Wireless LAN Management utility and drivers The diskette or CD contains the drivers and the software configuration utility that is used for managing the Wireless LAN Card as well as establishing the wireless connection with your Local Area Network (LAN). NOTE : PLEASE CONTACT YOUR VENDER IF ANYTHING IS MISSING. Page 5 95-31 User manual 3. Wireless LAN Basics Wireless LAN (Local Area Networks) systems offer a number of greater excellences over a traditional wired system. Wireless LANs (WLANs) are easier to setup and manage, more flexible and often more cost effective than their wired equivalence. By using radio frequency (RF) technology, the need for wired connections is minimized while WLANs transmit and receive data over the air. Therefore, WLANs combine data conne…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

FCC ID Label Location

Page 3 Page 4

FCC ID: NKH9531 ADT No.910612R01 Operational Description The transmitter of the EUT (Smart Wireless Advanced PCMCIA Adapter 802.11b) is powered by notebook and plugged in PCMCIA Slot. The antenna types are ceramic, printed and patch antenna, and there is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: NKH9531 ADT No.: 910612R01 FCC TEST REPORT REPORT NO.: RF900815R10A MODEL NO.: 95-31 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:Madge Networks Ltd. ADDRESS: Wexham Springs, Framewood Road, Wexham, Slough, SL3 6PJ, England ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 Lab Code: 200102-0 FCC ID: NKH9531 ADT No.: 910612R01 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 2.5cm away from the body of the user. Warning statement for keeping 2.5cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: NKH9531 ADT No.: 910612R01 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: NKH9531 ADT No.: 910612R01 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 0dBi or 1 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241233.341.62 6243732.511.61 11246231.621.59 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 2.5cm separation distance with the antenna.

FCC ID: NKH9531 Report No.: RF900815R10A1Issued: July 3, 2002 FCC TEST REPORT REPORT NO.: RF900815R10A MODEL NO.: 95-31 RECEIVED: June 12, 2002 TESTED: June 27, 2002 APPLICANT: Madge Networks Ltd. ADDRESS: Wexham Springs, Framewood Road, Wexham, Slough, SL3 6PJ, England ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: NKH9531 Report No.: RF900815R10A2Issued: July 3, 2002 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT.............................................................. 6 3.2DESCRIPTION OF TEST MODES................................................................ 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................... 7 3.4DESCRIPTION OF SUPPORT UNITS .......................................................... 8 4TEST TYPES AND RESULTS....................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ...............錯誤! 尚未定義書籤。 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT錯誤! 尚未定義書 籤。 4.1.2TEST INSTRUMENTS .................................................錯誤! 尚未定義書籤。 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4DEVIATION FROM TEST STANDARD ....................................................... 10 4.1.5TEST SETUP ...............................................................................................11 4.1.6EUT OPERATING CONDITIONS................................................................ 12 4.1.7TEST RESULTS.......................................................................................... 13 4.2RADIATED EMISSION MEASUREMENT ................................................... 19 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT................................. 19 4.2.2TEST INSTRUMENTS ................................................................................ 20 4.2.3TEST PROCEDURES................................................................................. 21 4.2.4DEVIATION FROM TEST STANDARD ....................................................... 21 4.2.5TEST SETUP .............................................................................................. 22 4.2.6EUT OPERATING CONDITIONS................................................................ 22 4.2.7TEST RESULTS.......................................................................................... 23 4.36dB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................ 27 4.3.2TEST INSTRUMENTS ................................................................................ 27 4.3.3TEST PROCEDURE ................................................................................... 28 4.3.4DEVIATION FROM TEST STANDARD ....................................................... 28 4.3.5TEST SETUP .............................................................................................. 28 4.3.6EUT OPERATING CONDITIONS................................................................ 28 4.3.7TEST RESULTS.......................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 33 FCC ID: NKH9531 Report No.: RF900815R10A3Issued: July 3, 2002 4.4.2TEST INSTRUMENTS ................................................................................ 33 4.4.3TEST PROCEDURES................................................................................. 34 4.4.4DEVIATION FROM TEST STANDARD ....................................................... 34 4.4.5TEST SETUP .............................................................................................. 34 4.4.6EUT OPERATING CONDITIONS................................................................ 34 4.4.7TEST RESULTS.......................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT...................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 36 4.5.2TEST INSTRUMENTS ................................................................................ 36 4.5.3TEST PROCEDURE ................................................................................... 37 4.5.4DEVIATION FROM TEST STANDARD ....................................................... 37 4.5.5TEST SETUP .............................................................................................. 37 4.5.6EUT OPERATING CONDITIONS................................................................ 37 4.5.7TEST RESULTS.......................................................................................... 38 4.6BAND EDGES MEASUREMENT ................................................................ 42 4.6.1LIMITS OF BAND EDGES MEASUREMENT ............................................. 42 4.6.2TEST INSTRUMENTS ................................................................................ 42 4.6.3TEST PROCEDURE ................................................................................... 42 4.6.4DEVIATION FROM…
